OWNER'S
MANUAL
STARTING SERIAL #
L106-017001
ENDING SERIAL #
L110-365999
MODEL NO.
POL14560X
POL14560X-CA
POL14560XEX
IMPORTANT
Read and follow all
Safety Precautions
and Instructions
before operating this
equipment.
Rev: 07-234
1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093
PHONE 660-747-8183 FAX 660-747-8650
Manufacturing quality lawn care equipment since 1945
14277
60" FINISH CUT
FRONT & REAR MOUNT
TRAILMOWER
Assembly
Operation
Service and Adjustment
Repair Parts
R
Made In The
USA
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Swisher TRAILMOWER POL14560X
Summary of Contents for Swisher TRAILMOWER POL14560X
- Page 1 www.swisherinc.com OWNER’S MANUAL STARTING SERIAL # L106-017001 ENDING SERIAL # L110-365999 MODEL NO. POL14560X 60” FINISH CUT POL14560X-CA FRONT & REAR MOUNT POL14560XEX TRAILMOWER Assembly IMPORTANT Operation Read and follow all Safety Precautions Service and Adjustment and Instructions before operating this equipment.
-
Page 2: Limited Warranty
Should you have any questions concerning this warranty, please contact us toll-free at 1-800- 222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. This machine can amputate hands, feet, and throw objects. - Page 4 Power Equipment, but Swisher cannot deny warranty solely for the lack of receipts. As the Power Equipment owner, you should be aware that Swisher, may deny you warranty coverage if your Power Equipment, or a covered part has failed due to abuse, neglect, or improper maintenance, unapproved modifications, or the use of parts not made or approved by the equipment manufacturer.
-
Page 5: Safety Decals
SAFETY DECALS Replace decals immediately if damaged.Order by part number from Swisher OD45- Warning Decal OD11- No step Decal OD55- Triangle Danger Decal OD43- Flying Debris Decal OD15 – Grass Only Decal OD33- Speed Decal OD29- Danger Decal... - Page 6 REQUIRED ASSEMBLY FIGURE - 1 FRONT WHEEL CASTER ASSEMBLY 1. Remove single nut (1) and washers (2) from caster shaft. 2. Place one washer (2) on the shaft of the caster/wheel sub-assembly. (4) 3. Slide same shaft through the bearing (3) in the frame with wheel towards the ground. 4.
- Page 7 6 Figure – 2 STARTING THE ENGINE See engine manufacturer’s instructions for the type and amount of oil and fuel used. For Trailmowers® that require a battery (sold separately), Swisher recommends using a standard “U 1 R” lawn & garden battery.
-
Page 8: Starting To Mow
• Engine must be on level ground to accurately check and fill oil DO NOT OVER FILL. • Make sure the tow vehicle parking brake is set, mower is level, and blades are disengaged. • Check spark plug wire, oil, and fuel. •... -
Page 9: General Troubleshooting
ALTERNATIVE STOPPING METHOD • Bring vehicle to complete stop, shut off engine, and set parking brake. • Disengage blades. • Manually turn key switch to the “OFF” position. • Always remember to remove keys to avoid accidental starting. TRANSPORTING MOWER •... -
Page 10: Mower Maintenance
MOWER MAINTENANCE GENERAL RECOMMENDATIONS The warranty on this Trailmower® does not cover items that have been subjected to operator abuse or negligence. To receive full value from the warranty, operator must maintain unit as instructed in this manual. Some adjustments will need to be made periodically to maintain your unit properly. All adjustments in this manual should be checked at least once each season. - Page 11 Outer Blades Center Blade Blade Driver Configuration Item No. Description Part # Center Shaft, 5.75" 9054 Blade Bearing Bearing Housing 9057TK Pulley Spacer 6065PM Blade Mount Plate 9008 Recomm ended Torque Specifications 20 1/2 ''Blade 9004 Item No. Torque ( ft-lbs ) Blade Pulley- 5.5"...
- Page 12 5/16-18 X 1 BOLT NB501 Go to www.swisherinc.com 3/8-16 X 1 1/2 BOLT NB107 BATTERY BOX 6112TK For information about the full line 1/4-20 X 3/4 BOLT NB154 of swisher products. 1/4-20 NYLOK NUT NB180 5/16-18 Serrated Flng Nut NB170...
- Page 13 MOTOR BASE DETAIL Slide plastic tube snug against toggle switch. HEAT SHIELD 6052TK NOT USED ON HONDA UNITS MOTOR BASE DETAIL Item No. Description Part # Heat Shield 6052TK Throttle 686N Knob - Throttle 686K Not Shown Toggle Switch 685SP Control Console 10737TK DETAIL 10...
-
Page 14: Engine Detail
ENGINE DETAIL DETAIL - 1 BRIGGS / TECUMSEH > DETAIL - 1 Item No. Description Part # UPPER SPACER 689L 5-1/2'' ENGINE PULLY 1/4/ X 1'' KEY STOCK 9031 LOWER SPACER 689S 3/8 BELLEVILLE WASHER FLAT WASHER TR150W 3/8-24 X 1BOLT [BRIGGS ] NB452N Not Shown 7/16-20 X 1 BLOT [TECUMSEH ]... -
Page 16: How To Order Repair Parts
MODEL NO. All mower parts listed herein may be ordered directly from Swisher or your nearest Swisher dealer. POL14560X All engine parts may be ordered from the nearest dealer of the engine supplied with your mower POL14560X-CA Color cannot be guaranteed on service parts.
