- Page 1 User Guide Guide de l'Utilisateur Manual do Usuário EFFECTS NITROGEN CHORUS NC-2...
- Page 2 Product Overwiew Thank you for choosing an Onerr product. Sophisticated digital technology in the NC-2 features two internal oscillators for a warmth and richness that is unsurpassed. The NC-2 is a great way to fill up your clean tones and fatten up your distorted tones with the rich modulations of detuned sounds.
-
Page 3: Panel Descriptions
Panel Descriptions AC adaptor jack Led indicator on/off Rate knob Color switch Depth knob Level knob Output jack (M) Input jack Output jack (S) Pedal switch Thumbscrew... - Page 4 Pedal Descriptions AC adaptor jack: Accepts connection of an external Thumbscrew: By loosing this thumbscrew you AC adaptor. By using an AC adaptor you can play with- will gain access to the battery compartment. For out being concerned about the battery life. instructions on how to replace the battery please refer to page 6.
- Page 5 Connect the snap cord to the battery, observing the proper polarity. Thumbscrew When the pedal is not in use ONERR highly suggests removing the battery from its compartment to prevent possibility of leaking and damage to this unit. Battery...
-
Page 6: Power Supply Specifications
When using an AC adaptor is sure to use a compatible model for your unit, otherwise irreparable damage may be caused. Optional Onerr AC adaptor: Onerr PA-21 or PA-23. AC input jack Power supply specifications: Output Voltage : 9 VDC Current Capacity: 100 mA (minimum) Output Plug: 2.1 x 5.5 mm (negative center) -
Page 7: Making The Connections
Making the Connections Onerr AC adaptor PA-21 / PA-23 Keyboard Guitar Bass Amplifier (A) Amplifier (B) Use (M) Output when using a single amplifier. - Page 8 Notes: - Only use reliable cords to connect your pedals. This is to be sure you won´t get troubles while playing. - Before powering your pedals, make all necessary linking connections. In case of you need to change any connection, do not forget to turn the power off in order to not cause any damage to your units.
- Page 9 Before using this product be sure to read Use only reliable AC adaptors with proper and check all instructions of this Owner's line voltage. Non-reliable AC adaptors manual. with different polarity or voltage may cause damage or malfunction and void the warranty.
-
Page 10: Warranty
Warranty Microtronix Eletrônica Ltda warrants this unit to be free from defects in materials and workmanship for a period of 1 (one) year from date of first purchase. This warranty does not include any kind of damage resulting from accidents, misuse, abusie, alteration to the internal circuitry or vital parts and damages caused by non-reliable AC adaptors. -
Page 11: Specifications
Specifications: Power supply: DC 9V alkaline or AC adaptor (Onerr model PA-21 or PA-23) Current draw: 38 mA Controls: Rate, Depth, Level and Color Switch: turn on/off effect Indicators: indicator on/off led Jacks: input, output (M) mono, output (S) Stereo and AC adaptor...
