- Page 1 100 Watt Power Inverter Model No.: PKC0AM Owner’s Manual and Warranty Information Read these instructions completely before using this product. Retain this Owner’s Manual for future reference. 9/13 © 2013...
- Page 2 CONTENTS SAFETY PRECAUTIONS ........................ 2 Power Inverter Safety ......................2 INTRODUCTION ..........................2 OPERATION (USING YOUR INVERTER) ..................3 Connecting to Power Source ....................3 USB Power Outlet Operation ....................3 Protective Features ......................... 4 Common Problems ......................... 4 CARE AND MAINTENANCE ......................4 Storage ...........................
- Page 3 OPERATION (USING YOUR INVERTER) The Power Inverter converts 12-volt DC (direct current) input voltage to 110/120-volt, 60 Hz AC (alternating current) power. The Inverter produces a “modified sine wave.” The modified sine wave is suitable for most AC powered appliances and personal electronic devices. The following devices may not work with a modified sine wave: • Photocopiers, laser printers, magneto-optical hard drives • Some laptops...
- Page 4 Protective Features Over-Voltage Protection (Red LED on Inverter will light) - The Inverter will automatically shut down when the input voltage exceeds 15 volts DC. Overload Protection (Red LED on Inverter will light) The Inverter will automatically shut down if the continuous draw exceeds its maximum wattage rating. If you continue to use the Inverter at or near the maximum output, it will eventually overheat and shut down.
- Page 5 If the wattage limitation is exceeded, the mobile power outlet will not power the accessory. This is known as “peak load,” “inductive load,” or “starting load.”...
- Page 6 400 (amp-hour rating of DC battery) / 10 (always use 10) = 40 amp-hours @ 120 volts AC 40 (amp-hours @ 120 volts AC) / 20 (amps) = 2 hours of operating time DO NOT EXPOSE ANY PEAK ELECTRONIC DEVICES TO MOISTURE DURING STORAGE OR OPERATION. USE PEAK ELECTONIC DEVICES IN WELL-VENTILATED AREAS.
- Page 7 SPECIFICATIONS Max output continuous power 100 W Max output peak surge 200 W (0.1 sec) North American Standard AC receptacles Max output current ≤0.91 A AC output voltage range 105 - 125 V AC output frequency range 60 ± 3 Hz...
- Page 8 Before returning this product for any reason, please call toll free (800) 477-5847. Do not return your PEAK® product to the place of purchase for service. Send your unit, postage prepaid and insured, along with a copy of the original sales receipt and a phone number to the address below.
