- Page 1 DENSITÉ series Densité 2 Housing Frame Guide to Installation and Operation M624-9900-102 22 May 2012 Miranda Technologies Inc 3499 Douglas-B.-Floreani St-Laurent, Québec, Canada H4S 2C6 Tel. 514-333-1772 Fax. 514-333-9828 www.miranda.com © 2012 Miranda Technologies Inc.
- Page 2 Guide to Installation and Operation SAFETY COMPLIANCE This equipment complies with: CSA C22.2 No. 60950-1 Safety of Information Technology Equipment UL 60950-1 Safety of Information Technology Equipment IEC 60950-1 Safety of Information Technology Equipment WARNING An appropriately listed/certified mains supply power cord must be used for the connection of the equipment to the mains voltage at either 120V~ or 240V~.
-
Page 3: Table Of Contents
Guide to Installation and Operation Table of Contents 1 Densité 2 Housing Frame ..................... 1 1.1 Introduction .............................. 1 1.2 Features ..............................1 1.3 Physical Layout ............................2 2 Installation ........................3 2.1 Unpacking ..............................3 2.2 Mechanical Installation ..........................3 2.3 Opening the Front Panel .......................... - Page 4 Guide to Installation and Operation CONTACT MIRANDA For technical assistance, please contact the Miranda Technical support centre nearest you: Americas Asia Europe, Middle East, Africa, UK Telephone: Telephone: Telephone: +1-800-224-7882 +852-2539-6987 +44 118 952 3444 e-mail: e-mail: e-mail: support@miranda.com asiatech@miranda.com eurotech@miranda.com...
-
Page 5: Densité 2 Housing Frame
Guide to Installation and Operation 1 Densité 2 Housing Frame 1.1 Introduction The Densité 2 Frame is a 2-RU housing frame, designed for high density and low cost. The basic configuration includes one power supply unit, and a basic controller card with front panel controls for card adjustments. Up to 20 cards can be installed within a single frame. -
Page 6: Physical Layout
Guide to Installation and Operation 1.3 Physical Layout Front Panel Appearance Status LEDs (Cards 1-10) Controller Status LED Status LEDs (Cards 11-20) Note the openings in the panel (numbered 1 to 20) which allow the status LEDs on the installed cards to be seen while the panel door is closed. -
Page 7: Installation
Guide to Installation and Operation 2 Installation 2.1 Unpacking Make sure the following items have been shipped with your Densité 2 frame: - Densité 2 frame, including 1 Power Supply unit (AC in), - 1 basic controller card - An AC power cord - Densité... -
Page 8: Installing Cards In The Densité 2 Frame
Guide to Installation and Operation 2.4 Installing Cards in the Densité 2 Frame Each card comes with a rear connector panel which must be installed at the same time. All cards and rear panels can be installed with the frame power on. The card has connectors which plug into a mid-frame mother board for distribution of power and for connection to the controller card, and a second connector which plugs directly into the rear connector panel for input and output. -
Page 9: Ventilation
Guide to Installation and Operation 2.5 Ventilation Ventilation for the frame is provided by a two fans mounted in the center of the rear panel, one behind each of the two power supply slots. These fans draw air through the frame and exhaust it to the rear. Ventilation slots are provided in the front panel to allow air to flow into the frame, and an air filter is mounted in the frame door. -
Page 10: Field-Serviceable Items
Guide to Installation and Operation 3 Field-Serviceable Items 3.1 Changing the Power Supply The Densité 2 frame supports dual redundant hot-swappable power supplies. The basic configuration includes a single supply, plus an empty slot for the optional redundant power supply. Installing a second power supply module and applying power to it automatically engages the redundant supply mode. -
Page 11: Replacing Or Upgrading The Controller Card
In case of failure of one of the two cooling fans on the rear of the frame, replace it by following these steps: 1. Procure a replacement fan. It is available from Miranda as part #0624-1200-100 2. Remove the defective fan from the frame: •... -
Page 12: Specifications
Guide to Installation and Operation 4 Specifications MECHANICAL Dimensions: 2RU x 19” W (485 mm) x 11.25” D (286 mm) with connectors Weight: 7 lbs (3.2 kg) with 1 PSU and no cards installed POWER Input Range: AC 96-264V, 60-50 Hz Rating: 300 W max Operating Temp.
