Summary of Contents for Onerr Digital Reverb DGR-1

  • Page 1 User Guide Guide de l'Utilisateur Manual do Usuário EFFECTS DIGITAL REVERB DGR-1...
  • Page 2 2 presets of chorus. The MIX knob gives you control of accurate adjustment of the direct signal mixed with the effect signal. The Digital Reverb DGR-1 Onerr is also furnished with two outputs (1-Mono 2-Stereo), whereby using two amplifiers you will get a fantastic stereo surround effect.
  • Page 3: Panel Descriptions

    Panel Descriptions AC adaptor jack Led indicator on/off Effect selector knob Digital display Mix knob Presets list Input jack Output jack A Output jack B CTL (control) Pedal switch Thumbscrew...
  • Page 4 Pedal Descriptions AC adaptor jack: Accepts connection of an external Pedal: Depress to turn on/off the pedal. AC adaptor. By using an AC adaptor you can play without Thumbscrew: By loosing this thumbscrew you will gain being concerned about the battery life. access to the battery compartment.
  • Page 5 Connect the snap cord to the battery, observing the proper polarity. Thumbscrew When the pedal is not in use ONERR highly suggests removing the battery from its compartment to prevent possibility of leaking and damage to this unit. Battery...
  • Page 6: Power Supply Specifications

    Warning: When using an AC adaptor is sure to use a compatible model for your unit, otherwise irreparable damage may be caused. Optional Onerr AC adaptor: Onerr PA-21 or PA-23. AC input jack Power supply specifications: Output voltage: 9 VDC Current capacity: 100 mA (minimum) Output plug: 2.1 x 5.5 mm (negative center)
  • Page 7: Making The Connections

    Making the Connections Keyboard ONERR AC Adaptor Guitar PA-21 ou PA-23 Amp. 1 Bass Microphone Amp. 2 Footswitch...
  • Page 8 Program: Notes: Room 1 - Only use reliable cords to connect your pedals. This is to be sure you won´t get Room 2 troubles while playing. Room 3 Plate 1 - Before powering your pedals, make all necessary linking connections. In case of you Plate 2 need to change any connection, do not forget to turn the power off in order to not Plate 3...
  • Page 9 Before using this product be sure to read Use only reliable AC adaptors with proper and check all instructions of this Owner's line voltage. Non-reliable AC adaptors manual. with different polarity or voltage may cause damage or malfunction and void the warranty.
  • Page 10: Warranty

    Warranty Microtronix Eletrônica Ltda warrants this unit to be free from defects in materials and workmanship for a period of 1 (one) year from date of first purchase. This warranty does not include any kind of damage resulting from accidents, misuse, abusie, alteration to the internal circuitry or vital parts and damages caused by non-reliable AC adaptors.
  • Page 11: Specifications

    Specifications* Power supply: DC 9 v alkaline or AC adaptor (Onerr model PA-21 or PA-23) Current draw: 70 mA Controls: Effect Selector, and Mix knob Switch: turn on/off effect, effect selection (by using an external footswitch) Indicators: indicator on/off led, effect preset Jack: input, CTL (control), output A, output B and AC adaptor Input impedance: >470 kOhm...
