Table of Contents Introduction........................3 Important Safety Data......................3 Safety Warnings And Recommendations................4 Rating Label Location......................6 Pellet Quality........................6 Installation........................7 Deciding Where to Locate the Appliance................7 Unpacking and Removing Pellet Stove From Pallet..............7 Clearances to Combustibles....................9 Alcove Clearances.......................9 Vent Termination Requirements..................10 Outside Fresh Air Connection...................11 Exhaust and Intake Locations...................11 Mobile Home Installation....................12 Corner Through Wall Installation..................12...
To prevent the possibility of a fire, ensure that the appliance is properly installed by adhering to the installation instructions. An ENVIRO dealer will be happy to assist you in obtaining information with regards to your local building codes and installation restrictions.
To prevent the possibility of a fire, ensure that the appliance is properly installed by adhering to the installation instructions. An ENVIRO dealer will be happy to assist you in obtaining information with regards to your local building codes and installation restrictions.
Page 5
GLASS: Do not abuse the glass by striking or slamming the door. Do not attempt to operate the stove with broken glass. The stove uses ceramic glass. Replacement glass must be purchased from an ENVIRO dealer. Do not attempt to open the door and clean the glass while the unit is in operation or if glass is hot. To clean the glass, use a soft cotton cloth and mild window cleaner, gas or wood stove glass cleaner, or take a damp paper towel and dip into the fly ash.
UALITY Pellet quality is important, please read the following: Your Enviro pellet stove has been designed to burn wood pellets only. Do not use any other type of fuel, as this will void any warranties stated in this manual. The performance of your pellet stove is greatly affected by the type and quality of wood pellets being burned.
Installation ECIDING HERE TO OCATE YOUR ELLET PPLIANCE 1. Check the “Clearances to Combustibles” section for proper spacing. Do not obtain combustion air from an attic, garage or any unventilated space. Combustion air may be obtained from a ventilated crawlspace. 3.
Page 8
Installation SSEMBLY 1. First install the hearth pad if you plan on using it. You may have to unscrew feet to raise unit up. Tilt the unit so it is balancing on the back feet, slide the hearth pad under the unit while making sure the side mounting tabs are on the outside of the base flange.
Hearth Pad with a minimum R Value of at least 0.84 must be placed underneath the unit and extend six inches in front of the unit measured from the glass. If the P3 is installed on carpet the use of a solid non combustible Hearth Pad must be used under leveling legs.
Installation ERMINATION EQUIREMENTS IT IS RECOMMENDED THAT YOUR PELLET STOVE BE INSTALLED BY AN AUTHORIZED DEALER/INSTALLER. Table 1: Use in conjunction with Figure 6 for allowable exterior vent termination locations. Letter Minimum Clearance Description 24 in (61 cm) Above grass, top of plants, wood, or any other combustible materials. 48 in (122 cm) Beside/below any door or window that may be opened.
If vented horizontally, joints shall be made gas tight with aluminum foil duct tape. 10.5in (26.5 cm) 6.625in (17 cm) 2.125 in (5.5 cm) Figure 9: P3 Inlet and Outlet Location.
CAUTION: THE STRUCTURAL INTEGRITY OF THE MANUFACTURED HOME FLOOR, WALL AND CEILING/ ROOF MUST BE MAINTAINED. ENVIRO P3 Hearth Pad Flooring Steel Frame ” Lag Bolts Ground Wire Directly to Metal Chassis Securely Fastened Figure 10: Mobile home installation.
Installation ORIZONTAL XHAUST HROUGH NSTALLATION Vent installation: install vent at clearances specified by the vent manufacturer. A chimney connector shall not pass through an attic or roof space, closet or similar concealed spaces, or a floor, or ceiling. Where passage through a wall or partition of combustible construction is desired, the installation shall conform to CAN/CSA-B365 Installation Code for Solid-Fuel-Burning Appliances and Equipment.
Installation 10. Install a vertical pipe, or if all requirements for direct venting are met, install vent termination. The stainless steel cap termination manufactured by the vent manufacturer is recommended. However, when the vent terminates several feet above ground level and there are no trees, plants, etc. within several feet, a 45° elbow can be used as termination.
Installation NSIDE ERTICAL NSTALLATIONS 1. Choose a stove location that is ideal. See the section Rain Cap (ensure cap is at least 3ft above the “D .” ECIDING HERE TO OCATE YOUR ELLET PPLIANCE 2 ft roof at the lowest point) (600 mm) 2.
Installation EARTH OUNT NSTALLATION Refer to Figures 18 and 19. Damper Removed 1. Install the hearth pad. or Fastened Open 2. Lock the fireplace damper in the open 10" (25.4 cm) Mantel position. Minimum 8" (20 cm) from top of stove 3.
OUNTED XHAUST LOWER The P3 can be equipped with an externally mounted exhaust blower. This optional kit includes all components necessary to install the exhaust blower on any vertical wall surface. Choose a location for your stove that meets the requirements stated in your manual and allows installation with the least amount of interference with house framing, plumbing, wiring, etc.
