Ovislink AirLive WL-1000UR User Manual

Broadband router with print server
Hide thumbs
Table of Contents

Advertisement

Quick Links

AirLive WL-1000UR
Broadband Router with Print Server
User's Manual
1

Advertisement

Table of Contents
loading

Related Manuals for Ovislink AirLive WL-1000UR

Summary of Contents for Ovislink AirLive WL-1000UR

  • Page 1 AirLive WL-1000UR Broadband Router with Print Server User’s Manual...

  • Page 2: Fcc Interference Statement

    Copyright The contents of this publication may not be reproduced in any part or as a whole, stored, transcribed in an information retrieval system, translated into any language, or transmitted in any form or by any means, mechanical, magnetic, electronic, optical, photocopying, manual, or otherwise, without the prior written permission.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1 Introduction ......................4 Functions and Features....................4 Packing List ........................6 Chapter 2 Hardware Installation..................7 2.1 Panel Layout......................7 2.2 Procedure for Hardware Installation ................9 Chapter 3 Network Settings and Software Installation ............10 3.1 Make Correct Network Settings of Your Computer..........

  • Page 4: Chapter 1 Introduction

    Congratulations on your purchase of this outstanding WL-1000UR. This product is specifically designed for Small Office and Home Office needs. It provides a complete SOHO solution for Internet surfing, and is easy to configure and operate even for non-technical users. Instructions for installing and configuring this product can be found in this manual.
  • Page 5 Wireless functions High speed for wireless LAN connection Up to 54Mbps data rate by incorporating Orthogonal Frequency Division Multiplexing (OFDM). Roaming Provides seamless roaming within the IEEE 802.11b (11M) and IEEE 802.11g (54M) WLAN infrastructure. IEEE 802.11b compatible (11M) Allowing inter-operation among multiple vendors. IEEE 802.11g compatible (54M) Allowing inter-operation among multiple vendors.

  • Page 6: Packing List

    When this feature is enabled, the router will detect and log the DoS attack comes from the Internet. Advanced functions System time Supported Allow you to synchronize system time with network time server. E-mail Alert Supported The router can send its info by mail. Dynamic dns Supported At present,the router has 3 ddns.dyndns,TZO.com and dhs.org.

  • Page 7: Chapter 2 Hardware Installation

    2.1 Panel Layout 2.1.1. Front Panel Figure 2-1 Front Panel LED: Function Color Status Description Power POWER Green Power is being applied to this product. indication System Status is flashed once per second to indicate system Status Green Blinking status is alive.
  • Page 8 2.1.2. Rear Panel Figure 2-2 Rear Panel Ports: Port Description Power inlet The port where you will connect your cable (or DSL) modem or Ethernet router. Port 1 - 4 The ports where you will connect networked computers and other devices. (WL-1000UR, IP-1000UR)The port where you will connect your USB printer...

  • Page 9: Procedure For Hardware Installation

    2.2 Procedure for Hardware Installation 2. Decide where to place your WL-1000UR Wireless Broadband Router You can place your WL-1000UR Wireless Broadband Router on a desk or other flat surface, or you can mount it on a wall. For optimal performance, place your WL-1000UR Wireless Broadband Router in the center of your office (or your home) in a location that is away from any potential source of interference, such as a metal wall or microwave oven.

  • Page 10: Chapter 3 Network Settings And Software Installation

    To use this product correctly, you have to properly configure the network settings of your computers and install the attached setup program into your MS Windows platform (Windows 95/98/NT/2000). 3.1 Make Correct Network Settings of Your Computer The default IP address of this product is 192.168.1.254, and the default subnet mask is 255.255.255.0. These addresses can be changed on your need, but the default values are used in this manual.

  • Page 11: Chapter 4 Configuring Wl-1000Ur Wireless Broadband Router

    This product provides Web based configuration scheme, that is, configuring by your Web browser, such as Netscape Communicator or Internet Explorer. This approach can be adopted in any MS Windows, Macintosh or UNIX based platforms.

  • Page 12: Start-Up And Log In

    After the connection is established, you will see the web user interface of this product. There are two appearances of web user interface: for general users and for system administrator. A window would pop-up asking for Login and Password. Please enter “admin” for login, and “ovislink” for password...

  • Page 13: Status

    4.2 Status This option provides the function for observing this product’s working status: A. WAN Port Status. If the WAN port is assigned a dynamic IP, there may appear a “Renew” or “Release” button on the Sidenote column. You can click this button to renew or release IP manually. B.

