- Page 1 User Guide Guide de l'Utilisateur Manual do Usuário EFFECTS COPPER TREMOLO CT-1...
- Page 2 Product Overwiew Thank you for choosing an Onerr product. Copper Tremolo CT-1 is designed to provide guitarists with classic and traditional vintage tremolo effect in a compact and solid pedal format. The three knob controls: WAVE, RATE and DEPTH give you...
-
Page 3: Panel Descriptions
Panel Descriptions AC adaptor jack Led indicator on/off Wave knob Rate knob Depth knob Output jack Input jack Pedal switch Thumbscrew... - Page 4 Pedal Descriptions AC adaptor jack: Accepts connection of an external Rate: Allows you a speed adjustment of tremolo effect. AC adaptor. By using an AC adaptor you can play without Wave: Alters LFO waveform from triangle to square, being concerned about the battery life. mixing both at the mid point.
- Page 5 Connect the snap cord to the battery, observing the proper Thumbscrew polarity. When the pedal is not in use ONERR highly suggests removing the battery from its compartment to prevent possibility of leaking and damage to this unit. Battery...
-
Page 6: Power Supply Specifications
Warning: When using an AC adaptor is sure to use a compatible model for your unit, otherwise irreparable damage may be caused. Optional Onerr AC adaptor: Onerr PA-21 or PA-23. AC input jack Power supply specifications: Output voltage: 9 VDC Current capacity: 100 mA (minimum) Output plug: 2.1 x 5.5 mm (negative center) -
Page 7: Making The Connections
Making the Connections Keyboard Onerr Guitar AC adaptor PA-21 / PA-23 Bass Amplifier... - Page 8 Notes: - Only use reliable cords to connect your pedals. This is to be sure you won´t get troubles while playing. - Before powering your pedals, make all necessary linking connections. In case of you need to change any connection, do not forget to turn the power off in order to not cause any damage to your units.
- Page 9 Before using this product be sure to read Use only reliable AC adaptors with proper and check all instructions of this Owner's line voltage. Non-reliable AC adaptors manual. with different polarity or voltage may cause damage or malfunction and void the warranty.
-
Page 10: Warranty
Warranty Microtronix Eletrônica Ltda warrants this unit to be free from defects in materials and workmanship for a period of 1 (one) year from date of first purchase. This warranty does not include any kind of damage resulting from accidents, misuse, abusie, alteration to the internal circuitry or vital parts and damages caused by non-reliable AC adaptors. -
Page 11: Specifications
Specifications* Power supply: DC 9 v alkaline or AC adaptor (Onerr model PA-21 or PA-23) Current draw: 10 mA Controls: Rate, Depth and Wave Switch: turn on/off effect. Indicators: indicator on/off led Jacks: input, output and AC adaptor Input impedance: >470 kOhm Frequency response: 40 to 16K Hz Modulation speed: 50 to1200 miliseconds.
