Chapter 5 Using - FrontRow symbio User Manual

5
940TM Pendant Microphone
Using
2
5in/13cm
3
940TM (bottom)
7
6
6
5 4
9
11
8
10
1. Place microphone around neck and
connect clasp
2. Adjust neck straps to position micro-
phone as close to mouth as possible
(approximately 5in/13cm)
3. Set channel to A or B (whichever is not
already in use)
4. Turn microphone on. Indicator light
should be green
5. Press mute switch as needed for private
1
conversations. Indicator light will blink green
6. Optional: if desired, plug in external
boom microphone
Light Legend
Green . . . . . . . . . . . . On
Blinking Green . . . . . . Muted
Blinking Red . . . . . . . . Low Battery
When Charging:
Off . . . . . . . . . . . . . . Alkaline Battery
Red . . . . . . . . . . . . . . Charging
The 940TM Pendant Microphone can be
used to transmit audio from a secondary
audio source (MP3 player, computer, portable
radio/CD/tape player) to the receiver.
7. Plug one end of the audio adaptor cord
(included) in the Audio Out/headphone
jack of the secondary audio source. Plug
the other end of the adaptor cord to
the Aux-In jack on the 940TM Pendant
Microphone
8. Turn the secondary audio source on
9. Turn the 940TM Pendant Microphone on
10. Turn the volume on the secondary audio
source all the way up and adjust the micro-
phone volume on the receiver to obtain
the optimal volume
11. You can "talk over" the secondary audio
by speaking into the microphone or mute
the microphone to ensure the best audio
sound quality
Detected, or
microphone power
is still on
