OWNER'S OPERATION AND INSTALLATION MANUAL
MODELS SL30PT AND SL30NT SERIES THERMOSTAT CONTROL
GAS LOG HEATER (BURNER SySTEM FOR CAST IRON STOVES)
WARNING: If the information in this manual is not fol-
lowed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
WARNING: This SL30PT/NT series vent-free gas log
heater is only approved for use in the Comfort Glow
series cast iron stove models CISC and CISG.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
(VENT-FREE) GAS STOVE HEATER
For more information, visit www.desatech.com
Advertisement
Table of Contents
Related Manuals for Comfort Glow SL30PT Series
Summary of Contents for Comfort Glow SL30PT Series
- Page 1 WARNING: This SL30PT/NT series vent-free gas log heater is only approved for use in the Comfort Glow series cast iron stove models CISC and CISG. INSTALLER: Leave this manual with the appliance.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Information .......... Troubleshooting ..........18 Product Identification ........... 4 Specifications ............ 1 Local Codes............4 Service Hints ............. 1 Product Features ..........5 Technical Service..........1 Air For Combustion and Ventilation ..... 5 Replacement Parts ..........1 Installation ............ -
Page 3: Safety Information
SAFETy INFORMATION WARNING: Do not use a Continued blower insert, heat exchanger insert or other accessory not ap- WARNING: This product con- proved for use with this heater. tains and/or generates chemicals known to the State of California to Due to high temperatures, the cause cancer or birth defects or appliance should be located out other reproductive harm. -
Page 4: Product Identification
Figure 1 - Typical Stove Cabinet Model 11. This heater needs fresh, outside air ventilation with Comfort Glow Gas Log Heater to run properly. This heater has an Oxygen De- pletion Sensing (ODS) safety shutoff system. -
Page 5: Product Features
PRODUCT FEATURES pROVIDING ADEQUATE VENTILATION OpERATION The following are excerpts from National Fuel This heater is clean burning. It requires no outside Gas Code, ANSI Z223.1/NFPA 54, Section 5.3, Air venting. There is no heat loss out a vent or up a for Combustion and Ventilation. - Page 6 3. Add the Btu/Hr of all fuel burning appliances AIR FOR COMBUSTION in the space. AND VENTILATION Vent-free heater _________ Btu/Hr Continued Gas water heater* _________ Btu/Hr Gas furnace ________ Btu/Hr Confined and Unconfined Space The National Fuel Gas Code ANSI Z223.1/NFPA Vented gas heater ________ Btu/Hr 54 defines a confined space as a space whose...
-
Page 7: Installation
AIR FOR COMBUSTION Ventilation Air From Outdoors Provide extra fresh air by using ventilation grills or AND VENTILATION ducts. You must provide two permanent openings: Continued one within 12" of the ceiling and one within 12" of the floor. Connect these items directly to the outdoors or spaces open to the outdoors. - Page 8 INSTALLATION CLEARANCES TO COMBUSTIBLES Continued (Vent-Free Operation Only) WARNING: Maintain the WARNING: Never install the minimum clearances. If you can, heater provide greater clearances from • in a bedroom or bathroom floor, ceiling and adjoining side • in a recreational vehicle and back walls.
-
Page 9: Stove Cavity Assembly
7. Remove remaining pallet wood attached to INSTALLATION bottom of stove body (see Figure 7). Use an Continued adjustable wrench to remove bolts. STOVE CAVITY ASSEMBLY 8. Fasten each leg to stove with four (4) bolts. 1. Lift off corrugated box enclosing stove Use a flat screw driver to tighten bolt to leg. - Page 10 14. If available, install gas log heater inside stove INSTALLATION cavity before installing the back panel (see In- Continued stalling Gas Log Heater Into Stove, page 11). 9. Fasten stove bottom to stove with four (4) 15. Fasten back panel to stove with six (6) M6 x 1 M6 x 1 - 25 mm bolts.
- Page 11 8. Set one-piece log on heater base as shown in INSTALLATION Figure 15. Make sure middle section at bot- Continued tom of log is seated into "U" shaped cutout in center of heater base. Log will fit securely on INSTALLING GAS LOG HEATER base.
- Page 12 The gas inlet connection for the stove heater is INSTALLATION located on the lower right-hand side of the stove Continued when viewed from the front of the unit. The gas connection can be made either through the bottom CONNECTING TO GAS SUPPLY right side or through the lower back opening as illustrated in Figure 17.
- Page 13 We recommend that you install a sediment trap in INSTALLATION supply line as shown in Figure 19. Locate sediment Continued trap where it is within reach for cleaning. Install in piping system between fuel supply and heater. Locate sediment trap where trapped matter is not CAUTION: Use only new, black likely to freeze.
