1.4.2
Fan Unit
The fan unit generates airflow in the server to suppress temperature increases in the
server. The M3000 server uses 80 mm fan units for the cooling system.
The fan units are redundant, so system operation continues even if one fan unit fails.
If a fan unit fails during system operation, you can replace the faulty fan unit using
active/hot replacement procedures. The failure of the fan units can be detected by
the XSCF.
FIGURE 1-7
FIGURE 1-7
Location No.
1
For information on how to replace the fan unit, see the SPARC Enterprise M3000
Server Service Manual.
1-16
SPARC Enterprise M3000 Server Overview Guide • March 2012
shows the fan unit locations.
Fan Unit Locations
1
Component
Fan unit (FAN_A#0, FAN_A#1)
Maximum Number per Server
2
