Summary of Contents for Fisher & Paykel SMARTLOAD DRYER DGGX2 US FP
- Page 1 ® SMARTLOAD DRYER Model DGGX2 US FP Product Code 96103-B 96103-B...
- Page 2 96103-B...
- Page 3 96103-B - APRIL 2006 PRODUCTS Fisher & Paykel Brand Voltage 120V 60Hz Model DGGX2 US FP Product Code 96103-B Fisher & Paykel Appliances 5900 Skylab Road Huntington Beach CA 92647 Telephone: 888 936 7872 COPYRIGHT © FISHER & PAYKEL LTD 2006 ALL RIGHTS RESERVED...
- Page 4 96103-B...
-
Page 5: Table Of Contents
96103-B CONTENTS TOP DECK AND ELECTRONICS........................6 CABINET, DRUM AND INLET DUCT ........................8 OUTLET DUCT ..............................12 CHASSIS COMPONENTS & MOTOR ASSEMBLY..................14 SUBDECK ASSEMBLY & DRUM DOOR ASSEMBLY ..................16 BASE PANEL AND COMPONENTS........................18 NOTES ................................21 GUIDE TO USING THIS MANUAL The model covered by this manual is listed on the front cover. The information detailed in this manual is subject to change without notice, the latest version is indicated by the reprint date and replaces any earlier editions. -
Page 6: Top Deck And Electronics
96103-B TOP DECK AND ELECTRONICS... - Page 7 96103-B TOP DECK AND ELECTRONICS PART DESCRIPTION 611933P SCREW ST 8X5/8 TA MTS PH HS ZNPL (PKT 10) 395262 CONSOLE PRINTED DX1 395644 PANEL CONTROL DX1 ( Silver 426819 INSERT CONSOLE GW11/DX1 395124P DISPLAY DRYER DX1 SERVICE 395116P LID ASSEMBLY DX1 395449 LABEL LID USE &...
-
Page 8: Cabinet, Drum And Inlet Duct
96103-B CABINET, DRUM AND INLET DUCT... - Page 9 96103-B CABINET, DRUM AND INLET DUCT PART DESCRIPTION 395108P LOCATOR PANEL (PKT 6) 395581P CABINET FRONT ASSEMBLY DX1 395110 BRACKET CABINET FRONT (2) Includes 395277 CABLE ASSEMBLY CABINET FRONT EARTH Includes 611805 SCREW ST 8X16 PLASTITE PAN ZNPL (2) Includes 395110 BRACKET CABINET FRONT 611805P...
- Page 10 96103-B CABINET, DRUM AND INLET DUCT...
- Page 11 96103-B CABINET, DRUM AND INLET DUCT PART DESCRIPTION 395055P CHASSIS INLET ASSY DX1 Includes PANEL CHASSIS INLET Includes DUCT INLET BACK Includes DUCT INLET FRONT Includes SHAFT BEARING INLET 395064 SPACER BEARING INLET Includes 395065 BOLT BEARING INLET Includes 395406 SHIELD DUCT INLET Includes 395458 SEAL DUCT INLET Includes...
-
Page 12: Outlet Duct
96103-B OUTLET DUCT... - Page 13 96103-B OUTLET DUCT PART DESCRIPTION 395005 BRACKET HOUSING COLLECTOR 395404 BRACKET CONTACT CONDUCTIVITY 395424P CONTACT CONDUCTIVITY(PKT 2) 395143 HARNESS CONDUCTIVITY CONTACTS Includes 395138 SCRAPER LINT 611805P SCREW ST 8X16 PLASTITE PAN PH (PKT 10) 395136 HOUSING COLLECTOR LINT 395249 COLLECTOR LINT ASSY 395560P BEARING ASSY DRUM OUTLET DX1 (PKT 7) 395432...
-
Page 14: Chassis Components & Motor Assembly
96103-B CHASSIS COMPONENTS & MOTOR ASSEMBLY... - Page 15 96103-B CHASSIS COMPONENTS & MOTOR ASSEMBLY PART DESCRIPTION 395628P MODULE SENSOR ASSY 395009 LENS POSITION SENSOR Includes 611805P SCREW ST 8X16 PLASTITE PAN PH (PKT 10) 395055P CHASSIS INLET ASSY DX1 Includes PANEL CHASSIS INLET Includes DUCT INLET BACK Includes DUCT INLET FRONT Includes SHAFT BEARING INLET...
-
Page 16: Subdeck Assembly & Drum Door Assembly
96103-B SUBDECK ASSEMBLY & DRUM DOOR ASSEMBLY... - Page 17 96103-B SUBDECK ASSEMBLY & DRUM DOOR ASSEMBLY PART DESCRIPTION 395025P DOOR DRUM DX1 395678 LABEL DOOR DRUM Includes 395362P CLIP BRACKET DOOR (PKT 3) 395029 BRACKET DOOR DX1 611805P SCREW ST 8X16 PLASTITE PAN PH (PKT10) 395094 BEAM CHASSIS DX1 395169P GRABBER DOOR KIT Includes...
-
Page 18: Base Panel And Components
96103-B BASE PANEL AND COMPONENTS... - Page 19 96103-B BASE PANEL AND COMPONENTS PART DESCRIPTION 610216P SCREW MC M4X8 TAPTITE PAN ZNP (PKT 10) 395355 HOUSING COMBUSTION TOP 395368 SHIELD HOUSING COMBUSTION SS 321 395351 HOUSING COMBUSTION BOTTOM 395228 BRACKET HOUSING HEAT 395192 THERMOSTAT AUTO RESET 395191 THERMOSTAT MANUAL RESET 395194 DETECTOR FLAME GAS 395235...
- Page 20 96103-B...
-
Page 21: Notes
96103-B NOTES...
