Owner's Manual

SPRAY GUN

Model No.
919.155310
• Safety Guidelines
• Operation
• Maintenance
• Storage
• Repair Parts
CAUTION:
Read the Safety Guidelines
and All Instructions Carefully Before
Operating.
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
Visit our Craftsman website: www.sears.com/craftsman
D28996 Rev. 0 03/21/03

Advertisement

Table of Contents
loading

Related Manuals for Craftsman 919.155310

Summary of Contents for Craftsman 919.155310

  • Page 1: Spray Gun

    • Safety Guidelines • Operation • Maintenance • Storage • Repair Parts CAUTION: Read the Safety Guidelines and All Instructions Carefully Before Operating. Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A. Visit our Craftsman website: www.sears.com/craftsman D28996 Rev. 0 03/21/03...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Maintenance ....6 Warranty ....2 Troubleshooting .

  • Page 3: Safety Guidelines

    IMPORTANT SAFETY INSTRUCTIONS • SAVE THESE INSTRUCTIONS • IMPROPER OPERATION OR MAINTENANCE OF THIS PRODUCT COULD RESULT IN SERIOUS INJURY AND PROPERTY DAMAGE. READ AND UNDERSTAND ALL WARNINGS AND OPERATING INSTRUCTIONS BEFORE USING THIS EQUIPMENT. The Following Hazards Can Occur During The Normal Use Of This Product: HAZARD Risk of explosion or fire - flammable materials WHAT COULD HAPPEN...

  • Page 4: Specifications

    HAZARD Risk of injection WHAT COULD HAPPEN HOW TO PREVENT IT Spray guns operate at pressures and velocities Never place hands in front of nozzle. high enough to penetrate human and animal Direct spray away from self and others. flesh, which could result in amputation or other serious injury.
  • Page 5 Prior to shipment, this gun was treated Attach air supply line to 1/4 NPS with an anticorrosive agent. Before air inlet. using this gun make sure that it is NEVER point carefully flushed with thinner. spray gun at self or any other person. Accidental (E) Non-Drip Cup discharge of material may result in serious injury.

  • Page 6: Maintenance

    MAINTENANCE Lubrication Always exercise Lubrication procedures must be ob- extreme care served after thoroughly cleaning the when using any solvent or thin- gun to ensure effective, high quality ner. Never clean gun near fire, performance of spray gun. flame, or any source of heat or sparks.

  • Page 7: Troubleshooting

    TROUBLESHOOTING NOTICE: See parts list to identify parts referred to in these Troubleshooting steps. Defective Pattern Likely Cause Suggested Remedy Dried material is clog- Soak side-ports in thinner to ging side-port “A” and clean clog. DO NOT poke causing side-port “B” any opening with hard to blow spray towards objects.

  • Page 8: Parts List

    PARTS LIST 7 8 9 DESCRIPTION PART NO DESCRIPTION PART NO Air Nozzle with Cap D25151 O-Ring D25174 Air Nozzle D25152 Spray Regulating Screw D25175 Washer D25153 Gasket D25176 D25154 Control Knob D25177 Fluid Nozzle D25155 Paint Needle Complete D25178 Packing Screw D25156 Spring for Paint Needle...
  • Page 9 CONTENIDO Operación ....11-12 Garantía .....2 Mantenimiento .

  • Page 10: Importantes Instrucciones De Seguridad

    IMPORTANTES INSTRUCCIONES DE SEGURIDAD • CONSERVE ESTAS INSTRUCCIONES • LA OPERACIÓN O MANTENIMIENTO INADECUADOS DE ESTE PRODUCTO PODRÍA RESULTAR EN LESIONES SERIAS O DAÑOS A LA PROPIEDAD. SÍRVASE LEER Y COMPRENDER TODAS LAS ADVERTENCIAS E INSTRUCCIONES OPERATIVAS ANTES DE UTILIZAR ESTE EQUIPO. Los siguientes peligros pueden ocurrir durante el uso normal de este producto: PELIGROS...

  • Page 11: Especificaciones

    PELIGROS Riesgo de Inyección ¿QUÉ PUEDE OCURRIR? ¿CÓMO PREVENIRLO? Las pistolas rociadoras operan a presiones y Jamás coloque las manos frente a una boquilla velocidades suficientemente elevadas para poder rociadora. penetrar el tejido humano y animal, lo cual podría determinar una amputación u otras lesiones serias. Oriente el rociado fuera del alcance propio y de otras ¡Consulte inmediatamente con un médico! personas.
  • Page 12 Previo a su envío, esta pistola fue tratada con del filtro de material. un agente anticorrosivo. Antes de usar esta 3. Conecte la manguera de suministro de pistola, asegúrese de enjuagarla aire a la toma NPS de 1/4. cuidadosamente con solvente. JAMÁS apunte la (E) Copa antigoteo...

  • Page 13: Mantenimiento

    MANTENIMIENTO Tenga siempre Lubricación extremo Los siguientes procedimientos de cuidado al usar solventes o lubricación deben observarse cuando se diluyentes. Jamás limpie la pistola limpie completamente la pistola, para poder cerca del fuego o llama abierta, o asegurar su efectividad y alta calidad de cualquier otra fuente de calor o rendimiento de la pistola rociadora.

  • Page 14: Diagnóstico De Problemas

    DIAGNÓSTICO DE PROBLEMAS NOTA: Vea la lista de partes para la identificación de piezas referidas en los siguientes pasos del Diagnóstico de problemas. Causas probables Solución sugerida Configuración del defecto Material reseco que Empape los orificios está obturando la salida laterales en diluyente con el lateral de “A”, siendo la objeto de limpiar la...

  • Page 15: Lista De Partes

    LISTA DE PARTES 7 8 9 N° DE PIEZA N° DE PIEZA REF DESCRIPCIÓN N° REF DESCRIPCIÓN N° O-Ring D25174 Boquilla de aire con copa D25151 Tornillo regulador de rociado D25175 Boquilla de aire D25152 Junta D25176 Arandela D25153 Perilla de control D25177 Copa D25154...
