Onerr Introgen Chorus NC-1 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Guide
Guide de l'Utilisateur
Manual do Usuário
EFFECTS
NITROGEN CHORUS NC-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Introgen Chorus NC-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Onerr Introgen Chorus NC-1

Summary of Contents for Onerr Introgen Chorus NC-1

  • Page 1 User Guide Guide de l'Utilisateur Manual do Usuário EFFECTS NITROGEN CHORUS NC-1...
  • Page 2 Product Overwiew Thank you for choosing an Onerr product. Nitrogen Chorus NC-1 electronically creates a mild variation in the tuning of the instrument. You can mix it with an original sound, which produces deep, subtle tones. The NC-1 is also great for clean tones and when...

  • Page 3: Panel Descriptions

    Panel Descriptions AC adaptor jack Led indicator on/off Rate knob Intensity knob Depth knob Input jack Output jack (S) Output jack (M) Pedal switch Thumbscrew...
  • Page 4 Pedal Descriptions AC adaptor jack: Accepts connection of an external Thumbscrew: By loosing this thumbscrew you will gain AC adaptor. By using an AC adaptor you can play with- access to the battery compartment. For instructions on out being concerned about the battery life. how to replace the battery please refer to page 6.
  • Page 5 Connect the snap cord to the battery, observing the proper polarity. Thumbscrew When the pedal is not in use ONERR highly suggests removing the battery from its compartment to prevent possibility of leaking and damage to this unit. Battery...

  • Page 6: Power Supply Specifications

    Warning: When using an AC adaptor is sure to use a compatible model for your unit, otherwise irreparable damage may be caused. Optional Onerr AC adaptor: Onerr PA-21 or PA-23. AC input jack Power supply specifications: Output voltage: 9 VDC Current capacity: 100 mA (minimum) Output plug: 2.1 x 5.5 mm (negative center)

  • Page 7: Making The Connections

    Making the Connections Onerr AC adaptor PA-21 / PA-23 Keyboard Guitar Bass Amplifier (A) In case of using a single output use the (S) as default. Amplifier (B)
  • Page 8 Notes: - Only use reliable cords to connect your pedals. This is to be sure you won´t get troubles while playing. - Before powering your pedals, make all necessary linking connections. In case of you need to change any connection, do not forget to turn the power off in order to not cause any damage to your units.
  • Page 9 Before using this product be sure to read Use only reliable AC adaptors with proper and check all instructions of this Owner's line voltage. Non-reliable AC adaptors manual. with different polarity or voltage may cause damage or malfunction and void the warranty.

  • Page 10: Warranty

    Warranty Microtronix Eletrônica Ltda warrants this unit to be free from defects in materials and workmanship for a period of 1 (one) year from date of first purchase. This warranty does not include any kind of damage resulting from accidents, misuse, abusie, alteration to the internal circuitry or vital parts and damages caused by non-reliable AC adaptors.

  • Page 11: Specifications

    Specifications* Power supply: DC 9 V alkaline or AC adaptor (Onerr model PA-21 or PA-23) Current draw: 16 mA Controls: Rate, Depth and Intensity Switch: turn on/off effect. Indicators: indicator on/off led Jacks: input, output (S), output (M) and AC adaptor...
