Inateck BCST-10 Quick Start Manual

Barcode scanner
Hide thumbs
1
2
3
4

Advertisement

Quick Links

x
Download this manual
2
Pairing with Devices
2
Offline Mode
3
Function Setup Barcodes
3
LED Indicators
4
Bluetooth Application
1
BCST-10 Barcode Scanner Overview
BCST-10 integrates high-performance processor and decoding board, it has fast decoding, high-precision reading ability, and high anti-interference ability. It can
easily read barcodes on paper, goods and other media. The DOF has greatly improvement with similar products, also it has highly scanning speed, powerful
reading ability with high accuracy.
Appearance:
Power
USB Port
Bluetooth Wireless mode
USB Wired mode
2
Pairing with Windows XP
1. Read 'Enter Setup' barcode, the indicator become purple
Enter Setup
2. Read 'Factory Reset' barcode, the indicator become red
Factory Reset
3. Restart BCST-10 barcode scanner
4. Open Bluetooth panel in the PC, click 'Add a device...'
5. Click 'Next' to searching for the devices
6. The computer will search Bluetooth devices automatically, A few
seconds later, you will find CT10 in the available devices list
7. Double click CT10 device or click 'Next', select 'Enter the
device's paring code', and input the pairing code 10010, click
'Next'
8. You will find a prompting at the lower right corner of your
computer desktop for adding a device. After around 5 seconds,
you will hear a beep from BCST-10, and the indicator from red
to blue, the pairing successfully.
Functions Setup:
BCST-10 Barcode Scanner change all the default
functions setup through reading the setup barcodes.
3
Pairing with Windows 7/8
1. Read 'Enter Setup' barcode, the indicator become purple
Enter Setup
2. Read 'Factory Reset' barcode, the indicator become red
Factory Reset
3. Read 'Enter Setup' barcode
Enter Setup
4. Read 'One-click Win7/8 Keyboard Connection' barcode
One-click Win7/8 Keyboard Connection
5. Read 'Exit with Save' barcode
Exit with Save
6. Restart BCST-10 barcode scanner
Performance Characteristics
Bluetooth
Light Source (Laser)
Decode Capability
Resolution
Nominal Working Distance
Decode Rate
Scan width
Decode mode
Scan mode
Print Contrast Minimum
Scan angles
Cylinder Horizontal Scan
Enter Setup
Indication
Radio Range
Read function barcod
Interfaces Supported
Processor
EEPROM
Exit with Save
Wireless Communication
Battery
Note:
1. If you want to setup the function of BCST-10. Read 'Enter Setup' barcode, then
'Function Setup' barcode, and read 'Exit with Save' at last.
2. If the device has been paired with a Bluetooth device and needs to be paired with
another Bluetooth device, please restore factory settings and then re-pair.
7. Turn on the Bluetooth in Win7/8 OS, search for BCST-10
8. Input the paring code 10010 in the Bluetooth pairing request
dialog
9. Click 'Next' or 'OK' button, you will hear a beep from BCST-10,
the paring successfully.
4

Pairing with MAC OS

Method 1 (This method is only applicable to English
keyboard. Please use Method 2 if barcode sequence
error occurs.)
1. Read 'Enter Setup' barcode, the indicator become purple
Enter Setup
2. Read 'Factory Reset' barcode, the indicator become red
Factory Reset
3. Restart BCST-10 barcode scanner
4. Open Bluetooth panel in the PC, click 'Bluetooth Setup
Assiatant...' to Searching for the devices
5. The computer will search Bluetooth devices automatically, A few
seconds later, you will find CT10 in the available devices list
Bluetooth class 2.1, Version +EDR
Laser LED 650+/-20nm
Codabar, Code 11, Code 93, MSI, Code 128, UCC/
EAN-128, Code 39, EAN-8, EAN-13, UPC-A, ISBN,
Industrial 25, Interleaved 25, Standard 25, 2/5 Matrix
3mil
6~30cm
100 decodes per second
30mm
Single-Line Aiming
Auto off mode / Manual mode
30%
Roll 30° Pitch 75° Yaw65°
Diameter 35mm
Beeper, LED
10m Visual range
SPP, HID, USB2.0
ARM 7 72MHz
128K, can store thousands of barcodes
HID and SPP dual mode data transmission under
Bluetooth class 2.1 protocol
1400mAh lithium battery
6. Double click CT10 device or click 'Continue', click 'Passcode
Option... ' and select 'Use a specific passcode', enter the passcode
10010, then click 'OK'.
7. It will shortly display "Pairing was completed successfully". After
around 5 seconds, you will hear a beep from BCST-10, and the
indicator from red to blue, the pairing successfully.
Method 2
1. Read 'Enter Setup' barcode, the indicator become purple
Enter Setup
2. Read 'Factory Reset' barcode, the indicator become red
Factory Reset
3. Read 'Enter Setup' barcode
Enter Setup
4. Read 'One-click Mac OS Connection' barcode
One-click Mac OS Connection
5. Read 'Exit with Save' barcode
