480V
AUTO-CUT 300 XT
™
PLASMA CUTTING SYSTEM
Operating
Manual
Revision: AC Issue Date: January 16, 2014
Manual No.: 0-5300
VictorThermalDynamics.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AUTO-CUT 300 XT and is the answer not in the manual?

Questions and answers

Related Manuals for Victor AUTO-CUT 300 XT

Summary of Contents for Victor AUTO-CUT 300 XT

  • Page 1 480V AUTO-CUT 300 XT ™ PLASMA CUTTING SYSTEM Operating Manual Revision: AC Issue Date: January 16, 2014 Manual No.: 0-5300 VictorThermalDynamics.com...
  • Page 2 WE APPRECIATE YOUR BUSINESS! Congratulations on your new Victor Thermal Dynamics product. We are proud to have you as our customer and will strive to provide you with the best service and reliability in the industry. This product is backed by our extensive warranty and world-wide service network. To locate your nearest distribu- tor or service agency call 1-800-426-1888, or visit us on the web at www.thermal-dynamics.com.
  • Page 3 Manufacturer assumes no liability for its use. Plasma Cutting Power Supply, Auto-Cut 300 XT™ ® Operating Manual No. 0-5300 Published by: Victor Technologies 82 Benning Street West Lebanon, New Hampshire, USA 03784 (603) 298-5711 www.thermal-dynamics.com © Copyright 2013 by Victor Technologies All rights reserved.
  • Page 4 This page intentionally blank...

  • Page 5: Table Of Contents

    TABLE OF CONTENTS SECTION 1: GENERAL INFORMATION ....................1-1 1.01 Notes, Cautions and Warnings ..............1-1 1.02 Important Safety Precautions ..............1-1 1.03 Publications....................1-2 1.04 Note, Attention et Avertissement ..............1-3 1.05 Precautions De Securite Importantes ............1-3 1.06 Documents De Reference ................1-5 1.07 Declaration of Conformity ................1-6 1.08 Statement of Warranty ................1-7 SECTION 2: SPECIFICATIONS ....................2-1...
  • Page 6 TABLE OF CONTENTS SECTION 5: MAINTENANCE....................5-1 5.01 General Maintenance .................5-1 5.02 Coolant Filter Cleaning Procedure ..............5-1 5.03 Coolant Replacement Procedure ..............5-2 5.04 Arc Starter Service ..................5-3 5.05 Arc Starter Spark Gap Adjustment .............5-4 SECTION 6: REPLACEMENT ASSEMBLIES & PARTS ............6-1 6.01 Replacement Power Supply ................6-1 6.02...
  • Page 7 TABLE OF CONTENTS APPENDIX 13: SUPPRESSOR PCB LAYOUT ..............A-30 APPENDIX 14: COOLING DIAGRAM .................. A-31 APPENDIX 15: SYSTEM SCHEMATIC PG 1 ............... A-32 APPENDIX 16: SYSTEM SCHEMATIC PG2 ................ A-34 APPENDIX 17: ADVANCED TROUBLESHOOTING ............A-36 APPENDIX 18: PUBLICATION HISTORY ................A-74...
  • Page 8 TABLE OF CONTENTS...

  • Page 9: General Information

    AUTO-CUT 300 XT SECTION 1: GENERAL INFORMATION GASES AND FUMES Gases and fumes produced during the plasma cutting process can be dangerous and hazardous to your health. 1.01 Notes, Cautions and Warnings • Keep all fumes and gases from the breathing area. Keep your Throughout this manual, notes, cautions, and warnings are used to head out of the welding fume plume.

  • Page 10: Publications

    AUTO-CUT 300 XT * These values apply where the actual arc is clearly seen. Experience has shown that lighter filters may be used when the arc is hidden by the workpiece. FIRE AND EXPLOSION Fire and explosion can be caused by hot slag, sparks, or the plasma arc.

  • Page 11: Note, Attention Et Avertissement

    AUTO-CUT 300 XT 1.05 Precautions De Securite Importantes 12. CSA Standard W117.2, CODE FOR SAFETY IN WELDING AND CUTTING, obtainable from the Canadian Standards As- sociation, Standards Sales, 178 Rexdale Boulevard, Rexdale, Ontario, Canada M9W 1R3 AVERTISSEMENTS 13. NWSA booklet, WELDING SAFETY BIBLIOGRAPHY obtainable L’OPÉRATION ET LA MAINTENANCE DU MATÉRIEL...
  • Page 12 AUTO-CUT 300 XT • Pour protéger vos yeux, portez toujours un casque ou un écran • Ce produit, dans le procéder de soudage et de coupe, produit de de soudeur. Portez toujours des lunettes de sécurité munies de la fumée ou des gaz pouvant contenir des éléments reconnu dans parois latérales ou des lunettes de protection ou une autre sorte L’état de la Californie, qui peuvent causer des défauts de naissance de protection oculaire.

  • Page 13: Documents De Reference

    AUTO-CUT 300 XT 1.06 Documents De Reference 8. Norme 51 de l’Association Américaine pour la Protection contre les Incendies (NFPA), LES SYSTEMES À GAZ AVEC ALIMENTATION EN OXYGENE POUR LE SOUDAGE, LA COUPE ET LES PROCÉDÉS Consultez les normes suivantes ou les révisions les plus récentes ayant ASSOCIÉS, disponible auprès de la National Fire Protection As-...

  • Page 14: Declaration Of Conformity

    Rigorous testing is incorporated into the manufacturing process to ensure the manufactured product meets or exceeds all design specifi cations. Victor Technologies. has been manufacturing products for more than 30 years, and will continue to achieve excellence in our area of manufacture.
  • Page 15 AUTO-CUT 300 XT Classification: The equipment described in this manual is Class A and intended for industrial use. WARNING This Class A equipment is not intended for use in residential locations where the electrical power is provided by the public low- voltage supply system. There may be potential difficulties in ensuring electromagnetic compatibility in those locations, due to conducted as well as radiated disturbances.

  • Page 16: Statement Of Warranty

    AUTO-CUT 300 XT 1.08 Statement of Warranty LIMITED WARRANTY: Victor Thermal Dynamics Corporation (hereinafter “Thermal”) warrants that its products will be free of defects in ® workmanship or material. Should any failure to conform to this warranty appear within the time period applicable to the Thermal products as stated below, Thermal shall, upon notification thereof and substantiation that the product has been stored, installed, operated, and maintained in accordance with Thermal’s specifications, instructions, recommendations and recognized standard industry practice, and...

