Ovislink Air Live Air4G User Manual

Wireless-n 4g/3g broadband router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Air4G
Wireless-N 4G/3G Broadband
Router
User's Manual

Advertisement

Table of Contents
loading

Related Manuals for Ovislink Air Live Air4G

Summary of Contents for Ovislink Air Live Air4G

  • Page 1 Air4G Wireless-N 4G/3G Broadband Router User’s Manual...
  • Page 2 This product contains some codes from GPL. In compliance with GPL agreement, AirLive will publish the GPL codes on our website. Please go to www.airlive.com and go to the "Support → GPL" menu to download source code. AirLive Air4G User’s Manual...
  • Page 3 Operation of this equipment in a residential area is likely to cause interference, in which case the user, at his own expense, will be required to take whatever measures are necessary to correct the interference. CE Declaration of Conformity This equipment complies with the requirements relating to electromagnetic compatibility. AirLive Air4G User’s Manual...

  • Page 4: Table Of Contents

    QOS ......................59 3.4.5. SNMP ......................60 3.4.6. Routing......................61 3.4.7. System Time ....................62 3.4.8. Scheduling ....................63 ......................65 3.5.1. System Info ....................66 3.5.2. Firmware Upgrade..................67 3.5.3. Backup Setting ...................67 3.5.4. Reset to Default ..................68 3.5.5. Reboot ......................68 3.5.6. Miscellaneous.....................68 AirLive Air4G User’s Manual...
  • Page 5 Table of contents 4. Troubleshooting ...............69 Appendix A. Spec Summary Table..........74 Appendix B. Licensing information ..........75 AirLive Air4G User’s Manual...

  • Page 6: Introduction

    1. Introduction Introduction The Air4G is a high-performance tool that supports wireless networking at home, work, or in a public place. The Air4G supports a USB 3G/4G modem card, either WCDMA, EVDO,LTE and even HSDPA as well, and supports wireless data transfers up to 150Mbps, and wired data transfers up to 100 Mbps.

  • Page 7: Hardware Installation

    1. Introduction 1.2 Hardware Installation A. Hardware configuration AirLive Air4G User’s Manua...
  • Page 8 Step 1. Plug a USB modem into USB port. Step 2. Insert RJ45 cable into LAN Port on the back panel of the router. Then plug the other end of into computer. AirLive Air4G User’s Manual...
  • Page 9 1. Introduction Step 3. Plug the power jack into the receptor on the back panel of the router. Then plug the other end into a wall outlet or power strip. AirLive Air4G User’s Manua...

  • Page 10: Getting Started With Easy Setup Utility

    Getting Started with Easy Setup Utility There are two approaches for you to set up the Air4G quickly and easily. One is through executing the provided Windows Easy Setup Utility on your PC, and the other is through browsing the device web pages and configuration.
  • Page 11 2. Getting Started with Easy Setup Utility Step 3. Then click the “Wizard” to continue. Step 4. Click “Next” to continue. AirLive Air4G User’s Manua...
  • Page 12 2. Getting Started with Easy Setup Utility Step 5. Select Wireless “Enable”, and then click “Next” to continue. Step 6. Enter SSID, Channel and Security options, and then click “Next” to continue. AirLive Air4G User’s Manual...
  • Page 13 2. Getting Started with Easy Setup Utility Step 7. Click” Let me select WAN service by myself” to select WAN service manually. Step 8. Select “3G/4G” Service by clicking 3G/4G icon to continue. AirLive Air4G User’s Manua...
  • Page 14 Utility will try to detect and configure the required 3G/4G service settings automatically. Click “Next” to continue. Step 10. Or you can select “Manual” and manually fill in the required 3G/4G service settings provided by your ISP. Click “Next” to continue. AirLive Air4G User’s Manual...
  • Page 15 2. Getting Started with Easy Setup Utility Step 11. Click “Next” to save your setting. Step 12. The Air4G is rebooted to make your entire configuration take effect. AirLive Air4G User’s Manua...
  • Page 16 2. Getting Started with Easy Setup Utility Step 13： ： ： ： Click “Next” to test the Internet connection or you can ignore test. Step 14： ： ： ： Click “Next” to test WAN Networking service. AirLive Air4G User’s Manual...
  • Page 17 2. Getting Started with Easy Setup Utility Step 15： ： ： ： Click “Finish” to complete the setting. Step16: After configured, you can also click the “Advanced” icon to diagnostic your network. AirLive Air4G User’s Manua...
  • Page 18 2. Getting Started with Easy Setup Utility Step17: Click the “Refresh” icon to diagnostic your network. Click “Next” to continue. AirLive Air4G User’s Manual...
  • Page 19 2. Getting Started with Easy Setup Utility Step18: Click the “Internet” icon to test the Internet connection. Internet Status: AirLive Air4G User’s Manua...
  • Page 20 2. Getting Started with Easy Setup Utility Step19: Click the “PC” icon to check the PC Network Status. PC Network Status: AirLive Air4G User’s Manual...
  • Page 21 2. Getting Started with Easy Setup Utility Step 20: Click the “Router” icon; it will direct to Air4G’s web UI. Direct to web UI. AirLive Air4G User’s Manua...