  • Page 14: Wizard

    4.3 Wizard Setup Wizard will guide you through a basic configuration procedure step by step. Press”Next ” Setup Wizard - Select WAN Type: For detail settings, please refer to 4.4.1 primary setup.

  • Page 15: Basic Setting

    4.4 Basic Setting 4.4.1 Primary Setup – WAN Type, Virtual Computers Press “Change”...
  • Page 16 This option is primary to enable this product to work properly. The setting items and the web appearance depend on the WAN type. Choose correct WAN type before you start. 1. LAN IP Address: the local IP address of this device. The computers on your network must use the LAN IP address of your product as their Default Gateway.
  • Page 17 4.4.1.1 Static IP Address WAN IP Address, Subnet Mask, Gateway, Primary and Secondary DNS: enter the proper setting provided by your ISP. 4.4.1.2 Dynamic IP Address Host Name: optional. Required by some ISPs, for example, @Home. Renew IP Forever: this feature enables this product to renew your IP address automatically when the lease time is expiring-- even when the system is idle.
  • Page 18 4.4.1.5 PPTP My IP Address and My Subnet Mask: the private IP address and subnet mask your ISP assigned to you. Server IP Address: the IP address of the PPTP server. PPTP Account and Password: the account and password your ISP assigned to you. If you don't want to change the password, keep it empty.
  • Page 19 4.4.1.6 L2TP First, please check your ISP assigned and Select Static IP Address or Dynamic IP Address. For example: Use Static My IP Address and My Subnet Mask: the private IP address and subnet mask your ISP assigned to you. Server IP Address: the IP address of the PPTP server.
  • Page 20 4.4.1.7 Virtual Computers Virtual Computer enables you to use the original NAT feature, and allows you to setup the one-to-one mapping of multiple global IP address and local IP address. • Global IP: Enter the global IP address assigned by your ISP. •...
  • Page 21 4.4.2 DHCP Server Press “More” The settings of a TCP/IP environment include host IP, Subnet Mask, Gateway, and DNS configurations. It is not easy to manually configure all the computers and devices in your network. Fortunately, DHCP Server provides a rather simple approach to handle all these settings. This product supports the function of DHCP server.
  • Page 22 4.4.3 Wireless Setting, and 802.1X setting Wireless settings allow you to set the wireless configuration items. 1. Network ID (SSID): Network ID is used for identifying the Wireless LAN (WLAN). Client stations can roam freely over this product and other Access Points that have the same Network ID. (The factory setting is “default”) 2.
  • Page 23 802.1X Check Box was used to switch the function of the 802.1X. When the 802.1X function is enabled, the Wireless user must authenticate to this router first to use the Network service. RADIUS Server IP address or the 802.1X server’s domain-name. RADIUS Shared Key Key value shared by the RADIUS server and this router.
  • Page 24 WPA-PSK 1. Select Preshare Key Mode If you select HEX,you have to fill in 64 hexadecimal (0, 1, 2…8, 9, A, B…F) digits If ASCII,the length of preshare key is from 8 to 63. 2. Fill in the key, Ex 12345678...
  • Page 25 Check Box was used to switch the function of the WPA. When the WPA function is enabled, the Wireless user must authenticate to this router first to use the Network service. RADIUS Server IP address or the 802.1X server’s domain-name. RADIUS Shared Key Key value shared by the RADIUS server and this router.

  • Page 26: Port Forwarding

    4.5 Port Forwarding 4.5.1 Virtual Server This product’s NAT firewall filters out unrecognized packets to protect your Intranet, so all hosts behind this product are invisible to the outside world. If you wish, you can make some of them accessible by enabling the Virtual Server Mapping.
  • Page 27 Service Port Server IP Enable 192.168.1.1 192.168.1.2 1723 192.168.1.6...

  • Page 28: Miscellaneous Items

    4.5.2 Special AP Some applications require multiple connections, like Internet games, Video conferencing, Internet telephony, etc. Because of the firewall function, these applications cannot work with a pure NAT router. The Special Applications feature allows some of these applications to work with this product. If the mechanism of Special Applications fails to make an application work, try setting your computer as the DMZ host instead.
  • Page 29 IP Address of DMZ Host DMZ (DeMilitarized Zone) Host is a host without the protection of firewall. It allows a computer to be exposed to unrestricted 2-way communication for Internet games, Video conferencing, Internet telephony and other special applications. NOTE: This feature should be used only when needed. Non-standard FTP port You have to configure this item if you want to access an FTP server whose port number is not 21.

