GSM/GPRS/GPS WATCH TRACKER
USER MANUAL
Preface
Thank you for purchasing the Mini Gp s Watch Tracker. This manual shows how to
operate the device smoothly and correctly. Make sure to read this manual carefully
before using this product. Please note that specification and information are subject to
changes without prior notice in this manual. Any change will be integrated in the latest
release. The manufacturer assumes no responsibility for any errors or omissions in
this document
1
Advertisement
Table of Contents
Related Manuals for Xexun GSM/GPRS/GPS WATCH TRACKER
Summary of Contents for Xexun GSM/GPRS/GPS WATCH TRACKER
- Page 1 GSM/GPRS/GPS WATCH TRACKER USER MANUAL Preface Thank you for purchasing the Mini Gp s Watch Tracker. This manual shows how to operate the device smoothly and correctly. Make sure to read this manual carefully before using this product. Please note that specification and information are subject to changes without prior notice in this manual.
-
Page 2: Table Of Contents
Content 1 Summary ---------------------------------------------------------------------------------- 2 Application --------------------------------------------------------------------------------- 3 Hardware Description 3.1 Front Face -------------------------------------------------------------------------------------- 3.2 Side Face -------------------------------------------------------------------------------------- 3.3 Interior --------------------------------------------------------------------------------------- 3.4 Buttom Face --------------------------------------------------------------------------------------- 4 Specifications ---------------------------------------------------------------------------------------- 5 Usage SIM card installation ----------------------------------------------------------------------- Battery and Charger ------------------------------------------------------------------------ Quick Startup ---------------------------------------------------------------------- Initialization ----------------------------------------------------------------------... -
Page 3: Application
1 Summary Working based on existing GSM/GPRS network and GPS satellites, this product can locate and monitor any remote targets by SMS or GPRS. Applications Rental vehicle / Fleet management etc Protect the child / the old / the disabled / pet etc Protect businessmen Personnel management Covert Tracking... -
Page 4: Side Face
3.2 Side Face SOS Button NOTE:As for ON/OFF Button,keep pressing 3 seconds is ON/OFF the tracker;while keep pressing second is switch to displaying Latitude&Longitude.it displays Time,Date,Day and Battery in 30 ON/OFF Button seconds later automatically. 3.3 Interior Battery connector SIM Card slot 3.4 Bottom Face Close the watch back cover by fixing the screws... -
Page 5: Usage
4 Specs. Content Specs. Dimension. 45(L)x38(W)x18(H) mm Weight Network GSM/GPRS Band 850/900/1800/1900Mhz or 900/1800/1900Mhz GPS chip SIRF3 chip GSM/GPRS Enfora module module GPS sensitivity -159dBm GPS accuracy Cold status 45s Time To First Fix Warm status 35s Hot status 1s 110－220V input Wall charger output... -
Page 6: Battery And Charger
5.1.3 Insert the SIM card into the holder,press the foil down and put the battery in place. 5.1.4 Close the back cover,and tighten the screws. 5.2 Battery and Charger 5.2.1 Charger Battery connector Chanrging slot for Watch Chanrging slot for battery Charging connector The LED indicator... - Page 7 Put the battery into the slot The green indicator is full charged The red indicator is charging Put the watch into the slot for charging directly Do charge the battery to capacity in 8 -12 hours for the first use. Please use the battery and charger provided by the manufacturer.
-
Page 8: Initialization
Turn on the unit outdoors by pressing the “on/off” button for 5 seconds,until the indicator is on and flashing,the flashing stoped to represent the success of receiveing GSM signal.In 30s to 60 seconds,the unit displays the real-time after received the GPS signal. For first use, please initialize the unit and restore it to default setting.( please refer to 5.4 for instruction.) When this unit receives GPS signals normally, you can use it and do all the following... -
Page 9: Real-Time Polling
authorized number. If the number is successfully authorized, the unit will reply SMS. “admin ok!”. 5.6.2 Cancel:Send SMS noadmin+password+space+authorized number to be delete by the first authorized number to delete the authorized number. 5.6.3 For roaming purpose, you have to add your country code ahead of the cell phone number, for example, please send admin123456 008613322221111 to tracker to set 13322221111 as an authorized number. -
Page 10: Geo-Fence
5.8.3 Cancel: Send notn+password to delete the “ auto track ”It will reply “notn ok!”. Remark: the interval must not be less than 5s. 5.9 Geo-fence This function is using for the owner to set up a geo-fence of the unit to restrict its movements within a district. -
Page 11: Overspeed Alert
lat: 22.566923 long: 114.051331 speed: 0.00 28/10/09 03:33 F:4.32V,0, Signal:F move imei:359587011016261 05 41.9 5.10.2 Cancel: Send SMS nomove+password to deactivate the movement alert. It will reply “nomove ok!”. 5.11 Overspeed Alert This function is using for the owner to control the target’s speed. 5.11.1 Setup: Send SMS speed+password+space+080 to the unit (suppose the speed is 80km/h), and it will reply “speed ok!”. -
Page 12: Low Battery Alert
5.13 Low battery Alert It begins to send SMS to the user every 30 minutes when the battery voltage is less than 3.7V. The alert SMS format as below: lat: 22.566923 long: 114.051331 speed:0.00 28/10/09 03:33 L:3.68V,0, Signal:F imei:359587011016261 05 41.9 5.14 IMEI Checking: Send SMS imei+password to the unit to check the IMEI number of the tracker. - Page 13 name ) by cell phone. （ NOTE: Some countries or regions should set APN’s User Name and APN’s Password,please consult your local for information.） service operator 5.15.1 Set an IP address and port: Setup: Send SMS adminip+123456+space+IP address+space+port. If setup successful, the tracker will reply SMS “adminip ok” Cancel: Send SMS noadminip+123456 5.15.2 Set APN Setup: Send SMS apn+123456+space+specify apn content.
-
Page 14: Cautions
Serial number + authorized number + GPRMC + GPS signal indicator + alert command + IMEI number + Number of satellites + Altitude+Battery voltage+ External power status+ Length of the string +CRC16 checksum. For example, it will send GPS coordinates as below illustrated 091029025041,13145826175,GPRMC,025041.000,A,2234.0528,N,11403.0760,E,0.00 ,0.00,291009,,,A*61,F,, imei:354776033427755,07,57.7,F:4.18V,0,136,720A Notes:... -
Page 15: Faults & Solutions
