Page 1: Service Manual
Service Manual Phaser 300i and Phaser 300RX ™ ™ Color Printer Warning The following servicing instructions are for use by qualified service personnel only. To avoid personal injury, do not perform any servicing other than that contained in operating instructions unless you are qualified to do so.
Page 2 Tektronix, Inc., Wilsonville, Oregon. Printed in the United States of America. All rights reserved. Contents of this publication may not be reproduced in any form without permission of Tektronix, Inc. This instrument, in whole or in part, may be protected by one or more U.S. or foreign patents or patent applications.
Page 3: Users Safety Summary
Users safety summary Terms in manual: CAUTION Conditions that can result in damage to the product. WARNING Conditions that can result in personal injury or loss of life. Power source: Does not apply more than 250 volts RMS between the supply conductors or between either supply conductor and ground.
Page 4 Service safety summary For qualiﬁed service personnel only: Refer also to the preceding Users Safety Summary. Do not service alone: Do not perform internal service or adjustment of this product unless another person capable of rendering ﬁrst aid or resuscitation is present. Use care when servicing with power on: Dangerous voltages may exist at several points in this product.
Page 5: Table Of Contents
Networked connection to a PC using the Ethernet port 2-11 Connecting the printer to a workstation 2-12 Direct connection to the workstation 2-12 Networked connection to a workstation 2-12 Installing a SCSI hard disk drive on a Phaser 300i (optional) 2-13 Service Manual...
Page 6 Driver and communication set up 2-21 Loading the Macintosh driver 2-21 Installing the Tektronix driver for Windows 3.1 2-22 If you have other Tektronix printer drivers already installed 2-22 Configuring the Tektronix Windows printer driver 2-23 Updating the standard Microsoft Windows PostScript driver 2-25...
Page 7 Key Operator Training Overview 4-1 Printer controls and indicators 4-2 Loading media 4-6 Clearing paper jams 4-8 Cleaning 4-8 Warranty information 4-10 Service support 4-10 Supplies ordering 4-11 If you need help 4-11 HAL information system 4-11 Customer Support Hotline 4-12 Service support 4-12 Electronic bulletin board 4-12 Theory of Operation...
Page 8 Troubleshooting System power-up sequence 6-1 Print engine troubleshooting 6-2 Verifying image processor operation by using the Test Pattern Generator 6-2 Verifying print engine operation by using its self-test print 6-3 Verifying power supply operation 6-4 Measuring power supply voltages 6-5 Inspecting the power supply fuses 6-6 Testing for a shorted motor 6-6 +40 and HV safety interlocks 6-7...
Page 9 Image processor hard and soft error indicators 6-43 Verifying the image processor's operation 6-43 Image processor self-diagnostics 6-44 Phaser 300i image processor rear panel switches for self-testing 6-44 Printing the configuration page 6-46 Printing the demo page 6-46 Rear panel switches (diagnostics) 6-47...
Page 10 Cleaning and Maintenance Service preventive maintenance procedure 7-1 Cleaning and inspecting 7-2 Paper-pick roller cleaning 7-2 Cleaning the feed rollers 7-4 Feed roller cleaning 7-4 Other cleaning 7-7 Cleaning the paper tension blade 7-7 Cleaning the paper clamp 7-9 Cleaning the drum 7-10 Cleaning the wiper blade 7-12 Cleaning the fuser rollers 7-14 Replacing the fuser wiper 7-15...
Page 11 Motors 8-28 X-axis motor, idler and cable 8-28 Rewinding the X-axis cable 8-29 Checking the X-axis cable tension 8-29 Y-axis motor 8-32 Looping the Y-axis drive belt 8-33 Adjusting the Y-axis belt tension 8-34 Paper-feed motor and belt 8-36 Tensioning the paper-feed drive belt 8-37 Exit motor and chain 8-38 Paper-clamp motor removal 8-39 Paper-clamp motor installation 8-40...
Page 12 Checks and Adjustments Required tools 9-1 Placing the printer in Utility or Service mode 9-2 XY Calibration 9-6 Printhead maintenance and test printing 9-7 Checking and adjusting the printhead 9-9 Printhead drive voltage adjustment 9-9 Printhead-to-media spacing (tailpiece adjustment) 9-11 Tilt adjustment 9-14 Voltage, convergence and temperature adjustment for a new printhead 9-17 Setting enhanced printing convergence 9-21...
Page 13 The Phaser 300 and its packaging 2-6 Figure 2-2 Removing the shipping block 2-7 Figure 2-3 Connecting a SCSI hard disk drive to the Phaser 300i 2-13 Figure 5-1 Block diagram of the printer 5-2 Figure 5-2 The printhead and its jet nozzles 5-4...
Page 14 Figure 7-4 Cleaning the lower feed roller 7-6 Figure 7-5 Cleaning the paper tension blade 7-8 Figure 7-6 Cleaning the paper clamp 7-9 Figure 7-7 Cleaning the drum with a wipe 7-10 Figure 7-8 Cleaning the drum with the cleaning tool 7-11 Figure 7-9 Cleaning the wiper blade 7-13 Figure 8-1...
Page 15 Figure 8-30 Removing the paper-tension blade 8-43 Figure 8-31 Removing the paper-tension blade 8-44 Figure 8-32 Removing the drip plate 8-46 Figure 8-33 Preparing to remove the drum 8-48 Figure 8-34 Removing the drum 8-49 Figure 8-35 Aligning the dot clock encoder strip 8-52 Figure 8-36 Removing the engine control board 8-53 Figure 8-37...
Page 16 Functional specifications 1-13 Table 1-5 Electrical specifications 1-14 Table 1-6 Environmental specifications 1-15 Table 2-1. Configuration page settings for the Phaser 300i 2-15 Table 2-2. Values for modifying the DEVPARAMS.PS file 2-30 Table 6-1 Motor and solenoid resistances 6-9 Table 6-2...
Page 17: General Information
Chapter General Information This ﬁeld service manual contains information useful for troubleshooting, repairing, adjusting, and maintaining the Tektronix Phaser™ 300i Color Printer. This manual includes troubleshooting guides, adjustment procedures, a ﬁeld replaceable units (FRU) list and assembly/disassembly procedures for selected FRUs.
Page 18: The Phaser 300I Color Printer
The Phaser 300i Color Printer combines Tektronix' phase-change ink-jet printing technology with Adobe’s PostScript Level 2 page description language. The Phaser 300i features RS-232 serial, standard parallel and AppleTalk interfaces for host communication. An Ethernet adapter is optionally available. It allows the printer to communicate using the EtherTalk and Novell protocols.
Page 19: The Phaser 300Rx Color Printer
The Phaser 300i can print on a variety of media weights and ﬁnishes ranging from Vellum to Bristol and on sizes ranging from 4 x 6 ins.
Page 20: Print Engine Assemblies
Front panel Ink loader Precision frame Power supply Paper-clamp Paper-path motor frame Fuser Waste bin Engine control board Maintenance system filter Exit motor Air pump 8818-20 Figure 1-2 Print engine major components Phaser 300i and 300RX Color Printer...
Page 21: Figure 1-3 Print Engine Components (Continued)
General Information Front panel Drum Pivoting Paper-tension paper guide blade Ink load lever Paper-feed rollers Paper path frame Power supply Ink load lever Maintenance station Y-axis idler Drip plate X-axis idler Paper tension motor Printhead Line voltage selector Umbilical cable Carriage Y-axis motor board...
Page 22: Figure 1-4 Print Engine Sensor, Switch And Solenoid Locations
(width) sensor 1– Paper x-sensor 1 edge (width) sensor 1– x-sensor 2 Rear access cover interlock switch Dot clock encoder sensor 8818-02 Figure 1-4 Print engine sensor, switch and solenoid locations Phaser 300i and 300RX Color Printer...
Page 23: Figure 1-5 Print Engine Sensor, Switches And Solenoid Locations (Continued)
General Information Manual-feed sensor Top access cover- Paper-out sensors open sensor Tray width sensor Tray length sensor Paper-exit sensor (under printer) Waste bin sensor 8818-27 Figure 1-5 Print engine sensor, switches and solenoid locations (continued) Service Manual...
Page 24: Rear Panel
You can also use the DIP switches to control the self-tests of the printer’s image processor board. The topic “Phaser 300i rear panel DIP switches” on page 1-10 explains the setting of the rear panel switches for normal printer operation.
Page 25: Phaser 300Rx
(RS-232) Status LED Setup DIP switches 8818-75 Figure 1-6 The Phaser 300i rear panels Phaser 300RX The Phaser 300RX rear panel only features a single host interface connector. Modified Tektronix parallel interface Parallel Figure 1-7 The Phaser 300RX rear panel...
Page 26: Phaser 300I Rear Panel Dip Switches
General Information Phaser 300i rear panel DIP switches The 300i's rear panel DIP switches control the functions of the printer. Combine the switch settings listed in the table below to customize the printer to users' normal operating needs. Table 1-1 Normal operation — 300i rear panel DIP switches Switch Position ↑...
Page 27: Front Panel
General Information Front panel These front panel features are found on the printer: Three push-button switches: UTILITIES, CLEAN PRINT HEAD and TEST PRINT A POWER LED A printer ERROR LED A two-line, 24 character LCD. The LCD displays status messages and menus.
Page 28 TEST PRINT While the printer is idle, pressing this button makes the printer print a seven-color test pattern. This basic test pattern helps identify malfunctioning jets and veriﬁes the printer's color printing capability as well as the paper path and fuser. 1-12 Phaser 300i and 300RX Color Printer...
Page 29: Specifications
General Information Speciﬁcations Table 1-2 Physical dimensions Dimensions Speciﬁcation Height: 13.5 in. (29.8 cm) Width: 25.5 in. (56.2 cm) Depth: 22 in. (48.5 cm), without tray installed 27 in (59.5 cm), with A-size paper tray installed Weight: Approximately 101 lbs. (45 kgs) Shipping weight is less than 150 lbs.
Page 30 -78V (±2%, adjustable from -68 to -102 V) RF emissions Both 115 and 220 VAC-conﬁgured instruments pass these standards: FCC Part 15 Class B VDE Class B EN55022 (CISPR 22) Class B VCCI (CISPR 22) Class B 1-14 Phaser 300i and 300RX Color Printer...
Page 31: Table 1-6 Environmental Specifications
General Information Table 1-6 Environmental speciﬁcations Characteristic Speciﬁcation Temperature Operating to 32 C (50 to 90 Non-operating to 60 C (-22 to 140 Media should be acclimated 24 hours before using in the printer. Humidity Operating 20 to 80% relative humidity, non-condensing Non-operating 10 to 95% relative humidity, non-condensing Media should be acclimated 24 hours before using in the...
Page 32: Regulatory Specifications
Interface Suppression of High Frequency Apparatus and Installations. VDE 0875, Regulation for RFI Suppression of Electrical Equipment and Installations FCC Class B (for 115 VAC equipment) pursuant to Sub-part J of Part 15. 1-16 Phaser 300i and 300RX Color Printer...
Page 33: Installing The Printer And Drivers
Installing the Printer and Drivers This chapter discusses installing the Phaser 300i printer and its drivers as a part of the S0 installation option. Tektronix Service Option S0 consists of three main functions detailed in this and the next two chapters of this manual: Chapter 2 “Installing the Printer and Drivers”...
Page 34: Pre-Install Questions For Customers
Installing the Printer and Drivers Pre-install questions for customers Prior to installing the printer, you should contact the customer and verify that he or she has prepared an appropriate location for the printer. You will also want to ensure that you have all the information you need to install the printer at the customer's site.
Page 35 _______ Swiss Option A5 (161-0154-00) Customers must provide the particular interface cable or network adapter they need to use with the printer. Customers can purchase the following from the Tektronix Graphics Supplies Order Desk by calling 1-800-835-6100. Parallel cable, IEEE-1284C to DB-25...
Page 36 750 kbyte hard disk space for ﬁles Based on the results of the pre-install interview with the customer, you may wish to access the Tektronix Highly Automated Library (HAL) at 1 800 835-6100 for articles that may help with installing the printer into a customer's network.
Page 37: Unpacking
Phaser 300 media sampler Ink sticks (ColorStix) A box of extra ink color sticks (optional item) Phaser 300i Printer Driver diskettes Phaser 300i Printer Driver Reference Manual Network Utilities manual (optional) Parallel cable adapter, IEEE 1284C to DB25) Note Interface cables must be ordered separately.
Page 38: Figure 2-1 The Phaser 300 And Its Packaging
Installing the Printer and Drivers Getting Started Vorbereitungen Börja Här Primi Passi Cómo Comenzar Mise en Route 8818-31 Figure 2-1 The Phaser 300 and its packaging Phaser 440 Color Printer...
Page 39: Setting Up The Printer
Installing the Printer and Drivers Setting up the printer Removing the shipping block The printer's printhead shipping block must be removed before turning the printer on. Do not throw the shipping block away; it must be installed before the printer can be shipped to a new location or back to the factory. To remove the shipping block: Open the top cover.
Page 40: Installing Simm Memory
Detailed instructions on moving the printer are in the user manual. Installing SIMM memory The standard conﬁguration for a Phaser 300i includes 10 Mbytes of memory. Three optional SIMMs can be added for a total of 22 Mbytes of memory. The additional memory allows the printer to process and print Tabloid-size images on Tabloid-Extra media.
Page 41: Setting Rear Panel Switches
Up: Vivid Blue will change the way blue is printed: it will look blue instead of purple. This feature can also be selected at the Tektronix driver. If color correction is sent with the print job, this setting will be ignored.
Page 42: Cabling The Printer