  • Page 30: Firewall Settings

    4.6 Firewall Settings...

  • Page 31: Packet Filter

    4.6.1 Packet Filter Packet Filter enables you to control what packets are allowed to pass the router. Outbound filter applies on all outbound packets. However, Inbound filter applies on packets that destined to Virtual Servers or DMZ host only. You can select one of the two filtering policies: 1.
  • Page 32 For source or destination port, you can define a single port (80) or a range of ports (1000-1999). Add prefix "T" or "U" to specify TCP or UDP protocol. For example, T80, U53, U2000-2999. No prefix indicates both TCP and UDP are defined. An empty implies all port addresses. Packet Filter can work with Scheduling Rules, and give user more flexibility on Access control.
  • Page 33 Example 2: (1.2.3.100-1.2.3.119) They can do everything except read net news (port 119) and transfer files via FTP (port 21) Others are all allowed. After Inbound Packet Filter setting is configured, click the save button. Outbound Filter: To enable Outbound Packet Filter click the check box next to Enable in the Outbound Packet Filter field.
  • Page 34 Example 1: (192.168.1.100-192.168.1.149) They are allowed to send mail (port 25), receive mail (port 110), and browse Internet (port 80); port 53 (DNS) is necessary to resolve the domain name. (192.168.1.10-192.168.1.20) They can do everything (block nothing) Others are all blocked.
  • Page 35 Example 2: (192.168.1.100-192.168.1.119) They can do everything except read net news (port 119) and transfer files via FTP (port 21) Others are allowed After Outbound Packet Filter setting is configured, click the save button.

  • Page 36: Domain Filter

    4.6.2 Domain Filter Domain Filter Let you prevent users under this device from accessing specific URLs. Domain Filter Enable Check if you want to enable Domain Filter. Log DNS Query Check if you want to log the action when someone accesses the specific URLs. Privilege IP Addresses Range Setting a group of hosts and privilege these hosts to access network without restriction.
  • Page 37 Example: In this example: 1. URL include “www.msn.com” will be blocked, and the action will be record in log-file. 2. URL include “www.sina.com” will not be blocked, but the action will be record in log-file. 3. URL include “www.google.com” will be blocked, but the action will not be record in log-file. IP address X.X.X.1~ X.X.X.20 can access network without restriction.

  • Page 38: Url Blocking

    4.6.3 URL Blocking URL Blocking will block LAN computers to connect to pre-defined Websites. The major difference between “Domain filter” and “URL Blocking” is Domain filter require user to input suffix (like .com or .org, etc), while URL Blocking require user to input a keyword only. In other words, Domain filter can block specific website, while URL Blocking can block hundreds of websites by simply a keyword.
  • Page 39 In this example: 1. URL include “msn” will be blocked, and the action will be record in log-file. 2. URL include “sina” will be blocked, but the action will be record in log-file 3. URL include “cnnsi” will not be blocked, but the action will be record in log-file. 4.

  • Page 40: Mac Address Control

    4.6.4 MAC Address Control MAC Address Control allows you to assign different access right for different users and to assign a specific IP address to a certain MAC address. MAC Address Control Check “Enable” to enable the “MAC Address Control”. All of the settings in this page will take effect only when “Enable”...
  • Page 41 Control table "Control table" is the table at the bottom of the "MAC Address Control" page. Each row of this table indicates the MAC address and the expected IP address mapping of a client. There are four columns in this table: MAC Address MAC address indicates a specific client.
  • Page 42 4.6.5 Miscellaneous Items Remote Administrator Host/Port In general, only Intranet user can browse the built-in web pages to perform administration task. This feature enables you to perform administration task from remote host. If this feature is enabled, only the specified IP address can perform remote administration. If the specified IP address is 0.0.0.0, any host can connect to this product to perform administration task.

  • Page 43: Advanced Settings

    4.7 Advanced Settings 4.7.1 System Time...

  • Page 44: System Log

    Get Date and Time by NTP Protocol Selected if you want to Get Date and Time by NTP Protocol. Time Server Select a NTP time server to consult UTC time Time Zone Select a time zone where this device locates. Set Date and Time manually Selected if you want to Set Date and Time manually.

