Fujitsu Sun Oracle SPARC Enterprise M3000 Overview Manual page 32

State Display by Combination of LEDs on the Operator Panel (Continued)
TABLE 1-7
Name
*
POWER XSCF STANDBY
XSCF
Off On
On On
Blinking On
* READY LED is referred to when the XSCF unit status is indicated.
Note – Some FRUs are equipped with status LEDs. For details of the status LEDs,
see the SPARC Enterprise M3000 Server Service Manual.
1-22 SPARC Enterprise M3000 Server Overview Guide • March 2012
Description
CHECK
Off The XSCF unit is in the standby state.
The server is waiting for power-on of the air
conditioning facilities in the data center.
Off Warm-up standby processing is in progress (power is
turned on after the end of processing).
The power-on sequence is in progress.
The server is in operation.
Off The power-off sequence is in progress.
(The fan units are stopped after the end of processing.)