Installing the Printer and Drivers Cabling the printer Note Carry spare serial and parallel cables. You can use them if you encounter a defective cable or as an alternate means of testing the printer-to-host communications. This topic explains making a hardware connection between the printer and its host computer, setting the communication parameters for the printer's serial and parallel ports to be compatible with the user's host computer and driver installation.
Page 43: Connecting The Printer To A Pc
Installing the Printer and Drivers Turn on the printer. During the printer's boot-up process, the printer's network name is displayed in the Mac's Chooser and its node address is resolved with the network. If the network features multiple zones, the network router assigns the printer a default zone name. The printer’s conﬁguration page lists the name.
Page 44: Connecting The Printer To A Workstation
Installing the Printer and Drivers Connecting the printer to a workstation Direct connection to the workstation Turn off the printer. Turn off the host computer. Attach the parallel interface cable to the workstation. Attach the other end to the printer. Alternatively, attach the serial cable to the workstation's serial port.
Page 45: Installing A Scsi Hard Disk Drive On A Phaser 300I (Optional)
Parallel SCSI Disk 8818-33 Figure 2-3 Connecting a SCSI hard disk drive to the Phaser 300i Select the desired SCSI address (0 through 6) on the SCSI drive. The printer’s SCSI address is 7. Turn on the disk drive ﬁrst, and then turn on the printer.
Page 46: Turning On The Printer
Turning on the printer The startup page When you turn on the Phaser 300i printer, it executes a series of self-tests to determine if there are any problems with the PostScript interface. After running self-tests, the printer prints a startup page if it has not been disabled. After running self-tests and printing the startup page, the printer is ready for operation.
Page 47 Installing the Printer and Drivers The conﬁguration page To provide further diagnostic information, the Phaser 300i printer is able to print a conﬁguration page. The conﬁguration page lists the values the printer stores in its NVRAM. These values can be very informative when troubleshooting the printer, particular in regards to networked operations.
Page 48 Installing the Printer and Drivers Table 2-1. Conﬁguration page settings for the Phaser 300i (cont'd.) Parameter Description Saved Default Limits or alternate choices NVRA Authorization A unique number downloaded to the <not authorized> Valid code number in the code printer (in the ﬁeld or at the factory) to...
Page 49 Installing the Printer and Drivers Table 2-1. Conﬁguration page settings for the Phaser 300i (cont'd.) Parameter Description Saved Default Limits or alternate choices NVRA Serial Port Indicates the type of interpreters in use PostScript Level 2 Not installed, Disabled, interpreter at the port <interpreter>...
Page 50 Installing the Printer and Drivers Table 2-1. Conﬁguration page settings for the Phaser 300i (cont'd.) Parameter Description Saved Default Limits or alternate choices NVRA TCP/IP port Indicates the type of interpreter in use at Not authorized, Disabled interpreter the port RARP/BOOTP Used for setting the printer’s IP address...
Page 51 Installing the Printer and Drivers Table 2-1. Conﬁguration page settings for the Phaser 300i (cont'd.) Parameter Description Saved Default Limits or alternate choices NVRA AppSocket Host List of TCP/IP network addresses for Unrestricted, only ﬁrst 16 on access lis host to access to printer...
Page 52 Installing the Printer and Drivers Table 2-1. Conﬁguration page settings for the Phaser 300i (cont'd.) Parameter Description Saved Default Limits or alternate choices NVRA Online, total space, free space SCSI Disk Indicates if a SCSI disk is attached to the Not connected printer.
Page 53: Driver And Communication Set Up
Driver and communication set up Loading the Macintosh driver The Phaser 300i printer uses the Adobe PostScript Level 2 language. To take advantage of the Level 2 features, Tektronix developed the Tektronix Phaser 300i driver which appears in the Chooser along with the LaserWriter 7.0.x or 8.0x driver.
Page 54: Installing The Tektronix Driver For Windows 3.1
2-23. If you have other Tektronix printer drivers already installed If you still have an earlier version of the Tektronix Windows driver, you can use the INSTALL.EXE program on that diskette to remove the older driver software.
Page 55: Configuring The Tektronix Windows Printer Driver
Drivers and Utilities Printing Reference to delete the ﬁles. When you are ﬁnished removing the old driver ﬁles, restart Windows. Go on to the topic “Installing the Tektronix driver” in this chapter, to install all of your Tektronix printers with the latest driver software.
Page 56 Installing the Printer and Drivers For a network port set up in Windows: Select your network (LPT or COM) port in the list. Choose the Network button to see the Printers-Network Connections dialog box. Fill in each item according to your conﬁguration, then choose the OK button. Refer to your Windows documentation for details, or ask your network administrator for help.
Page 57: Updating The Standard Microsoft Windows Postscript Driver
This option is only available to applications that use this Tektronix driver with Tektronix PostScript Level 2 printers, such as the Phaser 300i. When this box is checked, the Compress Bitmaps option is unavailable (grayed out).
Page 58 Installing the Printer and Drivers When prompted, insert the Tektronix–provided Windows 3.1 Printer Driver diskette into your computer’s disk drive. Choose your printer (without (TekColor) after the name) then click the OK button. When asked to insert a disk with the updated PSCRIPT.DRV ﬁle, enter system as the location so the current PSCRIPT.DRV ﬁle is used.
Page 59: Installing The Printer Driver For Os/2 Version 2
LPT2PRIN. Scroll through the printer drivers listed to locate the proper Tektronix printer driver name. If it is listed, select it, otherwise, point the cursor to any other driver listed and click the right mouse button. Click Install from the menu options.
Page 60 Select Options and make sure that it is properly set to Phaser 300i. If not, repeat the previous steps. While in this screen, set Job and Wait to 0, if they aren't already. Select the Output Tab. Ensure that the proper port is selected.
Page 61: Configuring The Printer's Serial Port For A Pc
Installing the Printer and Drivers Conﬁguring the printer's serial port for a PC Use the PostScript command ﬁle DEVPARAM.PS (located on the Printers Utilities diskette) to modify the printer’s serial port settings. The following example sets ﬂow control to Xon/Xoff, parity to none, data bits to 8, stop bits to 2 and the baud rate to 9600.
Page 62 Installing the Printer and Drivers Use a text editor or word processor to modify the DEVPARAMS.PS ﬁle. (Be sure to save the ﬁle as a text-only ﬁle.) Substitute the values you want for the values used in the sample DEVPARAM.PS. The possible values for each parameter are listed in the following table.
Page 63: Using Printcap To Configure A Workstation For The Printer's Serial Port
Installing the Printer and Drivers Using printcap to conﬁgure a workstation for the printer's serial port The printcap ﬁle conﬁgures the workstation's lpr queues. The ﬁle is usually found in the workstation's /etc. directory. The printer's rear panel switch settings should all be down.
Page 64: Configuring A Novell Netware Server For The Printer
Installing the Printer and Drivers If communication to the serial port uses 7 data bits, the value for xs changes as follows. All other set up parameters remain the same. px:\ :br#9600:rw:\ :fc#00000374:fs#00000003:\ :xc#0:xs#0040040:\ :mx#0:sf:sh:\ :sd=/var/spool/px:\ :if=/var/spool/px/if:\ :lp=/dev/ttya: To print a PostScript ﬁle, type: lpr -Ppx ﬁlename Conﬁguring a Novell NetWare server for the printer This is a brief overview of the steps you follow to conﬁgure a Novell NetWare...
Page 65: Configuring Tcp/Ip On A Unix Host
Installing the Printer and Drivers Alternately, you can use a utility called PCONSOLE to perform the same conﬁguration. However, using PCONSOLE, you will not “see” and select the printer on the network as you did in Step 4. Instead, you must enter the print server name (TEKxxxxxx) of the printer as it is shown on the printer’s conﬁguration page.
Page 67: Verifying The Printer And Host Connections
Verifying the Printer and Host Connections In this chapter, you verify that the host computer can print to the Phaser 300i printer. This chapter assumes that the printer and the printer drivers have been properly installed as explained in the previous chapter “Installing the Printer and Drivers.”...
Page 68: Printing The Directory From A Macintosh
Close the Chooser by clicking on the small box in the upper-left corner of the dialog box. The Phaser 300i is now your chosen printer. You have now veriﬁed that the printer is on the network and is communicating with the Macintosh.
Page 69: Verifying That An Application Communicates To The Printer
Contact the Customer Support Hotline 1-800-835-6100. Using the Error Handler utility If the Macintosh does not print to the Phaser 300i printer, download the Tektronix Error Handler. Place the printer's Macintosh Printer Utilities diskette in the disk drive.
Page 70: Pc Verification
Type in a line of text such as THIS IS A TEST . Click the File menu item and select Printer Setup... from the menu list. Select Phaser 300i from the displayed list of available printer drivers. Click OK .
Page 71: Os/2 Connection Verification
Verifying the Printer and Host Connections OS/2 connection veriﬁcation The Print Screen function is controlled from within the OS/2 System folder. Open the System folder, then open the System object. Click on the Print Screen Tab to view the Print Screen settings. Be sure that Enable has been selected.
Page 72: Novell Netware Verification
ﬁles created and sent for printing from other workstations on the network. The Phaser 300i, in turn, ﬁnds all ﬁle servers with Phaser 300i queues and extracts the print ﬁles from them. You must determine if a station can send a print ﬁle to the ﬁle server.
Page 73: Using The Error Handler Utility
Verifying the Printer and Host Connections Using the Error Handler utility If a PC has trouble printing directly to the Phaser 300i, download the Tek Error Handler utility ﬁle to the printer. The Tek Error Handler (TEKEHAND.PS) is for PostScript Level 1 and Level 2 printers.
Page 74: Workstation Verification
The Phaser 300i accepts ﬁles from networked UNIX and VMS workstations using TCP/IP communications. The printer supports BSD UNIX 4.3, AT&T's UNIX System V with BSD 4.3 lpr extensions, and DEC VMS with Tektronix PhaserSym software. The Phaser 300i conforms to Ethernet IEEE 802.3 network speciﬁcations.
Page 75: Using The Error Handler Utility
Verifying the Printer and Host Connections To print the Phaser 300i in the VMS environment, you must have the PhaserSym symbiont running on the host. To print to the printer from the host, you must ﬁrst have the printer’s queue established. This is site-dependent and requires the aid of the site’s network administrator.
Page 77: Key Operator Training
Chapter Key Operator Training This chapter covers the last portion of the Tektronix Service Option S0 installation: training the printer's key operator. The steps you follow here place an emphasis on encouraging the key operator to read and use the printer's customer manual and to clean and care for the printer.
Page 78: Printer Controls And Indicators
Furthermore, the printer will prevent unnecessary ink sticks from being loaded: it will prompt you to remove the ink stick. Phaser 300i and 300RX Color Printer...
Page 79 Key Operator Training Loading ink Open the ink cover. Insert an ink stick. Close the ink cover. Gently pull down on the ink load lever and release it. The ink cover must be closed for the ink load lever to release the ink stick into the melting chamber.
Page 80 Wipe and air knife . The ﬁrst time you press the CLEAN PRINT HEAD the printer performs a wipe operation to remove any paper ﬁber or other debris on the face of the printhead. Phaser 300i and 300RX Color Printer...
Page 81 Key Operator Training Purge. The second time you press the CLEAN PRINT HEAD the printer performs a four second purge operation. A purge operation will use the printer's maintenance station to draw ink through each nozzle which will clear any debris lodged in the nozzle. If you press the CLEAN PRINT HEAD button a third time, a longer 5 second purge cycle is performed.
Page 82: Loading Media
Tektronix logo) up. When using the tray, load the transparencies so the side with the stripe (showing the Tektronix logo) enters the printer ﬁrst. When using manual feed, insert the side with the white stripe (Tektronix logo) into the printer ﬁrst.
Page 83 Key Operator Training Phaser 300 transparencies can be enhanced for projection using the Tektronix Media Laminator. Use manual feed for thick paper (4 x 6 to 12 x 18 inches) such as: Cover Stock Envelopes (larger than 4 x 6 ins.) Grade, weight, and thickness: Bond: 13 to 40 lbs., about 0.003 to 0.01 ins.
Page 84: Clearing Paper Jams
The customer will need to purchase isopropyl alcohol (95%) at their local pharmacy in order to use the cleaning kit supplied with the printer. Phaser 300i and 300RX Color Printer...
Page 85 Key Operator Training Kit shipped with the printer: Cleaning instructions Cleaning tool Lint free wipes Foam swabs Bottle for isopropyl alcohol Replacement Kit (016-1144-00): Cleaning Instructions Cleaning tool Lint free wipes Foam swabs Fuser cleaning pad Fuser wiper Follow the instructions in the cleaning kit to clean the printer. Service Manual...
Page 86: Warranty Information
