PDi -P23LCDD Quick Start Manual

Communication
Systems Inc.
Better Solutions Are Within Reach™
WARNINGS
CAUTION :
To reduce the risk of electric shock do not
remove cover (or back). No user serviceable parts inside. Refer
servicing to qualified service personnel.
This symbol is intended to alert the user of the
presence of uninsulated 'dangerous voltage'
within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
This symbol is intended to alert the user of the
presence of important operating and maintenance
(servicing)
accompanying the appliance.
OVERHEAD FALLING HAZARD
WARNING: To prevent injury, this apparatus
must be securely attached to the wall in
accordance with the installation instructions. TVs
can pose a striking hazard when mounted at an
elevated position.
RAIN AND MOISTURE
WARNING: To avoid the hazards of fire or
electrical shock, DO NOT expose this television
to rain or moisture.
OXYGEN ENVIRONMENT
WARNING: Do not use in any oxygen tent or
oxygen chamber. Such use may cause a fire
hazard.
RAIN AND MOISTURE
WARNING: To avoid the hazards of fire or
electrical shock, DO NOT expose this television
to rain or moisture.
WET LOCATION
Apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such
as vases, shall be placed on the apparatus.
PRODUCT MODIFICATION
Do not attempt to modify this product in any way without written
authorization. Unauthorized modification could void the user's
authority to operate this product.
PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH +1-937-743-6010 PH +1-937-743-5664
PDI-P23LCDD Quick Start Guide
instructions in the literature
Document Number: PD196I148R1.DOC
INSTALLATION INSTRUCTIONS
PRODUCT ACCESSORIES
(Not Included with TV)
100mm VESA Wall Mount
Programming Remote
Patient Remote
¼" to 6-Pin Jumper Cable
¼" to ¼" Jumper Cable
NOTE TO CABLE TV INSTALLER
This reminder is provided to call the cable TV systems
installer's attention to Article 820-40 of the National Electrical
Code. The code provides guidelines for proper grounding
and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close
to the point of the cable entry as practical.
FCC Information
This device complies with Part 15 of the FCC Results.
Operation is subject to the following two conditions:
(1) This Device may not cause harmful interface, and
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
Notice : This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference
when the equipment is operated in a residential or
commercial installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one
of more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
Warning : Change or modifications not expressly approved
by the manufacturer could void the user's authority to operate
the equipment.
MAINTENANCE AND SERVICING
Never remove the back cover of the TV; this can expose you
to high voltage and other hazards. If the TV does not
operate properly, unplug it and call an authorized service
center or PDI.
CLEANING AND DISINFECTION
Clean the exterior of this television by removing dust with a
lint-free cloth. CAUTION: To avoid damage to the surface of
the television, do not use abrasive or chemical cleaning
agents.
DISCONNECTING DEVICE FROM MAINS
Main plug is the disconnecting device. The plug must
remain readily operable.
SERVICE INSTRUCTIONS
CAUTION: These servicing instructions are for use by
qualified service personnel only.
To reduce the risk of electric shock, do not perform any
servicing other than contained in the operating instructions
unless you are qualified to do so.
Page 1 of 8
