Ernitec SX Box Camera
User's Manual
Ver1.5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SX and is the answer not in the manual?

Questions and answers

Related Manuals for ERNITEC SX

Summary of Contents for ERNITEC SX

  • Page 1 Ernitec SX Box Camera User’s Manual Ver1.5...
  • Page 2 Ernitec SX Box cameraSeries User’s Manual Caution and Preventive Tips  Handle with care, do not drop the unit  Mount the unit in an equipment rack or place it on a solid, stable surface  Indoor use only. Do not place the unit in a humid, dusty, oily, or smoky site ...
  • Page 3 Ernitec SX Box Camera Series User’s Manual Important Information Before proceeding, please read and observe all instructions and warnings in this manual. Retain this manual with the original bill of sale for future reference and, if necessary, warranty service. When unpacking your unit, check for missing or damaged items. If any item is missing, or if damage is evident, DO NOT INSTALL OR OPERATE THIS PRODUCT.

  • Page 4: Table Of Contents

    Ernitec SX Box cameraSeries User’s Manual Table of Contents Overview ..........................4 Features ........................4 Package Contents ....................... 5 Dimensions ........................5 Connectors ........................6 Camera Cabling ........................7 Connect Power ......................7 Connect Ethernet Cable....................7 Lens Mounting ......................8 Connect Alarm I/O .......................

  • Page 5: Overview

    Ernitec SX Box Camera Series User’s Manual Overview Supported with both H.264 and MJPEG standard, the product series not only features in superior Full HD resolution for real-time streaming at 25/30 fps, but also supplies D1 Real-time streaming. With more computing power, the IP Camera could provide more flexibility for users and system managers.

  • Page 6: Package Contents

    Ernitec SX Box cameraSeries User’s Manual Package Contents Please check the package contains the following items listed below. Full HD Multiple Streams Back focus adjuster IP Camera (bundled software and Quick Guide documentation) Dimensions The IP Camera’s dimensions are shown below.

  • Page 7: Connectors

    Ernitec SX Box Camera Series User’s Manual Connectors The diagram below shows the IP Camera’s reset button and various connectors. Definition for each connector will be given as follows. DC 12V/ AC 24V/ PoE Network LEDs Network LEDs Reset Button...

  • Page 8: Camera Cabling

    Ernitec SX Box cameraSeries User’s Manual Camera Cabling Please follow the instructions below to complete IP Camera installation. Connect Power Please refer to Section: Connectors. Alternatively, connect the Ethernet cable to the camera’s PoE port and plug the other end of the cable into a PoE switch.

  • Page 9: Lens Mounting

    Ernitec SX Box Camera Series User’s Manual Lens Mounting If use C-Mount lens, after removing the camera’s plastic cover, users need to mount the C/CS mount adapter to the camera. Then attach the lens onto the C/CS mount adapter, as the illustrations shown below.

  • Page 10: System Requirements

    Ernitec SX Box cameraSeries User’s Manual System Requirements To perform the IP Camera via web browser, please ensure your PC is in good network connection, and meet system requirements as described below. Items System Requirement 1. Intel® Pentium® M, 2.16 GHz or Personal Computer Intel®...

  • Page 11: Access Camera

    Ernitec SX Box Camera Series User’s Manual Access Camera For initial access to the IP Camera, users can search the camera through the installer program: DeviceSearch.exe, which can be found in “DeviceSearch” folder in the supplied CD. Device Search Software Setup Step 1: Double click on the program Device Search.exe.
  • Page 12 Ernitec SX Box cameraSeries User’s Manual Additionally, users can change the IP Camera’s network property, either DHCP or Static IP, directly in the device finding list. Refer to the following section for changing the IP Camera’s network property. Example of Changing IP Camera’s Network Property Users can directly change an IP Camera’s network property, ex.
  • Page 13 Ernitec SX Box Camera Series User’s Manual The download procedure of DC Viewer software is specified as follows. Step 1: In the DC Viewer installation window, click on <Next> to start installation. Step 2: The status bar will show the installation progress. After the installation is completed, click on <Finish>...