The customer ﬁlls out the agreement and attaches a copy of the invoice or shipping memo for the printer and sends the agreement to Tektronix within 90 days of printer shipment. This starts the service agreement, its duration dating from the printer ship date.
Page 87: Supplies Ordering
Graphics Supplies Order Desk) to place a supplies order. Open Monday through Friday, 6:00 am to 5:00 pm (PST). Shipments are made within 24 hours. Outside the United States: Contact your nearest Tektronix dealer. If you need help HAL information system As an alternative to using the Customer Support Hotline, customers can call the Highly Automated Library (HAL).
Page 88: Customer Support Hotline
Tektronix supports an electronic bulletin board that customers with a modem can connect to download the latest versions of Tektronix drivers and software. To connect to the BBS, phone (503) 685-4504 and use 9600 baud, 8 bits, 1 stop bit, and no parity.
Page 89: Theory Of Operation
Chapter Theory of Operation Overview This section covers the theory of operation of each subsystem within the printer: Functional block diagram The printhead and printing Fusing The maintenance station The paper path Service Manual...
Page 90: Functional Block Diagram
The printhead is the heart of the printer. It is the device that actually places ink onto paper. The printhead contains the reservoirs for the ink it uses as well as a series of piezo-electric devices that squirt ink onto the paper. Phaser 300i and 300RX Color Printer...
Page 91 Theory of Operation The power supply The power supply provides the DC power source for the printers electronics and motors. It also provides the power for the printhead's heaters and piezo-electric crystals. The mechanicals The mechanicals include the x- and y-axis motors, the fuser, the paper clamp and paper tension blade motors, the paper feed motor and the ink-load solenoid.
Page 92: The Printhead And Printing
Head width = 994 pixels Cyan jet #0 Black jet #31 Close up view of adjacent jets 2 pixels between adjacent jets vertically 7 pixels between adjacent jets horizontally 8818-35 Figure 5-2 The printhead and its jet nozzles Phaser 300i and 300RX Color Printer...
Page 93: Figure 5-3 The Printhead's Jet Stack
Theory of Operation The core of the Phaser 300 printhead is the “jet stack” — a bonded pack of 14 etched stainless steel plates The active element in the jet stack is the piezo-electric crystal array that, when energized, ﬂexes to force a drop of ink out of a jet.
Page 94: Phaser 300 Ink
It provides a high quality image for most applications. When printing solid ﬁlls, the printhead ejects ink at a 4.25 kHz rate. An image on letter-size paper will take about 2 minutes to print. Phaser 300i and 300RX Color Printer...
Page 95: Premium Mode
Theory of Operation During Enhanced mode printing, the paper is advanced vertically the equivalent of 15 pixels between horizontal passes of the printhead across the paper (every fourth pass is advanced 17 pixels). This minimizes the “banding” that may otherwise appear during Standard mode printing. If there are any blank (white space) raster lines, the drum advances over the white space to the next printable raster line or to the end-of-page.
Page 96: Fusing
ﬂat spot in the poly-coated roller. If this occurs the fuser will probably need to be replaced. Paper Unfused dots Fused dots Fuser rollers 8818-37 Figure 5-4 The fuser Phaser 300i and 300RX Color Printer...
Page 97: Maintenance Station
Theory of Operation Maintenance station Like ink-jet printers, the Phaser 300 requires a maintenance station to keep the printhead jets working. The Phaser 300’s maintenance station performs four basic functions: Removes air bubbles from within the printhead after power up Removes ink and dust particles from the printhead’s faceplate Maintains meniscus control by preserving the anti-wetting properties of the printhead’s faceplate by keeping ink droplets from forming...
Page 98: Maintenance Station Cam
The middle track will be followed when the drum is rotating clockwise: the direction during the printing process. The outer maintenance track is followed when the drum rotates counterclockwise for purge or wipe cycles. 5-10 Phaser 300i and 300RX Color Printer...
Page 99: Figure 5-6 The Maintenance Station Cam
Theory of Operation To perform the maintenance cycles, the drum will rotate counterclockwise to three different positions: Air knife, wipe, and purge. Waste bin track Print track Maintenance track Purge Maintenance station pin Wipe Air knife 8818-39 Figure 5-6 The maintenance station cam For example, to perform a purge cycle, the drum is rotated counterclockwise to move the cam to the purge position which forces the maintenance station against the faceplate and allows the cam pin to move towards the drum following a...
Page 100: Maintenance Cycles
7 second jetting to clear the nozzles of contaminated ink Note A purge is performed on the second and third presses of the CLEAN PRINT HEAD button and at power up. 5-12 Phaser 300i and 300RX Color Printer...
Page 101: Ink Loading
Theory of Operation Ink loading The four ink levels for the four reservoirs of melted ink are displayed on the top row of the 2-line LCD display. The levels are displayed as icons that depict Full, Half-full and Empty conditions. The display prompts the user to add ink to the appropriate ink loading chute of the empty reservoir.
Page 102: Figure 5-7 Ink Load Mechanism
ﬁll it up. Ink load lever Ink door Ink stick Ink load chute Ink load door Printhead door solenoid interlock solenoid Printhead Ink melt chamber Ink reservoir 8818-40 Figure 5-7 Ink load mechanism 5-14 Phaser 300i and 300RX Color Printer...
Page 103: Paper Feeding
Theory of Operation Paper feeding Tray sensors: Tray length and width sensors determine the paper’s size and orientation; whether it is A-size (landscape or portrait), or B-size. Manual-feed sensor: Detects if there is media in the manual-feed slot. If so, the printer uses the paper tray’s size and orientation information (A-size: portrait, or landscape, or B-size) to place the image, unless the printer driver speciﬁes manual feed, this orientation is used.
Page 104: The Paper Path's Operation
Tray width sensor Paper edge/ drum position Paper-out sensor sensor Lift plate Paper- tension Tray blade length sensor Friction pad Manual-feed sensor Printhead Backup compressor roller Paper clamp 8818-04 Figure 5-8 Paper loading 5-16 Phaser 300i and 300RX Color Printer...
Page 105: Paper Measure
Theory of Operation Paper measure After clamping the paper, the drum rotates one revolution so that the paper will clear the feed rollers. The print engine also “measures” the length of the paper using its Y-axis paper-edge sensor. The top edge (in the paper clamp) of the paper is positioned in front of the printhead just below the paper tension blade.
Page 106: Printing
Having earlier memorized the length of the media, the drum rotates until the trailing edge of the paper is located above the drum stripper. Paper clamp Paper- tension blade Backup compresson roller Drum stripper 8818-07 Figure 5-11 Print positioning for exit 5-18 Phaser 300i and 300RX Color Printer...
Page 107: Fusing And Exiting
Theory of Operation Fusing and exiting The exit motor rotates the ﬁngers of the drum stripper against the drum and moves the fuser rollers into their fusing position. The drum then reverses direction and the paper is stripped off the drum into the fuser rollers. The fuser rollers use tremendous pressure to “cold fuse”...
Page 109: System Power-Up Sequence
Chapter Troubleshooting This chapter discusses troubleshooting the printer. Troubleshooting is discussed with two approaches: A step-by-step veriﬁcation procedure that systematically conﬁrms that particular components of the printer are properly functioning until a problem is found. A symptom/cause scheme that lists particular printer failures and error codes and their possible causes.
Page 110: Print Engine Troubleshooting
Test Pattern Generator can be attached to the printer while the printer is turned on. Select any test pattern using the Test Pattern Generator's ﬁve DIP switches and then press its TEST PRINT button. After the print is made, remove the Test Pattern Generator. Phaser 300i and 300RX Color Printer...
Page 111: Verifying Print Engine Operation By Using Its Self-Test Print
Troubleshooting If the printer prints a test pattern, then the printer's image processor board and print engine are working correctly. The printer's problem resides with the host computer-to-printer connection, or the host computer. Refer to the appropriate topics in Chapter 3 “Verifying the Printer and Host Connections.” (Note that since the Test Pattern Generator prints only through the parallel port, the possibility also exists that the hardware of any of the other hosts interface ports could be non-functioning, and could be the source of the print failure.
Page 112: Verifying Power Supply Operation
The motor and solenoid resistances are listed in Table 6-1, “Motor and solenoid resistances,” on page 6-9. If the power supply operates (with the umbilical cable disconnected), then suspect that the carriage board is overloading the high-voltage supply. Phaser 300i and 300RX Color Printer...
Page 113: Measuring Power Supply Voltages
Troubleshooting Measuring power supply voltages Turn off the printer and unplug it from its power outlet. AC Input: With the VOM set to measure AC voltages, measure for power being supplied to the printer. It should measure between 87 to 128 VAC (115 VAC nominal) or 174 to 250 VAC (220 VAC nominal).
Page 114: Inspecting The Power Supply Fuses
If the power supply is functional, proceed to the procedure “Testing motor resistances” on page 6-9. If the motors and solenoids are functional, but the power supply still does not function, replace it. Refer to the Chapter 8 topic “Power supply” on page 8-27. Phaser 300i and 300RX Color Printer...
Page 115: +40 And Hv Safety Interlocks
Troubleshooting +40 and HV safety interlocks The printer features a mechanical switch safety interlock. The interlock functions off of the rear access cover. When the switch senses the rear cover opened, it signals the power supply to turn off the +40 VDC supplied to the motors, heaters and the high voltage supplied to the printhead.
Page 116: Figure 6-2 Interlocks For Top And Rear Access Covers
If motor resistances are correct, replace the engine control board. Refer to the Chapter 8 topic “Engine control board” on page 8-53. Top access cover open sensor Rear access cover interlock switch 8818-42 Figure 6-2 Interlocks for top and rear access covers Phaser 300i and 300RX Color Printer...
Page 117: Testing Motor Resistances
Troubleshooting Testing motor resistances Required tools #1 POSIDRIV® screwdriver With a VOM set for measuring resistance, test each motor's windings for its correct resistance. Rotate the motor's drive shaft slowly while taking the measurement. Table 6-1 Motor and solenoid resistances Motor or solenoid Connector Resistance (approximately) X-axis motor...
Page 118: Media Jams And The Paper Path
6-10 Phaser 300i and 300RX Color Printer...
Page 119: Jam - Paper Tray
Transparency ﬁlm should have opaque edges so the media sensors are actuated. Use Tektronix Phaser 300 media only. Clean the pick-up rollers, friction pad and drum. Also clean the feed roller. A dirty drum may falsely trigger the drum position sensor.
Page 120: Jam - Manual-Feed Input
This failure can also be caused by faulty sensors or roller failure. The Chapter 9 topic “Sensors check” on page 9-25 discusses how to test sensors. 6-12 Phaser 300i and 300RX Color Printer...
Page 121: Jam - Rear Cover
Troubleshooting Media that is too thick or improperly loaded in the tray can jam the printer. The output tray may be too full. Warning The printhead is hot. To avoid injury, be careful not to touch it when removing a nearby jam. Jam —...
Page 122: Checking The Paper-Feed Motor And Drive Train
Are the springs in the paper feeder that lift the paper tray damaged? Remove the tray from the printer and then push down on the tray guides to determine if they operate correctly. 6-14 Phaser 300i and 300RX Color Printer...
Page 123: Paper Tray Indicates Empty When It Is Not
Troubleshooting Does the tray's spring-loaded paper stop, at the front of the tray, travel up and down freely? Determine if the paper feed roller spring pressure is unbalanced. Are the compression springs at each end of the rollers dislocated or stretched and therefor provide uneven pressure at each end of the roller? Is the paper clamp operating correctly? Is it clean?
Page 124: Printing And Print Quality Problems
The printhead must be wiped and purged with a clean head cycle; press the CLEAN PRINT HEAD button. Check the connections to the carriage board. Replace the print engine control board. Note Refer to Appendix B, “Test Patterns” for examples of print defects. 6-16 Phaser 300i and 300RX Color Printer...
Page 125: Stripes, Spots Or Streaks In Print (Missing Ink)
Troubleshooting Stripes, spots or streaks in print (missing ink) If the streaks are parallel to the paper path, check the fuser, fuser wiper, stripper ﬁngers, and rollers. Contamination on any of these is probably scratching the print or a “too-dry” fuser roller is pulling ink off the print (offsetting).
Page 126: The Image Is Printed Skewed On The Paper
The misalignment is the same in all three marks. Check convergence adjustment, and printhead-to-media spacing. Alignment: bad The misalignment is different in the three marks. The print engine frame is bent, no correction is possible . Figure 6-3 Checking printhead alignment 6-18 Phaser 300i and 300RX Color Printer...
Page 127: Entire Image Appears Fuzzy; Dots Feature Many Satellites
