User's Manual and Important Safety Information
Model: OC-1204A (12 Volt – 4 Amp) – Suits Golf Carts
FEATURES
The OzCharge OC-1204A Battery Chargers comprise of the latest microprocessor controlled technology
and they include the following features:
•
High frequency Switching Mode
•
Full time pulse charge output
•
Microprocessor controlled with safety timers at every stage.
•
Heavy-duty cables with Anderson PP30 Type Connector
•
Designed for Australian & New Zealand Conditions.
- - - - - - - - - - - - - - - - - - -
•
This charger is designed for indoor use only and should never be exposed to rain.
•
Do not attempt to use the charger if it has been dropped or damaged.
•
Never attempt to charge a damaged battery, frozen battery or non-rechargeable battery.
•
Do not use the charger in a closed area or poorly-ventilated area.
•
Never smoke, use an open flame, or create sparks near a battery or charger during charging
operation as this may cause an explosion / explosive gas.
•
Do not operate the charger if the cord or plug is damaged.
•
Do not disassemble the charger. Take it to a qualified person if a repair is required.
•
Must not be used or played with by infirm persons or children.
•
Switch off the mains power supply before connecting or disconnecting the unit to a Battery.
Automatic Battery Charger
Switching mode with Micro-controlled
Input: 220-260Vac / Output: 24Volt DC
WARNING
- - - - - - - - - - - - - - - - - - - - -
OC-1204A User's Manual - Rev 1.0
Advertisement
Related Manuals for OZ Charge OC-1204A
Summary of Contents for OZ Charge OC-1204A
- Page 1 User’s Manual and Important Safety Information Model: OC-1204A (12 Volt – 4 Amp) – Suits Golf Carts FEATURES The OzCharge OC-1204A Battery Chargers comprise of the latest microprocessor controlled technology and they include the following features: • High frequency Switching Mode •...
-
Page 2: Operating Instructions
(GREEN Full / Float LED ON) 3. Disconnecting the Battery charger from Battery. (a) Switch OFF and Remove the AC Power Socket from the outlet. (b) Disconnect the charger lead from the battery. OC-1204A User’s Manual - Rev 1.0... -
Page 3: Trouble Shooting
Full is ON - 4 hours Soft Start timed out - Battery cannot be charged and must light does not - 16 hours Bulk Charge timed out be replaced. come on CHARGING CURVE (VOLTAGE) OC-1204A User’s Manual - Rev 1.0... -
Page 4: Specifications
This Warranty is void if: 1. The product has been tampered or repaired by unauthorised personnel. 2. The warranty seal is broken or altered. 3. The warranty period has expired. OC-1204A User’s Manual - Rev 1.0...