  • Page 17: Section 2: Specifications

    AUTO-CUT 300 XT SECTION 2: SPECIFICATIONS 2.01 General Description Of The System A typical Auto-Cut 300 XT™ plasma cutting system includes: • One Power Supply • General Purpose Plasma Cutting Torch with Connecting Leads • Torch Spare Parts Kit The components are connected at installation.

  • Page 18: Power Supply Specifications & Electrical Requirements

    AUTO-CUT 300 XT 2.05 Power Supply Specifications & Electrical Requirements Auto-Cut 300 XT™ Specifications & Design Features Max OCV (U0) 425 vdc Minimum Output Current 5 Amps Max Output Current 300 Amps Output Voltage 60 - 180 vdc 300 Amp System...

  • Page 19: Power Supply Dimensions

    AUTO-CUT 300 XT 2.06 Power Supply Dimensions 55 inch 1397 mm 40.6 inch 1031.2 mm 610 lb / 277 kg 27.5 inch 698.5 mm Art # A-11918 Manual 0-5300 SPECIFICATIONS...

  • Page 20: Power Supply Rear Panel Features

    AUTO-CUT 300 XT 2.07 Power Supply Rear Panel Features J56 Gas Control J58 Arc Starter Gas Selection Switch Plasma Gas - In System Earth Water - In Ground Shield Gas - In Customer C.C.M. Optional Port J55 To Gas Control...

  • Page 21: Gas Requirements

    The customer will provide all gases and pressure regulators. Gases must be of high quality. Pressure regulators shall be equipped with stainless-steel diaphragms and installed as close as possible to the Gas Console. Auto-Cut 300 XT™ Power Supply: Gas Pressures, Flows, and Quality Requirements Quality...

  • Page 22: Xt Tm -301 Torch Specifications

    AUTO-CUT 300 XT 2.10 XT -301 Torch Specifications A. Torch Dimensions Art # A-11538 End Cap 19" 2.25" 482.7 mm 57.15 mm Mounting Tube 2.0" 15.5" 50.8 mm 393.8 mm 6.3" 160.1 mm 2.4" 61 mm 3.98" 101.1 mm 2.7"...
  • Page 23 AUTO-CUT 300 XT C. Torch Parts (Generic Parts Shown) Cartridge Shield Retainer Assemble First Art # A-11915 D. Parts - In - Place (PIP) The torch is designed for use with a power supply which senses coolant return flow to confirm that torch parts are in place.
  • Page 24 AUTO-CUT 300 XT E. Type Cooling Combination of gas stream through torch and liquid cooling. F. XT -301 Torch Data (with Auto-Cut 300 XT™ Power Supply) -301 Torch Ratings (when used with Auto-Cut 300 XT™Power Supply) Ambient 104° F Temperature 40°...

  • Page 25: Section 3: Installation

    Cooling System Requirements Coolant must be added to the system on installation. The amount required varies with torch leads length. Victor Thermal Dynamics recommends the use of its coolants 7-3580 and 7-3581 (for low temperatures). Coolant Capabilities Cat. Number and Mixture...

  • Page 26: Cables And Leads Identification

    AUTO-CUT 300 XT 3.02 Cables and Leads Identification Refer to section 3.05 and 3.06 for ground connections and ground cables. Arc Starter / Gas Control Module G: Torch Lead Set, Shielded (GCM-1000XT) - Coolant Supply Pilot Return w/ Negative Control...

  • Page 27: Cables & Leads Identification

    AUTO-CUT 300 XT 3.03 Cables & Leads Identification #8 AWG Cable Pilot Return, Power Supply to Arc Starter 2/0 (70 mm ) Cable Negative Lead, Power Supply to Arc Starter Green Green Coolant Leads, Power Supply to Arc Starter Control Cable, Power Supply...

  • Page 28: Position The Power Supply

    AUTO-CUT 300 XT 3.04 Position the Power Supply WARNINGS Do not touch live electrical parts. Disconnect input power conductors from de-energized supply line before moving unit. FALLING EQUIPMENT can cause serious personal injury and equipment damage. Use the lifting eye when using straps to lift the power supply.

  • Page 29: Connect Input Power And Ground Cables

    AUTO-CUT 300 XT 3.05 Connect Input Power and Ground Cables Connect Input Power and System Ground Cables 1. Remove the input power cover to the right of the coolant filter at the rear of the power supply. To do this remove the two screws then lift up and pull away.

  • Page 30: Connect Work Cable To Power Supply

    AUTO-CUT 300 XT 3.06 Connect Work Cable to Power Supply 1. Remove the output power cover to the left of the coolant filter at the rear of the power supply. To do this remove the two screws then lift up and pull away.

  • Page 31: Ground Connections

    For Victor Thermal Dynamics components it is recommended to use a minimum of 10 AWG (European 6 mm wire or flat copper braid with cross section equal to or greater than 10 AWG connected to the cutting table frame.
  • Page 32 AUTO-CUT 300 XT C. Creating An Earth Ground 1. To create a solid, low resistance, earth ground, drive a 1/2 in (12 mm) or greater diameter copper clad ground rod at least 6 - 8 ft (1.8 - 2.4 m) into the earth so that the rod contacts moist soil over most of its length. Depend- ing on location, a greater depth may be required to obtain a low resistance ground (see NOTE).

  • Page 33: Connect Gas And Coolant Supply Lines

    AUTO-CUT 300 XT 3.09 Connect Gas and Coolant Supply Lines 1. Connect the gas supply lines to the appropriate input ports as shown, upper left. NOTE Coolant lines are factory installed. If attaching optional HE400 see subsection 3.14 Plasma Gas - In...

  • Page 34: Cables For Cnc, Arc Starter/Gas Control

    AUTO-CUT 300 XT 3.10 Cables for CNC, Arc Starter/Gas Control 1. Connect one end of each cable to the power supply. Some cables shown are options and may not apply to your system. 2. Connect the other end of the CNC cable to the CNC device.

  • Page 35: Set Switches On The Command - Control Module

    AUTO-CUT 300 XT 3.11 Set Switches on the Command - Control Module Remove the power supply upper right side. Set switches on the CCM (Command-Control Module) per the illustra- tions. Switch settings and connection details are provided in the Appendix. Any changes made require a restart of the power supply.
  • Page 36 AUTO-CUT 300 XT CAUTION Printed circuit boards in the Command-Control Module are static sensitive. Discharge any built-up static charges in your body or surroundings before touching the printed circuit boards. SW11 SW12 SW13 SW-6: OK-to-Move: Contact closure, 120VAC @ 1A (Factory default setting) or DC Volts (16-18vdc@ up to 100 ma.)