Troubleshooting Ensure that the paper tension blade, paper clamp and drum are clean. Run the service mode's convergence adjustment to check and correct an alignment problem. Ensure that the printhead-to-media spacing is correctly set. See Chapter 9, “Checking and adjusting the printhead” on page 9-9. Entire image appears fuzzy;...
Page 128: The Fuser Stalls
Clean the wiper with an alcohol-moistened foam swab. Never scrape it with a tool or with your ﬁngertip. Following a printhead cleaning cycle the wiper is warm and the ink wipes off easily. 6-20 Phaser 300i and 300RX Color Printer...
Page 129: Service-Performed Procedures To Recover Faulty Jets
Troubleshooting If the problem persist, a “freeze/thaw” cycle may remove the obstruction. Turn the printer off and allow it to cool for at least 3 hours. Then turn it on again. During the cycle, ink in the nozzles solidiﬁes and is forced out by expanding ink when the ink is remelted. Purge three times after a freeze cycle, if necessary.
Page 130: Macintosh Printing Problems
Image prints in black-and-white In the print dialogue box, make that sure the Color/Grayscale option has been selected. Make sure that the Phaser 300i icon was selected in the Chooser. Try printing the job again. 6-22 Phaser 300i and 300RX Color Printer...
Page 131: Image Is Rotated 90 Degrees
6.0.x or higher. Earlier versions of the driver do not support color PostScript. The application may require special instructions to print, such as those contained in a .PPD ﬁle. Check in the Phaser 300i Drivers and Utilities Printing Reference or the disk readme ﬁles. Image is rotated 90 degrees In the application's Page Setup, make sure the image is selected to print in portrait or landscape orientation as you expect.
Page 132 TEST PRINT button to print an internal test print. Is the printer in PostScript mode? Check this by printing the conﬁguration page. Refer to Phaser 300i Drivers and Utilities Printing Reference for complete instructions on sending a utility ﬁle to the printer to set the port to PostScript mode.
Page 133: Windows Printing Problems
(CMY), blue is often printed as purple. To adjust blue from within Microsoft Windows: Within the Tektronix PostScript Windows driver you have an option, Vivid Blue, that alters the blue colors that are appearing purple.
Page 134: Workstation Printing Problems
ﬁle. Use a text editor to open and examine the ﬁle. From the Utilities diskette, use the utility ﬁle add-ctrl-D to add a CTRL-D to the end of the ﬁle. Then send the ﬁle to the printer. 6-26 Phaser 300i and 300RX Color Printer...
Page 135: Error Messages
Troubleshooting Error Messages During normal operation the top line of the two-line display indicates the ink level of each color. The bottom line indicates the printer's status by displaying a message. The front panel messages consist of two parts. The ﬁrst part describes the general state of the machine, such as Ready, Printing, Busy, or Stopped.
Page 136: Table 6-2 Error Codes And Their Meanings
Check for its freedom to move. 3. The pick (0r manual-feed) sensor is not working. To test, remove the paper tray, and remove any media from the manual-feed slot. The front panel should indicate Stopped--Add paper. 6-28 Phaser 300i and 300RX Color Printer...
Page 137 Troubleshooting Table 6-2 Error codes and their meanings (cont'd.) Error code and Possible causes and cures message The drum's home position hole was not detected. The system was attempting to do a Y-axis initialization. The drum rotates several times “Jam--Internal” to try to detect the drum home hole.
Page 138 The loaded media is too long. (>18.1inches) “Jam--Paper long” 1. The paper is too long. This is detected during the initial wrap while loading the paper. Open the top access cover and remove the paper to clear the jam. 6-30 Phaser 300i and 300RX Color Printer...
Page 139 Troubleshooting Table 6-2 Error codes and their meanings (cont'd.) Error code and Possible causes and cures message Loaded media is too short. (< 4.4 inches, 46 cm) “Jam--Paper 1. The paper is too short to eject. This is detected during the initial short”...
Page 140 2. The rails are dirty or lack oil. Clean the rails. Oil the rails and the carriage bearing. See Section 7. 3. The X-axis electronics are failing. Replace the engine control board. 6-32 Phaser 300i and 300RX Color Printer...
Page 141 Troubleshooting Table 6-2 Error codes and their meanings (cont'd.) Error code and Possible causes and cures message The expected power-up test scan of the X-axis was not within (6660-1024 counts) ±90 counts (18.8 inches ±0.067). This is the “Jam--Rear cover” position calibration scan where the printhead contacts the end of the frame.
Page 142 Recalibrate the paper-edge sensor using service mode XY Cal. 2. The paper-edge sensor (width) is not functional. Check the paper-edge sensor (width) mount, and connectors on the side of the printhead. Replace the paper-edge sensor (width). 6-34 Phaser 300i and 300RX Color Printer...
Page 143 Troubleshooting Table 6-2 Error codes and their meanings (cont'd.) Error code and Possible causes and cures message Less than two edges were found on a preprint scan. “Jam--Rear cover” 1. Paper is covering the paper-edge sensor (width). Inspect the carriage area for paper. 2.
Page 144 1. The paper is less than the minimum allowable width. The paper is automatically ejected. If the paper is of normal width, recalibrate the paper-edge sensor (width) with the XY Cal service test. Check all connectors. Replace the paper-edge sensor (width). 6-36 Phaser 300i and 300RX Color Printer...
Page 145 Troubleshooting Table 6-2 Error codes and their meanings (cont'd.) Error code and Possible causes and cures message The heater integrity check counter reached zero. When any heater is “SYSTEM turned on the counter decrements. When any heater is turned off the FAILURE 400"...
Page 146 With the power off, disconnect the supply connector and meter the connector for shorts. If this fails, replace the power supply, if this doesn't solve the problem, replace the engine control board. 6-38 Phaser 300i and 300RX Color Printer...
Page 147 Troubleshooting Table 6-2 Error codes and their meanings (cont'd.) Error code and Possible causes and cures message The 6-minute time limit for ink to reach the “SYSTEM one-ink-stick-added-threshold after loading an ink stick was exceeded. FAILURE 701" 1. The ink load sensor was falsely triggered. Cycle power and see if error recurs.
Page 148 3. The controller-to-print engine connection is loose. Inspect the connector. 4. The image processor board is malfunctioning. Replace the image processor board. 5. The print engine reset without the image processor board resetting, giving false 'Select' line signals. Power-cycle the printer. 6-40 Phaser 300i and 300RX Color Printer...
Page 149: Service Mode Message
This error occurs when there is a communication error between the print engine and the controller. Generally, you should never see this error with a Phaser 300i. If you do see it, there is probably an electronics failure with the image processor board or the interface from the image processor to the engine control board.
Page 150: Table 6-3 Communication Protocol Error Byte
Start Image speciﬁed with a width value not divisible by 2 (for color images) or 8 (for monochrome). Invalid argument format Command terminator (EOL) missing. Invalid command format Too many or too few arguments. Unrecognized command Command speciﬁed is not deﬁned. 6-42 Phaser 300i and 300RX Color Printer...
Page 151: Phaser 300I Image Processor
Troubleshooting Phaser 300i image processor Image processor normal indicators There are three indications that the print engine and its image processor are powered-up and operating normally: the front panel POWER LED is on (steady), Ready is displayed on the front panel LCD display and the rear panel STATUS light is blinking.
Page 152: Image Processor Self-Diagnostics
Troubleshooting Image processor self-diagnostics Phaser 300i image processor rear panel switches for self-testing The image processor features four types of self-diagnostic modes. The type of self-diagnostics run depend upon the position of rear panel DIP Switches 2, 3 and 4. The switch combinations are listed here.
Page 153: Table 6-4 Pxi Self-Test Led Displays
Troubleshooting Table 6-4 PXi self-test LED displays LEDs Summary message reported via RS-232 port following power-up self-test Lamp test – all eight LED are momentarily lighted for this test Kernel test – image processor board. Incorrectly installed ROMs can produce an error with this test. Instruction ROM test –...
Page 154 Like the startup page, demo pages are printed only if the startup page has not been disabled or turned off by the downloadable utility No startup page. 6-46 Phaser 300i and 300RX Color Printer...
Page 155: Rear Panel Switches (Diagnostics)
Troubleshooting Rear panel switches (diagnostics) Table 6-5 Image processor diagnostics -- rear panel DIP switches Switch Position (| means ON) 1 2 3 4 5 6 7 8 9 Diagnostics operation ↑ Image processor hardware reset . The image processor is - - - - - - - - held in a reset state while Switch 1 is up .
Page 156: Trace Mode
Hex 0x0F. Fault end Hex 0x01. Abort manual feed The left-most LED, called the health LED, always ﬂashes during printing and while the printer is idle. If an error occurs, the health LED stops ﬂashing. 6-48 Phaser 300i and 300RX Color Printer...
Page 157: Resetting Nvram
Troubleshooting Resetting NVRAM Resetting NVRAM returns all the image processor's NVRAM-stored parameters to their factory defaults except the print count (of images processed through the image processor) and the Adobe ﬁrmware serial number. To reset the image processor to its factory default values, follow this procedure: Place the rear panel DIP Switch 9 in the on position (up).
Page 159: Cleaning And Maintenance
Chapter Cleaning and Maintenance Service preventive maintenance procedure Whenever you check, service, or repair a printer, you should perform the following procedures. Cleaning the printer, as outlined in the following steps, assures proper operation of the printer and reduces the probability of having to service the printer in the future.
Page 160: Cleaning And Inspecting
Place the alcohol-dampened wipe against the bottom of the pick roller. Rotate the paper-pick roller by turning the bar. Repeat this until the wipe no longer turns black. Clean the two auxiliary pick rollers. Phaser 300i and 300RX Color Printer...
Page 161: Figure 7-1 Cleaning The Pick Roller
Cleaning and Maintenance If you have been using coated paper, you may need to clean the feed rollers to avoid paper jams too. 8818-63 Figure 7-1 Cleaning the pick roller Service Manual...
Page 162: Cleaning The Feed Rollers
Raise the end of the roller guide closest to the front panel. Remove the upper roller by pushing it down and then around the end of the roller guide. Figure 7-2 Unhooking the upper feed roller Phaser 300i and 300RX Color Printer...
Page 163: Figure 7-3 Removing The Upper Feed Roller
Cleaning and Maintenance Lift the end of the roller shaft straight up and remove it. Clean each roller on the upper roller shaft. Figure 7-3 Removing the upper feed roller Service Manual...
Page 164: Figure 7-4 Cleaning The Lower Feed Roller
Cleaning and Maintenance Clean the lower rollers. Reverse the removal procedure to reinstall the upper roller. 8345-57 Figure 7-4 Cleaning the lower feed roller Phaser 300i and 300RX Color Printer...
Page 165: Other Cleaning
Cleaning and Maintenance Other cleaning In most cases you will enter Utilities mode to perform cleaning of the tension blade, paper clamp, and drum, based on the cleaning artifacts seen on the TEST PRINT pattern output. Printing the TEST PRINT pattern is the best method of checking for a dirty paper path or a printhead nozzle problem.
Page 166: Figure 7-5 Cleaning The Paper Tension Blade
Cleaning and Maintenance Figure 7-5 Cleaning the paper tension blade Phaser 300i and 300RX Color Printer...
Page 167: Cleaning The Paper Clamp
Cleaning and Maintenance Cleaning the paper clamp To clean the paper clamp: Close the rear cover so the following message appears in the front panel display: Cleaning Mode ↑ ↓ Clean drum Press and hold the down arrow button to rotate the drum until the paper clamp appears and opens.
Page 168: Cleaning The Drum
Use a dry, lint-free cloth to wipe of any ﬁlm remaining on the drum. Figure 7-7 Cleaning the drum with a wipe Note If ink on the drum does not easily wipe off, you can use the cleaning tool with a wipe. 7-10 Phaser 300i and 300RX Color Printer...
Page 169: Figure 7-8 Cleaning The Drum With The Cleaning Tool
Cleaning and Maintenance 8818-18 Figure 7-8 Cleaning the drum with the cleaning tool Service Manual 7-11...
Page 170: Cleaning The Wiper Blade
Perform a CLEAN HEAD cycle. This warms up the wiper element and softens any ink and contaminates on the element, making it easier to clean. Use an alcohol-dampened cleaning swab to scrub the wiper clean. Remove the rear access door-open sensor override. 7-12 Phaser 300i and 300RX Color Printer...
Page 171: Figure 7-9 Cleaning The Wiper Blade
Cleaning and Maintenance Close the rear cover. When Ready is displayed on the front panel, run a clean head cycle by pressing CLEAN PRINT HEAD. Then make a test print by pressing TEST PRINT. Printhead Wiper 8818-70 Figure 7-9 Cleaning the wiper blade Service Manual 7-13...
Page 172: Cleaning The Fuser Rollers
Load the tray with 10 sheets of standard ofﬁce Bond paper (photocopy paper) in the input tray so the long edge enters the printer ﬁrst. Enter Utilities mode and scroll to Clean fuser. 7-14 Phaser 300i and 300RX Color Printer...
Page 173: Replacing The Fuser Wiper
