Ovislink AirLive WL-8064ARM User Manual

802.11g+ wireless adsl2/2+ modem router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AirLive WL-8064ARM
802.11G+ Wireless ADSL2/2+ Modem Router
User's Manual

Advertisement

Table of Contents
loading

Related Manuals for Ovislink AirLive WL-8064ARM

Summary of Contents for Ovislink AirLive WL-8064ARM

  • Page 1 AirLive WL-8064ARM 802.11G+ Wireless ADSL2/2+ Modem Router User’s Manual...
  • Page 2 Copyright The contents of this publication may not be reproduced in any part or as a whole, stored, transcribed in an information retrieval system, translated into any language, or transmitted in any form or by any means, mechanical, magnetic, electronic, optical, photocopying, manual, or otherwise, without the prior written permission.

  • Page 3: Fcc Interference Statement

    Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against radio interference in a residential environment. AirLive WL-8064ARM can generate, use and radiate radio frequency energy and, if not installed and used in accordance with the instructions in this manual, may cause harmful interference to radio communications.

  • Page 4: Table Of Contents

    Contents CHAPTER 1 INTRODUCTION................... 1 1.1 Features ............................2 1.2 Scope............................. 5 1.3 Audience............................6 1.4 Document Structure ........................7 1.5 System Requirement ........................8 1.6 Packet Contents..........................9 CHAPTER 2 KNOWING WL-8064ARM WIRELESS ADSL2/2+ ROUTER ..... 10 2.1 Front Panel: ..........................10 2.2 Back Panel: ..........................
  • Page 5 4.3.2.1.3 LAN Configuration – PPP IP Address ................55 4.3.2.1.4 LAN Configuration – Use The Following Static IP Address..........56 4.3.3 LAN Setup - Ethernet Switch ....................58 4.3.4 LAN Setup - Firewall/NAT Services ..................59 4.3.5 CONFIG – Save All ......................... 60 4.4 ADVANCED ........................
  • Page 6 4.6.6 TOOLS - Modem Test ....................107 4.6.7 TOOLS – Save All ...................... 108 4.7 STATUS ......................... 109 4.7.1 STATUS - Network Statistics ..................110 4.7.1.1 STATUS - Network Statistics - Ethernet ..............111 4.7.1.2 STATUS - Network Statistics – USB (Optional)............112 4.7.1.3 STATUS - Network Statistics - DSL................113 4.7.1.4 STATUS - Network Statistics - Wireless ..............114 4.7.2 STATUS –...

  • Page 7: Chapter 1 Introduction

    Chapter 1 Introduction Congratulations on your purchase of this outstanding WL-8064ARM Wireless ADSL2/2+ Router. This device is an IEEE 802.11g Wireless and 4 Port Switch built-in ADSL2/2+ Router that allows ADSL/ADSL2/ADSL2+ connectivity while providing Wireless LAN capabilities for residential, industries and SOHO environments. Wireless-G or the so-called 11g is the upcoming 54Mbps wireless networking standard that’s almost 5 times faster than the widely deployed Wireless-B or the so-called 11b products found in homes, businesses, and public wireless hotspots around the world.

  • Page 8: Features

    1.1 Features The WL-8064ARM Wireless ADSL2/2+ Router provides the following features: Compliant to ANSI T1.413 Issue 2, ITU-T G.992.1, ITU-T G.992.2, ITU-G.992.3, ITU 992.4, ITU G.992.5 and READSL2 standards. Support all Digital Loop ITU G.992.3 annex I and J specifications.Fully compliant with Annex A/B/B (U-R2) ADSL specifications. Downstream and Upstream data rates up to 24Mbps and 1Mbps.
  • Page 9 IEEE 802.11g Wireless Standards IEEE 802.11b/g standards compliant. Support data rates up to 54Mbps ( Auto-Rate Capable ). Support 11g+ with data transmission rate up to 108Mbps (Optional) Support OFDM (64QAM, 16QAM, QPSK, BPSK) and DSSS (DBPSK, DQPSK, CCK) modulation. Conforms to Wireless Ethernet Compatibility Alliance (WECA) Wireless Fidelity (Wi-Fi) Standard.
  • Page 10 Firewall Built in Firewall functionality. Support IP Filtering. Support MAC Filtering. Support Web Filtering. IPSec Pass-Through. Protection against IP and MAC address spoofing. UPnP Support UPnP functionality. Ethernet Standards Built-in 4 Ports 10/100Mbps Ethernet Switch which compliant with IEEE 802.3x standards Automatic MDI/MDI-X crossover for 100BASE-TX and 10BASE-T ports.

  • Page 11: Scope

    1.2 Scope This document provides the descriptions and usages for the WL-8064ARM Wireless ADSL2/2+ Router’s Web pages that are used in the configuration and setting process. Both basic and advanced descriptions and concepts are discussed. To help the reader understand more about these Web pages, some questions and answers (Q&A) are appended after the definition of each Web page along with the appendices at the end of the guide.

  • Page 12: Audience

    1.3 Audience This document is prepared for use by those customers who purchase the WL-8064ARM Wireless ADSL2/2+ Router and using the provided or embedded firmware. It assumes the reader has a basic knowledge of ADSL/ADSL2/ADSL2+, Wireless and networking.

  • Page 13: Document Structure

    1.4 Document Structure Chapter 1: Introduction, provides a brief introduction to the product and user guide. Chapter 2: Knowing The WL-8064ARM Wireless ADSL2/2+ Router, provides device specifications and hardware connection mechanism. Chapter 3: Setting Up TCP/IP In Windows, provides Windows system Network’s configurations. Chapter 4: Device Administration, describes the pages found under the Admin menu.

  • Page 14: System Requirement

    1.5 System Requirement Check and confirm that your systems confirm the following minimum requirements: Personal computer ( PC/Notebook ). Pentium II compatible processor and above. Ethernet LAN card or IEEE 802.11b or IEEE 802.11g Wireless adaptor installed with TCP/IP protocol. USB Port ( Optional ) 64 MB RAM or more.

  • Page 15: Packet Contents

    1.6 Packet Contents The WL-8064ARM Wireless ADSL2/2+ Router package contains the following items: One WL-8064ARM Wireless ADSL2/2+ Router One Power Adapter One RJ-11 ADSL Cable One CAT-5 Ethernet Cable One detachable SMA Antenna One CD-ROM ( Driver / Manual / Quick Setup Guide ) If any of the above items are damaged or missing, please contact your dealer immediately.