  • Page 22: Easy Setup By Configuring Web

    Browse to Activate the Setup Wizard Type in the IP Address (http://192.168.1.254) Type in the default password “admin” in the System Password and then click ‘login’ button. Select your language. Select “Wizard” for basic settings with simple way. AirLive Air4G User’s Manual...
  • Page 23 2. Getting Started with Easy Setup Utility Press “Next” to start the Setup Wizard. Configure with the Setup Wizard Step 1. Setup Login Password Change System Password. (Default：admin) Step 2. Select Time Zone AirLive Air4G User’s Manua...
  • Page 24 If you want to use 3G/4G service as the main internet access, please set the WAN interface as “Wireless WAN” and the WAN type as “3G/4G”. Step 5. 3G/4G Mode Select Auto-Detection then click “Next” to continue. AirLive Air4G User’s Manual...
  • Page 25 2. Getting Started with Easy Setup Utility Step 6. Wireless Settings Setup your Wireless Network: SSID and Channel. Step 7. Wireless Settings Setup your Encryption Key here, then click” Next” to continue. AirLive Air4G User’s Manua...
  • Page 26 2. Getting Started with Easy Setup Utility Step 8. Confirm your Setting. Click Apply Settings to complete the setting. Step 9. Click Finish to complete it. AirLive Air4G User’s Manual...

  • Page 27: Making Configuration

    Configuration Menu by opening the web-browser and typing in the IP Address of the device. The default IP Address is 192.168.1.254. Enter the default password “admin” in the System Password and then click ‘login’ button. Then, you can browse the “Advanced” configuration pages for configuring this device. AirLive Air4G User’s Manua...

  • Page 28: Basic Setting

    3. Making Configuration 3.1 Basic Setting 3.1.1. Network Setup AirLive Air4G User’s Manual...

  • Page 29: Lan Setup

    Subnet Mask: Input your Subnet mask. (All devices in the network must have the same subnet mask.) The default subnet mask is 255.255.255.0. Internet Setup 1. Combo WAN Status: Click on “Settings” there are three options: Disable, Load Sharing and Failover. AirLive Air4G User’s Manua...
  • Page 30 3. WAN Type: It depends what you select WAN Interface. (1) If you select “Ethernet WAN”, there are several WAN connection types of your ISP: Dynamic IP Address, Static IP Address, and PPP over Ethernet, PPTP and L2TP. AirLive Air4G User’s Manual...
  • Page 31 3. Making Configuration (2) If you select “Wireless WAN”, there are 3G/4G and iBurst to choose. AirLive Air4G User’s Manua...
  • Page 32 3. Making Configuration A. 3G/4G AirLive Air4G User’s Manual...
  • Page 33 (3) Manually: The device will not make the link until someone clicks the connect-button in the Status-page. 14. Keep Alive: This feature must collocate with the function "Auto" of "Auto Connect". Enable it to keep the connection always be established. AirLive Air4G User’s Manua...
  • Page 34 Meanwhile, if the device detected that the Ethernet WAN connection is recovered, your broadband connection will be switched to use the Ethernet WAN service. 2. WAN IP Address, Subnet Mask, Gateway, Primary and Secondary DNS: Enter the proper settings provided by your ISP. AirLive Air4G User’s Manual...
  • Page 35 (1) Connect-on-demand: The device will link up with ISP when the clients send outgoing packets. ] (2) Auto Reconnect (Always-on): The device will link with ISP until the connection is established. (3) Manually: The device will not make the link until someone clicks the connect-button in the Status-page. AirLive Air4G User’s Manua...
  • Page 36 For security, this field appears blank. If you don't want to change the password, leave it blank. 3. Connection Control: There are 3 modes to select: (1) Connect-on-demand: The device will link up with ISP when the clients send outgoing packets. AirLive Air4G User’s Manual...
  • Page 37 5. PPPoE Service Name: Optional. Input the service name if your ISP requires it. Otherwise, leave it blank. 6. Maximum Transmission Unit (MTU): Most ISP offers MTU value to users. The default MTU value is 0 (auto). E. PPTP AirLive Air4G User’s Manua...
  • Page 38 (3) Manually: The device will not make the link until someone clicks the connect-button in the Status-page. 9. Maximum Transmission Unit (MTU): Most ISP offers MTU value to users. The default MTU value is 0 (auto). AirLive Air4G User’s Manual...
  • Page 39 3. My IP Address and My Subnet Mask: The private IP address and subnet mask your ISP assigned to you. 4. Gateway IP and Server IP Address/Name: The IP address of the L2TP server and designated Gateway provided by your ISP. AirLive Air4G User’s Manua...

