Cast iron stove and direct-vent (freestanding fireplace heater) burner system

Advertisement

CAST IRON STOVE AND DIRECT-VENT
(FREESTANDING FIREPLACE HEATER)
OWNER'S OPERATION AND INSTALLATION MANUAL
NATURAL GAS BURNER SYSTEM MODEL CDVBN(A),
PROPANE/LP GAS BURNER SYSTEM MODEL CDVBP(A)
IMPORTANT: This direct-vent burner system must be installed into approved Comfort Glow cast
iron stove bodies, models CISGA series and CISCA series ONLY. See page 3 of this manual.
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result caus-
ing property damage, personal injury, or loss of life.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
FOR YOUR SAFETY
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch
• Do not use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's in-
structions.
• If you cannot reach your gas supplier, call the
fire department.
This appliance may be installed in an aftermarket* manufactured (mobile) home,
where not prohibited by state or local codes.
* Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer.
BURNER SYSTEM
REMOTE READY
Save this manual for future reference.
WARNING: Improper installation,
adjustment, alteration, service, or
maintenance can cause injury or
property damage. Refer to this
manual for correct installation and
operational procedures. For as-
sistance or additional information
consult a qualified installer, ser-
vice agency, or the gas supplier.
— Installation and service must
be performed by a qualified in-
staller, service agency, or the
gas supplier.
— This appliance is only for use
with the type of gas indicated on
the rating plate. This appliance is
not convertible for use with other
gases, unless a certified kit is used.