  • Page 45: Dynamic Dns

    IP Address for Syslog Host IP of destination where syslogs will be sent to. Check Enable to enable this function. E-mail Alert Enable Check if you want to enable Email alert (send syslog via email). SMTP Server IP and Port Input the SMTP server IP and port, which are connected with ':'.
  • Page 46 Next you can enter the appropriate information about your Dynamic DNS Server. You have to define: Provider Host Name Username/E-mail Password/Key You will get this information when you register an account on a Dynamic DNS server. Example: After Dynamic DNS setting is configured, click the save button.

  • Page 47: Snmp Setting

    4.7.4 SNMP Setting In brief, SNMP, the Simple Network Management Protocol, is a protocol designed to give a user the capability to remotely manage a computer network by polling and setting terminal values and monitoring network events. Enable SNMP You must check either Local or Remote or both to enable SNMP function. If Local is checked, this device will response request from LAN.

  • Page 48: Routing Table

    4.7.5 Routing Table Routing Tables allow you to determine which physical interface address to use for outgoing IP data grams. If you have more than one routers and subnets, you will need to enable routing table to allow packets to find proper routing path and allow different subnets to communicate with each other. Routing Table settings are settings used to setup the functions of static.
  • Page 49 Example: Configuration on NAT Router Destination SubnetMask Gateway Enabled 192.168.1.0 255.255.255.0 192.168.123.216 ˇ 192.168.0.0 255.255.255.0 192.168.123.103 ˇ So if, for example, the client3 wanted to send an IP data gram to 192.168.0.2, it would use the above table to determine that it had to go via 192.168.1.103 (a gateway), And if it sends Packets to 192.168.1.11 will go via 192.168.1.216 Each rule can be enabled or disabled individually.

  • Page 50: Schedule Rule

    4.7.6 Schedule Rule You can set the schedule time to decide which service will be turned on or off. Select the “enable” item. Press “Add New Rule” You can write a rule name and set which day and what time to schedule from “Start Time” to “End Time”. The following example configure “ftp time”...
  • Page 51 After configure Rule 1 Schedule Enable Selected if you want to Enable the Scheduler. Edit To edit the schedule rule. Delete To delete the schedule rule, and the rule# of the rules behind the deleted one will decrease one automatically. Schedule Rule can be apply to Virtual server and Packet Filter, for example:...
  • Page 52 Exanple1: Virtual Server – Apply Rule#1 (ftp time: everyday 14:10 to 16:20) Exanple2: Packet Filter – Apply Rule#1 (ftp time: everyday 14:10 to 16:20).

  • Page 53: Maintenance

    4.8 Maintenance...
  • Page 54 4.8.1 Change Password You can change Password here. We strongly recommend you to change the system password for security reason. 4.8.2 System Log You can View system log by clicking the View Log button...
  • Page 55 4.8.2 Firmware Upgrade You can upgrade firmware by clicking Firmware Upgrade button.
  • Page 56 4.8.3 Backup Setting You can backup your settings by clicking the Backup Setting button and save it as a bin file. Once you want to restore these settings, please click Firmware Upgrade button and use the bin file you saved. 4.8.4 Reset to default You can also reset this product to factory default by clicking the Reset to default button.
  • Page 57 4.8.6 Miscellaneous Items MAC Address for Wake-on-LAN Wake-on-LAN is a technology that enables you to power up a networked device remotely. In order to enjoy this feature, the target device must be Wake-on-LAN enabled and you have to know the MAC address of this device, say 00-11-22-33-44-55.

  • Page 58: Chapter 5 Print Server

    This product provides the function of network print server for MS Windows 95/98/NT/2000 and Unix based platforms. (If the product you purchased doesn’t have printer port, please skip this chapter.) 5.1 Configuring on Windows 95/98 Platforms After you finished the software installation procedure described in Chapter 3, your computer has possessed the network printing facility provided by this product.
  • Page 59 Find out the corresponding icon of your server printer, for example, the HP LaserJet 6L. Click the mouse’s right button on that icon, and then select the Properties item:...
  • Page 60 2. Click the Details item: 3. Choose the “PRTmate: (All-in-1)” from the list attached at the Print To item. Be sure that the Printer Driver item is configured to the correct driver of your server printer. 4. Click on the button of Port Settings: Type in the IP address of this product and then click the OK button.

  • Page 61: Configuring On Windows Nt Platforms

    5.2 Configuring on Windows NT Platforms The configuration procedure for a Windows NT platform is similar to that of Windows 95/98 except the screen of printer Properties: Compared to the procedure in last section, the selection of Details is equivalent to the selection of Ports, and Port Settings is equivalent to Configure Port.

