PA 18 ECO SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this device near water. 6) Clean only with a dry cloth. 7) Be sure to mount your speakers on a solid, stable and level base or stand. Vibrating floors do not provide reliable support for speaker enclosures or stacks.
Page 3
PA 18 ECO 1. CONNECTIONS Connections Two ¼ loudspeaker inputs are wired in parallel. You can alternatively connect one of the connectors to the output on your power amp and tap into the signal from the amp once again on the second connector, in order to feed this signal into an additional loudspeaker.
A high-to-mid-range box is connected to each of the amp outputs. The mono subwoofer signal is connected to one channel of an additional power amplifier, which powers one PA 18 ECO subwoofer. Stereo operation with a subwoofer DATA-MANFULL_PA18_ECO_ENG_Rev_A.PMD...
PA 18 ECO 4. SPECIFICATIONS ` U@HÃ96U6 Q6Ã 'Ã@8P Type Subwoofer Frequency response 45 Hz - 400 Hz Power rating (Peak program) 700 W Impedance Sound pressure level (1 W @ 1 m) 98 dB (Full Space) Dispersion Crossover frequency...