  • Page 16: Chapter 2 Knowing Wl-8064Arm Wireless Adsl2/2+ Router

    Chapter 2 Knowing WL-8064ARM Wireless ADSL2/2+ Router 2.1 Front Panel: The WL-8064ARM Wireless ADSL2/2+ Router’s LEDs indicators display information about the device’s status. Lights up when WL-8064ARM Wireless ADSL2/2+ Router is powered on. Lights up when Wireless system is ready. WL ACT Blinking when WL-8064ARM Wireless ADSL2/2+ Router is sending/receiving data.

  • Page 17: Back Panel

    2.2 Back Panel: The back panel of the WL-8064ARM Wireless ADSL2/2+ Router contains ADSL, Ethernet Switches, Reset, Power Adapter connection and SMA connector. ADSL Port for connecting to the ADSL2/2+ Service Provider. Ports 1~4 Four 10/100Mbps Ethernet Ports for connecting to the network devices RESET Restore the WL-8064ARM Wireless ADSL2/2+ Router to factory default setting.

  • Page 18: Connection Mechanism

    2.3 Connection Mechanism: This section describes the hardware connection mechanism of WL-8064ARM Wireless ADSL2/2+ Router on your Local Area Network (LAN) connected to the Internet, how to configure your WL-8064ARM Wireless ADSL2/2+ Router for Internet access or how to manually configure your Internet connection. You need to prepare the following items before you can establish an Internet connection through your WL-8064ARM Wireless ADSL2/2+ Router: 1.
  • Page 19 Following are the steps to properly connect your WL-8064ARM Wireless ADSL2/2+ Router: 1. Turn off your computer/notebook. 2. Connect the ADSL port of your WL-8064ARM Wireless ADSL2/2+ Router to the wall jack of the ADSL/ADSL2/ADSL2+ Line with a RJ-11 cable. 3.

  • Page 20: Chapter 3 Setting Up The Tcp/Ip In Windows

    Chapter 3 Setting up the TCP/IP in Windows The instruction in this chapter will help you configure your computers to be able to communicate with this WL-8064ARM Wireless ADSL2/2+ Router. Computers access the Internet using a protocol called TCP/IP (Transmission Control Protocol/ Internet Protocol).

  • Page 21: Windows Me / 98

    3.1 Windows ME / 98 Step 1: Click Start→Settings→Control Panel. Step 4: Go to IP Address icon and select Obtain an IP address. Step 2: Double-click the Network icon. Step 5: Go to Gateway icon and erase all previous setting. Step 3: Go to Configuration icon, select network Step 6: Go to DNS Configuration icon, select adapter installed and click Properties.

  • Page 22: Windows 2000

    3.2 Windows 2000 Step 1: Click Start→Settings→Control Panel. Step 4: Select Internet Protocol (TCP/IP) and click Properties. Step 2: Double-click the Network and Dial-up Connections. Step 5: Select Obtain an IP address automatically and DNS server address automatically. Then, click OK. Step 3: Right Click the Local Area Connection and select Properties.

  • Page 23: Windows Xp

    3.3 Windows XP Step 1: Click Start→Control Panel→Classic View. Step 4: Go to General icon, select Internet Protocol (TCP/IP) and click Properties. Step 2: Double-click the Network Connections. Step 5: Go to General icon, select Obtain an IP address automatically and DNS server address automatically.

  • Page 24: Checking Tcp/Ip Configuration

    3.4 Checking TCP/IP Configuration After your PC is configured and the system has rebooted, you can check the TCP/IP configuration using the following utility provided by your Windows system: Windows 98/ME: Click on “Start” and “Run”. In the open field, enter “winipcfg”, and then press “OK”. All the Ethernet adapter information will be shown on the appear Windows.
  • Page 25 Windows 2000: Click “Start” and “Run”. In the open field, enter “cmd” then click “OK”. In the command prompt, type “ipconfig /all”, then press “Enter”. All the Ethernet adapter information will be shown in the appear Windows. Check if you can get the following setting: The IP Address as 192.168.1.x The Subnet Mask as 255.255.255.0...
  • Page 26 Windows XP: Click “Start” and “Run”. In the open field, enter “cmd” then click “OK”. In the command prompt, type “ipconfig /all”, then press “Enter” All the Ethernet adapter information will be shown in the appear Windows. Check if you can get the following setting: IP address as 192.168.1.x The Subnet Mask as 255.255.255.0...

  • Page 27: Chapter 4 Device Administration

    Entry of the username and password will be prompted. Enter the default login “Username” and “Password”: The default login Username of the administrator is “Admin”, and the default login Password is “ovislink”. Note that the Username and Password are case sensitive.
  • Page 28 Upon entering the address into the web browser, the configurable HOME page with all the device configuration information will pop up as shown in Figure below. HOME: The Home section show the current WL-8064ARM Wireless ADSL2/2+ Router’s function information under different links. EZ SETUP: The EZ Setup is meant to help you install the WL-8064ARM Wireless ADSL2/2+ Router quickly and easily.
  • Page 29 Status Information: Shows the current device connection status. System Uptime: This field displays the time of the WL-8064ARM Wireless ADSL2/2+ Router has been in operation. DSL Status: Shows the WL-8064ARM Wireless ADSL2/2+ Router connection status. DSL Speed: This field displays the WL-8064ARM Wireless ADSL2/2+ Router Downstream/Upstream data rate in Kbps Wireless RF: Show the WL-8064ARM Wireless ADSL2/2+ Router wireless system status.