  • Page 62: Configuring On Windows 2000 And Xp Platforms

    5.3 Configuring on Windows 2000 and XP Platforms Windows 2000 and XP have built-in LPR client, users could utilize this feature to Print. You have to install your Printer Driver on LPT1 or other ports before you preceed the following sequence.
  • Page 63 2.Select “Ports” page, Click “Add Port…” 3. Select “Standard TCP/IP Port”, and then click “New Port…”...
  • Page 64 4.Click Next and then provide the following information: Type address of server providing LPD that is our NAT device:192.168.1.254 1. Select Custom, and then click “Settings…”...
  • Page 65 6. Select “LPR”, type ” lp“ lowercase letter in “Queue Name:” And enable “LPR Byte Counting Enabled”.
  • Page 66 7.Apply your settings...

  • Page 67: Configuring On Unix-Like Based Platforms

    5.4 Configuring on Unix-like based Platforms Please follow the traditional configuration procedure on Unix platforms to setup the print server of this product. The printer name is “lp.” In X-Windows, for example, In Redhat Platforms, Please follow the below steps to configure your printer on Red Hat 9.0.1. Start from the Red Hat---> System Setting--->...
  • Page 68 2. Click New---> Forward. 1. Enter the Pinter Name, Comments then forward.
  • Page 69 4. Select LPD protocol and then forward. 5. Enter Router LAN IP Address and the queue name "lp". Then forward.
  • Page 70 6. Select the Printer Brand and Model Name. Then Forward. 7. Click Apply to finish setup. 8. At last you must click Apply on the toolbox to make the change take effective.
  • Page 71 In Command Mode: Linux has built-in LPR client ,You can utilize it for printing. You can manual set it or via the tool "printtool" in X-windows. PS: The spool name is "lp"------all lowercase letter. Below is my setting. /etc/printcap ------------------------------------------------------------------------------ lp:\ :sd=/var/spool/lpd/lp:\ :mx#0:\...

  • Page 72: Configuring On Apple Pc

    5.5 Configuring on Apple PC 1.First, go to Printer center (Printer list) and add printer 2.Choose IP print and setup printer ip address (router Lan ip address). 3.Disable “Default Queue of Server.” And fill in ‘ lp ‘ in Queue name item. 4.Printer Model: Choose “General”...

  • Page 73: Appendix A Tcp/Ip Configuration For Windows 95/98

    This section introduces you how to install TCP/IP protocol into your personal computer. And suppose you have been successfully installed one network card on your personal computer. If not, please refer to your network card manual. Moreover, the Section B.2 tells you how to set TCP/IP values for working with this NAT Router correctly.
  • Page 74 6. The TCP/IP protocol shall be listed in the Network window. Click OK to complete the install procedure and restart your PC to enable the TCP/IP protocol. A.2 Set TCP/IP Protocol for Working with NAT Router 1. Click Start button and choose Settings, then click Control Panel. 2.
  • Page 75 a. Select Obtain an IP address automatically in the IP Address tab. b. Don’t input any value in the Gateway tab.
  • Page 76 c. Choose Disable DNS in the DNS Configuration tab. B. Configure IP manually a. Select Specify an IP address in the IP Address tab. The default IP address of this product is 192.168.1.254. So please use 192.168.1.xxx (xxx is between 1 and 253) for IP Address field and 255.255.255.0 for Subnet Mask field.
  • Page 77 b. In the Gateway tab, add the IP address of this product (default IP is 192.168.1.254) in the New gateway field and click Add button. c. In the DNS Configuration tab, add the DNS values which are provided by the ISP into DNS Server Search Order field and click Add button.
  • Page 78 Figure 1: Testing Environment (Use Windows 2000 Radius Server) 1 Equipment Details PC1: Microsoft Windows XP Professional without Service Pack 1. D-Link DWL-650+ wireless LAN adapter Driver version: 3.0.5.0 (Driver date: 03.05.2003) PC2: Microsoft Windows XP Professional with Service Pack 1a. Z-Com XI-725 wireless LAN USB adapter Driver version: 1.7.29.0 (Driver date: 10.20.2001) Authentication...

