Summary of Contents for Onerr Nickel Octave NO-1

  • Page 1 User Guide Guide de l'Utilisateur Manual do Usuário EFFECTS NICKEL OCTAVE NO-1...
  • Page 2 A third tone two octaves below the original. Playing alone with a single instrument, you can get sounds three octaves thick and each section has a separate volume control knob! The Onerr NO-1 features natural, clear octave sounds with stable pitch even for staccato picking sounds.
  • Page 3: Panel Descriptions

    Panel Descriptions AC adaptor jack Led indicator on/off Octave 1 knob Direct level knob Octave 2 knob Output jack Input jack Pedal switch Thumbscrew...
  • Page 4 Pedal Descriptions AC adaptor jack: Accepts connection of an external Octave 1: Gives you control of how much one octave AC adaptor. By using an AC adaptor you can play without below will be added to your original tone. Turn it to the being concerned about the battery life.
  • Page 5 Connect the snap cord to the battery, observing the proper Thumbscrew polarity. When the pedal is not in use ONERR highly suggests removing the battery from its compartment to prevent possibility of leaking and damage to this unit. Battery...
  • Page 6: Power Supply Specifications

    Warning: When using an AC adaptor is sure to use a compatible model for your unit, otherwise irreparable damage may be caused. Optional Onerr AC adaptor: Onerr PA-21 or PA-23. AC input jack Power supply specifications: Output voltage: 9 VDC Current capacity: 100 mA (minimum) Output plug: 2.1 x 5.5 mm (negative center)
  • Page 7: Making The Connections

    Making the Connections Keyboard Onerr Guitar AC adaptor PA-21 / PA-23 Bass Amplifier...
  • Page 8 Notes: - Only use reliable cords to connect your pedals. This is to be sure you won´t get troubles while playing. - Before powering your pedals, make all necessary linking connections. In case of you need to change any connection, do not forget to turn the power off in order to not cause any damage to your units.
  • Page 9 Before using this product be sure to read Use only reliable AC adaptors with proper and check all instructions of this Owner's line voltage. Non-reliable AC adaptors manual. with different polarity or voltage may cause damage or malfunction and void the warranty.
  • Page 10: Warranty

    Warranty Microtronix Eletrônica Ltda warrants this unit to be free from defects in materials and workmanship for a period of 1 (one) year from date of first purchase. This warranty does not include any kind of damage resulting from accidents, misuse, abusie, alteration to the internal circuitry or vital parts and damages caused by non-reliable AC adaptors.
  • Page 11: Specifications

    Specifications* Power supply: DC 9v alkaline or AC adaptor (Onerr model PA-21 or PA-23) Current draw: 15 mA Controls: Octave1, Octave 2 and Direct level. Switch: turn on/off effect Indicators: indicator on/off led Jacks: input, output and AC adaptor Input impedance: > 470 kOhm...