- Page 14 INSTALLATION Open Equipment Continued Shutoff Valve CAUTION: For propane/LP units, make sure external regula- Closed tor has been installed between Figure 20- Equipment Shutoff Valve propane/LP supply and heater. Equipment Shutoff Valve See guidelines under Connect- Propane/LP ing to Gas Supply, page 12. Supply Tank pRESSURE TESTING GAS SUppLY pIpING SYSTEM...
-
Page 15: Operating Heater
OPERATING HEATER 3. Turn control knob clockwise to the OFF position. FOR YOUR SAFETY 4. Wait five (5) minutes to clear out any gas. READ BEFORE LIGHTING Then smell for gas, including near the floor. If you smell gas, STOP! Follow “B” in the WARNING: If you do not fol- safety information, column 1. If you don’t low these instructions exactly, smell gas, go to the next step. a fire or explosion may result 5. Turn control knob counterclockwise to the PILOT position. Press in control knob causing property damage, per- for five (5) seconds (see Figure 23). -
Page 16: Inspecting Burners
OPERATING HEATER INSPECTING BURNERS Check pilot flame pattern and burner flame pat- Continued terns often. 8. Turn control knob counterclockwise to desired heating level. The burn- pILOT FLAME pATTERN ers should light. Set control knob to any Figure 25 shows a correct pilot flame pattern. heat level between HI and LO. -
Page 17: Cleaning And Maintenance
5. Blow air into the primary air holes on the CLEANING AND injector holder. MAINTENANCE 6. In case any large clumps of dust have now been pushed into the burner repeat steps 3 and 4. WARNING: Turn off heater Clean the pilot assembly also. A yellow tip on the pilot flame indicates dust and dirt in the pilot as- and let cool before cleaning. -
Page 18: Troubleshooting
TROUBLESHOOTING WARNING: Turn off heater and let cool before servicing. Only a qualified service person should service and repair heater. CAUTION: Never use a wire, needle or similar object to clean ODS/pilot. This can damage ODS/pilot unit. Note: All troubleshooting items are listed in order of operation. OBSERVED POSSIBLE CAUSE REMEDY... - Page 19 TROUBLESHOOTING Continued OBSERVED pROBLEM POSSIBLE CAUSE REMEDY Burner does not light after ODS/ 1. Burner orifice clogged 1. Clean burner (see Cleaning pilot is lit and Maintenance, page 17) or replace burner orifice 2. Inlet gas pressure is too low 2.
- Page 20 TROUBLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Fol- low the gas supplier’s instructions.
-
Page 21: Specifications
SPECIFICATIONS SL30pT SL30NT • Rating (Variable): 16,000/30,000 Btu/Hr • Rating (Variable): 16,000/30,000 Btu/Hr • Type Gas: Propane/LP Only • Type Gas: Natural Gas Only • Ignition: Piezo • Ignition: Piezo • Pressure Manifold: 8" W.C. • Pressure Manifold: 3.5" W.C. •... -
Page 22: Illustrated Parts Breakdown
ILLUSTRATED PARTS BREAkDOWN MODELS SL30pT (Shown) and SL30NT www.desatech.com 115580-01B... -
Page 23: Parts List
PARTS LIST This list contains replaceable parts used in your stove. For replacement parts see Replacement Parts on page 21 of this manual. PART NO. DESCRIPTION QTY. 10406-01 Stove Log • • 084-01 Nut, M5 • • Painted Base Assembly •... - Page 24 ILLUSTRATED PARTS BREAkDOWN STOVE MODELS CISC AND CISG www.desatech.com 115580-01B...
- Page 25 PARTS LIST STOVE MODELS CISC AND CISG This list contains replaceable parts used in your stove. For replacement parts see Replacement Parts on page 21 of this manual. NO. PART NO. DESCRIPTION QTY. 104171-06 Top Grate with Screen - Left (Black Only) 1C 104171-05 Top Grate with Screen - Center (Black Only) 1R 104171-07 Top Grate with Screen - Right (Black Only) 1046-01 Bottom Door (Charcoal)
-
Page 26: Parts Centrals
PARTS CENTRALS These Parts Centrals are privately owned businesses. They have agreed to support our customer’s needs by providing original replacement parts and accessories Tool & Equipment Company Washer Equipment Co. 5 Manila Ave. 1715 Main Street Hamden, CT 06514-0322 Kansas City, MO 64108-2195 1-800-397-7553 KS, MO, AR... - Page 27 NOTES _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ 115580-01B www.desatech.com...
-
Page 28: Warranty Information
WARRANTy INFORMATION kEEP THIS WARRANTy Model Serial No. Date Purchased Always specify model and serial numbers when communicating with the factory. We reserve the right to amend these specifications at any time without notice. The only warranty applicable is our standard written warranty.