  • Page 30: Ez Setup

    4.2 EZ SETUP The EZ SETUP is meant to help you install the WL-8064ARM Wireless ADSL2/2+ Router quickly and easily. Click on “Wizard” and the following screen will pop-up. Follow the Steps describe below to complete your installation.
  • Page 31 STEP 1. Select your country from the Country list and the ADSL service provider from the ISP List (If there are more than two ISP in your country) and note the “Encapsulation” type and “VPI/VCI” setting. Click “Config” if you can’t find any available parameters from the presetting country list.
  • Page 32 For the following “Encapsulation” type after clicking the “Next” button, the pop-up setup window wizard is shown below: PPPoA VC-Mux PPPoA LLC PPPoE LLC Manually enter your “User Name” and “Password” which will be provided by your Service Provider (ISP). Click “Apply” after setup.
  • Page 33 For countries with the following “Encapsulation” type after clicking the “Next” button, the pop-up window is shown below: 1483 Bridged LLC 1483 Routed VC-MUX In this current window, you will find THREE different Connection Type:...
  • Page 34 Static (Fixed IP by ISP): Click the radio button to enable Static (Fixed IP by ISP) option, then click “Next”, the following window will pop-up: Set IP Address: Static IP Settings are for users who have a Static IP Address ( WAN side ) from their ISP.
  • Page 35 DHCP (Get IP dynamically from ISP): Click the radio button to enable DHCP (Get IP dynamically from ISP). Click “Next” after your choice and the following window will pop-up: Place a check to enable the Default Gateway. The Default Gateway Address is provided by the ISP.
  • Page 36 Bridge: Click the radio button to enable DHCP (Get IP dynamically from ISP). Click “Next” after your choice and the following screen will pop-up: Select LAN: Select LAN group from the drop down manual or leave it as it’s default then click “Apply”...
  • Page 37 STEP 2. Click “Apply” after setup. Following windows will pop-up. The device’s system will save and activate your setting after clicking the “Apply” button. The following windows will pop up after the reboot process. Check the following items when the above window pop-up. Name: Show the ISP name selected in STEP 1.
  • Page 38 NOTE: If the final setting are differ from what you’d selected in STEP 1, click EZ SETUP and redo the setup procedures or else check your dealer immediately for technical support. NOTE: The WL-8064ARM Wireless ADSL2/2+ Router can be configured to maintain up to 8 Connection Profiles.
  • Page 39 STEP 3. Go to “STATUS” “Modem Status” and the following window will pop-up. Check the “Connection Status”, “Us Rate” and “Ds Rate”, the numbers/data show you the actual ADSL connection speed in Kbps. STEP 4. Launch your web browser, and enter the Google Website Address: “www.google.com”...

  • Page 40: Config

    4.3 CONFIG The CONFIG configuration page allows you to create new connections, edit existing connections, and configure other basic settings in WAN and LAN mode. The CONFIG Menu is divided into two sections : LAN Setup and WAN Setup. WAN Setup will be dealt with first.

  • Page 41: Config - Wan Setup

    4.3.1 CONFIG - WAN Setup WAN Setup: The WAN configuration page allows you to set the configuration for the WAN/ADSL ports. ADSL connections can be configured in a variety of ways depending on the ISP/WAN configuration, and the requirements of your home or office LAN. This 4 Ports 11g ADSL2/2+ Router supports the following ADSL connection types: PPPoE (RFC2516) PPPoA (RFC2364)

  • Page 42: Config - Wan Setup - New Connection

    4.3.1.1 CONFIG - WAN Setup – New Connection Click New Connection to setup a new connection profile. Different connection profiles may be required if you connect to more than one ADSL service provider, or if you vary the connection type you use, or if this WL-8064ARM Wireless ADSL2/2+ Router is used in different locations or countries.

  • Page 43: New Connection - Pppoe Connection Setup

    4.3.1.1.1 New Connection - PPPoE Connection Setup PPPoE: When PPPoE Mode is selected, the following screen will pop-up. Point-to-Point Protocol ( PPP ) is a method of establishing a network connection between network hosts. PPPoE, also known as RFC 2516, adapts PPP to work over Ethernet for ADSL connections.
  • Page 44 CHAP: Challenge-Handshake Authentication Protocol. Typically more secure than PAP, CHAP uses username and password in combination with a randomly generated challenge string which has to be authenticated using a one-way hashing function. MTU: Maximum Transmission Unit. The largest size packet that can be sent by the modem. If the network stack of any packet is larger than the MTU value, then the packet will be fragmented before the transmission.
  • Page 45 Connect: Click Connect to attempt an ADSL connection under this connection profile. Disconnect: Click Disconnect to drop the ADSL connection under this connection profile. Apply: Click Apply to complete the connection profile’s setting. Delete: Click Delete to delete a connection. Cancel: Click Cancel to ignore all the changes.

  • Page 46: New Connection - Pppoa Connection Setup

    4.3.1.1.2 New Connection - PPPoA Connection Setup PPPoA: When PPPoA mode is selected, the following screen will pop-up. Point-to-Point Protocol ( PPP ) is a method of establishing a network connection between network hosts. PPPoA, also known as RFC 2346, adapts PPP to work over ATM cells for ADSL connections.
  • Page 47 MTU: Maximum Transmission Unit. The largest size packet that can be sent by the modem. If the network stack of any packet is larger than the MTU value, then the packet will be fragmented before the transmission. This can be set from a minimum 128 to maximum 1500. On Demand: If enable On Demand mode, the connection will be dropped if no activity is detected after the specified Idle Timeout value.

  • Page 48: New Connection - Static Connection Setup

    4.3.1.1.3 New Connection - Static Connection Setup Static: When Static mode is selected, the following screen will pop-up. Most Internet users are provided with a dynamic IP address by their ISP for each session, however certain situations call for a Static IP address. This is typically when you want to host a website, or use VoIP or video-conferencing applications where other users must regularly connect to your computer.
  • Page 49 PVC Settings: PVC: This field allows you to choose the specific PVC for the PPP session. VPI: Virtual Path Identifier is a virtual path used for cell routing that is identified by an eight bit field in the ATM cell header. The VPI field specifies this eight bit identifier for routing. VCI: A Virtual Channel Identifier is a virtual channel that is identified by a unique numerical tag that is defined by a 16-bit field in the ATM cell header.

  • Page 50: New Connection - Dhcp Connection Setup

    4.3.1.1.4 New Connection - DHCP Connection Setup DHCP: When DHCP mode is selected, the following screen will pop-up. Dynamic Host Configuration Protocol (DHCP) allows the ADSL Router to automatically obtain the IP address from the server. This option is commonly used in situations where the IP address is dynamically assigned and is not known prior to assignment.
  • Page 51 QoS: Select the Quality of Service (QoS) type. If in doubt leave as default. PCR: Peak Cell Rate. This is an ATM (Asynchronous Transfer Mode) term to describe the rate cells per second that the source device may never exceed. Available only when VBR QoS is chosen.

