OBJ_DOKU-13191-003.fm Page 1 Wednesday, April 8, 2009 2:08 PM
Robert Bosch GmbH
Power Tools Division
70745 Leinfelden-Echterdingen
Germany
www.bosch-pt.com
1 619 929 E56 (2009.04) PS / 320 UNI
GBH Professional
3-28 DRE | 3-28 DFR
de Originalbetriebsanleitung
el Πρωτότυπο οδηγιών χρήσης
en Original instructions
tr Orijinal işletme talimat
fr Notice originale
pl Instrukcja oryginalna
es Manual original
cs Původní návod k používání
pt Manual original
sk Pôvodný návod na použitie
it
Istruzioni originali
hu Eredeti használati utasítás
nl Oorspronkelijke
ru Оригинальное руководст-
gebruiksaanwijzing
во по эксплуатации
da Original brugsanvisning
uk Оригінальна інструкція з
sv Bruksanvisning i original
експлуатації
no Original driftsinstruks
ro Instrucţiuni originale
fi
Alkuperäiset ohjeet
bg Оригинална инструкция
sr Originalno uputstvo za rad
sl Izvirna navodila
hr Originalne upute za rad
et Algupärane kasutusjuhend
lv Instrukcijas oriģinālvalodā
lt
Originali instrukcija
Advertisement
Table of Contents
Related Manuals for Bosch 3-28 DRE
Summary of Contents for Bosch 3-28 DRE
- Page 1 Robert Bosch GmbH Power Tools Division 70745 Leinfelden-Echterdingen GBH Professional Germany www.bosch-pt.com 3-28 DRE | 3-28 DFR 1 619 929 E56 (2009.04) PS / 320 UNI de Originalbetriebsanleitung el Πρωτότυπο οδηγιών χρήσης sr Originalno uputstvo za rad en Original instructions tr Orijinal işletme talimat...
- Page 2 OBJ_BUCH-770-003.book Page 3 Tuesday, April 7, 2009 9:51 AM GBH 3-28 DFR Professional GBH 3-28 DRE Professional 1 619 929 E56 | (7.4.09) Bosch Power Tools...
- Page 3 OBJ_BUCH-770-003.book Page 4 Tuesday, April 7, 2009 9:51 AM (3x) 1 619 929 E56 | (7.4.09) Bosch Power Tools...
- Page 4 OBJ_BUCH-770-003.book Page 5 Tuesday, April 7, 2009 9:51 AM 1 619 929 E56 | (7.4.09) Bosch Power Tools...
-
Page 5: Safety Notes
Loose clothes, jewellery or long hair can the power tool. Keep cord away from be caught in moving parts. heat, oil, sharp edges and moving parts. Damaged or entangled cords increase the risk of electric shock. 1 619 929 E56 | (7.4.09) Bosch Power Tools... -
Page 6: Hammer Safety Warnings
Damaged cables in- hazardous situation. crease the risk of an electric shock. Bosch Power Tools 1 619 929 E56 | (7.4.09) -
Page 7: Functional Description
1 Quick change keyless chuck (GBH 3-28 DFR) 2 SDS-plus quick change chuck (GBH 3-28 DFR) 3 SDS-plus tool holder 4 Dust protection cap 5 Locking sleeve 1 619 929 E56 | (7.4.09) Bosch Power Tools... -
Page 8: Technical Data
OBJ_BUCH-770-003.book Page 21 Tuesday, April 7, 2009 9:51 AM English | 21 Technical Data Rotary Hammer GBH 3-28 DRE GBH 3-28 DFR Professional Professional Article number 3 611 B3A 0.. 3 611 B4A 0.. Speed control Stop rotation Right/left rotation Quick change chuck –... -
Page 9: Noise/Vibration Information
OBJ_BUCH-770-003.book Page 22 Tuesday, April 7, 2009 9:51 AM 22 | English Noise/Vibration Information GBH 3-28 DRE GBH 3-28 DFR Professional Professional Measured values determined according to EN 60745. Typically the A-weighted noise levels of the product are: Sound pressure level... -
Page 10: Declaration Of Conformity
Engineering Certification depth stop correspond with the desired drilling depth X. Selecting Drill Chucks and Tools Robert Bosch GmbH, Power Tools Division D-70745 Leinfelden-Echterdingen Operating Mode Leinfelden, 10.10.2008 Material Assembly Concrete Ø... - Page 11 Inserting the Quick Change Chuck (see figure E) Changing the Key Type Drill Chuck Use only model-specific original equipment (GBH 3-28 DRE) and pay attention to the number of identifi- To work with tools without SDS-plus (e.g., drills cation grooves 18. Only quick-change...
-
Page 12: Changing The Tool
4 is not damaged. Removing Drilling Tools without SDS-plus A damaged dust protection cap should be (GBH 3-28 DRE) changed immediately. We recommend hav- ing this carried out by an after-sales service. Turn the sleeve of the key type drill chuck 15... - Page 13 The vacuum cleaner must be suitable for the material being worked. When vacuuming dry dust that is especially detrimental to health or carcinogenic, use a special vacuum cleaner. 1 619 929 E56 | (7.4.09) Bosch Power Tools...
-
Page 14: Starting Operation
