NL4 chassis connectors for
speaker connections
NOTICE!
Possible property damage by magnetic fields
Loudspeakers produce a static magnetic field. Therefore, maintain an appropriate
distance to devices that can be adversely affected or damaged by an external
magnetic field.
The drawing alongside shows the pin assignment of the lockable NL4 chassis connectors.
Pyrit 212 Sub
Installation
11