  • Page 37: Height Control Connections

    AUTO-CUT 300 XT 3.12 Height Control Connections The terminal strip has Arc Volts (-) connection to power supply negative output TORCH terminal, Arc Volts (+) connection to power supply positive output WORK terminal. These are for a height control that requires connection to the full non-divided arc voltage.

  • Page 38: Connect Torch Leads To The Gas Control Module / Arc Starter

    AUTO-CUT 300 XT 3.13 Connect Torch Leads to the Gas Control Module / Arc Starter 1. Remove the top cover from the Gas Control Module / Arc Starter. 2. Pass the torch leads and coolant leads through the torch leads port on the back of the module. Ensure that the leads outer jacket slides into the port.
  • Page 39 AUTO-CUT 300 XT Coolant Return Coolant Supply Connection (Tagged Red) Connection (Tagged Green) Plasma Gas Connection Shield Gas Connection Torch Leads Art # A-04832 5. Fold the end of the leads outer jacket back over the connection ring inside the module. Slide the leads clamp over the jacket and fasten the clamp and jacket to the connection ring.

  • Page 40: Torch Head Installation And Connection

    AUTO-CUT 300 XT 3.14 Torch Head Installation and Connection Install the Torch as follows: 1. Install the torch mounting block on the cutting table (gantry). Fasten the block in place. 2. Leave the end cap in place on the torch leads. Remove and discard the protective end caps from the Mount- ing Tube.

  • Page 41: Install Consumable Torch Parts

    AUTO-CUT 300 XT 5. Slide the positioning tube down to the torch head. Hold the torch head stationary. Rotate the positioning tube onto the torch head. Pull the leads back as needed to ensure a proper fit through the Mounting Tube.
  • Page 42 AUTO-CUT 300 XT 1: Stack Parts 2: Press Cartridge onto Stacked Parts Electrode Plasma Gas Distributor O-Ring on Tip No Gaps Between Parts Shield Gas Cartridge Covers Distributor O-Ring on Torch Tip Shield Cap 4: Check Shield Cap Protrusion 3: Thread Shield Cup onto Cartridge...
  • Page 43 AUTO-CUT 300 XT Cartridge Tool Assembled Cartridge Art # A-04344_AB Shield Cup Installing Shield Cup Onto Cartridge 6. Take the removal tool off the cartridge. Fit the cartridge assembly onto the torch head. The cartridge should seal to the large O-ring on the torch body as shown. If the cartridge does not seal on the O-ring, the cartridge is not fully tightened.
  • Page 44 AUTO-CUT 300 XT 7. Confirm proper parts assembly as shown. Torch Head Torch Head O-Ring 0.063 - 0.083" (1.6 - 2.1 mm) Protrusion Art # A-07202 8. Slide the ohmic clip over the shield cup if using ohmic torch height sensing.

  • Page 45: Voltage Divider For Ihc Torch Height Control

    Cutting tables use a Torch Height Control (THC), also called a Z axis control, most of which use feedback from the arc voltage to control the height. Several of these, including the iHC, part of the Victor Technologies XT CNC Controller, come with a Voltage Divider Printed Circuit Board that has to be installed inside the plasma power supply to divide the high arc voltage down to lower levels for use with control circuits.

  • Page 46: Control Cable

    AUTO-CUT 300 XT Control Cable. The iHC board can be supplied with a wire harness and connector (shown in previous image), to be installed in the rear panel hole labeled “Height Control” . The connector mates with a cable from the iHC. For other height control V-D boards a strain relief can be installed in this hole for those cables.

  • Page 47: 3:17 Fill Cooling System

    AUTO-CUT 300 XT 3:17 Fill Cooling System 1. Fill the coolant tank to the level shown, with Thermal Dynamics coolant. The coolant level is visible through the translucent coolant tank. The amount of coolant required varies with torch leads length.
  • Page 48 AUTO-CUT 300 XT e. Repeat steps ‘b’ through ‘d’ until the system no longer shuts down. Depending on the length of the torch leads this sequence may need to be done three to five times. f. After the system stays operational allow the...

  • Page 49: Section 4: Operation

    AUTO-CUT 300 XT SECTION 4: OPERATION 4.01 Power Supply Indicators AC Indicator Gas Indicator Status Indicator Temp Indicator DC Indicator Art # A-11909 AC Power Lamp Indicates unit has passed the input power tests and AC power is being supplied to the inverter modules via the input contactor when the ON/OFF switch is in ON position.

  • Page 50: Control Console Features

    AUTO-CUT 300 XT 4.02 Control Console Features Art # A-11917 Shield Gas Plasma Gas Pressure Gauge Pressure Gauge Run / Set Selector Amperage PLASMA SHIELD Selector SHIELD GAS H 2 0 MIST H 2 0 MIST GCM 1000 XT GAS CONTROL MANAGEMENT SYSTEM...

  • Page 51: System Operation

    AUTO-CUT 300 XT 4.03 System Operation This section contains operating information which is specific to the power supply. WARNINGS Frequently review the safety precautions in Section 1. If the power supply cord has a plug or is not permanently connected to power, be sure the power to the outlet is disconnected when inserting the plug into the outlet.
  • Page 52 AUTO-CUT 300 XT 3. Set Gas Pressures a. Place RUN/SET switch in SET mode. b. Adjust plasma and shield pressure regulators to correct pressure or correct flow if using H O Mist option. (refer to cut chart manual for required pressure/flow.) c.

  • Page 53: Gas Selection

    AUTO-CUT 300 XT 3. Use care in handling torch leads and protect them from damage. 4. When using water as the shield note the following: • Use clean drinking quality tap water to help prevent particulate build-up within the system water shield plumbing.

