How to deploy console cable to connect WIAS-3200N
and PC, to reset setting or check status via console
System's web management can also be accesses via WAN port as long as
the administrator uses an IP address listed in Management IP Address List
setting. If both WAN and LAN ports are unable to reach web management,
please use console interface to solve this issue.
Via the console port, administrators can enter the console interface for
handling problems and situations occurred during operation.
Step 1. Use the console cable (Supplied in your original package) to
connect the WIAS-3200N to a computer.
Step 2. Please make sure the COM port is available on the connected
computer.
Attach the RS-232 console cable
here, for management use only.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ovislink Airlive WIAS-3200N
Summary of Contents for Ovislink Airlive WIAS-3200N
- Page 1 How to deploy console cable to connect WIAS-3200N and PC, to reset setting or check status via console System’s web management can also be accesses via WAN port as long as the administrator uses an IP address listed in Management IP Address List setting.
- Page 2 How to deploy console cable to connect WIAS-3200N and PC, to reset setting or check status via console Step 3. Please open a Terminal simulation program, such as the Hyper Terminal or Putty is needed.
- Page 3 How to deploy console cable to connect WIAS-3200N and PC, to reset setting or check status via console Step 4. Please set the parameters as 9600, 8, None, 1, None.
- Page 4 How to deploy console cable to connect WIAS console cable to connect WIAS console cable to connect WIAS-3200N and PC, to reset setting or check status via console and PC, to reset setting or check status via console and PC, to reset setting or check status via console Note: The main console is a menu The main console is a menu-driven text interface with dialog boxes.
- Page 5 How to deploy console cable to connect WIAS-3200N and PC, to reset setting or check status via console Utilities for network debugging The console interface provides several utilities to assist the Administrator to check the system conditions and to debug any problems. The utilities are described as follows: 1.
- Page 6 How to deploy console cable to connect WIAS-3200N and PC, to reset setting or check status via console 4. Display the routing table: The internal routing table of the system is displayed, which may help to confirm the Static Route settings. 5.
- Page 7 How to deploy console cable to connect WIAS-3200N and PC, to reset setting or check status via console connection of null modem, the system also supports the SSH online connection for the setup. When using a null modem to connect to the system console, we do not need to enter administrator’s password to enter the console management interface.
