ERNITEC Orion SX Series Installation Manual

Hide thumbs Also See for Orion SX Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Ernitec Orion SX Series
Installation Guide
Ver1.5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Orion SX Series and is the answer not in the manual?

Questions and answers

Related Manuals for ERNITEC Orion SX Series

Summary of Contents for ERNITEC Orion SX Series

  • Page 1 Ernitec Orion SX Series Installation Guide Ver1.5...
  • Page 2 Ernitec Orion SX Installation Guide Caution and Preventive Tips  Handle with care, do not drop the unit  Mount the unit in an equipment rack or place it on a solid, stable surface  Indoor use only. Do not place the unit in a humid, dusty, oily, or smoky site ...
  • Page 3 Ernitec Orion SX Installation Guide Important Information Before proceeding, please read and observe all instructions and warnings in this manual. Retain this manual with the original bill of sale for future reference and, if necessary, warranty service. When unpacking your unit, check for missing or damaged items. If any item is missing, or if damage is evident, DO NOT INSTALL OR OPERATE THIS PRODUCT.
  • Page 4 Ernitec Orion SX Installation Guide Regulation This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 5 Ernitec Orion SX Installation Guide Warnings and Cautions Handle the camera carefully  Do not abuse the camera. Avoid striking, shaking, etc. The camera could be damaged by improper handing or storage. Installing electricity wiring carefully  Ask qualified personnel of electrical wiring for the installation. Please note that input electricity to the unit is at tolerance of DC 12V/AC 24V ±...
  • Page 6 Ernitec Orion SX Installation Guide Never face the camera towards the sun  Do not aim the camera at bright objects. Whether the camera is in use or not, never aim it at the sun or other extremely bright objects. Otherwise, the camera may be smeared or damaged.

  • Page 7: Table Of Contents

    Ernitec Orion SX Installation Guide Table of Contents Introduction ........................... 7 Standard Package Contents ....................7 Camera Cable Connections ....................9 Switch/Connector Definition ..................9 Cable Requirements ....................10 3.2.1 Power Connection ..................10 3.2.2 Ethernet Cable Connection ................ 10 Dome Camera Installation ....................

  • Page 8: Introduction

    Ernitec Orion SX Installation Guide Introduction The Full HD Speed Dome IP Camera is designed to deliver superb performance and durability with an intelligent and stylish housing that is suitable in any security and surveillance installation. Standard Package Contents Before proceeding, please check the box contains the items listed here. If any item is missing or has defects, DO NOT install or operate the product and contact your dealer for assistance.
  • Page 9 Ernitec Orion SX Installation Guide Outdoor Model M3 Standard Screw (x1) M3 Security Screw (x1)* M5 Standard Screw (x1) M5 Security Screw (x1)* Camera Body with Outdoor Mount Kit Quick Guide CD: Operation Manuals Waterproof Rubber Optical Cover Lubricant Security Torx* *Optional: For Vandal Proof Cover only.

  • Page 10: Camera Cable Connections

    Ernitec Orion SX Installation Guide Camera Cable Connections Before installing or connecting the Dome Camera, please refer to this section and complete preparations for dome setups and various switch settings. There will be a PE cloth sheet covered inside the dome cover and a lens cap on the lens for shipping protection.

  • Page 11: Cable Requirements

    Ernitec Orion SX Installation Guide Cable Requirements For operation, the network Speed Dome IP Camera require power cable and RJ-45 as described below: 3.2.1 Power Connection Please refer to the illustrations below to connect power core through the supplied power adaptor.

  • Page 12: Dome Camera Installation

    Ernitec Orion SX Installation Guide Dome Camera Installation Basing on user’s installation environments, the Dome Camera can be installed on ceiling, on wall or on pole. In the following sections, various Dome Camera installation accessories, installation methods and installation procedures will be described in detail.