  • Page 54: Power Supply Status Codes

    AUTO-CUT 300 XT • Normally used with nitrogen. • Provides very smooth cut surface. • Reduces smoke and heat input to the workpiece. • Effective up to 1/2 inch (12.7 mm) maximum material thickness. • Tap water provides low operating expense.
  • Page 55 AUTO-CUT 300 XT CCM Status Code Group 2 -- Plasma Power Supply Code Message Remedy / Comments Missing AC Phase Blown fuse, Bad power cable connection; Defective System Bias PCB Not used Reserved for legacy product Not used Reserved for legacy product Not used Reserved for legacy product Less than 60 VDC; Negative lead short to work or ground; Defective inverter (output DC Output Low shorted); CCM voltage sense (J24) disconnected or wire broken; Defective CCM.
  • Page 56 AUTO-CUT 300 XT Code Message Remedy / Comments Inverter 1A Incom- Unsupported Inverter Revision; Ribbon cable CCM J31 to Inverter Module 1 Section A dam- patible Revision aged; CCM code version incompatible with Inverter revision or model Inverter 1B Incom- Unsupported Inverter Revision; Ribbon cable CCM J32 to Inverter Module 1 Section B dam- patible Revision aged ; CCM code version incompatible with Inverter revision or model Inverter 2A Incom- Unsupported Inverter Revision; Ribbon cable CCM J33 to Inverter Module 2 Section A dam- patible Revision aged; CCM code version incompatible with Inverter revision or model Not used Reserved for other model with another inverter section Inverter 3A Incom- Unsupported Inverter Revision; Ribbon cable CCM J35 to Inverter Module 3 Section A dam-...
  • Page 57 AUTO-CUT 300 XT Code Message Remedy / Comments Not used Reserved for other model with another inverter section Inverter Input Voltage fault; voltage out of range or missing phase at AC Input of Inverter Inverter 3A Input Module 3 Section A; Poor AC Power Quality; Defective W2 contactor; Loose or open connec- Voltage Error tion between input terminals and W2 contactor or contactor and input of Inverter Section;...
  • Page 58 AUTO-CUT 300 XT Code Message Remedy / Comments Inverter 2A No Input Inverter section may have no input power. Contactor W1 not closed; Defective contactor or CB4 Power tripped; Inverter section input not connected; Defective Inverter. Inverter 2B No Input Inverter section may have no input power.
  • Page 59 AUTO-CUT 300 XT CCM Status Code Group 4 -- Torch Coolant System Code Message Remedy / Comments Coolant Level low Check coolant level, add as needed. Coolant fl ow as measured by fl ow switch FS1 is less than 0.7 gpm; Clogged fi lter;...
  • Page 60 AUTO-CUT 300 XT CCM Status Code Group 6 -- CCM Code Message Remedy / Comments Analog Voltage Error Defective CCM, replace. ADC or DAC error Defective CCM, replace. Reserved No information available; Contact customer service Data Memory error Defective CCM, replace.

  • Page 61: Cut Quality

    AUTO-CUT 300 XT 4.06 Cut Quality Cut quality requirements differ depending on application. For instance, nitride build-up and bevel angle may be major factors when the surface will be welded after cutting. Dross-free cutting is important when fi nish cut quality is desired to avoid a secondary cleaning operation.
  • Page 62 AUTO-CUT 300 XT Direction of Cut The plasma gas stream swirls as it leaves the torch to maintain a smooth column of gas. This swirl effect results in one side of a cut being more square than the other. Viewed along the direction of travel, the right side of the cut is more square than the left.

  • Page 63: Section 5: Maintenance

    AUTO-CUT 300 XT SECTION 5: MAINTENANCE 5.01 General Maintenance Perform the following checks periodically to ensure proper system performance. Power Supply Maintenance Schedule Daily Check coolant level; add coolant as needed. Check gas hose connections and pressures. Check cooling fan; clean as needed.

  • Page 64: Coolant Replacement Procedure

    AUTO-CUT 300 XT 5.03 Coolant Replacement Procedure Replace coolant as follows: 1. Disconnect the system from main input power. 2. Remove the lower right side panel. 3. Locate the coupling in the coolant line that comes from the bottom of the coolant tank, #1 in the following illustration.

  • Page 65: Arc Starter Service

    AUTO-CUT 300 XT 5.04 Arc Starter Service Arc Starter Service Chart Symptom Cause Check Remedy Flush system, Coolant has become conductive Use conductivity meter replace coolant. Pilot return wire not connected Visual inspection Connect Wire. Spark gap set too close Check with feeler gauge Set to 0.063”...

  • Page 66: Arc Starter Spark Gap Adjustment

    AUTO-CUT 300 XT 5.05 Arc Starter Spark Gap Adjustment 1. Shut off input power. Remove the top console cover. 2. Adjust the spark gap as shown. Re-install the top cover. 0.063" ± 0.002" 1.6 ± 0.05 mm Art # A-11913 5-�...

  • Page 67: Section 6: Replacement Assemblies & Parts

    AUTO-CUT 300 XT SECTION 6: REPLACEMENT ASSEMBLIES & PARTS 6.01 Replacement Power Supply Complete Unit / Component Catalog Numbers Catalog Number Auto-Cut 300 XT™ Power Supply, 480VAC +10 -15% 3-8113-2 Manual 0-5300 REPLACEMENT PARTS...

  • Page 68: Leads And Cables

    Control Cable Primary power Tube Torch CNC Cable Work Cable Work Art # A-11902_AB Leads Catalog Numbers; Auto-Cut 300 XT Power Supply, XT-301 Torch Leads Length 3 ft 5 ft 10 ft 15 ft 25 ft 35 ft 50 ft...
  • Page 69 AUTO-CUT 300 XT #8 AWG Cable Pilot Return, Power Supply to Arc Starter 2/0 (70 mm ) Cable Negative Lead, Power Supply to Arc Starter Green Green Coolant Leads, Power Supply to Arc Starter Control Cable, Power Supply to Arc Starter...

  • Page 70: Power Supply External Replacement Parts

    AUTO-CUT 300 XT 6.03 Power Supply External Replacement Parts Item # Description Catalog # GCM 1000 XT Top Cover 9-7345 Power and Leads Cable Covers 9-7346 Lifting Eye, Cable 9-7347 Upper Side Covers (2 total) 9-7301 Lower Left Side Cover 9-7304 �...

  • Page 71: Power Supply Replacement Parts - Lower Right Side

    AUTO-CUT 300 XT 6.04 Power Supply Replacement Parts - Lower Right Side Item # Description Catalog # Coolant Tank, Cap 9-7305 Coolant Tank 9-7306 Sensor, Coolant level 9-7307 Pump, Coolant, Assembly 9-7309 Motor, Pump 9-7308 Heat Exchanger Fan FAN1 9-7348...

  • Page 72: Power Supply Replacement Parts - Upper Right Side

    AUTO-CUT 300 XT 6.05 Power Supply Replacement Parts - Upper Right Side Item # Description Ref. Des. Catalog # Relays, Pump / Fan MC3 / MC2 9-7314 Relay, Inrush Control 9-733� Relay, Inrush 9-7337 Resistor, Inrush 9-7376 Auxilliary Transformer 9-7315...

  • Page 73: Power Supply Replacement Parts - Left Side

    AUTO-CUT 300 XT 6.06 Power Supply Replacement Parts - Left Side Item # Description Ref. Des. Catalog # Suppressor PCB 9-9254 Main Contactor (2 total) W1, W2 9-7318 Inverter Module, Full (2 total) 480 VAC 9-7330 Inverter Module, Partial 480 VAC...