Cleaning and Maintenance Press CLEAN PRINT HEAD. The printer will process all 10 sheets through its paper path. Press TEST PRINT to return to the top of the menu and then press CLEAN PRINT HEAD to exit Utility mode Replacing the fuser wiper The fuser wiper should be changed when you open a new box of black ink ColorStix.
Page 174: General Cleaning And Checking
Check and adjust, if necessary, the XY sensor calibration as explained in the topic “Sensors check” on page 9-25. Make a test print and listen for any unusual sounds that could indicate a motor under unusual strain or broken gear teeth, etc. 7-16 Phaser 300i and 300RX Color Printer...
Page 175: Fru Disassembly/Assembly
Chapter Disassembly/Assembly This chapter explains how to remove and replace many of the printer's Field Replaceable Units (FRUs). This chapter covers procedures for FRUs that are difﬁcult to remove or require special handling or precautions. Refer to Appendix A for a list of the printer's FRUs. Service Manual...
Page 176: Required Tools
Printhead-to-media adjustment tool (spring loader) 003-1491-00 Belt tension adjustment tool Fuser safety lock 105-1043-00 Dow Corning® Compound 4 silicone grease 006-0315-00 Rheolube grease 006-2037-00 95% isopropyl alcohol Antistatic mat 006-7056-00 ™ Velocite Oil No. 10 006-2530-01 Phaser 300i and 300RX Color Printer...
Page 177: The Printer Cabinet
FRU Disassembly/Assembly The printer cabinet The printer cabinet is comprised of four basic parts: The cabinet bottom. The cabinet top. The top access cover. The rear access cover. To remove the covers: Caution In the next step, notice the narrow clearance between the rear of the cabinet top and the printhead.
Page 178: Figure 8-1 Removing The Printer Cabinet Covers
Push rear access cover release button Lower rear access cover Printer front Remove 4 screws. Slowly, tilt forward, lift and remove the cabinet top. Note: narrow clearance Printer rear 8818-09 Figure 8-1 Removing the printer cabinet covers Phaser 300i and 300RX Color Printer...
Page 179: Paper Path Frame
FRU Disassembly/Assembly Paper path frame To remove the paper path frame from the printer, do the following: Power down the printer and remove the paper tray. Remove the printer cabinet covers. Disconnect the three wiring harnesses from the engine control board. Remove the two screws securing the brace between the power supply and the paper path frame.
Page 180: Backup System
Raise and hold open the fuser wiper holder portion of the backup system. While holding open the fuser wiper, gently pull the backup system's left-end snap-pin to release it from the fuser. Lift and remove the backup system. Phaser 300i and 300RX Color Printer...
Page 181: Figure 8-3 Removing The Backup System
FRU Disassembly/Assembly Release left snap-pin Lift and remove the back-up system Open and hold 8818-11 Figure 8-3 Removing the backup system Reverse these steps to reinstall the backup system. Install the right snap-pin ﬁrst. Service Manual...
Page 182: Paper Feed Rollers
Grasp the snap-ﬁtted roller and pull both ends free of the paper path frame. Caution Don't remove the lower roller by freeing one end and then swinging it out to free the other end — this could damage the roller's snap-ﬁt base. Phaser 300i and 300RX Color Printer...
Page 183: Figure 8-4 Removing The Paper Feed Rollers
FRU Disassembly/Assembly Reverse these steps to reinstall the rollers. The illustration shows the direction the one-way clutches should operate when properly installed. Refer to the later topic “Tensioning the paper-feed drive belt” on page 8-37 to set the proper paper feed drive belt tension. Remove this screw and rotate the One-way...
Page 184: Fuser
(due to an internal spring/cam action) and cause severe injury. The fuser is quite heavy; be careful. Unloop the drive chain; lift and remove the fuser. Disconnect the ground strap from the motor. 8-10 Phaser 300i and 300RX Color Printer...
Page 185: Figure 8-5 Removing The Fuser
FRU Disassembly/Assembly Caution When handling the fuser, DO NOT lay the fuser down so the weight of the fuser is on its plastic stripper ﬁngers. The weight of the fuser can bend or break the ﬁngers. Disconnect exit sensor 8818-21 Figure 8-5 Removing the fuser Reverse these steps to reinstall the fuser.
Page 186: Printhead
Supporting the printhead, gently remove the printhead’s hybrid ﬂex cable from its connector on the carriage board. Tilt the printhead back and gently free it from the rear rail. 8-12 Phaser 300i and 300RX Color Printer...
Page 187: Figure 8-6 Removing The Printhead
FRU Disassembly/Assembly Warning The printhead is hot. Allow it to cool before handling it. Ensure slide ramp is over to the left so the printhead moves back from the drum Back out the right- side tilt adjusting screw Disconnect the Gently free the sensors and printhead from...
Page 188: Installing The Printhead
Supporting the carriage board, gently insert the hybrid cable into its connector on the carriage board. 4 Printhead Hybrid 2 Carriage cable Rear 3 Plastic protector carriage rail 8818-48 Figure 8-7 Connecting the printhead’s hybrid cable 8-14 Phaser 300i and 300RX Color Printer...
Page 189: Figure 8-8 Installing The Printhead
FRU Disassembly/Assembly Pick up the printhead and remove the plastic protector from underneath. Position the printhead above the rear rail and press the printhead's tailpiece bearing in place on the rail. Note Ensure the tailpiece’s white bearing and its lubrication pad are properly positioned on the rail.
Page 190 Install the paper tray. Adjust the printhead for proper voltage, head-to-media spacing, XY calibration, printhead tilt and alignment. Refer to the Chapter 9 topic “Printhead maintenance and test printing” on page 9-7. 8-16 Phaser 300i and 300RX Color Printer...
Page 191: Air Pump
FRU Disassembly/Assembly Air pump Removing the air pump Power down the printer and remove the paper tray. Remove the printer cabinet covers. Remove the engine control board and frame assembly. It is secured to the bottom cabinet by two screws. If necessary, refer to the later procedure “Engine control board”...
Page 192: Figure 8-10 Removing The Air Pump
Outlet Inlet Air pump Power wiring harness (red and black) Cut top off of 3 Air hose to mounting posts vacuum chamber to remove air pump 8818-44 Figure 8-10 Removing the air pump 8-18 Phaser 300i and 300RX Color Printer...
Page 193: Installing The Air Pump
FRU Disassembly/Assembly Installing the air pump New mounting posts are supplied with a replacement pump. Hand-tighten them in place. Do not use pliers to tighten. Reconnect the power connectors. The red wire connects to the lug closest to the fuser, marked “+.” Place the air pump on the mounting posts.
Page 194: Front Panel, Ink Loading Chamber And Sheet Metal Bracket
Free the snap-ﬁt ink loading chambers from the bracket. Disconnect the Y-axis sensor's wiring harness from the ink load board. Remove the bracket. Cut the tie-wrap securing the air hose to the bracket. 8-20 Phaser 300i and 300RX Color Printer...
Page 195: Figure 8-11 Removing The Front Panel, Ink Loading Chambers And Sheet Metal Bracket
FRU Disassembly/Assembly Note Ensure that the ink lever guide is properly in place. If it is not, the ink lever will not operate correctly. Remove the front panel Unsnap ink loading chambers and remove Note the ink chamber alignment Ink lever Back out the guide set screw...
Page 196: Maintenance Station
Disconnect the maintenance station wiring harness from the engine control board. Engine Disconnect Pull this pin to release control maintenance the maintenance station board station wiring from the cam harness 8345-18A Figure 8-12 Disconnecting the maintenance station 8-22 Phaser 300i and 300RX Color Printer...
Page 197: Figure 8-13 Removing The Maintenance Station
FRU Disassembly/Assembly Remove the retainer between the maintenance station's pins. Reaching through the access hole in the side of the precision frame, pull the maintenance station's cam pin to release the maintenance station from the drum. You may have to rotate the drum to free it completely.
Page 198: Installing The Maintenance Station
Air valve hose as illustrated. It should not be bound under the sheet metal bracket. Air flow from pump Air flow to pump 8345-104 Figure 8-14 Routing the air hoses 8-24 Phaser 300i and 300RX Color Printer...
Page 199 FRU Disassembly/Assembly Slip the maintenance station, at an angle, into its mounted position; straighten it out and then insert its mounting pins in their respective slots. Install the maintenance station retainer. Connect the air hoses to the air pump as shown. Secure the air inlet hose to the pump with tie-wraps.
Page 200: Replacing The Maintenance Station Wiper
Clean the wiper with an alcohol-moistened swab. Maintenance station Wiper Wiper Ridge retainer element 8818-60 Figure 8-15 Replacing the wiper element 8-26 Phaser 300i and 300RX Color Printer...
Page 201: Power Supply
FRU Disassembly/Assembly Power supply Note After you install a new power supply you must adjust the supply's printhead drive voltages to match the printhead's requirements. Refer to the Chapter 9 topic “Checking and adjusting the printhead” on page 9-9. Power down the printer and remove the paper tray. Remove the printer cabinet covers.
Page 202: Motors
X-axis cable. Beveled edge 2 bushings Remove 2 screws X-axis motor Note how the wiring harness routes under the frame 8345-20A Figure 8-17 Removing the X-axis motor, idler and cable 8-28 Phaser 300i and 300RX Color Printer...
Page 203: Rewinding The X-Axis Cable
FRU Disassembly/Assembly Rewinding the X-axis cable If already installed, free the X-axis idler from the precision frame. Route the long end of cable through the idler; the short end of the cable should feed off the top of the idler, the long end off the bottom. Route the short end of the cable through the printhead carriage.
Page 204: Figure 8-18 Rewinding The X-Axis Cable
. . Install X-axis idler and tighten cable Long . . . look for the tension cable adjust screw head to just lift off of the frame 8345-21A Figure 8-18 Rewinding the X-axis cable 8-30 Phaser 300i and 300RX Color Printer...
Page 205 FRU Disassembly/Assembly X-axis cable - rear view Clasp - fastens to transducer under printhead Short cable Long cable end 8345-108 Service Manual 8-31...
Page 206: Y-Axis Motor
Reverse these steps to reinstall the Y-axis motor. Route the motor wiring harness off the bottom of the motor, then under the precision frame. Motor removal Lock screw Disconnect wiring harness Y-axis motor Longer lock screw for tension adjustment Figure 8-19 Removing the Y-axis motor 8-32 Phaser 300i and 300RX Color Printer...
Page 207: Looping The Y-Axis Drive Belt
FRU Disassembly/Assembly Looping the Y-axis drive belt Slip the belt off the large pulley toward the power supply. Position the belt so that the Y-axis motor can be installed. Install the Y-axis motor, but leave the screws untightened. Loop the belt around the motor drive pulley and over the top of the small idler pulley.
Page 208: Adjusting The Y-Axis Belt Tension
3 Push to 7 lbs. and tighten lock screw 2 Press gauge against idler roller arm 1 Slightly loosen lock screw 8818-68 Figure 8-21 Tensioning the Y-axis drum belt 8-34 Phaser 300i and 300RX Color Printer...
Page 209: Figure 8-22 Tensioning The Y-Axis Drum Motor Belt
FRU Disassembly/Assembly Drum motor belt. Place the end of the tension gauge against the Y-motor drive pulley. lay the shaft of the gauge against the power supply shield. (This sets the proper tensioning angle.) Push the tension gauge towards the pulley with a force of 6.8 kg (15 lbs.).
Page 210: Paper-Feed Motor And Belt
Reverse these steps to reinstall the motor. The illustration shows how the paper path drive belt should be looped around the gears. The illustration also shows the directions the one-way clutches should operate when properly installed. 8-36 Phaser 300i and 300RX Color Printer...
Page 211: Tensioning The Paper-Feed Drive Belt
FRU Disassembly/Assembly Tensioning the paper-feed drive belt This tension adjustment requires no special tools. Gravity makes the adjustment for you. Loosen the two screws securing the paper-feed motor to the paper path frame. Tap the motor lightly to ensure that it is loosely held in place and that only the weight of the motor is tensioning the paper-feed drive belt.
Page 212: Exit Motor And Chain
To avoid injury, be careful of the drive chain when the printer is powered-up and in operation. Disconnect terminals Red Black Unloop chain Disconnect sensor Lift and remove 8818-13 Figure 8-25 Removing the exit motor 8-38 Phaser 300i and 300RX Color Printer...
Page 213: Paper-Clamp Motor Removal
FRU Disassembly/Assembly Reverse these steps to reinstall the motor. Ensure the motor is properly encased in its rubber jacket and the assembly ﬁrmly seats in the cabinet bottom. When properly installed, the exit motor's rubber jacket is ﬂush with the top of the motor's cabinet pocket.
Page 214: Paper-Clamp Motor Installation
When properly inserted, the push rod should engage a tapered hole in the paper-clamp pivot. Push the push rod to test that it actuates the paper clamp. If it doesn't, reinsert the rod and test it again. 8-40 Phaser 300i and 300RX Color Printer...
Page 215: Figure 8-28 Inserting The Paper Clamp Motor With Push Rod Into The Drum
FRU Disassembly/Assembly Install the paper-clamp motor assembly. Be sure to reinstall the retainer clip under the lower screw to hold the motor assembly in place. Also, install the ground wire. Pivot point Paper clamp Push rod Paper Paper clamp pivot clamp motor 8345-80...
Page 216: Paper-Tension Blade Motor
Figure 8-29 Removing the paper-tension blade motor Reverse these steps to reinstall the motor. Be sure to route the motor's wiring harness out the hole in the precision frame located below the motor. 8-42 Phaser 300i and 300RX Color Printer...