  • Page 13: Optional Accessories

    Ernitec Orion SX Installation Guide Optional Accessories Dome Camera Accessories Transparent/Vandal Proof Transparent Cover (Standard) Vandal Proof Cover (Optional) Power Adapter 77H07-A1015 (Input: 100~115VAC/Output: 24VAC 36VA) 77H07-A2015 (Input: 220~230VAC/Output: 24VAC 36VA) NOTE: When wiring, make sure the G/Y wire (Ground) inserted into the mid-pin of the terminal block.
  • Page 14 Ernitec Orion SX Installation Guide In-Ceiling (T-Bar) Mount For In-Ceiling Installation. Height: 166 mm (6.5 inches); Diameter: 276 mm (10.9 inches); Weight: 1.1 kg (2.4 lbs) Standard Pendent Mount White; 348×104×138.6 mm (13.7×4.1×5.5 inches); 1.5 kg (3.3 lbs); Diameter: 45 mm (1.8 inches). Supplied with M8x12 screw x1, spring washer-8 x1, pendent tube washer x1, rubber washer-8 x1 and sponge x2.
  • Page 15 Ernitec Orion SX Installation Guide Compact Pendent Mount 184×104×115.2 mm (7.24×4.09×4.54 inches); 0.6 kg (1.2 lbs). Supplied with rubber washer-8 x1, pendent tube washer x1, spring washer-8 x1 and M8x12 screw x1. Straight Tube Iron; Height: 250/500 mm (9.8/19.7 inches);...
  • Page 16 Ernitec Orion SX Installation Guide Swan Tube For mounting with Swan Tube.White; Iron, Dimension: 835 x 300 mm (32.9×11.8 inches); Diameter: 45 mm (1.8 inches); Weight: 3.8 kg (8.4 lbs); Supplied with pendent tube washer x1, rubber washer-8 x1, waterproof rubber x1, spring washer-8 x1 and M8x12 screw x1.
  • Page 17 Ernitec Orion SX Installation Guide Corner Standard Mounting Plate 222(L)×204(W)×117(D) mm (8.7×8×4.6 inches); 2 kg (4.4 lbs). Supplied with washer-8 x4, spring washer-8 x4, M8x16 screw x4, and M8 nut x4. Pole Thin Direct Mounting 232(L)×136(W)×60(D) mm (9.1×5.4×2.4 inches); Diameter: 112~130 mm (4.4~5 inches); 0.7 kg (1.6 lbs).
  • Page 18 Ernitec Orion SX Installation Guide Pole Wide Direct Mounting 270(L)×170(W)×60(D) mm (10.6×6.7×2.4 inches); Diameter: 112~140 mm (4.4~5.5 inches); 1 kg (2.2 lbs). Supplied with M8x16 screw x4, washer x4, stainless steel straps x4 and spring washer-8 x4. Corner Thin Box Mounting 300(L)×164(W)×222(D) mm (11.8×6.5×8.7 inches);...
  • Page 19 Ernitec Orion SX Installation Guide Corner Wide Box Mounting 232(L)×234(W)×210(D) mm (9.1×9.2×8.3 inches); 2.7 kg (6 lbs); Supplied with M8x16 screw x4, washer-8 x4, and spring washer-8 x4. Pole Thin Box Mounting 291(L)×136(W)×242 (D) mm (11.5×5.4×9.5 inches); 3.1 kg (6.9 lbs); Supplied with M8x16 screw x4, washer-8 x4, spring washer x4 and stainless steel straps x4.
  • Page 20 Ernitec Orion SX Installation Guide Pole Wide Box Mounting 270(L)×166(W)×155(D) mm (10.6×6.5×6.1 inches); 3.2 kg (7.1 lbs); Supplied with M8x16 screw x4, washer-8 x4, spring washer-8 x4 and stainless steel straps x4. Wall Box Mounting 270(L)×166(W)×95(D) (10.6×6.5×3.7 inches); 2.2 kg (4.84 lbs); Supplied with M8x16 screw x4, washer-8 x4 and spring washer-8 x4.
  • Page 21 Ernitec Orion SX Installation Guide Stainless Strap Cutter For tension, cut and crimp stainless steel straps. 1.4 kg (3.1 lbs). Suitable for straps width: 1/2”, 5/8”, 3/4” v.1.5.0912 www.ernitec.com...