  • Page 40: Dhcp Server

    (3) Manually: The device will not make the link until someone clicks the connect-button in the Status-page. 9. Maximum Transmission Unit (MTU): Most ISP offers MTU value to users. The default MTU value is 0 (auto). 3.1.2. DHCP Server AirLive Air4G User’s Manual...
  • Page 41 DHCP server offers an IP to your PC. Click on “Save” to store your settings or click “Undo” to give up the changes. Press “Clients List” and the list of DHCP clients will be shown consequently. AirLive Air4G User’s Manua...
  • Page 42 • On the DHCP Clients List, please first select which client you wish to add to fix mapping, then click on “Fixed Mapping” button. • The setting will be saved, and click on below link of Fixed Mapping. AirLive Air4G User’s Manual...
  • Page 43 3. Making Configuration • The client has added to Fixed Mapping table. AirLive Air4G User’s Manua...

  • Page 44: Wireless Settings

    5. Wireless Mode: Choose “B/G mixed”, “B only”, “G only”, “N only”, “G/N mixed” or “B/G/N mixed”. The factory default setting is “B/G/N mixed”. 6. Authentication mode: You may select one of authentication to secure your wireless network: Open Shared, Auto, WPA-PSK, WPA, WPA2-PSK, WPA2, WPA-PSK/WPA2-PSK, or WPA /WPA2. AirLive Air4G User’s Manual...
  • Page 45 (9) WPA/WPA2: Another encryption options for WPA-TKIP and WPA2-AES, the others are same the WPA. By pressing “WPS Setup”, you can configure and enable the easy setup feature WPS (Wi-Fi Protection Setup) for your wireless network. AirLive Air4G User’s Manua...
  • Page 46 5. Config Method: You can select the Config Method here from “Pin Code” or “Push Button”. 6. WPS status: According to your setting, the status will show “Start Process” or “No used” Press “Wireless Clients List” and the list of wireless clients will be shown consequently. AirLive Air4G User’s Manual...

  • Page 47: Change Password

    You can change the System Password here. We strongly recommend you to change the system password for security reason. Click on “Save” to store your settings or click “Undo” to give up the changes. 3.2 Forwarding Rules AirLive Air4G User’s Manua...

  • Page 48: Virtual Server

    Server IP. Virtual Server can work with Scheduling Rules, and give user more flexibility on Access control. For the details, please refer to Scheduling Rule. There is well known services as below, if your service is not included, please configure it manually. AirLive Air4G User’s Manual...

  • Page 49: Special Ap

    NAT router. The Special Applications feature allows some of these applications to work with this product. If the mechanism of Special Applications fails to make an application work, try setting your computer as the DMZ host instead. AirLive Air4G User’s Manua...
  • Page 50 This device provides some predefined settings. Select your application and click “Copy to” to add the predefined setting to your list. Click on “Save” to store your settings or click “Undo” to give up the changes. AirLive Air4G User’s Manual...