  • Page 52: New Connection - Bridge Connection Setup

    4.3.1.1.5 New Connection - Bridge Connection Setup Bridge: When Bridge mode is selected, the following screen will pop-up. A Bridged connection basically disables the routing, firewall and NAT features of the WL-8064ARM Wireless ADSL2/2+ Router. In a Bridged connection, the WL-8064ARM Wireless ADSL2/2+ Router acts as a modem or hub, and just transmits packets between the WAN interface and the LAN interface.
  • Page 53 QoS: Select the Quality of Service (QoS) type. If in doubt leave as default. PCR: Peak Cell Rate. This is an ATM (Asynchronous Transfer Mode) term to describe the rate cells per second that the source device may never exceed. Available only when VBR QoS is chosen.

  • Page 54: New Connection - Clip Connection Setup

    4.3.1.1.6 New Connection - CLIP Connection Setup CLIP: When CLIP mode is selected, the following screen will pop-up. The Classical IP over ATM (CLIP) support provides the ability to transmit IP packets over an ATM network, CLIP support will encapsulate IP in an AAL5 packet data unit (PDU) frame using RFC1577and utilizes an ATM-aware version of the ARP protocol.
  • Page 55 MBS: Maximum Burst Size. A term used in ATM (Asynchronous Transfer Mode) to specify the maximum number of cells which can be transmitted at the contracted PCR (Peak Cell Rate). Available only when VBR QoS is chosen. CDVT: Cell Delay Variation Time. The Cell Delay Variation is a term used in ATM (Asynchronous Transfer Mode) to describe the time difference that is acceptable between cells being presented at the receiving host.

  • Page 56: Config - Wan Setup - Modem

    4.3.1.2 CONFIG - WAN Setup - Modem Modem: This field allows you to select from the following ADSL handshake protocols. Check your ISP for the connection type. MMODE: Multiple Mode ( Default ). T1413: T1.413 Mode. GDMT: G.dmt Mode. GLITE: G.Lite Mode. Apply: Click Apply to complete the setting.

  • Page 57: Config - Lan Setup

    4.3.2 CONFIG - LAN Setup The LAN Configuration page allow you to select or assign physical interfaces to LAN group and configure LAN IP Address and DHCP functionality.

  • Page 58: Lan Setup - Lan Configuration

    4.3.2.1 LAN Setup - LAN Configuration Click LAN Configuration and the following screen will be shown. Click Add or Remove Interfaces from list under the different LAN Group. The LAN Group features only supported under Bridge Mode setting. Interfaces under the same LAN Group (WLAN, Ethernet and USB) will have the ability to communicate with each other.

  • Page 59: Lan Configuration - Unmanaged

    4.3.2.1.1 LAN Configuration - Unmanaged Unmanaged: Click the Unmanaged radio button, the following configuration screen will pop-up. All filling items are hidden except the Server and Relay Off (Unchangeable) radio button will turn on. Click the Services items will guides you to detail setting. Refer to ADVANCED section for setting/configuration details.

  • Page 60: Lan Configuration - Obtain An Ip Address Automatically

    4.3.2.1.2 LAN Configuration – Obtain an IP Address Automatically Obtain an IP address automatically: The following configuration screen will pop-up. All filling items will be hidden except Host Name, Domain Name and Server and Relay Off (Unchangeable) radio button will turn Click Services selection items will guides you to detail setting.

  • Page 61: Lan Configuration - Ppp Ip Address

    4.3.2.1.3 LAN Configuration – PPP IP Address PPP IP Address: Click the PPP IP Address radio button, the following configuration screen will pop-up. All filling items are hidden except the Server and Relay Off (Unchangeable) radio button will turn on. Click the Services items will guides you to detail setting.

  • Page 62: Lan Configuration - Use The Following Static Ip Address

    4.3.2.1.4 LAN Configuration – Use The Following Static IP Address Use the following Static IP address: The following configuration screen will pop-up. Click the radio button to select Enable DHCP Server or Enable DHCP Relay or Server and Relay Off. Manually enter the necessary items based on each selection.
  • Page 63 Lease Time: Lease Time is the amount of time a network user will be allowed connection to the WL-8064ARM Wireless ADSL2/2+ Router with their current Dynamic IP address. The amount of time is in units of minutes; the default value is 3600 minutes (60 hours). Enable DHCP Relay: Click the radio button to enable the DHCP Relay.

  • Page 64: Lan Setup - Ethernet Switch

    4.3.3 LAN Setup - Ethernet Switch The Ethernet Switch page allows you to set the LAN port into the following modes (Default is “Auto”). Auto: The WL-8064ARM Wireless ADSL2/2+ Router will automatically sense which mode to use, selecting between 100 Mbps Full Duplex, 100 Mbps Half Duplex, 10 Mbps Full Duplex, and 10 Mbps Half Duplex.

  • Page 65: Lan Setup - Firewall/Nat Services

    4.3.4 LAN Setup - Firewall/NAT Services Firewall/NAT Services: Place a check to “Enable” the most basic Firewall and NAT Service to secure your system. The WL-8064ARM Wireless ADSL2/2+ Router is equipped with advanced Firewall features to provide security from malicious attack, hacking or eavesdropping across the Internet. It’s strongly recommend that you enable this feature for security purpose.

  • Page 66: Config - Save All

    4.3.5 CONFIG – Save All Save All: Click Save All in order to permanently save the current configuration of the 4 Ports 11g Wireless ADSL2/2+ Router. If you do restart the system without saving your configuration, the 4 Ports 11g Wireless ADSL2/2+ Router will revert back to the previously saved configuration.

  • Page 67: Advanced

    4.4 ADVANCED The Advanced Menu provides access to advanced networking, management and routing capabilities. Click the ADVANCED tab and the following screen will pop-up. UPnP: Configure UPnP for different connections. SNTP: Configure SNTP to configure time server on Internet. SNMP: Configure SNMP Management. IP QoS: Configure IP Quality of Service for different connections.

  • Page 68: Advanced - Upnp

    4.4.1 ADVANCED - UPnP UPnP: Universal Plug and Play is a protocol which automates connectivity between network devices, including computers, game consoles, digital cameras and other systems which connect via TCP/IP. Applications which implement the UPnP protocol are able to negotiate a connection with a UPnP-enabled device without requiring manual device configuration.

  • Page 69: Advanced - Sntp

    4.4.2 ADVANCED - SNTP SNTP: Simple Network Time Protocol is an efficient method of obtaining the time from a Time Server. Place a check at Enable SNTP to enable the SNTP functionality. Enable SNTP: Place a check to enable SNTP feature. SNTP Server: Enter the SNTP Server IP Address.

