1
BCST-10 Barcode Scanner Overview
The BCST-10 integrates a high-performance processor with an effective decoding board, combining a fast decoding speed, high precision and a high anti-interference ability in one device.
The device can easily read barcodes on paper and other surfaces. In comparison with similar products, the BCST-10 excells with lightning fast scanning speed, a powerful reading ability and
high accuracy.
Appearance:
Power
USB Port
Bluetooth Wireless mode
USB Wired mode
2
Pairing with Windows XP
1. Read the 'Enter Setup' barcode, the indicator blinks Blue and
green light
Enter Setup
2. Read the 'Factory Reset' barcode, the indicator blinks green light
Factory Reset
3. Restart the BCST-10 barcode scanner
4. Open the Bluetooth panel on your computer, click 'Add a device...'
5. Click 'Next' to search for nearby devices
6. The computer will automatically search for nearby Bluetooth
devices. After a few seconds 'CT********' will appear in the
available devices list
7. Double click 'CT********' or click 'Next', select 'Enter the device's
pairing code', put in the pairing code 10010, click 'next'
8. There will be a prompt at the lower right corner of your desktop
indicating the adding of a new device. After 5 seconds you will
hear a beep from the BCST-10 and the blue light flashes every
three seconds, indicating a successful pairing.
Function Setup:
The BCST-10 Barcode Scanner changes all default
settings by reading the setup barcodes.
3
Pairing with Windows 7/8/10
1. Read the 'Enter Setup' barcode, the indicator blinks Blue and
green light
Enter Setup
2. Read the 'Factory Reset' barcode, the indicator blinks green light
Factory Reset
3. Read the 'Exit with save' barcode
Exit with Save
4. Turn on your Bluetooth within the Win7/8/10 OS, enter the 'Control
Panel' - 'Devices and Printers' - 'Add a device' - select 'CT********'
to add the device to your computer
5. Double click the device name and enter the code: 10010
6. Click 'Next', the BCST-10 will beep to indicate a successful pairing
Scan the 'Enter Setup'
barcode.
You can always change
your settings by scanning
the specific setup barcode.
Scan the 'Exit with Save'
barcode to finish the
setting.
Note:
If you want to enter the setup of the BCST-10, please scan the 'Enter Setup' barcode,
then the 'Function Setup' barcode, followed by the 'Exit with Save' barcode.
4
Pairing with MAC OS
1. Read the 'Enter Setup' barcode, the indicator blinks Blue and
green light
Enter Setup
2. Read the 'Factory Reset' barcode, the indicator blinks green light
Factory Reset
3. Read the 'Enter Setup' barcode
Enter Setup
4. Read the 'One-click Mac OS Connection' barcode
One-click Mac OS Connection
Performance Characteristics
Bluetooth
Bluetooth class 2.1, Version +EDR
Bluetooth Operating Frequency
2402-2480MHz
Bluetooth transmission Power
4dBm
Light Source (Laser)
Laser LED 650+/-20nm
Decode Capability
Codabar, USPS, FedEx, Code 93, MSI, Code 128, UCC/
EAN-128, Code 39, EAN-8, EAN-13, UPC-A, UPC-E, ISBN,
Industrial 25, Interleaved 25, Standard 25, 2/5 Matrix
Resolution
3mil
Nominal Working Distance
6~30cm
Decode Rate
100 decodes per second
Scan width
30mm
Decode mode
Single-Line Aiming
Scan mode
Manual mode
Print Contrast Minimum
30%
Scan angles
Roll 30° Pitch 75° Yaw65°
Cylinder Horizontal Scan
Diameter 35mm
Indication
Beeper, LED
Radio Range
10m Visual range
Interfaces Supported
SPP, HID, USB2.0
Processor
ARM7 72MHz
EEPROM
256K, can store thousands of barcodes
Wireless Communication
HID and SPP dual mode data transmission under Bluetooth
class 2.1 protocol
Battery
1800mAh lithium battery
5. Read the 'Exit with Save' barcode
Exit with Save
6. Restart the BCST-10 barcode Scanner
7. Open the Bluetooth panel in your operating system, click
'Bluetooth Setup Assistant' to search for new devices
8. The computer will automatically search for nearby Bluetooth
devices. After a few seconds 'CT********' will appear in the
available devices list
9. Double click 'CT********' or click 'continue', a bluetooth pairing
request will pop up. (Note: The PIN code contains too many digits
by default, which could result in a failed pairing. Please click
'Passcode Option' and select 'Use a specific passcode' and put in
a new PIN code with fewer digits.)
10. Find the above mentioned numbers in the following barcodes,
scan them contiously and then select the 'Exit without Saving'
barcode to finish the pairing