  • Page 51: Miscellaneous

    Click on “Save” to store your settings or click “Undo” to give up the changes. 3.2.4. IP CAM After you plug AirLive IP Camera into PnP Router, please check the IP CAM table list as following. AirLive Air4G User’s Manua...

  • Page 52: Security Setting

    3. Making Configuration 3.3 Security Setting 3.3.1. Status To view the status of security settings for outbound filter, inbound filter and domain filter. AirLive Air4G User’s Manual...

  • Page 53: Packet Filters

    Virtual Servers or DMZ host only. You can select one of the two filtering policies: Allow all to pass except those match the specified rules Deny all to pass except those match the specified rules AirLive Air4G User’s Manua...
  • Page 54 Protocol: TCP or UDP or both. • Use Rule# • For source or destination IP address, you can define a single IP address (4.3.2.1) or a range of IP addresses (4.3.2.1-4.3.2.254). An empty implies all IP addresses. AirLive Air4G User’s Manual...

  • Page 55: Domain Filters

    Each rule can be enabled or disabled individually. Click on “Save” to store your settings or click “Undo” to give up the changes. 3.3.3. Domain Filters Domain Filter prevents users under this device from accessing specific URLs. AirLive Air4G User’s Manua...
  • Page 56 Check “Drop” to block the access. Check “Log” to log this access. 6. Enable: Check to enable each rule. Click on “Save” to store your settings or click “Undo” to give up the changes. AirLive Air4G User’s Manual...

  • Page 57: Url Blocking

    For example, you can use pre-defined word "sex" to block all websites if their URLs contain pre-defined word "sex". 3. Enable: Check to enable each rule. Click on “Save” to store your settings or click “Undo” to give up the changes. AirLive Air4G User’s Manua...

  • Page 58: Mac Control

    Choose "allow" or "deny" to allow or deny the clients, whose MAC addresses are not in the "Control table", to associate to the wireless LAN. Click on “Save” to store your settings or click “Undo” to give up the changes. AirLive Air4G User’s Manual...

  • Page 59: Miscellaneous

    DoS attack comes from the Internet. Currently, the router can detect the following DoS attack: SYN Attack, WinNuke, Port Scan, Ping of Death, Land Attack etc. Click on “Save” to store your settings or click “Undo” to give up the changes. AirLive Air4G User’s Manua...

  • Page 60: Advanced Setting

    3. Making Configuration 3.4 Advanced Setting AirLive Air4G User’s Manual...

  • Page 61: Status

    3. Making Configuration 3.4.1. Status To view the status of advanced settings for system time, dynamic DNS, routing and Qos. Click on “Refresh” to refresh the webpage. AirLive Air4G User’s Manua...

  • Page 62: System Log

    1 recipient, using ';' or ',' to separate these email addresses. 5. E-mail Subject: The subject of email alert, this setting is optional. Click on “Save” to store your settings or click “Undo” to give up the changes. AirLive Air4G User’s Manual...

  • Page 63: Dynamic Dns

    Serve .Provider, Host Name, Username/E-mail, and Password/Key. You can get this information when you register an account on a Dynamic DNS server. Click on “Save” to store your settings or click “Undo” to give up the changes. AirLive Air4G User’s Manua...

  • Page 64: Qos

    6. Enable: Check to enable the corresponding QOS rule. 7. User Rule#: The QoS rule can work with Scheduling Rule number#. Please refer to the Section 3.1.4.7 Schedule Rule. Click on “Save” to store your settings or click “Undo” to give up the changes. AirLive Air4G User’s Manual...

  • Page 65: Snmp

    PC’s IP address. The default value is 0.0.0.0, and it means that any internet connected computer can get some information of the device with SNMP protocol. Click on “Save” to store your settings or click “Undo” to give up the changes. AirLive Air4G User’s Manua...

  • Page 66: Routing

    IP address, subnet mask, gateway, and hop for each routing rule, and then enable or disable the rule by checking or un-checking the Enable checkbox. Click on “Save” to store your settings or click “Undo” to give up the changes. AirLive Air4G User’s Manual...

  • Page 67: System Time

    4. Sync with my PC: Click on the button if you want to set Date and Time using PC’s Date and Time manually. Click on “Save” to store your settings or click “Undo” to give up the changes. AirLive Air4G User’s Manua...