  • Page 70: Advanced - Snmp

    4.4.3 ADVANCED - SNMP SNMP: Simple Network Management Protocol ( SNMP ) is an application layer protocol that is used for managing networks. There are several components that make up the SNMP structure, including agents, network management stations ( NMS ), network management protocols, and a management information base ( MIB ).
  • Page 71 Trap Destination IP: This is the IP address to which SNMP traps are sent. There can be up to 5 different SNMP trap destination IP addresses. Trap Community: This is the password to access and view SNMP traps. The Trap Community can be up to 127 characters.

  • Page 72: Advanced - Ip Qos

    4.4.4 ADVANCED - IP QoS IP QoS: IP Quality of Service (QoS) prioritize data streams to ensure that basic connectivity is maintained when running multiple services over one connection. For example, if you are using a peer-to-peer file-sharing program at the same time as performing normal web browsing, you can configure QoS to limit the resources dedicated to the peer-to-peer session in order to ensure web browser connectivity.
  • Page 73 ADD: To add an IP QoS session, place a check at the Enable IPQoS then click Add button. The following screen will pop-up. Rule Name: Enter the IP QoS session name. Source IP: Enter the Source IP Address. Source Netmask: Enter the Source IP Subnet Mask. Source Start Port: Enter the Source IP Start Port which PPP session can be activated.

  • Page 74: Advanced - Port Forwarding

    4.4.5 ADVANCED - Port Forwarding Port Forwarding: Port Forwarding is necessary because NAT ( Network Address Translation ) only forwards traffic from the Internet to the LAN if a specific port mapping exists in the NAT translation table. Because of this, the NAT provides a level of protection for computers that are connected to your LAN.
  • Page 75 New IP: If you wish to manually add a LAN client so that you can apply rules to it, click on the New IP button. The following screen will pop-up. Refer to ADVANCED LAN Clients setting for more details. Enter the IP Address, Hostname and MAC Address as shown then click Apply to save your setting.
  • Page 76 Custom Port Forwarding: If there is no pre-defined Port Forwarding Rule for a particular application, a user rule can be created which defines the required Ports, Protocols and Port forwarding rules. Click the Custom Port Forwarding button and the following screen will pop-up. To create a custom rule you will need to know the specific port number and port type that the application requires.

  • Page 77: Advanced - Ip Filters

    4.4.6 ADVANCED - IP Filters The IP Filters page allows you to specify normal Port Forwards, Block traffic to specific LAN Clients or specify Custom IP Filters that will control the flow of data across the router. Select LAN Group: Select LAN Group from the drop down manual. LAN IP: Enter the router’s LAN IP Address.
  • Page 78 Custom IP Filters: Custom IP Filters allow you to specify individual rules that will deny traffic by defining the following: Source IP address or Source IP Subnet Mask. Destination IP address or Destination IP Subnet Mask. Port or Port range. Protocol.

  • Page 79: Advanced - Lan Clients

    4.4.7 ADVANCED - LAN Clients LAN Client names are a way of applying specific Port-forwarding, Access Control and QoS rules to individual computers on the LAN. If DHCP is used, all DHCP clients are automatically assigned and are designated as a LAN client.

  • Page 80: Advanced - Lan Isolation

    4.4.8 ADVANCED - LAN Isolation LAN Isolation provide blocking traffic from one LAN to another LAN. Place a check at the selected rules and click Apply to activate your setting.

  • Page 81: Advanced - Bridge Filters

    4.4.9 ADVANCED - Bridge Filters Bridge Filtering allows packets to be forwarded or blocked, depending on the MAC address. The Bridge Filtering configuration page allows you to set the configuration of MAC filtering. Bridge Filter ( Or sometimes known as MAC Filter ) enable rules to be defined which allow or deny data to pass through the Router based on the source and destination MAC address and data type of each data frame.
  • Page 82 Mode: Select t Allow or Deny for the rule. Delete: Place a check adjacent to the Bridge Filter Rule and click Apply to Delete the Bridge Filter Rule. Add: Click Add button to add the rule to the list of rules. Apply: Click Apply to complete the setting.

  • Page 83: Advanced - Web Filters

    4.4.10 ADVANCED – Web Filters Web Filter is a tool that have the ability to filter Internet content. Using an easy, category-based listing, you can control exactly what website content can or can not be accessed. Click the radio button to Enable or Disable the filter rules to ensure an accurate representation of the world of information reachable on the Internet.

  • Page 84: Advanced - Multicast

    4.4.11 ADVANCED - Multicast IGMP ( Internet Group Management Protocol ) Multicast enables communication between a single sender and multiple receivers on a network. It is used when data needs to be sent from one to many devices. Enable IGMP Multicast: Click to enable IGMP Multicast and then select a connection listed. Apply: Click Apply to complete the setting.

  • Page 85: Advanced - Static Routing

    4.4.12 ADVANCED – Static Routing If the Router is required to serve more than one network, you will need to set up a Static Route between the networks. Static routing can be used to allow users from one IP domain to access the Internet through the Router in another domain.

  • Page 86: Advanced - Dynamic Routing

    4.4.13 ADVANCED – Dynamic Routing Dynamic Routing makes use of the RIP Protocol to allow the ADSL2/2+ Router to automatically adjust to physical changes in the network. This 4 Ports ADSL2/2+ 11g Wireless Router, using the RIP (v1 or v2 ) protocol, will determine the network packet route based on the fewest number of hops between the Source and the Destination.

  • Page 87: Advanced - Access Control

    4.4.14 ADVANCED – Access Control Use Access Control to configure advanced security functions by customizing the WL-8064ARM Wireless ADSL2/2+ Router. Access control enables the user to selectively direct such traffic, for example to a Web Host in the DMZ or to specific ports opened for such applications as Telnet, Web, TFTP or FTP. Enable Access Control: Check this box to enable selective access from the WAN to your LAN for applications of the class indicated by the relevant check boxes.

  • Page 88: Advanced - Save All

    4.4.15 ADVANCED – Save All Save All: Click Save All in order to permanently save the current configuration of the WL-8064ARM Wireless ADSL2/2+ Router. If you do restart the system without saving your configuration, the WL-8064ARM Wireless ADSL2/2+ Router will revert back to the previously saved configuration. Save All: Click Save All to complete and permanently save the setting.

  • Page 89: Wireless

    4.5 WIRELESS The Wireless configuration page describe the detail instruction on Setup, Configuration, Channel Range, Security and Management for 11g Wireless user.