  • Page 74: Power Supply Replacement Parts Ras - Gcm 1000 Xt

    AUTO-CUT 300 XT 6.07 Power Supply Replacement Parts RAS - GCM 1000 XT Item # Description Ref. Des. Catalog # Gas Solenoid (3 required per unit) 9-6319 Water Filter Assembly 8-3460 HF Transformer 9-4959 Pressure Switch 9-6318 PCB, RAS1000 RF Cap Board...

  • Page 75: Power Supply Replacement Parts - Rear Panel

    AUTO-CUT 300 XT 6.08 Power Supply Replacement Parts - Rear Panel Item # Description Breaker Rating Cicuit Rating Ref. Des. Catalog # Coolant Filter Assy. 9-7320 Coolant Filter 9-7322 Gas Selection Switch 9-3325 Fuse, 8A SB 500V (2 total) 9-7377...

  • Page 76: Power Supply Replacement Parts - Front Of Gcm1000 Xt

    AUTO-CUT 300 XT 6.09 Power Supply Replacement Parts - Front of GCM1000 XT Item # Description Catalog # Pressure Gauge 8-6800 Gas Regulator 9-9509 Run/Set Selector Switch 9-3426 Potentiometer with Knob 9-2685 Shield Gas Selector Switch 9-3427 Flowmeter, H 9-77�2...

  • Page 77: Section 7: Torch Maintenance

    AUTO-CUT 300 XT SECTION 7: TORCH MAINTENANCE 7.01 Consumable Removal 1. Use the removal tool to hold the Shield Cup & Cartridge Assembly stationary. Turn the Shield Cup to remove it from the Cartridge Assembly Cartridge Tool Assembled Cartridge Art # A-04344_AB Shield Cup 2.

  • Page 78: O-Ring Lubrication

    AUTO-CUT 300 XT 7.02 O-Ring Lubrication Lubricate all three O-Rings on the Cartridge Assembly and all three O-Rings on the Torch Head periodically with O-Ring Lubricant supplied. Remove the snap ring on the cartridge assembly and slide the locking ring downward for access to the O-Ring under the locking ring.

  • Page 79: Torch Consumables Installation

    AUTO-CUT 300 XT 7.04 Torch Consumables Installation 1. Install the consumables as follows: WARNINGS Do not install consumables into the Cartridge while the Cartridge is attached to the Torch Head. Keep foreign materials out of the consumables and Cartridge. Handle all parts carefully to avoid damage, which may affect torch performance.
  • Page 80 AUTO-CUT 300 XT 1: Stack Parts 2: Press Cartridge onto Stacked Parts Electrode Plasma Gas Distributor O-Ring on Tip No Gaps Between Parts Shield Gas Cartridge Covers Distributor O-Ring on Torch Tip Shield Cap 4: Check Shield Cap Protrusion 3: Thread Shield Cup onto Cartridge...
  • Page 81 AUTO-CUT 300 XT 2, Remove the Removal Tool from the Cartridge and install the assembled Cartridge onto the Torch Head. CAUTION The cartridge assembly must cover the O-Ring on the torch head. Do not force the cartridge if it will not tighten fully. Remove the cartridge assembly and gently clean the threads on the torch head with a wire brush.
  • Page 82 AUTO-CUT 300 XT E. Coolant Leak Trouble-Shooting Never operate the system if coolant leaks from torch. A steady drip indicates that torch parts are damaged or in- stalled improperly. Operating the system in this condition can damage the torch head. Refer to the following chart for guidance on coolant leakage from the torch head.

  • Page 83: Appendix 1: Cnc Control Module

    AUTO-CUT 300 XT APPENDIX 1: CNC CONTROL MODULE CONTROL PCB CONNECTIONS (LV) OK To Move 2 High +10V Analog Current Control Wiper / Input Low (-) Divided Arc Volts Output Start/Stop Input Stop (NC) (LV) OK To Move 2 CNC Plasma Enable...

  • Page 84: Cnc Functions

    AUTO-CUT 300 XT CNC FUNCTIONS CNC I/O circuits provide at least 1000V galvanic isolation from the plasma power supply. While the CNC circuits are isolated from the power supply, many of the signal returns on J15 and TB1, TB2 & TB3 are common to each other.
  • Page 85 AUTO-CUT 300 XT Internal CNC connections. TB1, TB2 & TB3 on CCM module. Connections are provided on the CCM module TB1, TB2 & TB3 terminal blocks including most of the rear panel functions plus some additional features. All these signals are isolated from the plasma power supply but signals marked (comm.) and (-) are common to each other.
  • Page 86 AUTO-CUT 300 XT CNC Enable / Disable ( input) — Requires closed connection rated for 10 ma. @ 20VDC for unit to operate. Factory installed jumper between TB1-1&2 must be removing when connecting user supplied Enable/Disable circuit. 4 Start/Stop (input)—Switch (momentary or sustained) rating 35ma. @ 20 VDC Start / Stop circuit configuration.
  • Page 87 AUTO-CUT 300 XT OK to Move2 – Provides a second set of N.O. contacts that close when arc transfer is detected. Contacts are rated for maximum of 24 VAC/DC @ 1A. Simplified CNC Circuit. +10V @ 10ma. For Remote CC Pot – Previously CCM versions if one wanted to use a potentiometer for the Remote Analog Current Control (CC) input an external 10 V supply was required for Pot High..
  • Page 88 AUTO-CUT 300 XT Simplified CNC Circuit Autocut 300 XT Simplified CNC OK TO MOV E SELECT 18 V D C or Con tacts SW6A D C VO LT S +18VDC OK2 (cont act) C ONTA CT S +10V (CC Pot Hi )
  • Page 89 AUTO-CUT 300 XT J54 - Rem ote HM I & CN C CO M M (100) 1 - 24 V AC (101) 2 - 24 V AC Re t (102) 3- Jumper to 24 V AC Harness to Relay PCB...
  • Page 90 AUTO-CUT 300 XT CNC Connections Cutting Machine CNC Cable Power Supply START/STOP ..Source, 16 VDC, 10 ma..Divided Arc V (-) ..Divided Arc V (+) ..Pre Flow ON (+) ..Pre Flow ON (-) ..Corner Current Reduction (+)
  • Page 91 AUTO-CUT 300 XT This Page Intentionally Blank Manual 0-5300 APPENDIX...