  • Page 68: Scheduling

    2. Add New Rule: To create a schedule rule, click the “Add New Rule” button. You can edit the Name of Rule, Policy, and set the schedule time (Week day, Start Time, and End Time). The following example configures “ftp time” as everyday 14:10 to 16:20. AirLive Air4G User’s Manual...
  • Page 69 3. Making Configuration Click on “Save” to store your settings or click “Undo” to give up the changes. AirLive Air4G User’s Manua...

  • Page 70: Tool Box

    3. Making Configuration 3.5 Tool Box AirLive Air4G User’s Manual...

  • Page 71: System Info

    3. Making Configuration 3.5.1. System Info You can view the System Information and System log, and download/clear the System log, in this page. AirLive Air4G User’s Manua...

  • Page 72: Firmware Upgrade

    You can backup your settings by clicking the “Backup Setting” function item and save it as a bin file. Once you want to restore these settings, please click Firmware Upgrade button and use the bin file you saved. AirLive Air4G User’s Manual...

  • Page 73: Reset To Default

    1. Domain Name or IP address for Ping Test: Allow you to configure an IP, and ping the device. You can ping a specific IP to test whether it is alive. Click on “Save” to store your settings or click “Undo” to give up the changes. AirLive Air4G User’s Manua...

  • Page 74: Troubleshooting

    Type cmd. Press OK. Type ipconfig to get the IP of default gateway. Type “ping 192.168.1.254”. Assure that you ping the correct IP Address assigned to theAir4G. It will show four replies if you ping correctly. AirLive Air4G User’s Manual...
  • Page 75 B. What can I do if my country and ISP are not in the list? Please choose “Others” item from the list, and filling in dial-up settings manually. C. What can I do if my 3G/4G connection is failed even the dongle is plugged? AirLive Air4G User’s Manua...
  • Page 76 Move the Air4G and the wireless client into the same room, and then test the wireless connection. III. Disable all security settings such as WEP, and MAC Address Control. IV. Turn off the Air4G and the client, then restart it and then turn on the client again. AirLive Air4G User’s Manual...
  • Page 77 III. Try to keep the antenna at least 6 inches away from the wall or other objects. IV. Try changing the channel on the Air4G, and your Access Point and Wireless adapter to a different channel to avoid interference. Keep your product away from electrical devices that generate RF noise, like microwaves, monitors, electric motors, etc.
  • Page 78 Ensure the Air4G is powered on Find the Reset button on the right side III. Press the Reset button for 8 seconds and then release. After the Air4G reboots, it has back to the factory default settings. AirLive Air4G User’s Manual...

  • Page 79: Appendix A. Spec Summary Table

    Web-based UI, remote login, backup/restore setting Environment Operating: 0~40° C (32 ~ 104° F) *Lab Testing: -5 ~ 45° C (23 ~ 113° F) Temperature Storage: -10~70° C Operating:10%~90% non-condensing Humidity Storage: 0~95% non-condensing Certification CE/FCC , RoHS AirLive Air4G User’s Manua...

  • Page 80: Appendix B. Licensing Information

    2.2.7a syslogd spread from busybox wireless tools ntpclient of NTP client implementation RT61apd for 802.1X application vsftpd-2.0.3 quota-tools 3.13 GNU Wget Availability of source code Please visit our website or contact us to obtain more information. AirLive Air4G User’s Manual...
  • Page 81 You must make sure that they, too, receive or can get the source code. And you must show them these terms so they know their rights. AirLive Air4G User’s Manua...
  • Page 82 The act of running the Program is not restricted, and the output from the Program is covered only if its contents constitute a work based on the Program (independent of having been made by running the Program). Whether that is true depends on what the Program does. AirLive Air4G User’s Manual...
  • Page 83 Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you; rather, the intent is to exercise the right to control the distribution of derivative or collective works based on the Program. AirLive Air4G User’s Manua...
  • Page 84 AirLive Air4G User’s Manual...
  • Page 85 Many people have made generous contributions to the wide range of software distributed through that system in reliance on consistent application of AirLive Air4G User’s Manua...
  • Page 86 WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, AirLive Air4G User’s Manual...
  • Page 87 LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. END OF TERMS AND CONDITIONS AirLive Air4G User’s Manua...