  • Page 22: Ceiling Mount

    Ernitec Orion SX Installation Guide Ceiling Mount Generally, there are three kinds of Dome Camera ceiling mounting methods: hard-ceiling, in-ceiling and mounting with Straight Tube. Refer to the following sections for more details. The following figures show how cables connect to the Dome Camera in different ways.
  • Page 23 Ernitec Orion SX Installation Guide STEP 3 In the marked locations, drill each hole slightly smaller than the supplied Screw Anchors, and put supplied Anchors into these drilled holes. STEP 4 Fasten the Hard Ceiling Mount with the three supplied Self-tapping Screws.
  • Page 24 Ernitec Orion SX Installation Guide STEP 9 After installing the Camera on the Hard Ceiling Mount, put the Dome Cover back, and use a flat screw drive to fasten two supplied Flat Screws on the Dome Cover. STEP 10 Fasten the supplied Standard Screw (Security Screw for Vandal Proof Dome) on the Dome Cover.

  • Page 25: In-Ceiling (T-Bar) Mounting

    Ernitec Orion SX Installation Guide 4.3.2 In-Ceiling (T-Bar) Mounting Here lists the items and tools needed to mount the Dome Camera into the ceilings. The supplied items are all in the Dome Camera package. Package Contents: Lock Bar x1 ...
  • Page 26 Ernitec Orion SX Installation Guide STEP 2 Install the Fixing Plate on the bottom of Camera. STEP 3 Attach Hard Ceiling Mounting on the T-Bar Bottom Mount with three supplied screws. STEP 4 Install the Camera on the fixed Hard Ceiling Mount by turning the Camera clockwise.
  • Page 27 Ernitec Orion SX Installation Guide STEP 6 Place the Ceiling Sticker on the ceiling plate, and cut the circle part out of the ceiling. STEP 7 Put up the T-Bar Bracket into the ceiling opening and fix the In-Ceiling (T-Bar) Mount on the ceiling by tightening three screws clockwise.
  • Page 28 Ernitec Orion SX Installation Guide STEP 10 Put up the installed T-Bar Bottom Mount with Camera into the ceiling opening. STEP 11 Tighten the screws to fix T-Bar Bottom Mount on the T-Bar Bracket. STEP 12 Fix the Trim Ring to the T-Bar Bracket.

  • Page 29: Ceiling Mounting With Straight Tube

    Ernitec Orion SX Installation Guide 4.3.3 Ceiling Mounting with Straight Tube The Straight Tube is available in different length: 25 cm and 50 cm. Package Contents: M8x12 Screw x1  Spring Washer-8 x1  Pendent Tube Washer x1  Rubber Washer-8 x1 ...
  • Page 30 Ernitec Orion SX Installation Guide Mount the Dome Camera to the Mounting Kit. (Ensure Dome Camera fixed completely, and the thread holes on the Lock Screw Plate and Mounting Kit are aligned). Afterwards, screw the supplied M5 standard screw / security screw, as shown in the picture.

  • Page 31: Wall Mount

    Ernitec Orion SX Installation Guide Wall Mount The Dome Camera can be mounted on the wall with Compact Pendent Mount, Standard Pendent Mount and Wall Box. Please follow the installation instructions below for mounting the Dome Camera via different ways.
  • Page 32 Ernitec Orion SX Installation Guide Wall Mount: Swan Tube + Mounting Kit www.ernitec.com v.1.5.0912...

  • Page 33: Compact Pendent Mount

    Ernitec Orion SX Installation Guide 4.4.2 Compact Pendent Mount Package Contents: Rubber Washer-8 x1  Pendent Tube Washer x1  Spring Washer-8 x1  M8x12 Screw x1  Items Needed: Dome Camera  Power Cable  Ethernet Cable  Compact Pendent Mount and equipped items (optional accessory) ...
  • Page 34 Ernitec Orion SX Installation Guide 7) Run the cable(s) through the Compact Pendent Mount. NOTE: Please block the cable entry hole with the supplied sponge to avoid insects entering the Pendent Mount. The sponge can be placed in two ways as shown in the illustrations below.

  • Page 35: Standard Pendent Mount

    Ernitec Orion SX Installation Guide 4.4.3 Standard Pendent Mount Package Contents: M8x12 Screw x1  Spring Washer-8 x1  Pendent Tube Washer x1  Rubber Washer-8 x1  Sponge x2  Items Needed: Dome Camera  Power Cable  Ethernet Cable ...
  • Page 36 Ernitec Orion SX Installation Guide NOTE: Please block the cable entry hole with the supplied sponge to avoid insects entering the Pendent Mount. Refer to the illustrations in section 4.4.2 Compact Pendent Mount > Step 4. 5) Thread the cable(s) through the Mounting Kit and join the Mounting Kit to the Standard Pendent Mount with the supplied screws and washers.

