How to reset to factory default through console interface?
WIAS-1200G provides function to reset password or default setting via
guide you the process.
WIAS-1200G console port is 9-pin serial port, and there is a console cable including in the packing.
Before to run Windows Hyper terminal program, you should connect WIAS-1200G and your PC with
cable.
Just plug the console cable to WIAS-1200G and your PC serial port, then to follow the steps to configure
Hyper Terminal and enter WIAS-1200G to access the command via console port.
Via this port to enter the console interface for the administrator to handle the problems and situations
occurred during operation.
i.
Use the console cable (included in your original package) to connect the Gateway to the PC (at the right COM
port); you will need console cable and a desk top with "COM" port to get started.
ii.
Please make sure the COM port is configured to map to the right physical connector that will be used
through Windows Device Manager > Ports and select Prolific USB-to-Serial Comm Port, in this
example, it is COM5.
"Console
Port", the following steps to
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ovislink AirLive WIAS-1200
Summary of Contents for Ovislink AirLive WIAS-1200
- Page 1 How to reset to factory default through console interface? WIAS-1200G provides function to reset password or default setting via “Console Port”, the following steps to guide you the process. WIAS-1200G console port is 9-pin serial port, and there is a console cable including in the packing. Before to run Windows Hyper terminal program, you should connect WIAS-1200G and your PC with cable.
- Page 2 How to reset to factory default through console interface? iii. Open a HyperTerminal or Putty.
- Page 3 How to reset to factory default through console interface?
- Page 4 How to deploy console cable to connect WIAS-1200G and PC, to reset setting or check status via console Select the correct COM port. (Please refer to # 1 for how to know your COM port number) Enter the following COM port settings: In order to connect to the console port of AirLive WIAS-1200G, a console, modem cable and a terminal simulation program, such as the Hyper Terminal are needed.
- Page 5 How to deploy console cable to connect WIAS-1200G and PC, to reset setting or check status via console ※ ※ ※ ※ Note The main console is a menu-driven test interface with dialog boxes. Please use arrow keys on the keyboard to browse the menu and press the Enter key to make selection or confirm what you enter.
- Page 6 How to deploy console cable to connect WIAS-1200G and PC, to reset setting or check status via console Utilities for network debugging The console interface provides several utilities to assist the Administrator to check the system conditions and to debug any problems.
- Page 7 How to deploy console cable to connect WIAS-1200G and PC, to reset setting or check status via console Display ARP table: The internal ARP table of the system is displayed. Display system up time: The system live time (time for system being turn on) is displayed.
- Page 8 How to deploy console cable to connect WIAS-1200G and PC, to reset setting or check status via console Change admin password Besides supporting the use of console management interface through the connection of null modem, the system also supports the SSH online connection for the setup. When using a null modem to connect to the system console, we do not need to enter administrator’s password to enter the console management interface.