  • Page 79: Appendix B 802.1X Setting

    1.Enable DHCP server. 2.WAN setting: static IP address. 3.LAN IP address: 192.168.1.254/24. 4.Set RADIUS server IP. 5.Set RADIUS server shared key. 6.Configure WEP key and 802.1X setting. The following test will use the inbuilt 802.1X authentication method such as ,EAP_TLS, PEAP_CHAPv2(Windows XP with SP1 only), and PEAP_TLS(Windows XP with SP1 only) using the Smart Card or other Certificate of the Windows XP Professional.
  • Page 80 4. We will change EAP type to fit the variable test condition. Figure 2: Enable IEEE 802.1X access control...
  • Page 81 4. Windows 2000 RADIUS server Authentication testing: 4.1DUT authenticate PC1 using certificate. (PC2 follows the same test procedures.) Download and install the certificate on PC1. (Fig 4) PC1 choose the SSID of DUT as the Access Point. Set authentication type of wireless client and RADIUS server both to EAP_TLS.
  • Page 82 Figure 5: Authenticating Figure 6: Authentication success 4.2DUT authenticate PC2 using PEAP-TLS. PC2 choose the SSID of DUT as the Access Point. Set authentication type of wireless client and RADIUS server both to PEAP_TLS. Disable the wireless connection and enable again. The DUT will send the user's certificate to the RADIUS server, and then send the message of authentication result to PC2.
  • Page 83 Support Type: The router supports the types of 802.1x Authentication: PEAP-CHAPv2 and PEAP-TLS. Note. PC1 is on Windows XP platform without Service Pack 1. PC2 is on Windows XP platform with Service Pack 1a. PEAP is supported on Windows XP with Service Pack 1 only. Windows XP with Service Pack 1 allows 802.1x authentication only when data encryption function is enable.

  • Page 84: Appendix C Wpa-Psk And Wpa

    Wireless Router: LAN IP: 192.168.1.254 WAN IP: 192.168.2.216 Radius Server: 192.168.2.1 UserA : XP Wireless Card:Ti-11g Tool: Odyssey Client Manager Refer to: www.funk.com Download: http://www.funk.com/News&Events/ody_c_wpa_preview_pn.asp...
  • Page 85 Or Another Configuration: WPA-PSK In fact, it is not necessary for this function to authenticate by Radius Server, the client and wireless Router authenticate by themselves. Method1: 1. Go to the Web manager of Wireless Router to configure, like below: 2.
  • Page 86 3. Add and edit some settings:...
  • Page 87 4. Back to Connection: Then Select “Connect to network” You will see: Method2: 1. First, patch windows XP and have to install “Service package 1” Patch: http://www.microsoft.com/downloads/details.aspx?displaylang=en&FamilyID=5039 ef4a-61e0-4c44-94f0-c25c9de0ace9 2. Then reboot. 3. Setting on the router and client: Router: Client: Go to “Network Connection”...
  • Page 88 Choose “View available Wireless Networks” like below: Advanced choose “123kk”...
  • Page 89 WPA: For this function, we need the server to authenticate. This function is like 802.1x. The above is our environment: Method 1: 1. The UserA or UserB have to get certificate from Radius, first. http://192.168.122.1/certsrv account : fae1 passwd : fae1 2.
  • Page 90 4. Go to Odyssey Client Manager, choose “Profiles” and Setup Profile name as “1” Login name and password are fae1 and fae1. Remember that you get certificate from Radius in Step1.
  • Page 91 5. Then Choose “certificate” like above.
  • Page 92 6. Then go to Authentication and first Remove EAP/ TLS and Add EAP/TLS again.
  • Page 93 7. Go “Network” and Select “1” and ok...
  • Page 94 8. Back to Connection and Select “123kk. If successfully, the wireless client has to authenticate with Radius Server, like below: 9. Result: Method 2: 1. The UserA or UserB have to get certificate from Radius,first. http://192.168.122.1/certsrv account:fae1 passwd:fae1...
  • Page 95 2. Then Install this certificate and finish. 3. Setting on the router and client: Router:...
  • Page 96 Client: Go to “Network Connection” and select wireless adapter. Choose “View available Wireless Networks” like below: Advanced choose “123kk” Select “WirelessCA and Enable” in Trusted root certificate authority: Then, if the wireless client wants to associate, it has to request to authenticate.

  • Page 97: Appendix D Faq And Troubleshooting

    Reset to factory Default There are 2 methods to reset to default. Restore with RESET button First, turn off the router and press the RESET button in. And then, power on the router and push the RESET button down until the M1 and or M2 LED (or Status LED) start flashing, then remove the finger. If LED flashes about 8 times, the RESTORE process is completed.
