Pairing With Devices; Offline Mode - Inateck BCST-10 Quick Start Manual

Barcode scanner
Hide thumbs
1
2
3
4

Advertisement

Exit with Save
6. Restart BCST-10 barcode scanner
7. Open Bluetooth panel in the PC, click 'Bluetooth Setup
Assiatant...' to Searching for the devices
8. The computer will search Bluetooth devices automatically, A few
seconds later, you will find CT10 in the available devices list
9. Double click CT10 device or click 'Continue', it will popup
Bluetooth paring request dialog with the PIN code.
(Note: The PIN code contains too many digits by default which
could result in failure to the pairing process. Please click
'Passcode Option...' and select 'Use a specific passcode', enter
a new PIN code with fewer digits.)
10. Find above mentioned numbers in following barcodes, read
them continuously, and then read 'Exit without Save' barcode,
finish the pairing.
Enter Setup
2. Read 'Factory Reset' barcode, the indicator become red
Factory Reset
3. Read 'Enter Setup' barcode
Enter Setup
4. Read 'One-click Android Keyboard Connection' barcode
One-click Android Keyboard Connection
5. Read 'Exit with Save' barcode
Exit with Save
6. Restart BCST-10 barcode scanner
7. Turn on the Bluetooth in Android devices, search for CT10
8. Input the paring code 10010 in the Bluetooth pairing request dialog
9. Click 'Next' or 'OK' button, you will hear a beep from BCST-10, the
paring successfully.
Exit without Save
5
Pairing with IOS devices
1. Read 'Enter Setup' barcode, the indicator become purple
Enter Setup
2. Read 'Factory Reset' barcode, the indicator become red
Factory Reset
7

Offline Mode

If you are heading for a working area which lies outside the
Bluetooth signal range, you may activate the offline mode of the
scanner, following the steps described below. Under this enhanced
offline mode, all scanned data will be stored directly into the buffer
memory of the device. Furthermore, the data entries will be
permanently saved in the buffer memory prior to the manual upload
into the working station, so that you may upload them time and
again to your liking.
Due to the fact that the data entries will be automatically wiped
from the buffer memory during upload, a data loss is possible when
malfunctions occur during upload, e.g. if the working station suffers
a unanticipated system shut down.
An operation in offline mode is strongly recommended under the
following scenarios:
1) During the scanning process, the device often leaves the
Bluetooth signal range;
2) Due to a high quantity of blocking objects, the Bluetooth signal's
stability can't be ensured.
1. By scanning the following barcode, the offline mode will be
activated.
3. Read 'Enter Setup' barcode
Enter Setup
4. Read 'One-click Mac OS Connection' barcode
One-click IOS Connection
5. Read 'Exit with Save' barcode
Exit with Save
6. Restart BCST-10 barcode scanner
7. Turn on the Bluetooth in iOS devices, search for BCST-10
8. Click BCST-10 in available devices, it will popup Bluetooth paring
request dialog with the PIN code
9. Find left mentioned numbers in following barcodes, read them
continuously, and then read 'Exit without Save' barcode, finish the
pairing.
Offline mode activation
2. By scanning the following barcode, all data in the buffer memory
will be deleted (only in offline mode).
Buffer data purge
3. By scanning the following barcode, all data entries in the buffer
memory can be manually uploaded after reconnecting to the
working station (only in offline mode).
Manual data upload
4. By scanning the following barcode, the gross quantity of the
uploaded data entries will be summarised (only in offline mode).
Summarising of uploaded data entry quantity
5. By scanning the following barcode, the device leaves the offline
mode, normal mode will be reinitialised.
Exit without Save
6
Pairing with Android devices
1. Read 'Enter Setup' barcode, the indicator become purple
Quit offline mode
8
Keyboard Language Setting
Read 'Start Setting' Barcode - 'Select your keyboard language' -
Save and quit - Change your PC language as selected.
Read 'Start Setting' Barcode
Italian Keyboard
US Keyboard