Page 217: Paper-Tension Blade
FRU Disassembly/Assembly Paper-tension blade Caution Be careful not to scratch the drum. Scratches can affect print quality. The paper-tension blade is sharp. Be careful. Power down the printer and remove the paper tray. Remove the printer cabinet covers. Unhook the spring from the paper-tension blade cam follower. Remove the spring.
Page 218: Transducer
Transducer Carriage Carriage board Remove screws Disconnect the transducer harness 8345-29A Figure 8-31 Removing the paper-tension blade 8-44 Phaser 300i and 300RX Color Printer...
Page 219: Drip Plate
FRU Disassembly/Assembly Drip plate Caution Be careful not to scratch the drum. Scratches can affect print quality. Power down the printer and remove the paper tray. Remove the printer cabinet covers. Ensure that the printhead is in the home position in front of the maintenance station.
Page 220: Figure 8-32 Removing The Drip Plate
Disconnect the drip plate wiring harness Gently bend each rod to free it . . . and remove it through this hole Free the drip plate and remove it 8818-50 Figure 8-32 Removing the drip plate 8-46 Phaser 300i and 300RX Color Printer...
Page 221: Drum
FRU Disassembly/Assembly Drum Caution Be careful not to scratch the drum. Scratches on the drum affect print quality. For orientation, this procedure assumes you are standing in front of the printer. Power down the printer and remove the paper tray. Remove the printer cabinet covers.
Page 222: Figure 8-33 Preparing To Remove The Drum
Use the special spring compression tool to unload the spring from the retainer clip. Unclip the drum retainer at the right-end of the drum shaft. 8-48 Phaser 300i and 300RX Color Printer...
Page 223: Figure 8-34 Removing The Drum
FRU Disassembly/Assembly Carefully, slide the drum to the right (away from the Y-axis motor) so that the left-end of the drum shaft clears the precision frame. Gently work the drum free and lift it clear of the print engine. Remove the drum retainer clip Push drum...
Page 224 After proper installation, the maintenance station's cam pin should ride in the deep groove of the drum cam. The waste bin interlock should ride between the two raised ridges of the cam as shown in Figure 4-24. 8-50 Phaser 300i and 300RX Color Printer...
Page 225: Dot Clock Encoder Strip
FRU Disassembly/Assembly Dot clock encoder strip The dot clock encoder strip extends across the width of the print engine. Each end of the strip attaches to a hook, which in turn, attaches to the precision frame. To remove the encoder strip follow this procedure: Power down the printer and remove the cabinet top and rear cover.
Page 226: Figure 8-35 Aligning The Dot Clock Encoder Strip
Observe any deflection in encoder strip. Right-end encoder strip hook Lever the position of the encoder strip hook with a screw- driver to remove deflection. 8818-51 Figure 8-35 Aligning the dot clock encoder strip 8-52 Phaser 300i and 300RX Color Printer...
Page 227: Engine Control Board
FRU Disassembly/Assembly Engine control board Note If you replace the engine control board, you should perform the Chapter 9 topic “Checking and adjusting the printhead” on page 9-9. A new engine control board introduces electronic variations that can affect print quality. Power down the printer and remove the paper tray.
Page 228: Carriage Board
Remove the dot clock encoder strip by following the earlier procedure “Dot clock encoder strip” on page 8-51. Remove the four screws securing the carriage board to the carriage. Remove the board. Disconnect the data ribbon cable from the carriage board. 8-54 Phaser 300i and 300RX Color Printer...
Page 229: Figure 8-37 Removing The Carriage Board
FRU Disassembly/Assembly Caution Be careful not to damage the dot clock encoder strip. Unhook Remove this end Carriage screws of the encoder strip . . . Carriage board Dot clock encoder strip . . . feed the strip this way 8818-52 Figure 8-37 Removing the carriage board Reverse these steps to install the carriage board.
Page 230: Controller Interface Interconnect
Remove the cable. To engine control board Controller interface interconnect cable 3/8 inch nuts 8345-92 Figure 8-38 Removing the controller interface interconnect cable Reverse these steps to install the controller interface interconnect cable. 8-56 Phaser 300i and 300RX Color Printer...
Page 231: Image Processor Board
FRU Disassembly/Assembly Image processor board Power down the printer. Disconnect all host interface cables. Remove the screws securing the board's rear panel to the printer. Two versions of the image processor board are available. Grasp underneath the rear panel and slide the board out of the printer card cage.
Page 232: Figure 8-40 Removing The Image Processor Board (Serial Number Blxxmdy)
® t In D is s ta lle d E th e rn e t® 8818-77 Figure 8-40 Removing the image processor board (serial number B lxxmdy ) 8-58 Phaser 300i and 300RX Color Printer...
Page 233: Installing Ram Simms
FRU Disassembly/Assembly Installing RAM SIMMs Turn off the printer. Remove the image processor board. Insert a memory module in connector J9 (or in J8 if J9 is already ﬁlled, or in J7 if J8 is ﬁlled) (a) and tilt the module down until it locks in place (b).
Page 234: Figure 8-41 Installing Ram Simms (Serial Number B01Xxxx)
® t In D is s ta ll e E th e r n e t® 8818-79 Figure 8-42 Installing RAM SIMMs (serial number B lxxmdy ) 8-60 Phaser 300i and 300RX Color Printer...
Page 235: Installing The Ethernet Card
FRU Disassembly/Assembly Installing the Ethernet card Note EtherTalk and LocalTalk protocols require you to attach the Ethernet cable to the printer with the printer powered off. After connection, turn on the printer. During the printer's boot-up process, the printer's network node address is resolved with the network. Power down the printer.
Page 236: Enabling Tcp/Ip With The Downloadable Software Key
To obtain the authorization code the user must fax or mail a authorization request form included with the Ethernet card to Tektronix in order to receive a TCP/IP authorization code. Tektronix can generate an authorization code for an Ethernet-capable printer anytime once purchase of the TCP/IP option has been conﬁrmed, even long...
Page 237: Checks And Adjustments
Chapter Checks and Adjustments This chapter contains the procedures to calibrate the printer after you replace key Field Replaceable Units. It also contains procedures to let you evaluate if the printer's functionality. Finally, this chapter lists a series of steps you follow to inspect and clean the printer you are servicing.
Page 238: Placing The Printer In Utility Or Service Mode
Exit Next Quickly: Press and hold the CLEAN PRINT HEAD button. Press the TEST PRINT button. Release the TEST PRINT and then the CLEAN PRINT HEAD button. Figure 9-2 illustrates the service menu structure. Phaser 300i and 300RX Color Printer...
Page 239: Figure 9-1 Utility Mode Menu Structure
Checks and Adjustments Coded button press Utilities Service mode Busy - Self test Print head warmed up Utilities Busy - Warmup Utilities Clean head button press Application mode Exit Next Copy count: xxxxx Next Clean head button press Language: English Language: Deutsch Change Next...
Page 240: Figure 9-2 Service Mode Menu Structure
High Purge: All Jets High Purge: All Jets Start Next Stop Enh Convergence Adj. Print Adjust Enh Conv. Offs: -8 Change Next Enh Conv. Offs: 7 Change Next 8818-54 Figure 9-2 Service mode menu structure Phaser 300i and 300RX Color Printer...
Page 241 Checks and Adjustments Motors Paper Path NV Ram Menu Next Menu Next Menu Next Paper Path Menu NV RAM Menu Motors Menu Exit Next Exit Next Exit Next Single Sheet Cntlr Monitoring On/Off Start Next Blade Blade Change Next Open Next Close Multiple Sheet...
Page 242: Xy Calibration
X-sensor (the maintenance station side) is bad. The printer must pass this test to function. As prompted by the display, remove the transparency ﬁlm from the printer. The printer automatically exits to the XY Calibration menu. Phaser 300i and 300RX Color Printer...
Page 243: Printhead Maintenance And Test Printing
Checks and Adjustments Printhead maintenance and test printing Service Mode Service menu XXX XXX Calibration Maintenance Maint Menu Scroll Sensors Test Print Motors Clean Head Paper Path Self Test NV RAM Low Purge: Black Low Purge: Cyan Low Purge: Magenta Low Purge: Yellow Low Purge: All Jets High Purge: Black...
Page 244 Scroll to the Maint Menu item and press CLEAN PRINT HEAD to return to the main service menu. Phaser 300i and 300RX Color Printer...
Page 245: Checking And Adjusting The Printhead
Checks and Adjustments Checking and adjusting the printhead Adjusting the printhead is usually done when you replace the printhead. Adjustments are also done to “ﬁne-tune” bi-directional printing convergence as well as compensating for printhead aging. The adjustments consists of ﬁve adjustments, in this order: Printhead drive voltage Printhead-to-media spacing...
Page 246: Figure 9-3 Printhead Drive Voltage Adjustment
Checks and Adjustments High voltage adjustment pots Measure HV+ on pin 1 pin 3 Measure HV- on pin 5 Figure 9-3 Printhead drive voltage adjustment 9-10 Phaser 300i and 300RX Color Printer...
Page 247: Printhead-To-Media Spacing (Tailpiece Adjustment)
Checks and Adjustments Printhead-to-media spacing (tailpiece adjustment) Note All printhead adjustments must be made while the printhead is warmed up to its operating temperature. This adjustment is critical for the best print quality. It ensures that the printhead will always be the correct distance from the loaded media during printing, no matter the thickness of the media.
Page 248 Attach the spring loader to the tailpiece. Tighten the three tailpiece screws to 3.5 in./lbs. (0.40 Nm) starting with the upper right screw and proceeding counterclockwise. Remove the spring loader. Spring loader 8818-56 9-12 Phaser 300i and 300RX Color Printer...
Page 249 Checks and Adjustments Warning The printhead is hot. To avoid injury, don’t touch it. Move the printhead by pulling its X-axis cable. Slide the tailpiece slide ramp full left and return the printhead to its home-position. Remove the shim-clip from the paper tension blade. Slide the slide ramp full-left and gently move the printhead so it is centered before the drum and the Y-axis sensor.
Page 250: Tilt Adjustment
If magenta is lower than cyan: Loosen the right-side adjusting screw turn (as viewed from the rear of the printer). Tighten the left-side adjusting screw turn. Retighten the right-side adjusting screw. Press TEST PRINT to print another tilt adjustment pattern. 9-14 Phaser 300i and 300RX Color Printer...
Page 251 Checks and Adjustments Repeat Steps 6 and 7 until the magenta printing is level with the cyan printing. Press TEST PRINT to return to the Service menu. The printer will automatically eject the sheet of paper. Note Misalignment must not exceed pixel.
Page 252: Figure 9-4 Setting The Tilt Adjustment
First loosen this screw . . . First loosen this screw ..then tighten this screw . . . then tighten this screw 8818-57 Figure 9-4 Setting the tilt adjustment 9-16 Phaser 300i and 300RX Color Printer...
Page 253: Voltage, Convergence And Temperature Adjustment For A New Printhead
Checks and Adjustments Voltage, convergence and temperature adjustment for a new printhead Service Mode Service Menu XXX XXX Calibration Calibration Menu Maintenance XY Calibration Scroll Sensors Tilt Adjust Motors Convergence Adjust Paper Path Enh Convergence Adjust NV RAM Printhead convergence, temperature and voltage all interact to affect print quality.
Page 254 The ﬁrst pattern printed is 10, the second is 12, the third is 14, and so on up to 60. In the alignment patterns, the line to check for alignment is the middle line of the set of ﬁve vertical lines. 9-18 Phaser 300i and 300RX Color Printer...
Page 255: Figure 9-5 Setting Convergence For Standard Printing
Checks and Adjustments Note The numbers shown in the illustration are not actually printed on the test print. They are shown in the illustration for your convenience. Last one Correct setting value The center line is aligned First one The center bar The center bar is left of alignment.
Page 256 If the alignment does not remain consistent, then the printhead-to-media spacing may not be correct. Check, clean and adjust it, if necessary. Also try printing on thinner and thicker sheets of media to ensure the tailpiece performs correctly. 9-20 Phaser 300i and 300RX Color Printer...
Page 257: Setting Enhanced Printing Convergence
Checks and Adjustments Setting enhanced printing convergence Once standard printing mode convergence is good, press TEST PRINT to scroll to the Enh Convergence Adjust menu item to optimize enhanced print mode printing. Press CLEAN PRINT HEAD to enable the Enh Convergence adjustment function.
Page 258: Temperature Offset Adjustment
Proceed to the convergence adjustment earlier in this procedure to ensure that bi-directional printing is correct. Power down the printer and reinstall the power connector cover. Reinstall the cabinet top. 9-22 Phaser 300i and 300RX Color Printer...
Page 259: Figure 9-7 Printhead Temperature Adjustment
Checks and Adjustments Solid fills (pattern in this box is for head-test evaluation only) Uneven spacing Lines show a broken appearance. Good 8.5 kHz lines The printhead is too cold or the voltage is too low. Hooked ends Lines disrupted by "lane changing" and hooked ends that indicate the printhead is too hot or the voltage is too high.
Page 260: Adjusting For An Aged Printhead
