- Page 1 PHYP-200X back hyper extension Owner’s Manual WWW.BODYSOLID.COM ¡ ¢ ¡ £ ¤ ¤ ¥ ¦...
- Page 2 THERE IS A RISK ASSUMED BY INDIVIDUALS WHO USE THIS TYPE OF EQUIPMENT. TO MINIMIZE RISK, YOU MUST FOLLOW THESE RULES: Inspect equipment before each workout. Check that all nuts, bolts, screws and pop pins are in place and fully tightened. Also, before use, check cables for sign of wear. Replace all worn parts immediately.
-
Page 3: Table Of Contents
PHYP-200X TABLE OF CONTENTS • SAFETY INSTRUCTIONS....... PAGE 4 • PREPARATION........PAGE 5 • HARDWARE LIST........PAGE 6 • HARDWARE ILLUSTRATION....PAGE 7 • PART LIST / ILLUSTRATION....PAGE 11 • ASSEMBLY INSTRUCTIONS....PAGE 12 • EXPLODED VIEW........PAGE 18 •... -
Page 4: Safety Instructions
PHYP-200X SAFETY INSTRUCTIONS When using exercise equipment, The PHYP-200X is designed for your enjoyment. By you should always take basic following these precautions and using common sense, precautions including the you will have many safe and pleasurable hours of following: healthful exercise with your Powerline Back Hyper Extension. -
Page 5: Preparation
The bottles that are marked “Poison” is your touch up paint. Keep away from children. Set up the PHYP-200X on a solid, fl at surface. A smooth, fl at surface under the machine helps keep it level. : Obtain assistance! If you feel like you can’t assemble the PHYP-200X by yourself then do Provide ample space around the machine. -
Page 6: Hardware List
PHYP-200X HARDWARE LIST PART # SIZE DESCRIPTION QUANTITY... -
Page 7: Hardware Illustration
PHYP-200X HARDWARE ILLUSTRATION Part #1 M12X75mm hex head bolt Qty. 2 Part #2 M12X70mm hex head bolt Qty. 2 Part #3 M12X65mm hex head bolt Qty. 2 Part #4 5/16”X1 3/4” hex head bolt Qty. 4... - Page 8 PHYP-200X HARDWARE ILLUSTRATION CONT. Part #5 M12 nylon lock nut Qty. 6 Part #6 M12 washer Qty. 6 Part #7 5/16” washer Qty. 4 Part #8 5/16” spring washer Qty. 4...
- Page 9 PHYP-200X HARDWARE ILLUSTRATION CONT. Part #9 50mm dia. round foot cap Qty. 2 Part #10 1” round end cap Qty. 2 Part #11 2”X1 3/4” nylon bushing Qty. 1 Part #12 2”X2” end cap Qty. 1 Part #13 1 3/4”X1 3/4” end cap...
- Page 10 PHYP-200X HARDWARE ILLUSTRATION CONT. Part #14 1”X2” end cap Qty. 2 Part #15 rubber grip Qty. 2 Part #16 2”X2” foot cap Qty. 2 Part #17 3” dia. foam roller Qty. 2 Part #18 pop pin Qty. 1...
-
Page 11: Part List / Illustration
PHYP-200X PART LIST Part A Part B Part C mainframe support frame extension frame [1pcs] [1pcs] [1pcs] Part D Part E Part F grip frame u-base frame roller rod [1pcs] [1pcs] [1pcs] Part G thigh pad [2pcs]... -
Page 12: Assembly Instructions
PHYP-200X STEP 1 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: finger tighten all hardware in this step. DO NOT wrench tighten until the last step. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten. - Page 13 PHYP-200X STEP 1 Above shows STEP 1 assembled and completed...
- Page 14 PHYP-200X STEP 2 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: finger tighten all hardware in this step. DO NOT wrench tighten until the last step. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten.
- Page 15 PHYP-200X STEP 2 Above shows STEP 2 assembled and completed...
- Page 16 PHYP-200X STEP 3 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: finger tighten all hardware in this step. DO NOT wrench tighten until the last step. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten.
- Page 17 PHYP-200X STEP 3 Above shows STEP 3 assembled and completed...
-
Page 18: Exploded View
PHYP-200X EXPLODED VIEW... - Page 19 PHYP-200X NOTES...
-
Page 20: Contact Page
PHYP-200X please write your serial number in the boxes below S/N # Body-Solid ® Built for Life 1900 S. Des Plaines Ave. Forest Park, IL 60130 Phone:(708)427-3555 Fax:(708)427-3556 Hours: M-F 8:30 - 5:00 CST www.bodysolid.com Copyright 2011. Body-Solid. All rights reserved. Body-Solid reserves the right to change design and speci cations when we feel it will improve the product.
