744T User Guide and Technical Information
Accessories

Included Accessories

The accessories below are included with the 744T:
• XL-WPH - worldwide mains power supply, 100–240 VAC input, 12 VDC, 24 W output
• XL-B2 - Li-ion removable rechargeable battery, 4800 mAh
• XL-14 - 3.5 mm to 1/4-inch jack for headphone output extension
• XL-RJ - C. Link cable for unit-to-unit linking
• XL-MAN - Padded man-bag

Optional Accessories

The above accessories are just the start of building a fl exible recording kit. Available accessories from
Sound Devices include:
CL-1
•
Remote Control and Keyboard Interface used to control the 744T with an external keyboard.
XL-DVDRAM
•
An external bus-powered FireWire DVD Multi-drive. Based on the slot-loading Panasonic
UJ-85 drive mechanism the XL-DVDRAM is used with a 7-Series recorder to record directly to
optical disk or as a post-record storage volume.
CS-3
•
Production bag with shoulder strap, holds 744T and is compatible with PortaBrace RM acces-
sories; mounts onto CS-442, CS-302, and CS4W mixer bags
XL-1394
•
FireWire power fi lter to eliminate noise induced from bus-powered FireWire drives into analog
audio on the 744T
XL-1A (sold as pair)
•
TA3F to TA3F cable, used to connect the direct outputs of the a Sound Devices 442 mixer to the
channel 3/4 analog line-level inputs
XL-2 (sold as pair)
•
TA3F to XLR-M cable, used for output connection from the master analog output
XL-2F (sold as pair)
•
XLR-F to TA3F cable, used for input connection to line inputs 3 and 4 from balanced, XLR
outputs.
XL-BNC
•
BNC to BNC cable, to connect word clock from external sources to the 744T for synchronizing
the 744T; also used to sync external devices from the word clock of the 744T.
XL-LB2
•
5-pin LEMO to two (2) BNC, used to jam to and from video cameras.
XL-LL
•
5-pin LEMO to 5-pin LEMO, used to connect the 744T time code circuit to Ambient time code
sync boxes, slates, and controllers or to jam one 744T to another 744T; additionally used to jam
Aaton cameras from the 744T
74
v. 2.09 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
