744T User Guide and Technical Information
# Setup Name
63 Meter: Ballistics
64 Meter: Peak Threshold
65 Meter: Stealth Mode
66 HP: Rotary Switch Function
67 HP: Monitor Modes
68 HP: Favorite Mode
69 HP: Playback Mode
70 HP: Warning Bell Level
71 HP: Rec/Stop Bell
72 Tone: Level
73 Tone: Frequency
74 Tone: Mode
62
v. 2.09 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
Setup Description
Selects among five different meter ballistics
settings
User-set level in dBFS where track peak
LED's illuminate. 0 LED doubles as track peak
indicator.
Enables LEDs to toggle on and off with the
LCD backlight key.
Selects the functionality of the Rotary Switch's
button when in record and playback.
Select the sequence of the modes that appear
in the Headphone Source Display on the LCD.
Selects the audio source monitored when the
Rotary Switch is pressed during recording or
playback.
Selects the audio source sent to headphones
upon playback.
Set the output level of the multi-function warn-
ing bell.
Alerts the user with one beep at the start of
recording and two beeps when the recording
is stopped
Set the output level of the reference tone
Allows the user to set the frequency of the
reference tone oscillator
Select the destination of the reference tone or
to disables it completely
Setup Options
• VU only • Peak+VU
• Peak only • Peak-hold + VU
• Peak-hold only
0 to −20 dBFS (1 dB increments)
• Off
• On
• Disabled:
push makes no change to the headphone matrix.
• Selects Favorite Mode:
in record and playback modes, push will change
the headphone source immediately to the favorite
selected in HP: Favorite Mode.
• Headphones to C/D Meters:
momentarily shows headphone level on tracks C & D
LED meters.
• Playback/Monitor Drive Select
Selects the media source for file playback and record
monitoring
Up to 20 source selections can be entered in any
order. See headphone monitor section in guide
for adjustment and Favorite Mode below for list of
headphone selections.
Inputs 1,2 Tracks A,B (MS)
Inputs 3,4 Tracks C,D (MS)
Tracks A,B Monitor A,B (MS)
Tracks C,D Monitor C,D (MS)
Monitor A,B Inputs 1+2+3+4
Monitor C,D Inputs 1, 2+3+4
Input 1,1 Inputs 1+2,1+2
Input 2,2 Inputs 1+3,1+3
Input 3,3 Inputs 2+4,2+4
Input 4,4 Inputs 3+4,3+4
Track A,A Inputs 1+2,3+4
Track B,B Inputs 1+3,2+4
Track C,C Tracks A+B+C+D
Track D,D Tracks A, B+C+D
Monitor A,A Tracks A+B,A+B
Monitor B,B Tracks A+C,A+C
Monitor C,C Tracks B+D,B+D
Monitor D,D Tracks C+D,C+D
Inputs 1,2 (MS) Tracks A+B,C+D
Inputs 3,4 (MS) Tracks A+C,B+D
In B-format stereo
Trk B-format stereo
• No change
• Same as options listed above
off, −60 to –12 dBFS in 1 dB steps
• Disabled
• Enabled
−40 to 0 dBFS in 1 dB steps
100–10,000 Hz in 100 Hz steps
• disabled
• to record tracks only
• to outputs only
• to record tracks and outputs