If the enhanced printing mode alignment patterns show (marked with an E) show misconvergence, you can scroll to the Enh Convergence menu item and “ﬁne-tune” the convergence as explained in the topic“Setting enhanced printing convergence” on page 9-21. 9-24 Phaser 300i and 300RX Color Printer...
Page 261: Sensors Check
Checks and Adjustments Sensors check Service Mode Service menu XXX XXX Calibration Maintenance Scroll Sensors Sensors Menu Motors Paper Out Paper Path Hand Feed NV RAM Paper Exit Paper-length Paper Width Cyan Yellow Magenta Black Load Lever Top Cover Waste Bin This service mode menu item allows you to check the action of the interrupt-type sensors used in the printer.
Page 262: Motors Check
Note that the Fuser motor test runs only for as long as you hold down the CLEAN PRINT HEAD button. The fuser is parked following the test. Scroll to the Motors Menu item. Press CLEAN PRINT HEAD to exit to the service mode menu. 9-26 Phaser 300i and 300RX Color Printer...
Page 263: Paper Path Check
Checks and Adjustments Paper path check Service Mode Service menu XXX XXX Calibration Maintenance Scroll Sensors Motors Paper Path Paper Path Menu NV RAM Single Sheet Multiple Sheet Incremental Sheet This test mode lets you observe the printer as it processes one or more sheets of media through the paper path.
Page 264 The test automatically returns to the Paper Path Menu item after the paper is processed. While in the Paper Path submenu item, press CLEAN PRINT HEAD to return to the Service menu. 9-28 Phaser 300i and 300RX Color Printer...
Page 265: Nv Ram
Checks and Adjustments NV RAM Service Mode Service menu XXX XXX Calibration Maintenance Scroll Sensors Motors Paper Path NV RAM NV RAM Menu Cntlr Monitoring: On Command Timeout: On Copy Count: XXXXXX Head drive: 1 or 2 NVRam Value: O X YYYY This menu item allows you to observe and change the settings stored in the print engine’s NVRAM.
Page 266 ORed sum of its bit assignments. This memory map outlines the contents of NVRAM. After scrolling through the list, the printer exits to the next submenu item. Press TEST PRINT to return to the top of NVRam Value Menu. 9-30 Phaser 300i and 300RX Color Printer...
Page 267 Checks and Adjustments Address Bit Assignments (hex masks) System modes and Standard Waveform Periods 0007 Language Mode Select 0000 = English 0001 = German 0002 = French 0003 = Italian 0004 = Spanish 0005 = Japanese 0000 = Default setting 0008 Controller installed bit 0 enables “SYSTEM FAIL 920”...
Page 268 Printhead temperature offset for enhanced and premium mode 0F00 Printhead temperature offset for standard mode 1000 Waveform table selection for jet firing 0 = standard waveform 1 = high altitude waveform FFFF NVRAM checksum 9-32 Phaser 300i and 300RX Color Printer...
Page 269: Maintenance Station Vacuum Check
Checks and Adjustments Maintenance station vacuum check Proper vacuum is essential for the maintenance station to function properly. If the vacuum is not great enough, the maintenance station cannot clear clogged or blocked jets. Power down the printer and remove the cabinet top and rear cover. With a T-connector, attach a vacuum gauge to the air hose inlet of the air pump.
Page 270 Lastly, the air pump could be faulty. The test returns to the top of the Maintenance Menu after the cleaning cycle. Press CLEAN PRINT HEAD to exit to the Service menu. 9-34 Phaser 300i and 300RX Color Printer...
Page 271 Service Manual Addendum Phaser 300X ™ Color Printer This addendum contains information for servicing Phaser 300X Color Printers. Aug 1996 070-8818-81 Service Manual...
Page 272 PCL support, and a color control strip. Upgrading a Phaser III PXi or Phaser 300i Upgrading a Phaser III PXi or a Phaser 300i depends on the version of printer, its serial number and possible upgrades already installed as detailed in the following table.
Page 273 Important! About the printer’s IP address For Phaser 300i and Ethernet-capable Phaser III printers. If the printer has both the Ethernet card (factory-installed Option 01 or ﬁeld-installed 4680FP1 kit) and the TCP/IP authorization (factory-installed Option P2 or ﬁeld-installed 4680FP2) installed, the printer probably has been programmed with an IP address so it can operate in a TCP/IP environment.
Page 274 Ethernet card installed. Refer to the Phaser 300X user manual for more information. If a customer needs additional RAM, order 4690F4M 4-Mbyte RAM Upgrade Kits as needed from a local authorized Tektronix dealer. If the printer needs an Ethernet card, order the 4680FP1 Ethernet Card Upgrade Kit.
Page 275: Fru Parts List
FRU Parts List Changes to Tektronix instruments are made to accommodate improved components as they become available. It is important when ordering parts to include the following information: Component's part number. Instrument type or number. Instrument serial number. Modiﬁcation number, if any.
Page 276 REAR PANEL, 4699PXI 386-6905-00 BBxxxx6 B6Exxxx REAR PANEL, 4699PXI A1-14 671-2533-04 ETHERNET CKT. BD. A1-15 212-0713-00 SCREW, #10, PHS T-25 TORX A1-16 212-0714-00 SCREW, #10, PHS T-25 TORX A1-17 334-8366-09 LOGO, PHASER 300I 334-8366-09 LOGO, PHASER 300X Phaser 300X Color Printers...
Page 277 (2 plc's) (2 plc's) (2 plc's) 8818-74 The printer cabinet Service Manual...
Page 278: Fru Parts List Of The Exploded Printer
FRU parts list of the exploded printer Figure Part number Serial number Quantity Name and description Effective Discontinued A2- 1 348-1214-00 FEET A2-2A 204-0832-00 FUSE HOLDER BODY A2- 2B 159-0047-00 FUSE 10A 250V 0.3 SEC (115VAC POWER) A2- 2B 159-0353-00 FUSE, 5A 250V 0.3 SEC (220VAC POWER) A2-2C...
Page 279 FRU parts list of the exploded printer (cont'd.) A2-3 369-0046-00 COOLING FAN A2-30 650-3036-00 INK LOAD CKT. BD. ASSY. A2-31 650-3037-00 X-SENSOR & BRACKET, LEFT AND RIGHT A2-32 650-3040-00 HEAD ASSY. A2-35 650-3032-00 CARRIAGE CKT. BD. ASSY. A2-36 650-2652-03 DRIP PLATE ASSY. A2-37 650-3097-01 PURGE SYSTEM ASSY.
Page 280 The internal printer Phaser 300X Color Printers...
Page 281: Printer Accessories
Printer accessories Figure Part number Serial number Quantity Name and description Effective Discontinued 003-0762-00 TENSION SCALE, 0-15LBS 003-0814-00 BIT, SCREWDRIVER, TORX T-10 003-0966-00 BIT, SCREWDRIVER, TORX T-15 003-1377-00 VACUUM GAUGE, 0-90CM. OF HG. 003-1462-01 BIT, SCREWDRIVER, TORX T-25 006-0315-00 SILICONE GREASE,DOW CORNING #4,5.3.OZ.
Page 282 MANUAL,TECH. FIELD SERVICE, PHASER 300 070-8873-01 USER MANUAL PHASER 300 (ENGLISH ONLY) 070-8873-11 USER MANUAL PHASER 300i (FRENCH) 070-8873-21 USER MANUAL PHASER 300i (ITALIAN) 070-8873-31 USER MANUAL PHASER 300i (GERMAN) 070-8873-41 USER MANUAL PHASER 300i (SPANISH) 070-8875-01 PRINTER TOOLS MANUAL...
Page 283 Printer accessories (cont'd.) 4680FP1 ETHERNET CARD 4690F4M 4 MBYTE RAM UPGRADE Z350DSK EXTERNAL 2.1 GBYTE SCSI HARD DISK 469LAM PHASER MEDIA LAMINATOR Service Manual...
Page 285 Appendix Field Replaceable Units List This appendix provides a list of ﬁeld replaceable units for the Phaser 300i. Changes to Tektronix instruments are made to accommodate improved components as they become available. It is important when ordering parts to include the following information: Component's part number.
Page 286: Table A-1. Fru Parts List Of The Printer Cabinet
IMAGE PROCESSOR - PXI CKT. BD. A1-10 671-1561-01 4 MB RAM SIMM, CKT BOARD A1-11 386-6850-00 RX INTERFACE A1-12 650-2427-00 HANDFEED GUIDES A1-13 386-6675-00 B01xxxxx REAR PANEL, 4699PXI 368-6905-00 B lxxdmy REAR PANEL, 4699PXI A1-14 671-2533-04 ETHERNET CKT. BD. Phaser 300i and 300RX Color Printer...
Page 287: Figure A-1. The Printer Cabinet
Field Replaceable Units List (2 plc's) (2 plc's) (2 plc's) 8818-74 Figure A-1. The printer cabinet Service Manual...
Page 288 119-4161-00 ASSY. TRANSDUCER A2-26 650-2577-00 TIMING FENCE (DOT CLOCK) A2-27 650-3034-00 FRONT PANEL BOARD A2-28 650-3038-00 BEZEL ASSEMBLY A2-29 650-2279-00 LEVER ASSEMBLY: INK LOAD A2-2A 204-0832-00 FUSE BODY A2-2B 200-2264-00 FUSE CAP, 115V BEIGE Phaser 300i and 300RX Color Printer...
Page 289 Field Replaceable Units List Table A-2. FRU parts list of the exploded printer (cont'd.) A2-2B 200-2265-00 FUSE CAP 220V BLACK A2-3 369-0046-00 COOLING FAN A2-30 650-3036-00 INK LOAD CKT. BD. ASSY. A2-31 650-3037-00 X-SENSOR & BRACKET, LEFT AND RIGHT A2-32 650-3040-00 HEAD ASSY.
Page 291: Figure A-2 The Internal Printer
Figure A-2 The internal printer (2 plc's) (2 plc's) (2 plc's) VIEW REVERSED (2 plc's) 4 (plc's) (2 plc's) (2 plc's) 4 (plc's) 3 (plc's) 8818-23 Service Manual...
Page 292 012-1465-00 50 PIN SCSI TO 50 PIN SCSI-2 (MINI) CABLE 013-1299-00 36 PIN TO IEEE 1284C PARALLEL (MINI) CABLE ADAPTER 016-1144-01 CLEANING KIT: 4698/99 SERIES 065-0535-00 SHIPPING CTN KIT 003-1491-00 HEAD-TO-MEDIA ADJUSTER, SPRING LOADER Phaser 300i and 300RX Color Printer...
Page 293: Figure B-1 Front Panel Test Pattern
Appendix Test Patterns Front panel test pattern This appendix illustrates the test patterns produced by the print engine. It also illustrates a number of defective prints and the reason for the defects. Chapter 6 “Troubleshooting” discusses solutions to the problems shown in this appendix.
Page 294: Figure B-2 Print Quality Check Test Pattern
3) shadowing or spurting jet, 2) red = yellow + magenta varying shades of color pattern that is not actually used by Phaser 300i 3) green = yellow + cyan 4) general primary color 4) blue = cyan + magenta solid-fill quality printers;...
Page 295 Test Patterns Missing jet. Clogged ink nozzle. A wipe and/or purge should clear this. Typically, for clogged jets, only a single jet will be missing. Multiple missing jets are usually caused by something else as indicated later in this topic. Service Manual...
Page 296 Test Patterns Dirty printhead faceplate. The troubled jet ejects ink but the ink is deﬂected in ﬂight. A printhead wipe should clear this problem. Also ensure that the wiper element is clean and in good working order. Service Manual...
Page 297 Test Patterns Dirty dot clock linear encoder strip. The printhead cannot accurately track its position during its shuttling. The dot clock sensor (mounted on the underside of the carriage board) is being “confused” by the contamination on the dot clock strip. Gently, clean the dot clock strip with water-dampened cloth and then dry the dot clock strip.
Page 298 Test Patterns Dirty paper tension blade. Note the characteristic teardrop-like smearing caused when the paper is pulled past the contamination on the blade. In the test pattern, a dirty paper tension blade may block the upper-most cyan jet and cause a break in the test pattern's long horizontal cyan line. Service Manual...
Page 299 Test Patterns Y-motor malfunction. The gears and belts are not moving smoothly. Note the changes in image density caused by variations in the Y-direction motion of the drum. Service Manual...
Page 300 Test Patterns Bad ground. Typically you will see many missing or intermittent ink-jets of many colors. Check the electrical connections from the printhead to the power supply. Service Manual...
Page 301 Test Patterns Other print defects This illustration shows a combination of print problems. The ink smear problems can be corrected by cleaning ink off of the drum, the paper clamp, or the paper tension blade. Spotting and offsetting can be corrected by replacing the fuser wiper.
Page 302 Index Adobe PostScript Level 2 1-2 fan, engine 6-5 air pump feed roller cleaning 7-4 check 9-33 ﬁeld replaceable units list A-1 removing 8-17 Font Downloader Utility 2-13 antistatic mat 8-2 front panel description 1-11 removing 8-20 front panel, messages 6-27 backup system FRUs removing 8-6...
Page 303 OS/2 Version 2, Tektronix driver 2-27 Press Color Adjust 1-10 OS/2 Version 2.0, loading drivers 2-27 preventive maintenance 7-1 print modes, description 5-6 printcap ﬁle 2-31 printer troubleshooting 6-1 printer page description ﬁle 3-3 Index-2 Phaser 300i and 300RX Color Printer...
Page 304 printhead voltage adjustment 9-17 tailpiece adjustment 9-11 printhead TCP/IP, conﬁguring 2-33 convergence 9-17 TCP/IP, veriﬁcation of printing 3-8 description 5-4 TekColor 2-21 installing 8-14 terminator, SCSI 2-13 removing 8-12 test pattern 1-12 temperature adjustment 9-17 Test Pattern Generator printhead drive voltage using D-1 adjusting 9-9 verifying the image processor 6-2...
Page 305 C-1 workstation connecting the printer 2-11 using the Error Handler Utility 3-9 workstation veriﬁcation 3-8 wrinkled print 6-20 X-axis cable tension, setting 8-29 X-sensor calibrating 9-6 Y-axis belt tension,setting 8-34 Y-sensor calibrating 9-6 Index-4 Phaser 300i and 300RX Color Printer...
Page 306: Wiring Diagrams
Appendix Wiring Diagrams Figure C-1 illustrates the connections of all the printers motors, heaters, sensors and circuit board to the engine control board which forms the “brain” of the printer Paper feed moter Y-axis sensor Media Hand Front Width cover feed panel Rear cover...
Page 308: Test Pattern Generator
The Test Pattern Generator contains PostScript scripts to start test patterns for a number of Tektronix color printers. It allows you to test a printer as if it was receiving a ﬁle from a host computer. The test patterns are generated by the printer's image processor and then printed by the print engine.
Page 309: Figure D-1. Plugging The Test Pattern Generator Into The Printer's Parallel Port
Test pattern generator attach to parallel port 8818-59 Figure D-1. Plugging the Test Pattern Generator into the printer's parallel port For newer printers you will need the parallel connector cable adapter, part number 013-1299-00. Phaser 300i and 300RX Color Printer...
Page 310 Test Pattern Generator Press the Test Pattern Generator's START button. Its green LED ﬂashes as you press the button. The printer will print the transmitted print ﬁle. Besides print ﬁles, the test pattern generator also allows you to turn off and on the printer's start-up page.

