DENSITÉ series
FOL-1601
L-Band Fiber Receiver
Guide to Installation and Operation
M830-9800-101
6 May 2008
Miranda
Technologies Inc.
3499 Douglas-B.-Floreani
St-Laurent, Québec, Canada H4S 1Y6
Tel. 514-333-1772
Fax. 514-333-9828
www.miranda.com
© 2008 Miranda Technologies Inc..

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DENSITE FOL-1601 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Miranda DENSITE FOL-1601

  • Page 1 DENSITÉ series FOL-1601 L-Band Fiber Receiver Guide to Installation and Operation M830-9800-101 6 May 2008 Miranda Technologies Inc. 3499 Douglas-B.-Floreani St-Laurent, Québec, Canada H4S 1Y6 Tel. 514-333-1772 Fax. 514-333-9828 www.miranda.com © 2008 Miranda Technologies Inc..
  • Page 2 EN 61000-3-2 & -3-3, Disturbance in Supply Systems EN 61000-4-2, -3, -4, -5, -6, -8 & -11 Electromagnetic Immunity How to contact us: For technical assistance, please contact the Miranda Technical support centre nearest you: Europe, Middle East, Americas Asia...
  • Page 3: Table Of Contents

    GUIDE TO INSTALLATION AND OPERATION Table of Contents FOL-1601 L-Band Fiber Receiver ....................1 Introduction ............................1 Features .............................. 1 Block Diagram............................. 1 Front Card-edge Interface........................2 Installation ..........................3 Unpacking ............................3 Installation in the Densité frame......................3 Rear Panel Connectors........................3 Operation ............................4...
  • Page 4 GUIDE TO INSTALLATION AND OPERATION FOL-1601...
  • Page 5: Fol-1601 L-Band Fiber Receiver

    1 FOL-1601 L-Band Fiber Receiver 1.1 Introduction The FOL-1601 is a fiber optic receiver that allows an L-band satellite signal to be generated from a single mode fiber. The fiber transmission is totally protocol transparent and the FLO-1601 / FOL-1601 maintains high signal fidelity over the whole transmission.
  • Page 6: Front Card-Edge Interface

    GUIDE TO INSTALLATION AND OPERATION 1.4 Front Card-edge Interface The front card-edge of the FOL-1601 incorporates two elements: • Status LED (see section 3.2) • Select Button (see section 3.3) FOL-1601 SELECT button Status LED Figure 1.6 Front card-edge layout...
  • Page 7: Installation

    2.2 Installation in the Densité frame The FOL-1601 and its associated rear connector rear panel must be mounted in a DENSITÉ frame. It is not necessary to switch off the frame’s power when installing or removing the card. See the DENSITÉ Frame manual for detailed instructions for installing cards and their associated rear panels.
  • Page 8: Operation

    3.2 Card-Edge Status LED The status monitor LED is located on the front card-edge of the FOL-1601, and is visible through the front access door of the DENSITÉ frame. This multi-color LED indicates the status of the FOL-1601 by color, and by flashing/steady illumination.
  • Page 9: Local Control Using The Densité Frame Control Panel

    3.3 Local control using the Densité frame control panel 3.3.1 Overview Push the SELECT button on the FOL-1601 card edge (see Section 1.4) to assign the local control panel to operate the FOL-1601. Use the control panel buttons to navigate through the menu, as described below.
  • Page 10 SAVE menu items to select a register (USER 1 to USER 5) and either save the current configuration into that register (SAVE) or reconfigure the FOL-1601 according to the contents of the register (LOAD). CONFIG ALARMS / ALARM LEVEL – for each alarm, set the color that will be displayed on the FOL-1601’s status LED.
  • Page 11: Remote Control Using The Rcp-100

    Please refer to the RCP-100 Guide to Installation and Operation for detailed instructions on installing and operating the RCP-100, and for instructions on how to connect the RCP-100 to the FOL-1601 (or any other supported card) so that the menu can be accessed.
  • Page 12: Specifications

    The output power of the companion FLO-1601 transmitter is +3dBm, so for short-haul circuits with little attenuation it may be necessary to use an optical attenuator at the FOL-1601 input to reduce the incoming power to within the specification. RF Outputs...