  • Page 92: Appendix 2: Ccm Cpu Pcb Layout

    AUTO-CUT 300 XT APPENDIX 2: CCM CPU PCB LAYOUT = Test Point Art # A-11675 A-10 APPENDIX Manual 0-5300...
  • Page 93 AUTO-CUT 300 XT CCM CPU PCB Test Points ISO +5.0V +24V +3.3V ISO GND +5.0V TOTAL DEMAND 3.3V=400A TP10 TP11 CPU TEMP SENSE TP12 +3.3VA TP13 -15VDAC TP1� TP15 +15VDAC TP16 CLKO TP18 OSC_CLOCK LED Reference Fiber Out 2 Fiber Out 1...

  • Page 94: Appendix 3: Ccm I/O Pcb Layout

    AUTO-CUT 300 XT APPENDIX 3: CCM I/O PCB LAYOUT = Test Point Art # A-11676_AB A-12 APPENDIX Manual 0-5300...
  • Page 95 AUTO-CUT 300 XT CCM I/O PCB J Connectors Test Points BASIC CNC EXTENDED CNC RELAY - INTERFACE BOARD /COOLANT FANS ON /TORCH PUMP ON ARC / TIP VOLTS LOW COOLANT FLOW (SW) TEST GAS BOX COOLANT FLOW SIGNAL (PULSE) +15V ISOLATED...

  • Page 96: Appendix 4: Pilot Pcb Layout

    AUTO-CUT 300 XT APPENDIX 4: PILOT PCB LAYOUT = Test Point Art # A-11677 A-1� APPENDIX Manual 0-5300...
  • Page 97 AUTO-CUT 300 XT Pilot PCB Test Points PILOT GATE TP� LED Reference Green PILOT ENABLE Green +5V Manual 0-5300 APPENDIX A-15...

  • Page 98: Appendix 5: Relay And Interface Pcb Layout

    AUTO-CUT 300 XT APPENDIX 5: RELAY AND INTERFACE PCB LAYOUT = Test Point Art # A-11678 A-1� APPENDIX Manual 0-5300...
  • Page 99 AUTO-CUT 300 XT Relay and Interface PCB Test Points -15V +5VDC +12V +24V +15V +5VDC LED Reference Green 1 TORCH GAS ON Green PILOT ENABLE Green PILOT CURRENT DETECTED Green WORK CURRENT DETECTED Green CONTACTORS ON Green RF ON Green FANS ON...

  • Page 100: Appendix 6: Display Pcb Layout

    AUTO-CUT 300 XT APPENDIX 6: DISPLAY PCB LAYOUT = Test Point Art # A-11679 A-1� APPENDIX Manual 0-5300...
  • Page 101 AUTO-CUT 300 XT Display PCB Test Points +5VDC +24VDC Manual 0-5300 APPENDIX A-19...

  • Page 102: Appendix 7: System Bias Pcb Layout

    AUTO-CUT 300 XT APPENDIX 7: SYSTEM BIAS PCB LAYOUT = Test Point Art # A-11680 A-20 APPENDIX Manual 0-5300...
  • Page 103 AUTO-CUT 300 XT System Bias PCB Test Points 24VDC DC INPUT POSITIVE TP� Vcc1 Vcc2 GATE PRIMARY GND +12V PRIMARY P_ISOL_GND TP10 DC SENSE POSITIVE LED Reference MISSING PHASE AC V HIGH AC V LOW Green VAC_IDA Green +12V PRIMARY...

  • Page 104: Appendix 8: Main Inverter Bottom Pcb Layout

    AUTO-CUT 300 XT APPENDIX 8: MAIN INVERTER BOTTOM PCB LAYOUT = Test Point A-22 APPENDIX Manual 0-5300...
  • Page 105 AUTO-CUT 300 XT Main Inverter Bottom PCB Test Points GATE 2A GATE 1A GATE 3A GATE 4A GATE 2B GATE 1B GATE 4B GATE 3B TP10 +12VP TP11 +12VDC TP12 THERMISTOR SIDE A TP13 THERMISTOR SIDE B TP14 +5VDC TP15...

  • Page 106: Appendix 9: Main Inverter Top Pcb Layout

    AUTO-CUT 300 XT APPENDIX 9: MAIN INVERTER TOP PCB LAYOUT = Test Point A-2� APPENDIX Manual 0-5300...
  • Page 107 AUTO-CUT 300 XT Main Inverter Top PCB Test Points GATE 2A GATE 1A GATE 3A GATE 4A GATE 2B GATE 1B GATE 4B GATE 3B TP10 +12VP TP11 +12VDC TP12 THERMISTOR SIDE A TP13 THERMISTOR SIDE B TP14 +5VDC TP15...

  • Page 108: Appendix 10: Control And Fault Pcb Layout

    AUTO-CUT 300 XT APPENDIX 10: CONTROL AND FAULT PCB LAYOUT = Test Point /230V Art # A11683 A-2� APPENDIX Manual 0-5300...
  • Page 109 AUTO-CUT 300 XT Control and Fault PCB Test Points TP22 +12VDC TP23 +5VDC TP24 GATE 1+ TP25 A_OUT1 TP26 B_OUT1 TP27 GATE 1- TP2� I_SNS1 TP29 GATE 2+ TP30 I_DMD1 0.5V-6.7V TP31 GATE 2- TP32 -12VDC TP33 START 2 TP34...

  • Page 110: Appendix 11: Cap Bias Bottom Pcb Layout

    AUTO-CUT 300 XT APPENDIX 11: CAP BIAS BOTTOM PCB LAYOUT Art # A-11685 A-2� APPENDIX Manual 0-5300...

  • Page 111: Appendix 12: Cap Bias Top Pcb Layout

    AUTO-CUT 300 XT APPENDIX 12: CAP BIAS TOP PCB LAYOUT Art # A-11686 Manual 0-5300 APPENDIX A-29...

  • Page 112: Appendix 13: Suppressor Pcb Layout

    AUTO-CUT 300 XT APPENDIX 13: SUPPRESSOR PCB LAYOUT Art # A-11684 A-30 APPENDIX Manual 0-5300...

  • Page 113: Appendix 14: Cooling Diagram

    AUTO-CUT 300 XT APPENDIX 14: COOLING DIAGRAM Manual 0-5300 APPENDIX A-31...

  • Page 114: Appendix 15: System Schematic

    AUTO-CUT 300 XT APPENDIX 15: SYSTEM SCHEMATIC PG 1 INVERTER MODULE (IM) #3 (top) IM #3 Section B (upper) AC INPUT J105B J100 -- 30 CKT RIBBON J104B J103B 019X502700 J105A AC INPUT IM #3 Section A (lower) J100 -- 30 CKT RIBBON...
  • Page 115 2/18/2013 9/30/2013 9/16/2013 Drawn Date Misc updates & corrections 6/27/2013 10/05/2012 The information contained herein is proprietary to Victor Technologies. Size Sheet More updates & corrections Not for release, reproduction or distribution without written consent. Drawing Number Title SCHEMATIC 042X1345...