  • Page 90: Wireless - Setup

    4.5.1 WIRELESS - Setup The Setup configuration page describe the basic wireless setting for the WL-8064ARM Wireless ADSL2/2+ Router. By default, any wireless PC that is configured with the correct SSID will be allowed access to your wireless network. Enable AP: Place a check to Enable or Disable the built in Wireless Access Point built in the WL-8064ARM Wireless ADSL2/2+ Router.
  • Page 91 User Isolation: If enabled, Wireless Stations will not be able to communicate with each other or with stations on the wired network. This feature normally should be disabled. Apply: Click Apply to complete the setting. Cancel: Click Cancel to ignore all the changes. To complete and save the setting, click Save All after clicking the Apply button.

  • Page 92: How To Set Up And Test Basic Wireless Connectivity

    Admin and default password: ovislink, or using whatever IP Address and Username and Password you have set up. Click the WIRELESS → Setup link in the main menu of the WL-8064ARM Wireless ADSL2/2+ Router. Click to Enable AP feature.

  • Page 93: Wireless - Configuration

    4.5.2 WIRELESS - Configuration The Configuration page describes how to configure the wireless features of your WL-8064ARM Wireless ADSL2/2+ Router. Beacon Period: Enter a value between 1 ~ 4095 milliseconds. The Beacon Interval value indicates the frequency interval of the beacon. A beacon is a packet broadcast by the WL-8064ARM Wireless ADSL2/2+ Router to synchronize the wireless network.
  • Page 94 Video Blast Support: Place a check to enable the Video Blast functionality. Check the following items when Video Blast features is enabled. IP Address: Enter the IP Address which support the Video Blast feature. Protocol: The Protocol selected to support Video Blast feature. Dest Port: Enter the Destination Port to support the Video Blast feature.

  • Page 95: Wireless - Security

    4.5.3 WIRELESS - Security The Security page describes how to configure the Wireless Security Level of your WL-8064ARM Wireless ADSL2/2+ Router. There are four security level provided by this WL-8064ARM Wireless ADSL2/2+ Router : “None”, “WEP”, “802.1x” and “WPA”.

  • Page 96: Wireless - Security - None

    4.5.3.1 WIRELESS – Security - None None: The Wireless security is not been used. No encryption will be applied. This setting is useful for troubleshooting your wireless connection, but leaves your wireless data fully exposed. Apply: Click Apply to complete the setting. Cancel: Click Cancel to ignore all the changes.

  • Page 97: Wireless - Security - Wep

    4.5.3.2 WIRELESS – Security - WEP WEP: Wired Equivalent Privacy. WEP is a security protocol for wireless local area networks defined in the 802.11b standard. WEP is designed to provide the same level of security as that of a wired LAN. WEP aims to provide security by encrypting data over radio waves so that it is protected as it is transmitted from one end point to another.

  • Page 98: How To Configure Wep

    How To Configure WEP: To configure WEP data encryption, follow these steps: Log in to the WL-8064ARM Wireless ADSL2/2+ Router at its default LAN address of http://192.168.1.1 with its default Username : Admin and default password : Admin. Click the WIRELESS configuration link in the main menu of the WL-8064ARM Wireless ADSL2/2+ Router.

  • Page 99: Wireless - Security - 802.1X

    4.5.3.3 WIRELESS – Security – 802.1x 802,1x: IEEE 802.1X defines the architecture that contains three major components: Authenticator, Supplicant, and Authentication Server. Server IP Address: This field is required. Enter the IP address of the Radius Server on your LAN. Port: Enter the port number used for connections to the Radius Server.

  • Page 100: Wireless - Security - Wpa

    4.5.3.4 WIRELESS – Security - WPA WPA: Wi-Fi Protected Access ( WPA ) is a specification of standards-based, interoperable security enhancements that increase the level of data protection and access control for existing and future wireless LAN systems. WPA-PSK. Wi-Fi Protected Access (WPA) data encryption provides data security. The very strong authentication along with dynamic per frame re-keying of WPA make it virtually impossible to compromise.

  • Page 101: Wireless - Management

    4.5.4 WIRELESS - Management Unlike wired network data, your wireless data transmissions can extend beyond your walls and can be received by anyone with a compatible adapter. The Management configuration page allow you to set the security features of your WL-8064ARM Wireless ADSL2/2+ Router which are appropriate to your needs. Click on WIRELESS then Management, the following screen will pop-up.

  • Page 102: Wireless - Management - Access List

    4.5.4.1 WIRELESS – Management – Access List Access List: By default, any wireless computer that is configured with the correct wireless network name or SSID will be allowed access to your wireless network. For increased security, you can restrict access to the wireless network to only specific computers based on their MAC addresses.

  • Page 103: Wireless - Management - Associated Stations

    4.5.4.2 WIRELESS – Management – Associated Stations Associated Stations: Click on Associated Stations and the following screen will pop-up. Restricting access by MAC address adds an obstacle against unwanted access to your network. Ban Station: Click and select the Ban Station from the list. Apply: Click Apply to complete the setting.

  • Page 104: Wireless - Management - Multiple Ssid

    4.5.4.3 WIRELESS – Management – Multiple SSID Multiple SSID: Click on Multiple SSID and the following screen will pop-up. By default, any wireless PC that is configured with the correct SSID will be allowed access to your wireless network. An SSID is a 32 character (maximum) alphanumeric key identifying the name of the wireless local area network.

  • Page 105: Wireless - Save All

    4.5.5 WIRELESS – Save All Save All: Click Save All in order to permanently save the current configuration of the WL-8064ARM Wireless ADSL2/2+ Router. If you do restart the system without saving your configuration, the WL-8064ARM Wireless ADSL2/2+ Router will revert back to the previously saved configuration. Save All: Click Save All to complete and permanently save the setting.

  • Page 106: Tools

    4.6 TOOLS TOOLS: The TOOLS page allows you to save the configuration, restart the device, update the firmware/image code, setup user and remote log information and run ping/test of the WL-8064ARM Wireless ADSL2/2+ Router. System Commands: Save the current configuration, restart the WL-8064ARM Wireless ADSL2/2+ Router and restore to factory defaults setting.

  • Page 107: Tools - System Commands

    4.6.1 TOOLS - System Commands The System Commands page allow you to carry out basic system actions. Restart: Use this button to restart the WL-8064ARM Wireless ADSL2/2+ Router system. NOTE: You will be redirected to the WL-8064ARM Wireless ADSL2/2+ Router Homepage after the unit has successfully rebooted.

