- Page 1 2000 Watt Power Inverter Model No.: PKC0AX Owner’s Manual and Warranty Information Read these instructions completely before using this product. Retain this Owner’s Manual for future reference. © 2013 9/13...
-
Page 2: Table Of Contents
CONTENTS SAFETY PRECAUTIONS ........................ 2 Power Inverter Safety ......................2 INTRODUCTION ..........................3 FEATURES ............................3 OPERATION (USING YOUR INVERTER) ..................3 Determining Power Consumption (Current Draw of Equipment) ..........4 Power Source .......................... 4 Determining Battery Capacity and Operating Time ..............4 Positioning of Power Inverter .................... -
Page 3: Introduction
• Do not disassemble the Power Inverter. There are no serviceable components within the Inverter. • Do NOT install or operate the Power Inverter in areas designated as IGNITION PROTECTED. The Inverter is NOT APPROVED for ignition protected areas. • Always turn the Inverter ON/OFF switch and remote switch ON/OFF button to the OFF position and disconnect the battery cables from the battery or power source when not in use to avoid draining the battery. -
Page 4: Determining Power Consumption (Current Draw Of Equipment)
The following appliances or devices could be damaged if plugged into the Inverter: • Small battery operated appliances that can be plugged directly into the AC receptacle such as flashlights, cordless razors and toothbrushes. • Certain battery chargers for cordless tool battery packs. These chargers can be identified by a warning label stating dangerous voltages are present at the battery terminals. -
Page 5: Positioning Of Power Inverter
To increase the operating time, the amp-hour rating must be increased. Either choose a battery with a higher amp-hour rating, or connect multiple batteries together in parallel. If the 12-volt DC battery has a rating of 200 amp-hours, connecting two 12-volt DC batteries, each having a 200 amp-hour rating in a parallel arrangement, would increase the amp-hour rating to 400 amp-hours, doubling the time of operation. -
Page 6: Hard Wire To Power Source
Slide the lock washer, then the red positive (+) cable lead, then the flat washer, onto the red positive (+) screw connector stud. Tighten the screw connector cap securely. Remove the black negative (-) screw connector cap, the flat washer and the lock washer. Slide the lock washer, then the black negative (-) cable lead, then the flat washer, onto the black negative (-) screw connector stud. -
Page 7: Usb Power Outlet Operation
Legend Battery Charging Source 12-volt Batteries 300-amp ANL Fuse Power Inverter Negative (-) Cable (see SPECIFICATIONS for cable requirements) Positive (+) Cable (see SPECIFICATIONS for cable requirements) Additional Batteries Connected in Parallel Circuit USB Power Outlet Operation The USB power outlet does not support data communications. The outlet has a maximum of 5 volts/2.1 A. -
Page 8: Power Output Wattage Indicator
Power Output Wattage Indicator The Inverter is equipped with a power output wattage indicator which displays how much wattage is currently being used. The output indicator has ten separate red lights, with each one representing approximately 200 watts of output when lit. If the device you are powering requires approximately 1000 watts, five of the red indicator lights will be lit. -
Page 9: Common Problems
To Reset the Inverter Turn off the Inverter using the ON/OFF switch on the Inverter or the remote switch ON/OFF button, depending upon how the Inverter was controlled. Unplug all the devices from the Inverter. Turn the Inverter back on using the ON/OFF switch on the Inverter or the remote switch ON/OFF button. -
Page 10: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS What issues can cause my mobile power outlet to stop working? Overheating, incorrect input voltage, and overloading are some basic symptoms. The unit is equipped with self-protection features that help prevent damage to the mobile power outlet and accessories being powered by it. -
Page 11: Specifications
I accidentally connected the wires from the mobile power outlet to my vehicle in reverse and the mobile power outlet will not work. Is the unit damaged? It is dependent on testing the unit afterwards. There are no replaceable fuses in the mobile power outlet nor is it recommended to open or service the unit. -
Page 12: Troubleshooting
Battery condition may Recharge or replace battery. output be poor Faulty connection Make sure the battery and Inverter terminals are clean. Inverter does The internal protection Contact Old World Industries. not work after has disabled the Inverter connecting the cables in reverse... -
Page 13: Limited Warranty
LIMITED WARRANTY Manufacturer warrants to the original consumer, or purchaser, that the PEAK® PKC0AX 2000 Watt Power Inverter will be free from defects in material and workmanship for one year from the date of sale to the original purchaser. Manufacturer hereby excludes and disclaims any and all other warranties, expressed or implied, beyond those warranties specified above.