  • Page 116: Appendix 16: System Schematic Pg2

    AUTO-CUT 300 XT APPENDIX 16: SYSTEM SCHEMATIC PG2 AMBIENT J12 = Mini-Fit Jr COOLANT 400 VAC -- Single 18 AWG in pins 1 & 4 (90) 480 VAC -- Single 18 AWG in pins 1 & 8 230 VAC -- 18 AWG wires in pins 1,5,2,6...
  • Page 117 9/12/2013 PCB1 Drawn Date Misc updates & corrections 6/27/2013 10/5/2012 The information contained herein is proprietary to Victor Technologies. Size Sheet TDYN SILK More updates & corrections Not for release, reproduction or distribution without written consent. ESD SILK Drawing Number...

  • Page 118: Appendix 17: Advanced Troubleshooting

    AUTO-CUT 300 XT APPENDIX 17: ADVANCED TROUBLESHOOTING System Overview The Auto-Cut 200 & 300 XT & Ultra-Cut 100, 200, 300 & 400 XT power supplies include one, two or three inverter mod- ules (IM). Each IM may have either 1 or 2 inverter sections designated A or B sections.
  • Page 119 AUTO-CUT 300 XT will only have ribbon cables in J31 & J32; a 200A will have J31-J33 filled with the others empty. 300A will have J34 missing with the others filled. Other boards in the system include the System Bias Supply, the Relay & Interface PCB, Display PCB, Pilot PCB and AC Suppression PCB.
  • Page 120 AUTO-CUT 300 XT The AC Suppression PCB has capacitors and other transient suppression components to protect the system from transients on the AC lines. It also provides power for the neon AC present indicators which illuminate when AC power is connected even with ON-OFF switch, CB1, off.
  • Page 121 AUTO-CUT 300 XT Status codes. The codes for the power supply are displayed on the Display PCB 4 digit numerical display. Some codes refer to the Gas Controls but more detailed Gas Control codes will be found on the individual gas controls. The gas con- trols used with the XT family of plasma supplies have not changed.
  • Page 122 AUTO-CUT 300 XT Power Supply Status Codes Group 1, Process Codes Plasma Enable Is Disabled Code 101 is activated by either an open circuit between TB1-1 & 2 on CCM I/O PCB or Plasma Enable switched off on the GCM 2010 or on the TSC 3000. TB1-1 & 2 comes from the factory with a jumper installed. An in- staller may remove the jumper and connect a separate Plasma Enable switch or use the Plasma Enable wires included in the 37 pin CNC cable used with the Ultra-Cut XT &...
  • Page 123 AUTO-CUT 300 XT If a TSC 3000 is not connected or unit is an Auto-Cut, K7 on the Relay PCB is de-energized and GND is con- nected through its normally closed contacts. If the TSC is connected, 24 VAC through a jumper in the TSC 3000 energizes K7, opening its NC contacts and now GND connects through the TDC 3000 Plasma Enable switch.
  • Page 124 AUTO-CUT 300 XT Pilot Ignition Failure Code 102 is activated when there is no pilot current after 15 seconds of firing the Arc Starter. Pilot ignition requires the Pilot board to be enabled, pilot switch (IGBT) turned on and high voltage pulses (HF) from the arc Starter (either the Remote Arc Starter RAS 1000 XT or GCM 1000 XT or the arc starter built in to the AC 200 XT) applied between the tip and the electrode of the torch.
  • Page 125 AUTO-CUT 300 XT Arc starter without Spark Gap (Ultra-Cut) 1. Check for power to the RAS 1000XT’s Ignition Module during the 15 seconds following preflow (ignition phase). Arc starter power comes through the rear panel circuit breaker CB4, make sure it isn’t tripped.
  • Page 126 AUTO-CUT 300 XT Reasons why RAS Control relay would not close: 6. Pilot current flowing. There actually is pilot current flowing somewhere. Unlikely as it would normally set the 208 fault but we have to rule it out. a. Disconnect J41 on the Pilot board, if HF still doesn’t fire and the Relay board Pilot LED, D11, is still on, it’s due to a fault in the detection circuits.
  • Page 127 AUTO-CUT 300 XT Troubleshooting Pilot Board problems. 1. The Pilot board is behind the CCM in the AC 300 XT and all Ultra-Cut XTs or on the upper section of the second inverter module in an AC 200 XT and has two LEDs. The first one, D11, a green LED, indicates the board has bias power and should be on all the time when the unit is turned on.
  • Page 128 AUTO-CUT 300 XT Transfer Lost Arc transferred to metal for at least 50 ms. then went out. Causes for 104 code: • Cut demand set much lower than recommended for torch parts, i.e. 100A consumables in torch but cut current set for 30 or 50A (or zero). Current may be too low to keep arc on.
  • Page 129 AUTO-CUT 300 XT • Cut current set too low for torch parts being used. Pilot current is set based on cut current. If cut current is too low pilot current will be lower and may not transfer at the height used for higher current consum- ables.
  • Page 130 AUTO-CUT 300 XT Part Process not Configured. This represents a status, not a fault. This is used with the DFC 3000 only. It means the operator hasn’t loaded the cutting process from either the TSC 3000 or from the program embedded in the cutting table CNC control- ler.
  • Page 131 AUTO-CUT 300 XT PWR Present • When power is first applied to the inverter (contactor closed) CCM checks for presence of the +12V bias on the Inverter Control and Fault board. If not present will set codes in the range of 265-270.
  • Page 132 AUTO-CUT 300 XT 202-204 Not used. Reserved codes from the earlier product. DC Output Low DC output (voltage) low means one or more inverter sections are enabled but the output voltage is below a preset voltage. Shortly after receiving the Start signal from the CNC, but before the end of preflow, both sections of IM#1 are enabled and CCM measures the power supply output voltage between negative (Torch) to positive (Work) at the output terminals.
  • Page 133 AUTO-CUT 300 XT Relay PCB • Relay board LED D12, Work Current Detected, will light if the current sensor signal exceeds 0.05V. If D12 is on, measure the sensor output signal at J1-3 with signal common on J1-1. This signal should be 0V +/- 0.04VDC.
  • Page 134 AUTO-CUT 300 XT Relay Board or CCM If D11 on the Relay PCB is still on after the previous tests, measure the output to the CCM on the 40 pin ribbon cable (Relay J4 to CCM J23) between pins 23 (-) and 25 (+). It should be less than 0.1V. If not, the Relay board is bad.