  • Page 14: Setup Video Resolution

    Ernitec SX Box cameraSeries User’s Manual Setup Video Resolution Users can setup Video Resolution on Video Format page of the user-friendly browser-based configuration interface. Video Format can be found under this path: Streaming> Video Format. The default value of Video Resolution is as below: H.264- 1920 x 1080 (15 fps) + H.264- 1280 x 720 (30 fps)

  • Page 15: Configuration File Export/ Import

    Ernitec SX Box Camera Series User’s Manual Configuration File Export/ Import To export/ import configuration files, users can access the Maintenance page on the user-friendly browser-based configuration interface. The Maintenance setting can be found under this path: System> Maintenance. Users can export configuration files to a specified location and retrieve data by uploading an existing configuration file to the IP Camera.

  • Page 16: Appendix A: Technical Specifications

    Ernitec SX Box cameraSeries User’s Manual Appendix A: Technical Specifications Camera 2M Real time 1/2.7” Progressive CMOS Image Sensor Effective Pixels 1920(H) x 1080(V) 0.2 lux (Color) Minimum Illumination 0.02 lux (B/W) White Balance Manual / AWB/ ATW Shutter Speed 1~ 1/10000 sec.
  • Page 17 Ernitec SX Box Camera Series User’s Manual General Operating Temperature -10°C ~ 50°C (14°F ~ 122°F) Humidity 10% ~ 90%, No Condensation Dimension 125 x 82 x 52 mm (L x W x H) w/o Lens Weight 330 g (0.73 lb)
  • Page 18 Ernitec SX Box cameraSeries User’s Manual Camera Image Sensor 3M Sony Progressive CMOS 5M Progressive CMOS Effective Pixels 2048(H) x 1536(V) 2592(H) x 1944(V) 0.2 lux (Color) Minimum Illumination 0.02 lux (B/W) White Balance Manual / AWB/ ATW Shutter Speed 1~ 1/10000 sec.
  • Page 19 Ernitec SX Box Camera Series User’s Manual General Operating Temperature -10°C ~ 50°C (14°F ~ 122°F) Humidity 10% ~ 90%, No Condensation Dimension 125 x 82 x 52 mm (L x W x H) w/o Lens Weight 330 g (0.73 lb)

  • Page 20: Appendix B: Delete The Existing Dc Viewer

    Ernitec SX Box cameraSeries User’s Manual Appendix B: Delete the Existing DC Viewer For users who have installed the DC Viewer in the PC previously, please first delete the existing DC Viewer from the PC before accessing to this IP Camera.

  • Page 21: Appendix C: Setup Internet Security

    Ernitec SX Box Camera Series User’s Manual Appendix C: Setup Internet Security If ActiveX control installation is blocked, please either set Internet security level to default or change ActiveX controls and plug-ins settings. Internet Security Level: Default Step 1: Start the Internet Explorer (IE).

  • Page 22: Appendix D: Back Focus Adjustment

    Ernitec SX Box cameraSeries User’s Manual Appendix D: Back Focus Adjustment When to adjust back focus Back Focus refers to the distance from the rear lens element to the camera focal plane. In most cases, it is required to adjust back focus only when the camera’s lens cannot hold focus throughout its zoom range.

  • Page 23: Appendix D: Video Resolution

    Ernitec SX Box Camera Series User’s Manual Appendix D: Video Resolution 2M- Quad Streams H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 (15 fps) 352 x 240 (30 fps) 1280 x 1024 (15 fps)
  • Page 24 Ernitec SX Box cameraSeries User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 (30 fps) 1280 x 720 (15 fps) 640 x 480 (30 fps) 352 x 240 (30 fps)
  • Page 25 Ernitec SX Box Camera Series User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 (30 fps) 1280 x 720 (15 fps) 640 x 480 (30 fps) 1280 x 720 (30 fps)
  • Page 26 Ernitec SX Box cameraSeries User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 640 x 480 (30 fps) 352 x 240 (30 fps) 1024 x 768 (30 fps) 352 x 240 (30 fps)

