Trouble Shooting

In most situations, the Inverter requires very little service. However, if Inverter is not
able to work perfectly, please refer to the following instructions before calling your
local dealer.
Should any problems arise, the LED on the front panel will be red and the LCD displays
the relevant information. Please refer to the following for a list of potential problems
and their solutions.
SYSTEM FAULT
Ground I Fault
1. The ground current is too high.
2. Unplug the inputs from the PV generator and check the peripheral AC system.
3. After the cause is cleared, re-plug the PV panel and check PV-Inverter status.
4. If the problem persists please call service.
Isolation Fault
1. Check the impedance is between PV (+) & PV (-) and the PV-Inverter is earthed.
The impedance must be greater than 8M.
2. If the problem persists please call service.
Grid Fault
1. Wait for 5 minutes, if the grid returns to normal, PV-Inverter automatically restarts.
2. Make sure grid voltage and frequency meet the specifications.
3. If the problem persists please call service.
4. Check grid usability.
No AC connection
1. Grid is not connected.
2. Check grid connection cables.
INVERTER FAILURE
PV Over Voltage
1. Check the open PV voltage; see if it is greater than or too close to 450VDC.
2. If PV voltage is less than 450VDC, and the problem still occurs, please call local service.
Consistent Fault
1. Disconnect PV (+) or PV (-) from the input, restart the PV-Inverter.
2. If it does not work, call service.
If there is no display on the panel, please check PV-input connections. If the voltage is
higher than 90V, call your local service.
During periods of little or no sunlight, the PV-Inverter may continuously start up and
shut down. This is due to insufficient power generated to operate the control
circuits.
20
Growatt1000
Input Data
Max. DC power 1300W
450V
Max. DC voltage
PV voltage range 70V-450V
MPP voltage range 110V-400V
Number of MPP trackers/
1 / 1
strings per MPP tracker
Max. input current
10A/10A
/per string
Output Data
1000W
Nominal AC output power
Max. AC power 1100W
Max. output current 5.5A
AC nominal voltage; range 220,230,240V;
180Vac-280Vac
AC grid frequency ; range 50Hz,60Hz;±5Hz
Phase shift (cos φ) 1
THDI
< 3%
AC connection
Single phase
Efficiency
Max . efficiency 97%
Euro-eta 95.5%
MPPT efficiency 99.5%
Protection Devices
yes
DC reverse polarity protection
yes
AC short-circuit protection
yes
Ground fault monitoring
yes
Grid monitoring
Integrated all-pole sensitive
yes
leakage current monitoring unit
General Data
Dimensions (W / H / D) in mm 360/329/132
Weight 11.5 KG
Operating temperature range –25°C..+60°C
Continuous full output power
–25°C..+50°C
temperature range
Noise emission (typical) ≤25 dB(A)
Consumption: operating
<5W /< 0.5 W
(standby) / night
Topology transformerless
Cooling concept No fan
Installation: Indoor/
yes / yes
Outdoors (IP65 electronics)
Certificates and Approvals
VDE 0126-1-1,N4105,
IEC 62109,G83,CE,
ENEL Guideline(CEI 0-21+A70)
7

Specifications

Sungold 1000
1300W
450V
70V-450V
110V-450V
1 / 1
10A/10A
1000W
1100W
5.5A
230V;
207Vac~263Vac
50Hz,60Hz;±5Hz
1
< 3%
Single phase
97%
95.5%
99.5%
yes
yes
yes
yes
yes
360/329/132
11.5 KG
–25°C..+60°C
–25°C..+50°C
≤ 25 dB(A)
<5W /< 0.5 W
transformerless
No fan
yes / yes
AS 4777, AS/NZS 3100