  • Page 135 AUTO-CUT 300 XT Possible cause for work current to low. • All the above plus a short to chassis caused by: o User installed equipment connect behind the current sensor that makes a connection to work or earth allowing current flow to bypass work sensor.
  • Page 136 AUTO-CUT 300 XT Inverter 1 not found. There must be an inverter connected in the 1st section, 1A, to be able to pilot. During the power up sequence, before power is connected to the inverters, the CCM does a continuity test to see if its section 1A ribbon cable (J31 on CCM) is connected.
  • Page 137 AUTO-CUT 300 XT Troubleshooting: 1. If System Bias board has either the wrong jumper or is defective it will call out the first inverter section, code 231, because all the inverters won’t match the incorrect signal and 1A is checked first.
  • Page 138 AUTO-CUT 300 XT System Bias voltage identification is invalid. At power up the System Bias board measures the input voltage and sends signals to the CCM indicating which range of voltage it has detected. See section 231-236 for details. If one of the 3 voltage ranges, 208-230V, 380- 415V or 480V isn’t identified then both ID signals are high resulting in an invalid signal.
  • Page 139 AUTO-CUT 300 XT Troubleshooting: 1. If the fault is L239 applying START will clear the fault unless it becomes active again. An occasional prob- lem may be due to incoming voltage swells (voltage increases lasting from ½ cycle to as much as a minute).
  • Page 140 AUTO-CUT 300 XT 4. If the incoming voltage is OK and the problem persists it may be System Bias, CCM or connection between J62 and J27. a. If the incoming voltage is OK and D14, ACV LOW, is on or the signal “AC V LOW b” on J62-10 is “high”...
  • Page 141 AUTO-CUT 300 XT 253-258 Inverter Over Temperature. Each inverter section (IS) contains one or more temperature sensors. If any of these detect an over temperature condition it activates the signal “OVERTEMP_FLT going to the CCM over the inverter sections ribbon cable.
  • Page 142 AUTO-CUT 300 XT Troubleshooting: 1. If room temperature exceeds 40 deg C, cool the room, or operate the unit at reduced duty cycle or lower current. 2. Confirm that air is exhausting from opening in the right side panel. As the fan(s) are behind the radiator it’s hard to see them to confirm they are turning but perhaps you can use an inspection mirror.
  • Page 143 AUTO-CUT 300 XT 3. On the Relay board D22, CONTACTOR ON LED (green) next to relay K1 lights if K1 is being told to energize. a. If it’s on check for 120 VAC between J8-1 and J8-9. If present the relay board is OK.
  • Page 144 Gas pressure faults only show up when you try to start the torch, not during purging or setting flows . With the Auto-Cut 200 XT and the Auto-Cut 300 XT (GCM 1000 XT), the gas pressure sensor is only on the plasma gas and is in series with Run/Set switch.
  • Page 145 AUTO-CUT 300 XT Gas Control returns wrong command sequence. Firmware incompatibility. Consult factory for latest firmware update. Possible electromagnetic interference from the Arc Starter; inspect grounding; bonding; and isolation. Mismatch between the CCM and gas control type. The Auto-Cut XT CCM is designed to work with the GCM 1000 (AC 300 XT) or the built in gas control of the AC 200 XT.
  • Page 146 AUTO-CUT 300 XT Coolant Level Low The coolant reservoir (tank) has a normally open (tank dry) float type level switch, LS1. When the coolant level in the tank is below about ½ full this fault will signal the need to add coolant. It will not stop the process dur- ing a cut but will instead show the 405 fault as a warning.
  • Page 147 AUTO-CUT 300 XT Troubleshooting: 1. First note whether the fault is an “E” meaning it’s currently low or an “L” meaning it was low but isn’t now. Flow that remains low could indicate a failed component or a blockage such as clogged filter or pinched hose.
  • Page 148 AUTO-CUT 300 XT 2. Fans are powered by 230 VAC. The 230 VAC for the fan(s) is switched by the MC2 control relay (except the AC 200 XT where the fan(s) is powered directly from the T1 transformer at J13).
  • Page 149 AUTO-CUT 300 XT Reasons for 404 faults (Coolant not flowing): • In new installation, coolant has not circulated all the way through the leads. Add more coolant if neces- sary and recycle the power to restart the pump and 4 minute timer.
  • Page 150 AUTO-CUT 300 XT d. If jumping TP3 to TP1 does not turn the fans on then the Relay board or the 40 pin ribbon cable pin 13 is at fault. CCM I/O PCB 230 VAC from T1 To test Pump relay jump TP3 to TP1.
  • Page 151 AUTO-CUT 300 XT Coolant flow is correct but system doesn’t detect it due to defective components: • Defective or disconnected FS1 flow switch. • Relay board. • CCM. Flow Switch FS1 disconnected – FS1 comes with wire about 1 ft. long and a connector that connects to a 3 wire harness.
  • Page 152 AUTO-CUT 300 XT Troubleshooting: 1. GCM 1000XT (also called a Basic Gas Control) does not use CANBUS (fiber-optic) communication. A jumper in the gas control connector J56 pins 8 & 9, gives the signal “Basic ID” telling the CCM not to expect any CANBUS.
  • Page 153 AUTO-CUT 300 XT The black end of the fiber cable is inserted into the transmitter which is the gray housing on the PCB. The other end of the transmitting fiber is blue and goes into the receiver with the black housing.
  • Page 154 AUTO-CUT 300 XT USB Log File Creation Fault When updating the CCM, DMC and DPC programs from a flash drive, a log file called CCM_LOG.TXT is cre- ated on the flash which reports on the results of the update including any problems. If that log file can’t be created you get 613.
  • Page 155 AUTO-CUT 300 XT This Page Intentionally Blank Manual 0-5300 APPENDIX A-73...

  • Page 156: Appendix 18: Publication History

    AUTO-CUT 300 XT APPENDIX 18: PUBLICATION HISTORY Cover Date Change(s) April 22, 2013 AA First Release July 2, 2013 Updated section 3 with information about V-D Board installation for height controller per ECOB2488 Jan. 16, 2014 Updated many items, text and art throughout the manual. Added Advanced Trouble shooting and plumbing diagrams to Appendix per ECOB2552.
  • Page 158 I N N O V A T I O N T O S H A P E T H E W O R L D ™ U.S. Customer Care: 800-426-1888 / 800-535-0557 Canada Customer Care: 905-827-4515 / 800-588-1714 • International Customer Care: 940-381-1212 / 940-483-8178 © 2012 Victor Technologies International, Inc. victortechnologies.com Printed in U.S.A.
