SUPERNOVA P99-D Instruction Manual

SUPERNOVA P99-D
INSTRUCTION MANUAL
CONGRATULATIONS
The P99-D is the most popular lighting system in 24hr racing. It achieves an optimal, daylight-like beam via
two different reflectors for high- and low beams. Due to microprocessors in the lamp and battery the
Supernova H.I.D. spotlights are extremely long lasting.
Please take the time to carefully read this owner's manual through, before using your new light, so that you
can be sure that you will be able to operate your lamp safely and correctly. We wish you many hours of fun
with your Supernova Lighting System!
PACKAGE CONTENTS - TECHNICAL DATA INHALT - TECHNISCHE DATEN
P99-D XENON H.I.D. headlight
2 x 14 watt high intensity discharge bulbs
Color temperature: 6500 Kelvin
Burn time:
Housing material : polished & anodized aluminium
remote control with deep discharge protection,
battery capacity display, charge display.
Controls version: PMX7.0
Waterproof solid gold connectors
H
orizontally and vertically adjustable mounting
Battery bottle with integrated charger and energy booster
Battery capacity :
Optional battery pack:
Energy booster voltage: 14,5 V
Cell count:
Cell technology:
Integrated charger with temperature sensor
Charger: 8800mAh battery 85% in 2.25 h 100% in 4,25 h
4400mAh battery 85% in 1.5 h
High efficiency power supply for worldwide use.
100-240 Volt / 50-60 Hz.
Up to 3 A charge current.
Optional accessories: Supernova tail light (# E808),
extension cable 1m (# E430 ), helmet mount (# E802),
12 V car charging cable (# E432), center handlebar mount
(#. E780), 4400mAh Kraftwerk battery (# E030).
Accessories can be ordered at www.supernova-lights.com.
ca. 2 hrs @ 28 watts
ca. 4 hrs @ 14 watts
ca. 5h 30min @ 10 watts
8800mAh
4400mAh
6
Lithium Ion
100% in 2.25 h
1
SUPERNOVA P99-D
XENON P99-D
!
IMPORTANT SAFETY FEATURES
1. To avoid unintentional light activation, the battery must be separated from the lamp after use.
2. NEVER open or twist the battery lid. This may damage the seal.
3. The lamp casing can become very hot. Let the casing cool down completely prior to handling.
4. Keep the lamp casing away from flammable materials to avoid unintentional combustion.
5. Carry a back-up light at all times.
6. Unplug the lamp by pulling the plug directly - never pull the cable.
7. Never transport the lamp when the battery is attached.
8. Ensure that the cooling fins of the battery lid is not obstructed while the lamp is in use or charging.
9. Only use the power adapter provided by SUPERNOVA. The car adapter (optional) can only be
used with a 12 volt outlet. Never use 24 volts.
10. Please keep this lighting system out of the reach of children.
11. When using the lighting system attached to your bike, please ensure that the
battery pack is safely secured in the 'water bottle mount.
EXTREMELY BRIGHT!
The SUPERNOVA lighting systems are extremely bright. Never look directly into the lamp, when
in use or while turning it on or off. Particularly when mounted on the helmet, consider the glare to
surrounding people. Due to its extreme light intensity, use of this lamp may be prohibited in some
countries. Please check your country's applicable regulations prior to use.
OTHER IMPORTANT SAFETY INFORMATION
Reduce your speed when the red LED starts flashing. Be prepared that the light will automatically
turn off. Lighting periods listed here are approximations and may vary with the age and
temperature of the battery. This lighting system is completely sealed and has been tested for use
and safety under extreme weather conditions. Nevertheless this lighting system should never be
submerged in water.
2