  • Page 108: Tools - Remote Log

    4.6.2 TOOLS - Remote Log Remote Log: Using the Remote Log page, you can allow a user or users on the Internet to configure, upgrade and check the status of your WL-8064ARM Wireless ADSL2/2+ Router. Log Level: Select the Log Level from the drop down manual. The WL-8064ARM Wireless ADSL2/2+ Router provides the following Log Level : Panic, Alert, Critical, Error, Warning, Notice, Info and Debug.

  • Page 109: Tools - User Management

    4.6.3 TOOLS - User Management User Management: The User Management page enables you to change your User Name and/or Password. It is recommended that you change the User Name and password from the default Admin to ensure the security of the WL-8064ARM Wireless ADSL2/2+ Router. For security reasons, the router has its own user name and password.

  • Page 110: Tools - Update Gateway

    4.6.4 TOOLS - Update Gateway Update Gateway: Firmware is the software that controls the WL-8064ARM Wireless ADSL2/2+ Router and also provides the user interface that is subject of this manual. The Firmware resides in the WL-8064ARM Wireless ADSL2/2+ Router internal Flash memory; currently loaded firmware version can be found under STATUS Product Information.
  • Page 111 The following screen will pop-up when clicking the Update Gateway button. Click Browse button to locate the configuration file or update image file from your computer's hard drive then click Update Gateway. After the configuration file upgrade process, click Restart Gateway to activate your previous setting. Select a File: Click on the Browse…...

  • Page 112: Tools - Ping Test

    4.6.5 TOOLS - Ping Test Ping Test: The Ping Test page provides an easy way to ping the WL-8064ARM Wireless ADSL2/2+ Router without invoking the command line interface. Enter IP Address to ping: Enter the IP Address to ping. Packet size: Enter the packet size in bytes. Number of echo requests: Enter the number of echo request.

  • Page 113: Tools - Modem Test

    4.6.6 TOOLS - Modem Test Modem Test: The Modem Test page can be used to check whether your Modem is properly connected to the Network. This test may take a few seconds to complete. To perform the test, select your connection from the list and press the Test button.

  • Page 114: Tools - Save All

    4.6.7 TOOLS – Save All Save All: Click Save All in order to permanently save the current configuration of the WL-8064ARM Wireless ADSL2/2+ Router. If you do restart the system without saving your configuration, the WL-8064ARM Wireless ADSL2/2+ Router will revert back to the previously saved configuration. Save All: Click Save All to complete and permanently save the setting.

  • Page 115: Status

    4.7 STATUS The Status Menu provides dynamically-updated information about your WL-8064ARM Wireless ADSL2/2+ Router’s Network Status, Connection Status, Modem Status and device performance. Network Statistics: View the Statistics of different interfaces - Ethernet/USB/ADSL/Wireless. Connection Status: View the Status of different connections. DHCP Clients: View the list of DHCP clients.

  • Page 116: Status - Network Statistics

    4.7.1 STATUS - Network Statistics The Network Statistics show the Select Network Interface type to peruse statistics for each type of connection. Click Ethernet, USB, DSL or Wireless to view your Network Statistics.

  • Page 117: Status - Network Statistics - Ethernet

    4.7.1.1 STATUS - Network Statistics - Ethernet Ethernet: Shows the Transmit/Receive Frames, Error Frames, Collision and CRC Errors information of the Ethernet Interface. The traffic counter will reset if the device is rebooted. Refresh: Click Refresh button to reload Web browser. Changes may have occurred, but the Web browser may be caching the old configuration.

  • Page 118: Status - Network Statistics - Usb (Optional)

    4.7.1.2 STATUS - Network Statistics – USB (Optional) USB: Shows the Transmit/Receive Frames and Total Bytes Receive/Transmit information of the USB Interface. The traffic counter will reset if the device is rebooted. Refresh: Click Refresh button to reload Web browser. Changes may have occurred, but the Web browser may be caching the old configuration.

  • Page 119: Status - Network Statistics - Dsl

    4.7.1.3 STATUS - Network Statistics - DSL DSL: Shows the Total Bytes Receive/Transmit and Error Count information of the ADSL (WAN) Interface. The traffic counter will reset if the device is rebooted. Refresh: Click Refresh button to reload Web browser. Changes may have occurred, but the Web browser may be caching the old configuration.

  • Page 120: Status - Network Statistics - Wireless

    4.7.1.4 STATUS - Network Statistics - Wireless Wireless: Shows the packets transmit/receive information through the Wireless Interface. The traffic counter will reset if the device is rebooted. Refresh: Click Refresh button to reload Web browser. Changes may have occurred, but the Web browser may be caching the old configuration.

  • Page 121: Status - Connection Status

    4.7.2 STATUS – Connection Status The Connection Status page display status of the current active connection. Refresh: Click Refresh button to reload Web browser. Changes may have occurred, but the Web browser may be caching the old configuration.

  • Page 122: Status - Dhcp Clients

    4.7.3 STATUS - DHCP Clients The DHCP Clients page shows the MAC Address, IP Address, Host Name and Lease Time for each DHCP client connected to the WL-8064ARM Wireless ADSL2/2+ Router. Refresh: Click Refresh button to reload Web browser. Changes may have occurred, but the Web browser may be caching the old configuration.

  • Page 123: Status - Modem Status

    4.7.4 STATUS - Modem Status The Modem Status page shows the 4 Ports 11g Wireless ADSL2/2+ physical layer or link status. The information displayed on this page is either inherent to the WL-8064ARM Wireless ADSL2/2+ Router or set by the ADSL Central Office (CO) DSLAM, neither of which cannot be changed by the user. Refresh: Click Refresh button to reload Web browser.

  • Page 124: Status - Product Information

    4.7.5 STATUS - Product Information The Product Information show the complete information and various parameters of the WL-8064ARM Wireless ADSL2/2+ Router including Software Versions.

  • Page 125: Status - System Log

    4.7.6 STATUS - System Log The System Log page shows the events triggered by the system. Click System Log to access the WL-8064ARM Wireless ADSL2/2+ Router’s System Log information. This page contains information that is dynamic and will refresh every 5~10 seconds.. Refresh: Click Refresh button to reload Web browser.

  • Page 126: Help

    4.8 HELP The HELP section is used to display a Help system for this WL-8064ARM Wireless ADSL2/2+ Router. Click the HELP button for more information on configuration and settings for each section at anytime.

