VENT-FREE PROPANE/LP GAS FREESTANDING
PEDESTAL STOVE SYSTEM
OWNER'S OPERATION AND INSTALLATION MANUAL
S26PT
20,000 to 26,000 Btu/Hr
Thermostatically-
Controlled
f i r e - p a r t s . c o m
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result caus-
ing property damage, personal injury, or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
— WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not
use any phone in your building.
•
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
•
If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed by
a qualified installer, service agency, or the gas
supplier.
This appliance may be installed in an aftermarket*, permanently located, manufactured
(mobile) home, where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This
appliance is not convertible for use with other gases.
*Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer
Save this manual for future reference.
WARNING: Improper installation,
adjustment, alteration, service,
or maintenance can cause injury
or property damage. Refer to this
manual for correct installation
and operational procedures. For
assistance or additional infor-
mation consult a qualified in-
staller, service agency, or the
gas supplier.
WARNING: This is an unvented
gas-fired heater. It uses air (oxy-
gen) from the room in which it is
installed. Provisions for ad-
equate combustion and ventila-
tion air must be provided. Refer
to Air for Combustion and Ven-
tilation section on page 4 of this
manual.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Comfort Glow S26PT
Summary of Contents for Comfort Glow S26PT
- Page 1 VENT-FREE PROPANE/LP GAS FREESTANDING PEDESTAL STOVE SYSTEM OWNER’S OPERATION AND INSTALLATION MANUAL S26PT 20,000 to 26,000 Btu/Hr Thermostatically- Controlled f i r e - p a r t s . c o m WARNING: Improper installation, WARNING: If the information in this manual is not...
-