  • Page 37: Wall Box Mounting

    Ernitec Orion SX Installation Guide 4.4.4 Wall Box Mounting Package Contents: M8x16 Screw x4  Washer-8 x4  Spring Washer-8 x4  Items Needed: Dome Camera  Power Cable  Ethernet Cable  Standard/ Compact Pendent Mount and equipped items (optional ...
  • Page 38 Ernitec Orion SX Installation Guide 5) Thread the cable(s) through the Mounting Kit and join the Mounting Kit to the Standard/ Compact Pendent Mount with the supplied screws and washers. Then adjust the Waterproof Rubber to the joint. 6) Connect the cable(s) to the Dome Camera.

  • Page 39: Corner Mount

    Ernitec Orion SX Installation Guide Corner Mount 4.5.1 Corner Standard Mounting Plate/Corner Plate Mini Package Contents: Washer-8 x4  Spring Washer-8 ×4  M8x16 Screw x4  M8 Nut x4  Items Needed: Dome Camera  Power Cable  Ethernet Cable ...
  • Page 40 Ernitec Orion SX Installation Guide NOTE: Please block the cable entry hole with the supplied sponge to avoid insects entering the Pendent Mount. Refer to the illustrations in section 4.4.2 Compact Pendent Mount > Step 4) Attach the Waterproof Rubber to the Standard/ Compact Pendent Mount.

  • Page 41: Corner Thin/Wide Box Mounting

    Ernitec Orion SX Installation Guide 4.5.2 Corner Thin/Wide Box Mounting Package Contents: M8x16 Screw x4  Washer-8 x4  Spring Washer-8 x4  Items Needed: Dome Camera  Power Cable  Ethernet Cable  Standard/ Compact Pendent Mount and equipped items (optional ...
  • Page 42 Ernitec Orion SX Installation Guide 4) Attach the Waterproof Rubber to the Standard/ Compact Pendent Mount. 5) Thread the cable(s) through the Mounting Kit and join the Mounting Kit to the Standard/ Compact Pendent Mount with the supplied screws and washers.

  • Page 43: Pole Mount

    Ernitec Orion SX Installation Guide Pole Mount 4.6.1 Pole Thin/Wide Direct Mounting Package Contents: Stainless Steel Straps x4  M8x16 Screw x4  Washer x4  Spring Washer-8 x4  Items Needed: Dome Camera  Power Cable  Ethernet Cabl ...
  • Page 44 Ernitec Orion SX Installation Guide NOTE: Please block the cable entry hole with the supplied sponge to avoid insects entering the Pendent Mount. Refer to the illustrations in section 4.4.2 Compact Pendent Mount > Step 4) Attach the Waterproof Rubber to the Standard/ Compact Pendent Mount.

  • Page 45: Pole Thin/Wide Box Mounting

    Ernitec Orion SX Installation Guide 4.6.2 Pole Thin/Wide Box Mounting Package Contents: M8x16 Screw x4  Washer-8 x4  Spring Washer x4,  Stainless Steel Straps x4  Items Needed: Dome Camera  Power Cable  Ethernet Cable  Standard/ Compact Pendent Mount and equipped items (optional ...
  • Page 46 Ernitec Orion SX Installation Guide 4) Attach the Waterproof Rubber to the Standard/ Compact Pendent Mount. 5) Thread the cable(s) through the Mounting Kit and join the Mounting Kit to the Standard/ Compact Pendent Mount with the supplied screws and washers.

  • Page 47: Appendix A: Technical Specification

    Ernitec Orion SX Installation Guide Appendix A: Technical Specification Items Orion SX 802-18x Orion SX 802-20x CAMERA Sensor 1/2.8” Sony Progressive Scan CMOS Sensor Optical Zoom Digital Zoom 1~8x variable Focal Length 4.7~84.6 mm 4.7~94 mm Focus Mode Auto / Manual...
  • Page 48 Ernitec Orion SX Installation Guide Items Orion SX 802-18x Orion SX 802-20x Video Compression H.264 Main Profile/ MJPEG Video Streaming Multiple Streams, H.264 + MJPEG/ H.264 + H.264 Video Resolution 1080P/ 720P/ VGA/ D1 Frame Rate 30/25 fps @ 1080P...
