(DENSITÉ) SERIES
DESCRIPTION
The SDA-1141 is a reclocked serial digital video
distribution amplifier with analog video
monitoring outputs. The SDA-1141 handles V-bit
and provides 5 reclocked outputs and 4
copmposite analog video monitoring outputs; it
also provides automatic equalization for up to 350
meters of cable (Belden 1694A), and signal
presence detection and remote reporting. The
SDA-1141 includes reclocking, providing an
additional level of signal integrity in longcable
length applications. The SDA-1141 supports serial
digital video (SMPTE 259M) at 270 Mbps. The SDA-
1141 is designed to be used in a DENSITÉ frame. A
"single" or "double" rear connector panel is
required.
FUNCTIONAL BLOCK DIAGRAM
Input
Re-
Auto
Digital Video
E Q clocker
Attention
Microcontroller
Status
SPECIFICATIONS SPECIFICATIONS
SPECIFICATIONS SPECIFICATIONS
INPUT
Signal: SMPTE-259M-C (270 Mbps)
Cable length: 350 m (1148') @ 270Mbps for
Belden 1694A
Return loss: > 15 dB up to 270 Mbps
SDA-1141
Outputs
1
2
D/A
S D I
3
&
N T S C /
P A L
4
Encoder
5
1
2
M O N
3
4
Remote
SDA-1141 Reclocked Digital Video DA with Monitoring
Guide to Installation and Operation
FEATURES
•
(1) 75Ω isolated Digital video input
•
(9) 75Ω Digital video outputs
•
Auto-detects 525 or 625-line format
•
Compatible with SMPTE-259M-C (270 Mbps)
digital video signals
•
Compatible with DVB-ASI (270 Mbps)
•
Reclocking of outputs
•
Signal presence detection and remote
reporting
•
Automatic cable equalization.
SPECIFICATIONS (cont'd) SPECIFICATIONS (cont'd) SPECIFICATIONS (cont'd) SPECIFICATIONS (cont'd)
DIGITAL OUTPUTS
Signal (5):
Return loss:
Jitter (wideband):
ANALOG OUTPUTS
Signal (4):
Return Loss:
PROCESSING PERFORMANCE
Digital Digital
Digital Digital
Signal path:
Processing delay:
Analog Analog
Analog Analog
Quantization:
Sampling:
Freq. Response:
Noise (unweighted):
Processing Delay:
VBI:
Power: Power: Power: Power:
SDA-1141
M458-9900-100
March 2002
SMPTE-259M-C (270 Mbps)
> 15 dB for up to 270 Mbps
< 0.2 UI p-p
NTSC (525/60) SMPTE 170M
PAL-M (525/60) ITU R BT.470-6
PAL-N (625/50) ITU R BT.470-6
>35 dB up to 5.75 MHz
10 bits
10.5 ns
10 bits
27 MHz (2X oversampling)
±0.5 dB to 4.2 MHz
<54 dB to 5.75 MHz
1.4 µs
passed
1.5 W (single), 2 W (double)
