- Page 1 PPA-13X PPA-13 ® VERSION 0904 & A s s e m b l y I n s t r u c t i o n s O W N E R ’ S M A N U A L v. 052009...
- Page 2 If you skip ahead, you may learn later that you have to disassemble components and that you may have damaged the equipment. m Assemble and operate the PPA-13X on a solid, level surface. Locate the unit a few feet from the walls or furniture to provide easy access.
-
Page 3: Unpacking The Equipment
Please take the time to carefully read through this manual thoroughly. Instructions contained in this document are not intended to cover all details or variations possible with Powerline equipment, or to cover every contingency that may be met in conjunction with installation, operation, maintenance or troubleshooting of the equipment. -
Page 4: Installation Requirements
CAUTION: To set up this unit, you will need assistance. Do not attempt assembly by yourself. You must review and follow the instructions in this Owner’s Manual. If you do not assemble and use the PPA-13X according to these guidelines, you could void the Powerline warranty. -
Page 5: Assembly Tips
A s s e m b l y I n s t r u c t i o n s Assembly of the PPA-13X takes professional installers about 1 hour to complete. If this is the first time you have assembled this type of equipment, plan on significantly more time. - Page 6 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Some components may be pre-installed. Secure Plate (B) and Center Arm Frame (A) together as shown by using: Two A1 (M10x70 hex head bolt) Two B1 (M10 nylon lock nut) Slide Plastic Cover (D2) onto Center Arm Frame (A).
- Page 7 PPA-13 PPA-13 S T E P PPA-13 Above shows Step 1 assembled and completed. VERSION 0904 PAGE 2 PAGE 2...
- Page 8 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Finger tighten all hardware in this step unless otherwise noted. Attach Cable (D3) to Right Arm (D) by sliding it into position. Bring Cable (D3) around the Pulley on Pulley Plate (B) then down towards Pulley Holder with Hook (F) as shown.
- Page 9 S T E P PPA-13 PAGE 3...
- Page 10 H a r d w a r e L i s t Part# Description Center Arm Frame Plate Left Arm Right Arm Pulley Holder Pulley Holder with Hook (911-5001) Hex Head Bolt M10x70 Hex Head Bolt M10x50 Hex Head Bolt M10x40 Hex Head Bolt M8x65...
- Page 11 H a r d w a r e H a r d w a r e ( T o S c a l e ) HARDWARE HARDWARE HARDWARE (Actual Size Shown) (Actual Size Shown) (Actual Size Shown) H a r d w a r e ( T o S c a l e ) (A1) M10 x 70mm Hex Head Bolt...
- Page 12 E x P L O D E D V I E W PPA-13 D I A g R A M P PA - 1 3 x PAGE 2 PAGE 2...
- Page 13 N o t e s...
- Page 14 1900 S. Des Plaines Ave. Forest Park, Il 60130 1 (800) 556-3113 Hours: M-F 8:30 - 5:00 www.bodysolid.com Copyright 2009. Body-Solid. All rights reserved. Body-Solid reserves the right to change design and specifications when we feel it will improve the product. Body-Solid machines maintain several patented and patent pending features and designs.
