Onerr Digital Delay DGD-2 User Manual

24-bit audio resolution delay

Advertisement

Quick Links

User Guide
Guide de l'Utilisateur
Manual do Usuário
EFFECTS
DIGITAL DELAY DGD-2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Digital Delay DGD-2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Onerr Digital Delay DGD-2

  • Page 1 User Guide Guide de l'Utilisateur Manual do Usuário EFFECTS DIGITAL DELAY DGD-2...
  • Page 2 Delay, giving musicians more versatility in the studio and better performance for live applications by using the TAP TEMPO capacity. The Onerr DGD-2 is designed for all kinds of instruments and applications. The HOLD function allows musicians to record riffs of...
  • Page 3: Panel Descriptions

    Panel Descriptions AC adaptor jack Led indicator on/off and functions Effect level knob Mode switch Feedback knob Delay time knob Input jack Output jack A Output jack B Pedal switch Thumbscrew...
  • Page 4 Pedal Descriptions AC adaptor jack: AC adaptor Jack: Accepts connection Depress and hold it for about 2 seconds to turn on/off in of an external AC adaptor. By using an AC adaptor you can the TAP TEMPO mode. For more instructions about how play without being concerned about the battery life.
  • Page 5 Delay Time Knob: Gives you control of Delay Time in Delay: In this position the indicator led will light in red milliseconds. after depressing the pedal. This indicates that the DGD-2 The minimum delay time of this unit is 10 milliseconds is now working in delay mode and all knob controls are and the maximum is 1250 milliseconds.
  • Page 6 The Real Time Tap Tempo (RTTP) The RTTP function is a great ally for the musician as it Now it is quite simple! While working in RTTP mode, to allows fast and accurate adjustments of DELAY TIME in increase or decrease the DELAY TIME, you just need to real time.
  • Page 7 Connect the snap cord to the battery, observing the proper polarity. Thumbscrew When the pedal is not in use ONERR highly suggests removing the battery from its compartment to prevent possibility of leaking and damage to this unit. Battery...
  • Page 8: Power Supply Specifications

    Warning: When using an AC adaptor is sure to use a compatible model for your unit, otherwise irreparable damage may be caused. Optional Onerr AC adaptor: Onerr PA-21 or PA-23. AC input jack Power supply specifications: Output voltage: 9 VDC Current capacity: 100 mA (minimum) Output plug: 2.1 x 5.5 mm (negative center)
  • Page 9: Making The Connections

    Making the Connections Keyboard Onerr AC adaptor Guitar PA-21 / PA-23 Amp. 1 Bass Microphone Amp. 2...
  • Page 10 Notes: - Only use reliable cords to connect your pedals. This is to be sure you won´t get troubles while playing. - Before powering your pedals, make all necessary linking connections. In case of you need to change any connection, do not forget to turn the power off in order to not cause any damage to your units.
  • Page 11 Before using this product be sure to read Use only reliable AC adaptors with proper and check all instructions of this Owner's line voltage. Non-reliable AC adaptors manual. with different polarity or voltage may cause damage or malfunction and void the warranty.
  • Page 12: Warranty

    Warranty Microtronix Eletrônica Ltda warrants this unit to be free from defects in materials and workmanship for a period of 1 (one) year from date of first purchase. This warranty does not include any kind of damage resulting from accidents, misuse, abusie, alteration to the internal circuitry or vital parts and damages caused by non-reliable AC adaptors.
  • Page 13: Specifications

    Specifications* Power Supply: DC 9V alkaline or AC adaptor (Onerr model PA-21 or PA-23) Current draw: 77 mA Controls: Effect Level, Feedback and Delay Time Switch: turn on/off effect, Delay/Hold Mode Indicators: indicator on/off led, Hold and Tap Tempo led.
