Summary of Contents for The box CL 112
- Page 1 CL 112 / CL 115 / CL 118 Sub MKII active subwoofer user manual...
- Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 23.10.2015, ID: 341323, 341324, 341325...
-
Page 3: Table Of Contents
Safety instructions............................. 8 Features............................... 12 Installation..............................13 4.1 Tips on handling speakers......................15 Connections and operating elements................... 16 Technical specifications........................20 Plug and connection assignments....................22 Protecting the environment......................26 CL 112 / CL 115 / CL 118 Sub MKII... -
Page 4: General Information
General information General information This manual contains important instructions for the safe operation of the unit. Read and follow the safety instructions and all other instructions. Keep the manual for future reference. Make sure that it is available to all those using the device. If you sell the unit please make sure that the buyer also receives this manual. -
Page 5: Further Information
Online guides and terms. Personal consultation For personal consultation please contact our technical hotline. If you have any problems with the device the Service customer service will gladly assist you. CL 112 / CL 115 / CL 118 Sub MKII... -
Page 6: Notational Conventions
General information 1.2 Notational conventions This manual uses the following notational conventions: Letterings The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. - Page 7 This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in material and environmental damage if it is not avoided. Warning signs Type of danger Warning – high-voltage. Warning – danger zone. CL 112 / CL 115 / CL 118 Sub MKII...
-
Page 8: Safety Instructions
Safety instructions Safety instructions Intended use This device is intended to be used in a sound reinforcement system. Use the device only as described in this user manual. Any other use or use under other operating conditions is consid‐ ered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use. - Page 9 Do not modify the mains cable or the plug. Failure to do so could result in electric shock/death or fire. If in doubt, seek advice from a regis‐ tered electrician. CL 112 / CL 115 / CL 118 Sub MKII...
- Page 10 Safety instructions CAUTION! Possible hearing damage The device can produce volume levels that may cause temporary or permanent hearing impairment. Over an extended period of time, even levels that seem to be uncritical can cause hearing damage. Decrease the volume level immediately if you experience ringing in your ears or hearing impairment.
- Page 11 Unplug the device before electrical storms occur and when it is unused for long periods of time to reduce the risk of electric shock or fire. CL 112 / CL 115 / CL 118 Sub MKII...
-
Page 12: Features
Features Features Special features of the device: Inputs: XLR and 1/4" phone sockets, RCA sockets (CL 115 and CL 118) Outputs: NL4 chassis connectors for passive speaker boxes (top), DIRECT OUT (CL 115 and CL 118) 36 mm pole mount flange Butterfly handles Transport casters PU coating... -
Page 13: Installation
Establish all connections as long as the unit is switched off. Use the shortest possible high- quality cables for all connections. CL 112 / CL 115 / CL 118 Sub MKII... - Page 14 Installation CAUTION! Risk of injury due to heavy weight Due to the heavy weight of the device, at least two persons are required for trans‐ port and installation. NOTICE! Possible property damage by magnetic fields Loudspeakers produce a static magnetic field. Therefore, maintain an appropriate distance to devices that can be adversely affected or damaged by an external magnetic field.
-
Page 15: Tips On Handling Speakers
If you notice distortion during operation, either the amp or the speaker is overloaded. This may permanently damage the amp or the speaker. Always reduce the volume when you hear dis‐ tortion. CL 112 / CL 115 / CL 118 Sub MKII... -
Page 16: Connections And Operating Elements
Connections and operating elements Connections and operating elements Rear panel CL 112 SUB MKII active subwoofer... - Page 17 Connections and operating elements Rear panel CL 115 SUB MKII, CL 118 SUB MKII CL 112 / CL 115 / CL 118 Sub MKII...
- Page 18 Connections and operating elements 1 Mains switch [POWER] Turns the device on and off. 2 IEC chassis plug with fuse holder for the power supply. 3 [SAT POWER OUT RIGHT | LEFT] Speaker outputs (NL4 chassis connectors). 4 [INPUT RIGHT | LEFT] Inputs for balanced or unbalanced line level signals (XLR sockets).
- Page 19 11 [INPUT RIGHT | LEFT] Inputs for balanced or unbalanced line level signals (XLR / 1/4" combo sockets). 12 [DIRECT OUT] Outputs for connecting the subwoofer to another active sound system. CL 112 / CL 115 / CL 118 Sub MKII...
-
Page 20: Technical Specifications
Technical specifications Technical specifications CL 112 SUB MKII (item CL 115 SUB MKII (item CL 118 SUB MKII (item no. 341323) no. 341324) no. 341325) System Active subwoofer Active subwoofer Active subwoofer Speakers 1 × 12" woofer 1 × 15" woofer 1 ×... - Page 21 420 mm × 475 mm × 500 mm 460 mm × 565 mm × 610 mm 540 mm × 620 mm × 660 mm (W × D × H) Weight 29 kg 40 kg 47 kg CL 112 / CL 115 / CL 118 Sub MKII...
-
Page 22: Plug And Connection Assignments
Plug and connection assignments Plug and connection assignments Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’... - Page 23 The result is a pure signal without any noise inter‐ ference. 1/4" TS phone plug (mono, unbalanced) Signal Ground, shielding 1/4" TRS phone plug (mono, bal‐ anced) Signal (in phase, +) Signal (out of phase, –) Ground CL 112 / CL 115 / CL 118 Sub MKII...
- Page 24 Plug and connection assignments 1/4" TRS phone plug (stereo, unbalanced) Signal (left) Signal (right) Ground XLR plug (balanced) Ground, shielding Signal (in phase, +) Signal (out of phase, –) active subwoofer...
- Page 25 Plug and connection assignments XLR plug (unbalanced) Ground, shielding Signal Bridged to pin 1 NL4 connections 1, + Signal 1 (in phase) 1, – Signal 1 (out of phase) CL 112 / CL 115 / CL 118 Sub MKII...
-
Page 26: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 28 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
