SuperStor Ultra
Stainless Steel
Storage Tank
INSTALLATION
START-UP
MAINTENANCE
PARTS
Storage Tank Models
SSU-30CB / SSU-45CB
SSU-60CB / SSU-80CB / SSU-119CB
For Residential and Commercial Use
This manual must only be used by a qualified heating installer/service technician. Read all instructions in this manual before installing.
Perform steps in the order given. Failure to comply could result in substantial property damage, severe personal injury, or death.
NOTICE: HTP reserves the right to make product changes or updates without notice and will not be held liable for typographical errors
in literature.
NOTE TO CONSUMER: PLEASE KEEP ALL INSTRUCTIONS FOR FUTURE REFERENCE.
120 Braley Rd. P.O. Box 429
East Freetown, MA 02717-0429
www.htproducts.com
LP-32 Rev. 6.7.13
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HTP SSU-30CB
Summary of Contents for HTP SSU-30CB
- Page 1 Perform steps in the order given. Failure to comply could result in substantial property damage, severe personal injury, or death. NOTICE: HTP reserves the right to make product changes or updates without notice and will not be held liable for typographical errors in literature.
-
Page 2: Table Of Contents
The following defined terms are used throughout this manual to bring attention to the presence of hazards of various risk levels, or to important product information. DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. -
Page 3: Part 1 - General Safety Information
B. WIRING ....................................... 9 PART 5 – OPERATING THE STORAGE TANK .......................... 9 PART 6 – MAINTENANCE AND TROUBLESHOOTING ......................10 HTP CUSTOMER INSTALLATION RECORD FORM ........................12 PART 1 – GENERAL SAFETY INFORMATION A. PRECAUTIONS This storage tank is approved for indoor installations only. Clearance to combustible materials: 0” top, bottom, sides and back. Tank must have room for service: 24”... -
Page 4: Specifications And Performance Ratings
Locate the storage tank where any leakage from the relief valve, related piping, tank, or connections will not result in damage to surrounding areas or lower floors of the building. The storage tank should be located near a floor drain or installed in a drain pan. HTP... - Page 5 Chemical imbalance of the water supply may affect efficiency and cause severe damage to the storage tank and associated equipment. HTP recommends having water quality professionally analyzed to determine whether it is necessary to install a water softener. It is important that the water chemistry on both the domestic hot water and central heating sides are checked before installing the storage tank, as water quality will affect the reliability of the system.
-
Page 6: Part 3 -Piping
pH of Water pH is a measure of relative acidity, neutrality or alkalinity. Dissolved minerals and gases affect water pH. The pH scale ranges from 0 to 14. Water with a pH of 7 is considered neutral. Water with a pH lower than 7 is considered acidic. Water pH higher than 7 is considered alkaline. - Page 7 maintains periodic inspection of production of listed equipment. The T&P valve must be plumbed down, so discharge will exit at least 6” above the structural floor and not contact any live electrical parts. In the bottom of the tee (Branch) vertically down, install a ¾” NPT x ¾”...
-
Page 8: Typical Installation
D. TYPICAL INSTALLATION Figure 3 – Typical Storage Tank Installation... -
Page 9: Potable Expansion Tank
NOTE: If a backflow preventer or no return valve is installed, a thermal expansion tank is required on the cold water inlet between the storage tank and backflow preventer. E. POTABLE EXPANSION TANK A thermal expansion tank is required in the system designed for potable water use, to offset the expansion of stored water as the temperature is elevated. -
Page 10: Part 6 - Maintenance And Troubleshooting
A water heating system can deliver scalding water. Be careful whenever using hot water to avoid scalding injury. Certain appliances, such as dishwashers and automatic clothes washers, may require increased water temperature. By setting the thermostat to obtain the increased water temperature required by these appliances, you may create the potential for scald injury. To protect against injury, you should install a mixing valve in the water APPROXIMATE TIME / TEMPERATURE system. - Page 11 TROUBLESHOOTING NO HOT WATER PROBLEM POSSIBLE SOLUTION Zone valve not opening Open manually to replace. Circulator not operating Check or replace Tank control set too low Raise tank temperature* (SEE NOTE BELOW) Boiler control set too low Raise boiler temperature Wiring incorrect Recheck wiring Tank control failure...
-
Page 12: Htp Customer Installation Record Form
HTP CUSTOMER INSTALLATION RECORD FORM The following form should be completed by the installer for you to keep as a record of the installation in case of a warranty claim. After reading the important notes at the bottom of the page, please also sign this document.
