PDi -P23LCDD Quick Start Manual

Communication
Systems Inc.
Better Solutions Are Within Reach™
WARNINGS
CAUTION:
To reduce the risk of electric shock do not remove
cover (or back). No user serviceable parts inside. Refer servicing to
qualified service personnel.
This symbol is intended to alert the user of the
presence of important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
This symbol is intended to alert the user of the
presence of uninsulated 'dangerous voltage' within
the product's enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
OVERHEAD FALLING HAZARD
TV can pose a striking hazard when mounted at an
elevated position. Use only PDI mounting
brackets, support arms, and appropriate hardware to
assure TV will not fall from the mounted position.
Failure to do so may cause injury or death.
RAIN AND MOISTURE
WARNING: To avoid the hazards of fire or electrical
shock, DO NOT expose this television to rain or
moisture.
OXYGEN ENVIRONMENT
WARNING: Do not use in any oxygen tent or
oxygen chamber. Such use may cause a fire hazard.
WET LOCATION
Apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such as
vases, shall be placed on the apparatus.
PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH +1-937-743-6010 FX +1-937-743-5664
PDI-P23LCDD Quick Start Guide
PRODUCT ACCESSORIES
(Not Included with TV)
Programming Remote
Patient Remote
100mm VESA Wall Mount
¼" to 6-Pin Jumper Cable
¼" to 6-Pin Jumper Cable
NOTE TO CABLE TV INSTALLER
This reminder is provided to call the cable TV systems installer's
attention to Article 820-40 of the National Electrical Code. The
code provides guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected to the grounding
system of the building, as close to the point of the cable entry as
practical.
FCC
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
residential or commercial installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
MAINTENANCE AND SERVICING
Never remove the back cover of the TV; this can expose you to
high voltage and other hazards. If the TV does not operate
properly, unplug it and call an authorized service center or PDI.
CLEANING AND DISINFECTION
Clean the exterior of this television by removing dust with a lint-
free cloth. CAUTION: To avoid damage to the surface of the
television, do not use abrasive or chemical cleaning agents. Spot
test a new disinfectant by applying a test cleaning a non-obvious
small spot on the TV's back cabinet, keypad, and LCD panel.
Allow the disinfectant to soak per its instructions and then wipe
clean. Do not use the disinfectant if the TV's surfaces show any
sign of discoloration or softening.
SERVICE INSTRUCTIONS
CAUTION: These servicing instructions are for use by qualified
service personnel only.
To reduce the risk of electric shock, do not perform any servicing
other than contained in the operating instructions unless you are
qualified to do so.
PRODUCT MODIFICATION
Do not attempt to modify this product in any way without written
authorization. Unauthorized modification could void the user's
authority to operate this product.
Document Number: PD196I152R1.DOC
Page 1 of 12
INSTALLATION INSTRUCTIONS
PD108-420
PD108-421
PD168-103
PD106-416
PD106-417