  • Page 27: Triple Streams

    Ernitec SX Box Camera Series User’s Manual 2M- Triple Streams H.264-1 + H.264-2 + H.264-3 / MJPEG H.264-1 H.264-2 H.264-3 / MJPEG 800 x 600 (15 fps) 720 x 480 (15 fps) 1280 x 1024 (15 fps) 640 x 480 (15 fps)
  • Page 28 Ernitec SX Box cameraSeries User’s Manual H.264-1 + H.264-2 + H.264-3 / MJPEG H.264-1 H.264-2 H.264-3 / MJPEG 1280 x 720 (30 fps) 352 x 240 (30 fps) 1024 x 768 (30 fps) 352 x 240 (30 fps) 800 x 600 (30 fps)

  • Page 29: Dual Streams

    Ernitec SX Box Camera Series User’s Manual 2M- Dual Streams H.264-1 + H.264-2 / MJPEG H.264-1 H.264-2 / MJPEG BNC SUPPORT 1280 x 1024 (15 fps) 1280 x 720 (30 fps) 1024 x 768 (30 fps) 1920 x 1080 (15 fps) 800 x 600 (30 fps) √...

  • Page 30: Real Time / 3M / 5M- Quad Streams

    Ernitec SX Box cameraSeries User’s Manual 2M Real time / 3M / 5M- Quad Streams H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 (10 fps) 352 x 240 (10 fps)
  • Page 31 Ernitec SX Box Camera Series User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 (15 fps) 1280 x 720 (15 fps) 640 x 480 (15 fps) 352 x 240 (30 fps)
  • Page 32 Ernitec SX Box cameraSeries User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 (30 fps) 1280 x 720 (15 fps) 640 x 480 (30 fps) 1280 x 720 (30 fps)
  • Page 33 Ernitec SX Box Camera Series User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 800 x 600 (30 fps) 352 x 240 (30 fps) 720 x 480 (30 fps) 352 x 240 (30 fps)
  • Page 34 Ernitec SX Box cameraSeries User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 800 x 600 (30 fps) 352 x 240 (30 fps) 720 x 480 (30 fps) 720 x 480 (30 fps)

  • Page 35: Real Time / 3M / 5M- Triple Streams

    Ernitec SX Box Camera Series User’s Manual 2M Real time / 3M / 5M- Triple Streams H.264-1 + H.264-2 + H.264-3 / MJPEG H.264-1 H.264-2 H.264-3 / MJPEG 720 x 480 (10 fps) 720 x 480 (10 fps) 640 x 480 (10 fps)
  • Page 36 Ernitec SX Box cameraSeries User’s Manual H.264-1 + H.264-2 + H.264-3 / MJPEG H.264-1 H.264-2 H.264-3 / MJPEG 1280 x 720 (30 fps) 1280 x 1024 (15 fps) 800 x 600 (30 fps) 720 x 480 (30 fps) 1280 x 1024 (30 fps)
  • Page 37 Ernitec SX Box Camera Series User’s Manual H.264-1 + H.264-2 + H.264-3 / MJPEG H.264-1 H.264-2 H.264-3 / MJPEG 800 x 600 (30 fps) 720 x 480 (30 fps) 800 x 600 (30 fps) 640 x 480 (30 fps) 352 x 240 (30 fps)

  • Page 38: Real Time / 3M / 5M- Dual Streams

    Ernitec SX Box cameraSeries User’s Manual 2M Real time / 3M / 5M- Dual Streams H.264-1 + H.264-2 / MJPEG H.264-1 H.264-2 / MJPEG BNC SUPPORT 720 x 480 (10 fps) 2952 x 1944 (10 fps) 640 x 480 (10 fps) 352 x 240 (10 fps) *The resolution is for 5M Model only.

  • Page 39: Real Time / 3M / 5M- Single Stream

    Ernitec SX Box Camera Series User’s Manual 2M Real time / 3M / 5M- Single Stream H.264 Only BNC SUPPORT 2592 x 1944 (10 fps)* 2048 x 1536 (15 fps)** 1920 x 1080 (30 fps) Low Latency*** √ 1920 x 1080 (30 fps) √...