Installation HROUGH XTERIOR LOWER NSTALLATION ORIZONTAL ERMINATION 90° Elbow 45°Elbow with Rodent screen or stainless steel termination hood 2ft (610mm) Riser Pipe Adaptor Exterior Blower and Housing Electrical Cable Figure 23: Through Wall Installation with Exterior Blower Kit. NOTE: Ensure that all interior vent connections are sealed by placing a small bead of high temperature silicone around each chimney connection.
Installation YPICAL HROUGH XTERIOR LOWER NSTALLATION ERTICAL ERMINATION Follow the previous pages for through wall installations. Ensure that vent pipe is properly secured to wall using wall straps. Maintain clearances to combustibles on vent pipe as well as unit. Roof Sheathing Rain Cap Roof Flashing Roof Rafters...
Operating Instructions ONTROL OARD UNCTIONS 1. POWER BUTTON: This is the green button with the power symbol, it is used to turn the unit on and off. When the power is on and the blue LED beside the button will be illuminated. The LED will flash during the start-up cycle. Once start- up cycle is complete the power LED will stay on.
Operating Instructions PERATION ELLET TOVE PRE-BURN INSTRUCTIONS: The burn pot liner holes must be clear and the liner installed properly against the ignitor tube for proper operation. Check the hopper for enough pellets to start the unit. DO NOT OPERATE THE UNIT WITH THE DOOR OR ASH PAN OPEN. TO START: Press the Power button.
Operating Instructions For less experienced installers or owners a magnehelic gauge can be used to determine the proper Damper setting. A magnehelic gauge will accurately measure the pressure in your firebox. There is a small hole on underneath the ash lip on the right side of the firebox front, see figure 31. You want a reading of .10-.13 WC (25-32 Pa) depending on pellet quality.
” wrench or socket, Brush, Soft Cloth, Vacuum with fine filter bag Figure 32: P3 Burn pot and Liner BURNER POT AND LINER (2-3 days) Every two to three days (when the unit is cold), remove the burn-pot liner from the stove. Using a metal scraper, remove material that has accumulated or is clogging the liner’s holes.
Page 25
• Using a ” socket, loosen the six screws in the ash box compartment; four on the back. Loosen the four (4) screws, rotate • Rotate the back cover counter counter-clockwise & remove. clockwise. • Figure 34: P3 Clean-Out Covers.
Page 26
This will allow for optimal heat transfer to convection air. REMOVAL OF FIREBOX PANELS Figure 35: P3 Heat Exchanger Tubes • Open the door, remove the door, burn pot and burn pot liner. •...
Page 27
DOOR GLASS REPLACEMENT Never run a stove with broken glass, new glass must be purchased and installed by a Enviro dealer. The door glass is made of high temperature “PYROCERAM” ceramic glass. The proper glass size is 13” x 9.5” x 0.2” (5mm).
Troubleshooting DO NOT: ● Service the stove with wet hands. The stove is an electrical appliance, which may pose a shock hazard if handled improperly. Only qualified technicians should deal with possible internal electrical failures. ● Do not remove any screws from the firebox without penetrating oil lubrication. WHAT TO DO IF: 1.
Page 29
If there is no smoke the Hopper Lid switch may not be engaged or there has been a component failure. The components will need to be tested, contact an Enviro dealer. The High limit switch is a manual reset switch and a small red button on the back of the switch will need to be manually pressed in order for the unit be started again.
Page 30
Troubleshooting 6. Auger is not Feeding Pellets. • If this is the first time starting the unit or during the previous burn the unit ran out of pellets the Auger will need to be primed. You may get an E3 while auger is filling with pellets, just press the power button again. Once the Auger is full of pellets it will start dropping them into the burn pot.
Wiring Diagram Supplied Armor Cable Grey Optional Exterior Vacuum Exhaust Blower Grey Switch Black White Ribbon Cable Combustion White Blower Blue Brown Thermostat Exhaust Connection Temperature Power Switch Cord Brown Chassis Ground 115V 115V White Black White 2A 2A 2A 2A 5A Ignitor Black (Hot) White (Common)
Removed or Cabinet Sides Removed. / N'ENLEVEZ PAS CETTE ETIQUETTE ATTENTION: Pièces en mouvement peut causer des blessures. Ne pas l'appareil avec ENVIRO MODEL / MODELE ENVIRO: P3 grille arrière supprimé ou Sides Cabinet supprimé. INSTALLED AS A FREESTANDING STOVE MODEL (FS) INPUT Rating: 8,000 to 30,000 BTU/Hr CAUTION: Hot Parts.
Installation Data Sheet The following information must be recorded by the installer for warranty purposes and future reference. NAME OF OWNER: NAME OF DEALER: _________________________________________ _________________________________________ ADDRESS: ADDRESS: _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ PHONE:___________________________________ PHONE:___________________________________ NAME OF INSTALLER: MODEL:___________________________________ SERIAL NUMBER:___________________________ _________________________________________ DATE OF PURCHASE: _____________...
