INSTALLATION

Electrical connection

DANGER!
If the mains cable or plug is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid SERIOUS INJURY OR DEATH!

Connection types

Connect the machine as per the instructions on the ratings plate.
230Vac Ph+N
Machine:
Blue
Brown
Supply hose
Yellow/Green
2Ph+N
Machine:
230Vac Ph+N
Blue
Brown
Supply hose
Black
Yellow/Green
2Ph+N
Machine:
Blue
Brown
Supply hose
Black
Yellow/Green
The coffee machine should only be connected to the power supply by qualified
personnel. The following safety instructions should be followed at all times:
Check that the electrical specifications on the ratings plate match the specifications
of the power supply at the point of installation.
The coffee machine must be connected to an earthed socket that complies with the
regulations in force in the country of installation.
You should protect the electric line of the installation with a circuit breaker switch
appropriated for the power consumption of the machine, specified on its ratings
plate.
A residual current circuit breaker must be installed in accordance with the
characteristics of the area of the installation.
Check the characteristics, power rating of the system and that the diameter of the
cables are suitable for the power used by the machine.
Do not connect the coffee machine to the power supply via extension boards,
adapters or shared sockets.
The manufacturer will not be held liable for damage to persons, animals or property
resulting from incorrect installation of the coffee machine.
230Vac Ph+N
Supply
Machine:
230Vac Ph+N
NEUTRAL
Supply hose
PHASE
2Ph+N
Supply Machine:
NEUTRAL
Supply hose
PHASE
2Ph+N
Supply Machine:
2Ph 230Vac
NEUTRAL
Supply hose
PHASE
Supply Machine:
2Ph 230Vac
Blue
PHASE
Brown
PHASE Supply hose
Yellow/Green
Supply Machine:
2Ph 380Vac+N
Blue
NEUTRAL
Brown
PHASE
Black
PHASE
Yellow/Green
Supply Machine:
3Ph 230Vac
Blue
PHASE
Brown
PHASE
Black
PHASE
Yellow/Green
ROSETTA
125Vac Ph+N
Supply
125Vac Ph+N
Blue
NEUTRAL
Brown
PHASE
Yellow/Green
380Vac 3Ph
Supply
3Ph 380Vac+N
Blue
NEUTRAL
Brown
PHASE
Supply hose
Grey
PHASE
Black
PHASE
Yellow/Green
230Vac 3Ph
Supply
3Ph 230Vac
Blue
PHASE
Brown
PHASE
Supply hose
Black
PHASE
Yellow/Green
17