This manual is also suitable for:

Phaser 300rx

Tektronix Phaser 300i Service Manual

Figure 1-1 the Phaser 300 Color Printer

1 General Information

Figure 1-2 Print Engine Major Components

Figure 1-3 Print Engine Components (Continued)

Table 1-2 Physical Dimensions

Table 1-3 Printer Clearances

Table 1-6 Environmental Specifications

Figure 1-5 Print Engine Sensor, Switches and Solenoid Locations (Continued)

2 Installing the Printer and Drivers

Verifying the Printer and Host Connections

4 Key Operator Training

5 Theory of Operation

Figure 5-1 Block Diagram of the Printer

Figure 5-2 the Printhead and Its Jet Nozzles

Figure 5-3 the Printhead's Jet Stack

Figure 5-4 the Fuser

6 Troubleshooting

Figure 6-1 Measuring the DC Voltages (Test Points)

Table 6-5 Image Processor Diagnostics -- Rear Panel DIP Switches

Table 6-6 Trace Mode LED Patterns

Cleaning and Maintenance

Figure 7-1 Cleaning the Pick Roller

FRU Disassembly/Assembly

Figure 8-41 Installing RAM Simms (Serial Number B01Xxxx)

Checks and Adjustments

Quick Links

Service Manual

Troubleshooting

Related Manuals for Tektronix Phaser 300i

Summary of Contents for Tektronix Phaser 300i
