Chapter 8 Using - FrontRow symbio User Manual

8
950H Pass-Around Microphone (optional)
using
5
1
3
5in. (13cm)
2
4
3in. (7cm)
6
1. Turn microphone on
2. Note indicator light
Green = On and transmitting
Blinking red = Low battery
3. To allow hands-free use (for example,
when reading aloud and turning pages),
attach the lavaliere clip. Adjust neck strap
to position microphone approximately
4 - 5in (10 - 13cm) from mouth.
4. Keep top of microphone approximately
3 - 4in. (7.5 – 10cm) from mouth
5. Do not block emitter diodes
6. Turn off microphone and place microphone
in charger at the end of the day
NOTe: The 950H is factory set on Channel B.
If you are using two microphones, they
must be on different channels.
CAuTION: The lavaliere clip should easily
slide on and snap into place. Do NOT
snap the clip around the body or install the
microphone backward or damage may result.
15