  • Page 127: What Is A Firewall

    Appendix A: Router Terms What is a firewall? A firewall is a device that protects one network from another, while allowing communication between the two. A firewall incorporates the functions of the NAT router, while adding features for dealing with a hacker intrusion or attack.

  • Page 128: What Is A Gateway

    What is a Gateway? The Internet is so large that a single network cannot handle all of the traffic and still deliver a reasonable level of service. To overcome this limitation, the network is broken down into smaller segments or subnets that can deliver good performance for the stations attached to that segment.

  • Page 129: Appendix B: Frequently Asked Questions

    Similar to the previous question, a ping test would determine whether or not a connection is established. However, this time use a URL instead of and IP Address, such as http://www.ovislink.com.tw/ Alternatively, if the ADSL LED is solidly on, then the ADSL link is established.
  • Page 130 What is ISM band? Ans. The FCC and their counterparts outside of the U.S. have set aside bandwidth for unlicensed use in the ISM (Industrial, Scientific and Medical) band. Spectrum in the vicinity of 2.4 GHz, in particular, is being made available worldwide. This presents a truly revolutionary opportunity to place convenient high-speed wireless capabilities in the hands of users around the globe.
  • Page 131 What is SSID? Ans. Short for Service Set Identifier. SSID is a 32 character unique identifier attached to the header of packets sent over a WLAN that acts as a password when a mobile device tries to connect to the BSS. The SSID differentiates one WLAN from another, so all Access Point and all devices attempting to connect to a specific WLAN must use the same SSID.

  • Page 132: Appendix C: Troubleshooting Guide

    Appendix C: Troubleshooting Guide The Troubleshooting Guide provides answers to common problems regarding the WL-8064ARM Wireless ADSL2/2+ Router settings, connections, and computer settings. The WL-8064ARM Wireless ADSL2/2+ Router does not work (None of the LEDs light up) Ans. Check the following: 1.
  • Page 133 LAN (Link/Act) LED does not light up. Ans. Check the following: 1. Make sure that the LAN cables are securely connected to the 10/100Base-T port. 2. Make sure that you are using the correct cable type for your Ethernet equipment. 3.
  • Page 134 I need to upgrade the Firmware. Ans. In order to upgrade the Firmware with the latest features, go to the OvisLink’s website and download the latest Firmware at http://www.ovislink.com.tw/. Before proceed the upgrading process, check the following details: 1. Download the latest Firmware and save at your pointed location.
  • Page 135 Failed to connect with the WL-8064ARM Wireless ADSL2/2+ Router via Wireless LAN card. Ans. Ensure that the WL ACT LED indicator of the WL-8064ARM Wireless ADSL2/2+ Router is correctly illuminated. 1. Check whether your Wireless LAN setting (e.g. SSID, Channel Number) is the same as your WL-8064ARM Wireless ADSL2/2+ Router.

  • Page 136: Appendix D: Upnp Setting On Windows Xp

    Appendix D: UPnP Setting on Windows XP D.1 Adding UPnP: If you are running Microsoft Windows XP, it is recommended to add the UPnP component to your system. Proceed as follows: Click “Start” “Settings” then “Control Panel”. The “Control Panel” window appears. Click “Add or Remove Programs”.
  • Page 137 The “Add or Remove Programs” window appears. Click “Add/Remove Windows Components”. The “Windows Components Wizard” appears. Select “Networking Services” in the Components list and click “Details”.
  • Page 138 The “Networking Services” window appears. Select “Universal Plug and Play” and click “OK”. Click “Next” to start the installation and follow the instructions in the Windows Components Wizard. Note : System may ask for original Windows XP CD-ROM. Insert the CD-ROM and direct Windows to the proper location of the CD-ROM.
  • Page 139 A “Completing the Windows Components Wizard” will appears indicating the installation was successful. Click “Finish” to quit.

  • Page 140: Appendix E: Glossary

    Appendix E: Glossary The Glossary provides an explanation of terms and acronyms discussed in this user guide. 10BASE-T: IEEE 802.3 specification for 10 Mbps Ethernet over twisted pair wiring. 100BASE-Tx: IEEE 802.3 specification for 100 Mbps Ethernet over twisted pair wiring. 802.11b: IEEE specification for wireless networking at 11 Mbps using direct-sequence spread-spectrum (DSSS) technology and operating in the unlicensed radio spectrum at 2.4GHz.
  • Page 141 CHAP: Challenge Handshake Authentication Protocol: Typically more secure than PAP, CHAP uses username and password in combination with a randomly generated challenge string which has to be authenticated using a one-way hashing function. CLP: Cell Loss Priority: ATM cells have two levels of priority, CLP0 and CLP1. CLP0 is of higher priority, and in times of high traffic congestion, CLP1 error cells may be discarded to preserve the Cell Loss Ratio of the CLP0 cells.
  • Page 142 FEC: Forward Error Correction: An error correction technique in which a data packet is processed through an algorithm that adds extra error correcting bits to the packet. If the transmitted message is received in error, these bits are used to correct the error bits without retransmission. Firewall: A firewall is a method of implementing common as well as user defined security policies in an effort to keep intruders out.
  • Page 143 IAD: Integrated Access Device: A device that multiplexes and demultiplexes communications in the CPE onto and out of a single telephone line for transmission to the CO. IP: Internet Protocol: The method by which information is sent from one computer to another through the Internet.
  • Page 144 NAT: Network Address Translation: The translation of an IP address of one network to a different IP address known by another network. This gives an outside (WAN) network the ability to distinguish a device on the inside (LAN) network, as the inside network has a private set of IP address assigned by the DHCP server not known to the outside network.
  • Page 145 SNAP: SubNetwork Attachment Point. SNMP: Simple Network Management Protocol: Used to govern network management and monitor devices on the network. SNMP is formally described in RFC 1157. SNR: Signal-to-Noise Ratio: Measured in decibels, SNR is a calculated ratio of signal strength to background noise.
  • Page 146 VCI: Virtual Channel Identifier: A virtual channel identified by a unique numerical tag that is defined by a 16-bit field in the ATM cell header. The purpose of the virtual channel is to identify where the cell should travel. VC-Mux: Virtual Circuit based Multiplexing: In VC Based Multiplexing, the interconnect protocol of the carried network is identified implicitly by the VC (Virtual Circuit) connecting the two ATM stations (each protocol must be carried over a separate VC).

Table of Contents
